Lexus UX (2022 year). Manual in english

467

8-1. Specifications

Vehic

le spe

cif

ion
s

Oil capacity (Drain and refill



reference

)

: The engine oil capacity is a reference

quantity to be used when changing the
engine oil. Warm up the engine and turn
off the hybrid system, wait more than 5
minutes, and check the oil level on the
dipstick.

Engine oil selection

“Toyota Genuine Motor Oil” is used in
your Lexus vehicle. Lexus recom-
mends the use of approved “Toyota
Genuine Motor Oil”. Another motor
oil of matching quality can also be
used.
Oil grade:
0W-16:
API grade SN “Resource-Conserv-
ing”, SN PLUS “Resource-Conserv-
ing” or SP “Resource-Conserving”; or
ILSAC GF-6B multigrade engine oil
0W-20 and 5W-30:

API grade SM “Energy-Conserving”,
SN “Resource-Conserving”, SN PLUS
“Resource-Conserving” or SP
“Resource-Conserving”; or ILSAC
GF-6A multigrade engine oil
Recommended viscosity (SAE):

Temperature range anticipated
before next oil change

Preferred

SAE 0W-16 is filled into your Lexus
vehicle at manufacturing, and the best
choice for good fuel economy and
good starting in cold weather.
If SAE 0W-16 oil is not available, SAE
0W-20 oil may be used. However, it
should be replaced with SAE 0W-16
at the next oil change.

Hybrid battery (traction battery)

Type

Nickel-Metal hydride battery

Voltage

7.2 V/module

Capacity

6.5 Ah (3HR)

Quantity

30 modules

Nominal voltage

216 V

Lubrication system

With filter

4.3 L (4.5 qt., 3.8
Imp.qt.)

Without filter

3.9 L (4.1 qt., 3.4 Imp.qt.)

468

8-1. Specifications

Oil viscosity (0W-16 is explained here
as an example):
• The 0W in 0W-16 indicates the

characteristic of the oil which allows
cold startability. Oils with a lower
value before the W allow for easier
starting of the engine in cold
weather.

• The 16 in 0W-16 indicates the vis-

cosity characteristic of the oil when
the oil is at high temperature. An oil
with a higher viscosity (one with a
higher value) may be better suited if
the vehicle is operated at high
speeds, or under extreme load con-
ditions.

How to read oil container labels:
Either or both API registered marks
are added to some oil containers to
help you select the oil you should use.

API Service Symbol

Top portion: “API SERVICE SP” means
the oil quality designation by American
Petroleum Institute (API).
Center portion: “SAE 0W-16” means the
SAE viscosity grade.
Lower portion: “Resource-Conserving”
means that the oil has fuel-saving and envi-
ronmental protection capabilities.

ILSAC Certification Mark

The International Lubricant Specification
Advisory Committee (ILSAC) Certifica-
tion Mark is displayed on the front of the
container.

469

8-1. Specifications

Vehic

le spe

cif

ion
s

: The coolant capacity is the quantity of reference.

If replacement is necessary, contact any authorized Lexus retailer or Lexus authorized
repairer, or any reliable repairer.

Spark plug

12-volt battery

Cooling system

Capacity

Gasoline
engine



Vehicles without exhaust heat recirculator sys-
tem

6.1 L (6.4 qt., 5.4 Imp.qt.)



Vehicles with exhaust heat recirculator system

6.9 L (7.3 qt., 6.1 Imp.qt.)

Power con-
trol unit

1.6 L (1.7 qt., 1.4 Imp.qt.)

Coolant type

Use either of the following:
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non-

silicate, non-amine, non-nitrite, and non-borate
coolant with long-life hybrid organic acid tech-
nology

Do not use plain water alone.

Ignition system

Make

DENSO FC16HR-Q8

Gap

0.8 mm (0.031 in.)

NOTICE

Iridium-tipped spark plugs

Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

Electrical system

Specific gravity reading at 20°C
(68°F):

1.250 or higher

470

8-1. Specifications

: The fluid capacity is a reference quantity.

If replacement is necessary, contact any authorized Lexus retailer or Lexus authorized
repairer, or any reliable repairer.

: The fluid capacity is the quantity of reference.

If replacement is necessary, contact any authorized Lexus retailer or Lexus authorized
repairer, or any reliable repairer.

Charging rates:

Quick charge
Slow charge

15 A max.
5 A max.

Hybrid transmission

Fluid capacity

3.8 L (4.0 qt., 3.3 Imp.qt.)

Fluid type

Toyota Genuine ATF WS

NOTICE

Hybrid transmission fluid type

Using transmission fluid other than the above type may cause abnormal noise or vibra-

tion, or ultimately damage the transmission of your vehicle.

Rear differential (rear electric motor) (AWD models)

Fluid capacity

1.2 L (1.3 qt., 1.1 Imp.qt.)

Fluid type

Toyota Genuine ATF WS

NOTICE

Transmission fluid type

Using transmission fluid other than the above type may cause abnormal noise or vibra-

tion, or ultimately damage the transmission of your vehicle.

Brakes

Pedal clearance

109 mm (4.29 in.) Min.

Pedal free play

1.0 - 6.0 mm (0.04 - 0.24 in.)

471

8-1. Specifications

Vehic

le spe

cif

ion
s

: Minimum pedal clearance when depressed with a force of 300 N (31 kgf, 66 lbf) while

the hybrid system is operating.

: Make sure to confirm that the brake system warning light (yellow) does not illuminate. (If

the brake system warning light illuminates, refer to P.414)



17-inch tires (type A)



17-inch tires (type B)

Parking brake indicator

When pushing the parking brake switch for 1 to 4
seconds: comes on
When pulling the parking brake switch for 1 to 4
seconds: turns off

Fluid type

SAE J1703 or FMVSS No. 116 DOT 3,
SAE J1704 or FMVSS No. 116 DOT 4

Steering

Free play

Less than 30 mm (1.2 in.)

Tires and wheels

Tire size

215/60R17 96H

Tire inflation pressure
(Recommended cold tire inflation
pressure)

Front: 250 kPa (2.5 kgf/cm

or bar, 36 psi)

Rear: 250 kPa (2.5 kgf/cm

or bar, 36 psi)

Wheel size



6 1/2 J

Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

Tire size

215/60R17 96H

Tire inflation pressure
(Recommended cold tire inflation
pressure)

Front: 230 kPa (2.3 kgf/cm

or bar, 33 psi)

Rear: 230 kPa (2.3 kgf/cm

or bar, 33 psi)

Wheel size



6 1/2 J

Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

472

8-1. Specifications



18-inch tires



Compact spare tire (type A)

: if equipped



Compact spare tire (type B)

: if equipped

When towing a trailer (vehicles with towing package)

Add 20.0 kPa (0.2 kgf/cm

or bar, 3 psi) to the recommended tire inflation pressure and

drive at speeds below 100 km/h (62 mph).

Tire size

225/50RF18 95V

Tire inflation pressure
(Recommended cold tire inflation
pressure)

Front: 230 kPa (2.3 kgf/cm

or bar, 33 psi)

Rear: 230 kPa (2.3 kgf/cm

or bar, 33 psi)

Wheel size



7 J

Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

Tire size

T145/90D16 106M

Spare tire inflation pressure
(Recommended cold tire inflation
pressure)

420 kPa (4.2 kgf/cm

or bar, 60 psi)

Wheel size



Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

Tire size

T145/70D18 107M

Spare tire inflation pressure
(Recommended cold tire inflation
pressure)

420 kPa (4.2 kgf/cm

or bar, 60 psi)

Wheel size



Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

474

8-1. Specifications

Use of ethanol blended gasoline in a

gasoline engine

Lexus allows the use of ethanol blended

gasoline where the ethanol content is up to

10%. Make sure that the ethanol blended

gasoline to be used has a Research Octane

Number that follows the above.

If your engine knocks

Consult any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer.

You may occasionally notice light knock-

ing for a short time while accelerating or

driving uphill. This is normal and there is

no need for concern.

Fuel information

When you find these types of fuel
label at the gas station, use only the
fuel with one of the following labels.

EU area:
You must only use unleaded gaso-
line conforming to European stan-
dard EN228.
Select unleaded gasoline with a
Research Octane Number of 95 or
higher for optimum engine perfor-
mance.

Except EU area:
You must only use unleaded gaso-
line.
Except Azerbaijan, Georgia, Rus-
sia, Ukraine and Kazakhstan:
Select unleaded gasoline with a
Research Octane Number of 95 or
higher for optimum engine perfor-
mance.
For Azerbaijan, Georgia, Russia,
Ukraine and Kazakhstan: Select
unleaded gasoline with a Research
Octane Number of 91 or higher for
optimum engine performance.

NOTICE

Notice on fuel quality

Do not use improper fuels. If improper

fuels are used, the engine will be dam-

aged.

Do not use gasoline with metallic addi-

tives, for example manganese, iron or

lead, otherwise it may cause damage

on your engine or emission control

system.

Do not add aftermarket fuel additives

which contain metallic additives.

EU area: Bioethanol fuel sold under

names such as “E50” or “E85” and

fuel containing a large amount of etha-

nol should not be used. The use of

these fuels will damage the vehicle’s

fuel system. In case of any doubt, ask

any authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer.

Except EU area: Bioethanol fuel sold

under names such as “E50” or “E85”

and fuel containing a large amount of

ethanol should not be used. Your vehi-

cle can use gasoline mixed with 10%

max ethanol. The use of fuel with more

than 10% ethanol content (E10) will

damage the vehicle’s fuel system. You

must ensure that refueling is carried

out only from a source where fuel

specification and quality can be guar-

anteed. In case of any doubt, ask any

authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer.

476

8-2. Customization

8-2.Customization

Changing using the meter control
switches

Press

of the meter con-

trol switches, select

Press

of the meter con-

trol switches, select the item, and
press “OK”.

Press

of the meter con-

trol switches, select the desired set-
ting, and press “OK”.

To go back to the previous screen or
exit the customize mode, press

Changing using the Remote Touch

Press the “MENU” button on the
Remote Touch.

Select “Setup” on the menu screen
and select “Vehicle”.

Select “Vehicle customisation” or
“Drive mode customisation”.

Various setting can be changed. Refer to

the list of settings that can be changed for

details.

For details on the Remote Touch, refer
to the “NAVIGATION AND MULTI-
MEDIA SYSTEM OWNER’S MAN-
UAL”.

When customizing using the Remote

Touch

Stop the vehicle in a safe place, apply the

parking brake, and shift the shift lever to P.

Also, to prevent 12-volt battery discharge,

leave the hybrid system operating while

customizing the features.

Some function settings are changed simultaneously with other functions being cus-
tomized. Contact any authorized Lexus retailer or Lexus authorized repairer, or
any reliable repairer for further details.

Customizable features

Your vehicle includes a variety of
electronic features that can be per-
sonalized to your preferences. The
settings of these features can be
changed by using the meter control
switches, the Remote Touch or at
any authorized Lexus retailer or
Lexus authorized repairer, or any
reliable repairer.

Customizing vehicle features

WARNING

Cautions during customization

As the hybrid system needs to be operat-

ing during customization, ensure that the

vehicle is parked in a place with ade-

quate ventilation. In a closed area such as

a garage, exhaust gases including harm-

ful carbon monoxide (CO) may collect

and enter the vehicle. This may lead to

death or a serious health hazard.

NOTICE

During customization

To prevent 12-volt battery discharge,

ensure that the hybrid system is operat-

ing while customizing features.

Customizable features

477

8-2. Customization

Vehic

le spe

cif

ion
s

Settings that can be changed using the Remote Touch

Settings that can be changed using the meter control switches

Settings that can be changed by any authorized Lexus retailer or Lexus autho-

rized repairer, or any reliable repairer

Definition of symbols: O = Available,



= Not available

Gauges, meters and multi-information display (



P.99, 103, 108)

Function

Default setting

Customized set-

ting

Language

English

French



German

Spanish

Italian

Russian

Dutch

Turkish

Ukrainian

Arabic

Units

km (L/100 km)

km (km/L)



miles (MPG)

Speedometer display

Digital

Analog



Drive information 1

Current fuel con-

sumption



Average fuel

economy (after

reset)

Drive information 2

Distance (driving

range)



Average vehicle

speed (after

reset)

Clock

24-hour display

12-hour display



478

8-2. Customization

: For details about each function:



P.99, 103, 112

: The default setting varies according to country.

: The customized setting varies according to country.

: Except F SPORT models

: 2 of the following items: current fuel consumption, average fuel economy (after reset),

average fuel economy (after start), average fuel economy (after refuel), average vehicle
speed (after reset), average vehicle speed (after start), elapsed time (after reset),
elapsed time (after start), distance (driving range), distance (after start), blank.

: F SPORT models

Head-up Display

(



P.114)

Pop-up display

Off



Accent color

Color 1

Color 2



Tachometer setting

Change accord-

ing to driving

mode

Always tachome-

ter



Always Hybrid

System Indicator

Rev indicator

Off



Rev indicator red zone setting

4000 r/min

2000 - 6200

r/min



Rev peak

Off



EV indicator

Off



Suggestion function

On (when the

vehicle is
stopped)



Off

Rear seat reminder function

Off



Function

Default setting

Customized set-

ting

Gauge information

Hybrid System

Indicator

Tachometer



No content

Function

Default setting

Customized set-

ting

479

8-2. Customization

Vehic

le spe

cif

ion
s

: If equipped

Door lock (



P.128, 451)

Power back door

(



P.135)

Route guidance to destina-
tion/street name

Off



Driving support system display

Off



Compass

Off



Audio system operation status

Off



Rotation

Horizontal posi-

tion

Rotating counter-

clockwise/clock-

wise



Function

Default setting

Customized set-

ting

Unlocking using a mechanical key

All doors

unlocked in one

step

Driver’s door

unlocked in one

step, all doors

unlocked in two

step

 

Speed linked door locking function

Off



Shift position linked door locking
function

Off



Shift position linked door unlocking
function

Off



Driver’s door linked door unlock-
ing function

Off



Function

Default setting

Customized set-

ting

Power back door operation

Off



Power back door opening position

1 to 4

 

Function

Default setting

Customized set-

ting

480

8-2. Customization

: If equipped

: When the towing hitch is installed, Hands Free Power Back Door (kick sensor) does not

work

Smart entry & start system

and wireless remote control (



P.126, 145)

: If equipped

Smart entry & start system

(



P.145)

Buzzer volume

Level 3

Level 1



Level 2

Operation buzzer

Off

 

Hands Free Power Back Door
(kick sensor)

Off



Hands Free Power Back Door
(kick sensor) when the power
switch is OFF

*1, 2

Off

 

Function

Default setting

Customized set-

ting

Time elapsed before automatic
door lock function is activated if
door is not opened after being
unlocked

30 seconds

60 seconds

 

120 seconds

Open door warning buzzer

Off

 

Function

Default setting

Customized set-

ting

Smart entry & start system

Off



Smart door unlocking

All the doors

Driver’s door



Time elapsed before unlocking all
the door when gripping and hold-
ing the driver’s door handle

2 seconds

Off

 

1.5 seconds

2.5 seconds

Number of consecutive door lock
operations

As many as

desired

2 times

 

Function

Default setting

Customized set-

ting

481

8-2. Customization

Vehic

le spe

cif

ion
s

: If equipped

Wireless remote control (



P.126)

: If equipped

Driving position memory

(



P.153)

: If equipped

Function

Default setting

Customized set-

ting

Wireless remote control

Off

 

Unlocking operation

All doors

unlocked in one

step

Driver’s door

unlocked in one

step, all doors

unlocked in two

step



The function that activates the

switch of the wireless

remote control when locking the
door (



P.135)

Off

On (Unlocking all

the door)

 

On (Unlocking

back door only)

Function

Default setting

Customized set-

ting

Selecting doors linked to the mem-
ory recall function

Driver’s door

All doors

 

Driver’s seat slide movement when
exiting the vehicle

Full

Off



Partial

Steering wheel movement

Tilt only

Off



Telescopic only

Tilt and telescopic

482

8-2. Customization

Outside rear view mirrors (



P.162)

: If equipped

Power windows and moon roof

(



P.164, 166)

: If equipped

Automatic light control system (



P.201)

Lights (



P.201)

Function

Default setting

Customized set-

ting

Automatic mirror folding and
extending operation

Linked to the

locking/unlock-

ing of the doors

Off

 

Linked to opera-

tion of the power

switch

Function

Default setting

Customized set-

ting

Mechanical key linked operation

Off

 

Wireless remote control linked
operation

Off

 

Wireless remote control linked
operation signal (buzzer)

Off

 

Function

Default setting

Customized set-

ting

Light sensor sensitivity

Standard

-2 to 2



Extended Headlight Lighting (Time
elapsed before headlights auto-
matically turn off)

30 seconds

60 seconds

 

90 seconds

120 seconds

Function

Default setting

Customized set-

ting

Welcome lighting

Off

 

Lexus UX (2022 year). Manual in english - page 27
