9-1. Specifications



17-inch tires



18-inch tires

A: Wedge base bulbs (amber)
B: Wedge base bulbs (clear)

Tires and wheels

Tire size

215/60R17 96H

Tire inflation pressure
(Recommended cold tire inflation
pressure)

Front: 250 kPa (2.5 kgf/cm

2

 or bar, 36 psi)

Rear: 250 kPa (2.5 kgf/cm

2

 or bar, 36 psi)

Wheel size

17



 6 1/2 J

Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

Tire size

225/50R18 95V

Tire inflation pressure
(Recommended cold tire inflation
pressure)

Front: 230 kPa (2.3 kgf/cm

2

 or bar, 33 psi)

Rear: 230 kPa (2.3 kgf/cm

2

 or bar, 33 psi)

Wheel size

18



 7 J

Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

Light bulbs

Light bulbs

W

Type

Exterior

Front turn signal lights (vehicles with sin-
gle-beam headlights)

21

A

Interior

Vanity lights

8

B

475

9

9-2. Customization

Vehic

le spe

cif

ic

at

ion
s

9-2.Customization

Q

Changing using the meter control
switches

1

Press

 or

 of the meter con-

trol switches, select

.

2

Press

 or

 of the meter con-

trol switches, select the item, and
press “OK”.

3

Press

 or

 of the meter con-

trol switches, select the desired set-
ting, and press “OK”.

To go back to the previous screen or

exit the customize mode, press

.

Q

Changing using the Remote Touch

1

Press the “MENU” button on the
Remote Touch.

2

Select “Setup” on the menu screen
and select “Vehicle”.

3

Select “Vehicle customisation”.

Various setting can be changed. Refer to

the list of settings that can be changed for

details.

For details on the Remote Touch, refer
to the “NAVIGATION AND MULTI-
MEDIA SYSTEM OWNER’S MAN-
UAL”.

Q

When customizing using the Remote

Touch

Stop the vehicle in a safe place, apply the

parking brake, and shift the shift position to

P. Also, to prevent 12-volt battery dis-

charge, leave the EV system operating

while customizing the features.

Some function settings are changed simultaneously with other functions being cus-
tomized. Contact any authorized Lexus retailer or Lexus authorized repairer, or
any reliable repairer for further details.

Settings that can be changed using the Remote Touch

Settings that can be changed using the meter control switches

Settings that can be changed by any authorized Lexus retailer or Lexus autho-

rized repairer, or any reliable repairer

Customizable features

Your vehicle includes a variety of
electronic features that can be per-
sonalized to your preferences. The
settings of these features can be
changed by using the meter control
switches, the Remote Touch or at
any authorized Lexus retailer or
Lexus authorized repairer, or any
reliable repairer.

Customizing vehicle features

NOTICE

Q

During customization

To prevent 12-volt battery discharge,

ensure that the EV system is operating

while customizing features.

Customizable features

A

B

C

476

9-2. Customization

Definition of symbols: O = Available,



 = Not available

Q

EV system (



P.111, 120)

Q

Gauges, meters and multi-information display (



P.161, 164)

Function

Default setting Customized setting

Charging current

MAX

16A



O



8A

Charging limit

Full

90%



O



Battery cooler

On

Off



O



Function

*1

Default setting

Customized set-

ting

Language

*2

English

French



O



German

Italian

Dutch

Spanish

Russian

Turkish

Arabic

Units

*2

km

(kWh/100km)

km (km/kWh)



O



miles

(miles/kWh)

Speedometer display

Digital

Analog



O



Drive information 1

Current electric-

ity consumption

*3



O



Average electric-

ity consumption

(after reset)

A

B

C

A

B

C

477

9

9-2. Customization

Vehic

le spe

cif

ic

at

ion
s

*1

: For details about each function:



P.166

*2

: The default setting varies according to country.

*3

: 2 of the following items: current electricity consumption, average electricity consump-

tion (after reset), average vehicle speed (after reset), average vehicle speed (after start),
elapsed time (after reset), elapsed time (after start), distance (driving range), distance
(after start), blank.

Q

Head-up Display

*

 (



P.168)

Drive information 2

Distance (driving

range)

*3



O



Average vehicle

speed (after

reset)

Clock

24-hour display

12-hour display



O



Pop-up display

On

Off



O



Accent color

Color 1

Color 2

O

O



Suggestion function

On

On (when the

vehicle is
stopped)

O



O

Off

Rear seat reminder function

On

Off



O



Function

Default setting

Customized set-

ting

EV system

EV System Indi-

cator

No content



O



Driving support display (Naviga-
tion system

*

)

On

Off



O



Driving support display (Driving
assist

*

)

On

Off



O



Driving support display (Com-
pass

*

)

On

Off



O



Function

*1

Default setting

Customized set-

ting

A

B

C

A

B

C

478

9-2. Customization

*

: If equipped

Q

Door lock (



P.178, 458)

Q

Power back door

*

 (



P.185)

Driving support display (Audio)

On

Off



O



Rotation

Horizontal posi-

tion

Rotating counter-

clockwise/clock-

wise



O



Function

Default setting

Customized set-

ting

Unlocking using a mechanical key

All doors

unlocked in one

step

Driver’s door

unlocked in one

step, all doors

unlocked in two

step

 

O

Speed linked door locking function

On

Off

O



O

Shift position linked door locking
function

Off

On

O



O

Shift position linked door unlocking
function

Off

On

O



O

Driver’s door linked door unlock-
ing function

On

Off

O



O

Function

Default setting

Customized set-

ting

Power back door opening position

5

1 to 4

O

 

Power back door operation

On

Off



O



Buzzer volume

Level 3

Level 1



O



Level 2

Operation buzzer

Off

On

 

O

Function

Default setting

Customized set-

ting

A

B

C

A

B

C

A

B

C

479

9

9-2. Customization

Vehic

le spe

cif

ic

at

ion
s

*

: If equipped

Q

Smart entry & start system

*

 and wireless remote control (



P.176, 195)

*

: If equipped

Q

Smart entry & start system

*

 (



P.195)

*

: If equipped

Hands Free Power Back Door
(kick sensor)

*

On

Off



O

O

Hands Free Power Back Door
(kick sensor) when the power
switch is OFF

*

On

Off

 

O

Function

Default setting

Customized set-

ting

Time elapsed before automatic
door lock function is activated if
door is not opened after being
unlocked

30 seconds

60 seconds

 

O

120 seconds

Open door warning buzzer

On

Off

 

O

Function

Default setting

Customized set-

ting

Smart entry & start system

On

Off

O



O

Smart door unlocking

All the doors

Driver’s door

O



O

Time elapsed before unlocking all
the door when gripping and hold-
ing the driver’s door handle

2 seconds

Off

 

O

1.5 seconds

2.5 seconds

Number of consecutive door lock
operations

As many as

desired

2 times

 

O

Function

Default setting

Customized set-

ting

A

B

C

A

B

C

A

B

C

480

9-2. Customization

Q

Wireless remote control (



P.176)

*

: If equipped

Q

Steering wheel (



P.204)

Q

Outside rear view mirrors (



P.206)

*

: If equipped

Function

Default setting

Customized set-

ting

Wireless remote control

On

Off

 

O

Unlocking operation

All doors

unlocked in one

step

Driver’s door

unlocked in one

step, all doors

unlocked in two

step

O



O

The function that activates the

 switch of the wireless

remote control when locking the
door (



P.185)

*

Off

On (Unlocking all

the door)

 

O

On (Unlocking

back door only)

Function

Default setting

Customized set-

ting

Auto tilt away function

Tilt only

Off

O



O

Telescopic only

Tilt & telescopic

Function

Default setting

Customized set-

ting

Automatic mirror folding and
extending operation

*

Linked to the

locking/unlock-

ing of the doors

Off

 

O

Linked to opera-

tion of the power

switch

A

B

C

A

B

C

A

B

C

481

9

9-2. Customization

Vehic

le spe

cif

ic

at

ion
s

Q

Power windows and moon roof

*

 (



P.209, 211)

*

: If equipped

Q

Reverse warning buzzer

Q

Automatic light control system (



P.240)

Q

Lights (



P.240)

Function

Default setting

Customized set-

ting

Mechanical key linked operation

Off

On

 

O

Wireless remote control linked
operation

Off

On

 

O

Wireless remote control linked
operation signal (buzzer)

On

Off

 

O

Function

Default setting

Customized set-

ting

Signal (buzzer) when the shift posi-
tion is in R

Off

On

 

O

Function

Default setting

Customized set-

ting

Light sensor sensitivity

Standard

-2 to 2

O



O

Extended Headlight Lighting (Time
elapsed before headlights auto-
matically turn off)

30 seconds

60 seconds

 

O

90 seconds

120 seconds

Function

Default setting

Customized set-

ting

Welcome lighting

On

Off

 

O

Light reminder buzzer

On

Off

 

O

A

B

C

A

B

C

A

B

C

A

B

C

482

9-2. Customization

Q

Rear window wiper (



P.255)

Q

AHS (Adaptive High-beam System)

*1

 (



P.242)

*1

: If equipped

*2

: The headlights will operate under AHB (Automatic High Beam) control. (



P.246)

Function

Default setting

Customized set-

ting

Rear window wiper operation
when the back door is opened

On

Off

 

O

Washer linked rear window wiper
operation

On

Off

 

O

Shift position linked rear window
wiper operation

Once

Off

 

O

Continuous

Function

Default setting

Customized set-

ting

Adaptive High-beam System

On

Off

*2

 

O

Clearance between a vehicle
ahead and the shaded high beams

Wide

Narrow

 

O

Standard

Intensity adjustment of the high
beams when driving around a
curve (illuminates the area in the
direction vehicle is turning more
brightly)

On

Off

 

O

Projection distance adjustment of
the low beams according to the
distance to a preceding vehicle

On

Off

 

O

Illumination of the cornering lights
when starting off

On

Off

 

O

High beam light distribution con-
trol for rain

On

Off

 

O

A

B

C

A

B

C

483

9

9-2. Customization

Vehic

le spe

cif

ic

at

ion
s

Q

PCS (Pre-Collision System) (



P.262)

Q

LTA (Lane Tracing Assist) (



P.269)

Q

RSA (Road Sign Assist) (



P.278)

Function

Default setting

Customized set-

ting

PCS (Pre-Collision System)

On

Off



O



Adjust alert timing

Middle

Early



O



Late

Function

Default setting

Customized set-

ting

Vehicle sway warning function

On

Off



O



Vehicle sway warning sensitivity

Standard

High



O



Low

Lane centering function

On

Off



O



Steering assist function

On

Off



O



Alert type

Steering wheel

vibration

Buzzer



O



Alert sensitivity

High

Standard



O



Function

Default setting

Customized set-

ting

RSA (Road Sign Assist)

*1

On

Off



O



Excess speed notification
method

*2

Display only

No notification



O



Display and

buzzer

Excess speed notification level

2 km/h (1 mph)

5 km/h (3 mph)



O



10 km/h (5 mph)

No overtaking notification method

Display only

No notification



O



Display and steer-

ing wheel vibra-

tion

A

B

C

A

B

C

A

B

C

484

9-2. Customization

*1

: RSA function becomes on when the power switch is turned to ON.

*2

: If a speed limit with supplemental mark is exceeded, the notification buzzer does not

operate.

*3

: Vehicles with navigation system

Q

Dynamic radar cruise control with full-speed range (



P.282)

Q

BSM (Blind Spot Monitor)

*

 (



P.293)

*

: If equipped

Q

Lexus parking assist-sensor

*

 (



P.306)

*

: If equipped

Other notifications method (No-
entry notification)

*3

Display only

No notification



O



Display and

buzzer

Function

Default setting

Customized set-

ting

Dynamic Radar Cruise Control
with Road Sign Assist

Off

On



O



Function

Default setting

Customized set-

ting

Outside rear view mirror indicator
brightness

Bright

Dim



O



Alert timing for presence of
approaching vehicle (sensitivity)

Intermediate

Early



O



Late

Only when vehi-

cle detected in

blind spot

BSM (Blind Spot Monitor)

On

Off



O



Function

Default setting

Customized set-

ting

Lexus parking assist-sensor

On

Off



O

O

Function

Default setting

Customized set-

ting

A

B

C

A

B

C

A

B

C

A

B

C

485

9

9-2. Customization

Vehic

le spe

cif

ic

at

ion
s

Q

RCTA (Rear Crossing Traffic Alert) function

*

 (



P.313)

*

: If equipped

Q

PKSA (Parking Support Alert)

*

 (



P.305)

*

: If equipped

Q

PKSB (Parking Support Brake)

*

 (



P.318)

*

: If equipped

Q

Automatic air conditioning system (



P.346)

Function

Default setting

Customized set-

ting

RCTA (Rear Crossing Traffic
Alert) function

On

Off



O

O

Function

Default setting

Customized set-

ting

Buzzer volume

Level 2

Level 1



O

O

Level 3

Function

Default setting

Customized set-

ting

PKSB (Parking Support Brake)
function

On

Off



O

O

Function

Default setting

Customized set-

ting

Switching between outside air and
recirculated air mode linked to
“AUTO” switch operation

On

Off

O



O

A/C auto switch operation

On

Off

O



O

A

B

C

A

B

C

A

B

C

A

B

C

486

9-2. Customization

Q

Remote Air Conditioning System (



P.355)

Q

Seat heaters

*

/seat ventilators

*

 (



P.357)

*

: If equipped

Q

Heated steering wheel

*

 (



P.357)

*

: If equipped

Function

Default setting Customized setting

Operation using the “A/C” button
on the wireless remote control

Press and hold

for 0.8 seconds

Press once

 

O

Press twice

Press and hold for

2.4 seconds

Off

Stopping the operation using the
“A/C” button on the wireless
remote control

Press twice

Press once

 

O

Press and hold for

0.8 seconds

Press and hold for

2.4 seconds

Off

Function

Default setting

Customized set-

ting

Driver’s seat temperature prefer-
ence in automatic mode

Standard

-2 (cooler) to 2

(warmer)

O



O

Passenger’s seat temperature
preference in automatic mode

Standard

-2 (cooler) to 2

(warmer)

O



O

Function

Default setting

Customized set-

ting

Steering wheel heating preference
in automatic mode

Standard

-2 (low) to 2

(high)

O



O

A

B

C

A

B

C

A

B

C

487

9

9-2. Customization

Vehic

le spe

cif

ic

at

ion
s

Q

Illumination (



P.361)

*

: If equipped

Function

Default setting

Customized set-

ting

Time elapsed before the interior
lights turn off

15 seconds

Off

O



O

7.5 seconds

30 seconds

Operation after the power switch
is turned off

On

Off

 

O

Operation when the doors are
unlocked

On

Off

 

O

Operation when you approach the
vehicle with the electronic key on
your person

On

Off

 

O

Rear interior light and footwell
lights

On

Off

 

O

Time elapsed before the outside
door handle lights

*

 turn off

15 seconds

Off

O



O

7.5 seconds

30 seconds

Outside door handle lights

*

On

Off

 

O

Operation of the outside door han-
dle lights

*

 when you approach the

vehicle with the electronic key on
your person

On

Off

 

O

Operation of the outside door han-
dle lights

*

 when the doors are

unlocked

On

Off

 

O

Operation of the outside door han-
dle lights

*

 when a door is opened

On

Off

 

O

Fading out of the outside door han-
dle lights

*

 when they turn off

Long

Short

 

O

A

B

C

488

9-2. Customization

Q

Vehicle customization

O

When the speed linked door locking

function and shift position linked door

locking function are both on, the door

lock operates as follows.

• When shifting the shift position to any

position other than P, all the doors will be

locked.

• If the vehicle is started with all the doors

locked, the speed linked door locking

function will not operate.

• If the vehicle is started with any door

unlocked, the speed linked door locking

function will operate.

O

When the smart entry & start system is

off, the entry unlock function cannot be

customized.

O

When the doors remain closed after

unlocking the doors and the timer acti-

vated automatic door lock function acti-

vates, signals will be generated in

accordance with the operational signal

(Emergency flashers) function setting.

O

Some settings can be changed using a

switch or the Center Display. If a setting

is changed using a switch, the changed

setting will not be reflected on the Center

Display until the power switch is turned

off and then to ON.

Q

Clock settings screen

If the clock adjustment screen is displayed

continuously when attempting to change

the clock settings, the system may be mal-

functioning. Have the vehicle inspected by

any authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer.

489

9

9-3. Initialization

Vehic

le spe

cif

ic

at

ion
s

9-3.Initialization

*

: If equipped

Items to initialize

The following item must be initialized for normal system operation after such
cases as the 12-volt battery being reconnected, or maintenance being per-
formed on the vehicle:

List of the items to initialize

Item

When to initialize

Reference

Lexus parking assist-sensor

*

• After reconnecting or changing

the 12-volt battery

P.308

PKSB (Parking Support Brake)

*

• After reconnecting or changing

the 12-volt battery

P.322

Tire pressure warning system

• When rotating the tires
• When the tire inflation pressure is

changed by changing tire size
(When there are multiple speci-
fied pressures)

• After registering the ID codes

P.401

Lexus parking assist monitor

*

• 12-volt battery has been rein-

stalled

• The steering wheel has been

moved while the 12-volt battery
was being reinstalled

• 12-volt battery power is low

Refer to

“NAVIGA-

TION AND

MULTIME-

DIA SYS-

TEM

OWNER’S

MANUAL”.

Panoramic view monitor

*

Power back door

*

• After reconnecting or changing

the 12-volt battery

• After changing a fuse

P.190

Power window

• When functioning abnormally

P.209

Moon roof

*

P.212
