Lexus UX (2022 year). Manual in english

209

4-3. Operating the lights and wipers

ivin
g

Switching to the high beams

Push the lever away from you.

The Automatic High Beam indicator will
turn off and the high beam indicator will
turn on.
Pull the lever to its original position to acti-
vate the Automatic High Beam system
again.

Switching to the low beams

Press the Automatic High Beam
switch.

The Automatic High Beam indicator will
turn off.
Press the switch to activate the Automatic
High Beam system again.

Temporarily switching to the low
beams

Pull the lever toward you and then
return it to its original position.

The high beams are on while the lever is
pulled toward you, however, after the lever
is returned to its original position, the low
beams remain on for a certain amount of
time. Afterwards, the Automatic High
Beam will be activated again.

Temporarily switching to the low beams

It is recommended to switch to the low

beams when the high beam may cause

problems or distress to other drivers or

pedestrians nearby.

Turning the high beams on/off
manually

210

4-3. Operating the lights and wipers



Rear fog light switch

Turns the rear fog lights off

Turns the rear fog lights on

Releasing the switch ring returns it to

Operating the switch ring again turns the
rear fog lights off.



Front and rear fog light switch

Turns the front and rear fog

lights off

Turns the front fog lights on

Turns both front and rear fog

lights on

Releasing the switch ring returns it to

Operating the switch ring again turns only
the rear fog lights off.

Fog lights can be used when



Vehicles with rear fog lights only

The headlights are turned on.



Vehicles with front and rear fog lights

Front fog lights: The front position lights are

turned on.

Rear fog lights: The front fog lights are

turned on.

Fog light switch

When in difficult driving conditions,
such as in rain and fog, turn on the
front fog lights to secure front visi-
bility and turn on the rear fog lights
to notify following vehicles the exis-
tence of your vehicle.

Turning on the fog lights

211

4-3. Operating the lights and wipers

ivin
g

Operating the

lever operates

the wipers or washer as follows:



Intermittent windshield wipers with
interval adjuster

Off

Intermittent operation

NOTICE

To prevent 12-volt battery discharge

Do not leave the lights on longer than

necessary when the hybrid system is off.

Windshield wipers and
washer

Operating the lever can change
wiper operation to automatic/man-
ual or squirt washer fluid.

NOTICE

When the windshield is dry

Do not use the wipers, as they may dam-

age the windshield.

Operating the wiper lever

212

4-3. Operating the lights and wipers

Low speed operation

High speed operation

Temporary operation

Wiper intervals can be adjusted when
intermittent operation is selected.

Increases the intermittent wind-
shield wiper frequency

Decreases the intermittent wind-
shield wiper frequency

Washer/wiper dual opera-

tion

Pulling the lever operates the wipers and
washer.
The wipers will automatically operate a
couple of times after the washer squirts.
Vehicles with headlight cleaners: When
the power switch is in ON and the head-
lights are on, if the lever is pulled, the head-
light cleaners will operate once. After this,
the headlight cleaners will operate every

5th time the lever is pulled.



Rain-sensing windshield wipers

When AUTO is selected, the wipers
will operate automatically when the
sensor detects falling rain. The system
automatically adjusts wiper timing in
accordance with rain volume and vehi-
cle speed.

Off

Rain-sensing operation

Low speed operation

High speed operation

Temporary operation

When AUTO is selected, the sensor
sensitivity can be adjusted by turning
the switch ring.

213

4-3. Operating the lights and wipers

ivin
g

Increases the sensitivity

Decreases the sensitivity

Washer/wiper dual opera-

tion

Pulling the lever operates the wipers and
washer.
The wipers will automatically operate a
couple of times after the washer squirts.
(After operating several times, the wipers
operate once more time after a short delay
to prevent dripping. However, the dripping
prevention does not operate while the
vehicle is moving.)
Vehicles with headlight cleaners: When
the power switch is in ON and the head-
lights are on, if the lever is pulled, the head-
light cleaners will operate once. After this,
the headlight cleaners will operate every
5th time the lever is pulled.

The windshield wipers and washer can

be operated when

The power switch is in ON.

Effects of vehicle speed on wiper opera-

tion (vehicles with rain-sensing wind-

shield wipers)

Vehicle speed affects the Intermittent wiper

interval.

Raindrop sensor (vehicles with rain-

sensing windshield wipers)

The raindrop sensor judges the amount

of raindrops.

An optical sensor is adopted. It may not

operate properly when sunlight from the

rising or setting of the sun intermittently

strikes the windshield, or if bugs, etc. are

present on the windshield.

If the wiper switch is turned to the

“AUTO” position while the power switch

is in ON, the wipers will operate once to

show that AUTO mode is activated.

If the temperature of the raindrop sensor

is 90°C (194°F) or higher, or -15°C

(5°F) or lower, automatic operation may

not occur. In this case, operate the wipers

in any mode other than AUTO mode.

If no windshield washer fluid sprays

Check that the washer nozzles are not

blocked, if there is washer fluid in the

washer fluid tank.

214

4-3. Operating the lights and wipers

When the windshield wipers are not
being used, they retract to below the
hood. To enable the windshield wipers
to be lifted when parking in cold condi-

tions or when replacing a windshield
wiper insert, change the rest position of
the windshield wipers to the service
position using the wiper lever.

Raising the wipers to the service
position

Within approximately 45 seconds of
turning the power switch off, move the
wiper lever to the

position and

hold it for approximately 2 seconds or
more.

The wipers will move to the service posi-
tion.

Lifting the windshield wipers

While holding the hook portion

the wiper arm, lift the windshield wiper
from the windshield.

WARNING

Caution regarding the use of wind-

shield wipers in AUTO mode (vehi-

cles with rain-sensing windshield

wipers)

The windshield wipers may operate

unexpectedly if the sensor is touched or

the windshield is subject to vibration in

AUTO mode. Take care that your fin-

gers, etc. do not become caught in the

windshield wipers.

Caution regarding the use of washer

fluid

When it is cold, do not use the washer

fluid until the windshield becomes warm.

The fluid may freeze on the windshield

and cause low visibility. This may lead to

an accident, resulting in death or serious

injury.

NOTICE

When the washer fluid tank is empty

Do not operate the switch continually as

the washer fluid pump may overheat.

When a nozzle becomes blocked

In this case, contact any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

Do not try to clear it with a pin or other

object. The nozzle will be damaged.

To prevent 12-volt battery discharge

Do not leave the wipers on longer than

necessary when the hybrid system is off.

Changing the windshield wiper
rest position/Lifting the wind-
shield wipers

215

4-3. Operating the lights and wipers

ivin
g

Lowering the windshield wipers to the

retracted position

With the windshield wipers placed on the

windshield, turn the power switch to ON

and then move the wiper lever to an operat-

ing position. When the wiper switch is

turned off, the windshield wipers will stop at

the retracted position. Even if the wipers

deviate while the power switch is OFF, the

wipers will return to the normal position.

NOTICE

When lifting the windshield wipers

Do not lift the windshield wipers when

they are in the retracted position

below the hood. Otherwise, they may

contact the hood, possibly resulting in

damage to a windshield wiper and/or

the hood.

Do not lift a windshield wiper by the

wiper blade. Otherwise, the wiper

blade may be deformed.

Do not operate the wiper lever when

the windshield wipers are lifted. Oth-

erwise, the windshield wipers may

contact the hood, possibly resulting in

damage to the windshield wipers

and/or hood.

216

4-3. Operating the lights and wipers

Operating the

switch operates

the rear wiper as follows:

Off

Intermittent operation

Normal operation

Washer/wiper dual opera-

tion

Pushing the lever operates the wiper and
washer.
The wiper will automatically operate a cou-
ple of times after the washer squirts.

The rear window wiper and washer can

be operated when

The power switch is in ON.

If no windshield washer fluid sprays

Check that the washer nozzles are not

blocked, if there is washer fluid in the

washer fluid tank.

Reverse-linked rear window wiper

function

When the shift lever is shifted to R when the

front wipers are operating, the rear window

wiper will operate once.

Back door opening linked rear window

wiper stop function

When the rear window wiper is operating, if

the back door is opened while the vehicle is

stopped, operation of the rear window

wiper will be stopped to prevent anyone

near the vehicle from being sprayed by

water from the wiper. When the back door
is closed, wiper operation will resume.

: The setting must be customized at any

authorized Lexus retailer or Lexus autho-
rized repairer, or any reliable repairer.

Customization

Setting of the reverse-linked function can

Rear window wiper and
washer

The rear window wiper and washer
can be used by operating the lever.

NOTICE

When the rear window is dry

Do not use the wiper, as it may damage

the rear window.

Operating the wiper lever

217

4-3. Operating the lights and wipers

ivin
g

be changed. (Customizable fea-

tures:



P.483)

NOTICE

When the washer fluid tank is empty

Do not operate the switch continually as

the washer fluid pump may overheat.

When a nozzle becomes blocked

In this case, contact any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

Do not try to clear it with a pin or other

object. The nozzle will be damaged.

To prevent 12-volt battery discharge

Do not leave the wiper on longer than

necessary when the hybrid system is off.

218

4-4. Refueling

4-4.Refueling



Turn the power switch off and
ensure that all the doors and win-
dows are closed.



Confirm the type of fuel.

Fuel types



P.474

Fuel tank opening for unleaded gasoline

To help prevent incorrect fueling, your vehi-

cle has a fuel tank opening that only accom-

modates the special nozzle on unleaded

fuel pumps.

Opening the fuel tank cap

Before refueling the vehicle

WARNING

When refueling the vehicle

Observe the following precautions while

refueling the vehicle. Failure to do so

may result in death or serious injury.

After exiting the vehicle and before

opening the fuel door, touch an

unpainted metal surface to discharge

any static electricity. It is important to

discharge static electricity before refu-

eling because sparks resulting from

static electricity can cause fuel vapors

to ignite while refueling.

Always hold the grips on the fuel tank

cap and turn it slowly to remove it.

A whooshing sound may be heard

when the fuel tank cap is loosened.

Wait until the sound cannot be heard

before fully removing the cap. In hot

weather, pressurized fuel may spray

out the filler neck and cause injury.

Do not allow anyone that has not dis-

charged static electricity from their

body to come close to an open fuel

tank.

Do not inhale vaporized fuel.

Fuel contains substances that are

harmful if inhaled.

Do not smoke while refueling the vehi-

cle.

Doing so may cause the fuel to ignite

and cause a fire.

Do not return to the vehicle or touch

any person or object that is statically

charged.

This may cause static electricity to

build up, resulting in a possible ignition

hazard.

When refueling

Observe the following precautions to

prevent fuel overflowing from the fuel

tank:

Securely insert the fuel nozzle into the

fuel filler neck.

Stop filling the tank after the fuel noz-

zle automatically clicks off.

Do not top off the fuel tank.

NOTICE

Refueling

Do not spill fuel during refueling.

Doing so may damage the vehicle, such

as causing the emission control system to

operate abnormally or damaging fuel

system components or the vehicle’s

painted surface.

219

4-4. Refueling

ivin
g

Press the opener switch.

Turn the fuel tank cap slowly and
remove it, then put it into the holder
on the fuel filler door.

If the fuel filler door cannot be opened



P.450

After refueling, turn the fuel tank cap
until you hear a click. Once the cap is
released, it will turn slightly in the
opposite direction.

Opening the fuel tank cap

Closing the fuel tank cap

WARNING

When replacing the fuel tank cap

Do not use anything but a genuine Lexus

fuel tank cap designed for your vehicle.

Doing so may cause a fire or other inci-

dent which may result in death or serious

injury.

220

4-5. Using the driving support systems

4-5.Using the driving support systems

: If equipped

PCS (Pre-Collision System)



P.231

LTA (Lane Tracing Assist)



P.239

AHS (Adaptive High-beam Sys-
tem)



P.203

AHB (Automatic High Beam)



P.207

RSA (Road Sign Assist)



P.249

Dynamic radar cruise control with
full-speed range



P.253

: If equipped

Two types of sensors, located behind
the front grille and windshield, detect
information necessary to operate the
drive assist systems.

Radar sensor

Front camera

Lexus Safety System +

The Lexus Safety System + consists
of the following drive assist systems
and contributes to a safe and com-
fortable driving experience:

Driving assist system

WARNING

Lexus Safety System +

The Lexus Safety System + is designed to

operate under the assumption that the

driver will drive safely, and is designed to

help reduce the impact to the occupants

and the vehicle in the case of a collision

or assist the driver in normal driving con-

ditions.
As there is a limit to the degree of recog-

nition accuracy and control performance

that this system can provide, do not

overly rely on this system. The driver is

always responsible for paying attention

to the vehicle’s surroundings and driving

safely.

Sensors

A
B

221

4-5. Using the driving support systems

ivin
g

WARNING

To avoid malfunction of the radar sen-

sor

Observe the following precautions.
Otherwise, the radar sensor may not

operate properly, possibly leading to an

accident resulting in death or serious

injury.

Keep the radar sensor and the radar

sensor cover clean at all times.

Radar sensor

Radar sensor cover

If the front of the radar sensor or the front
or back of the radar sensor cover is dirty
or covered with water droplets, snow,
etc., clean it.
Clean the radar sensor and radar sensor
cover with a soft cloth to avoid damaging
them.

Do not attach accessories, stickers

(including transparent stickers) or

other items to the radar sensor, radar

sensor cover or surrounding area.

Do not subject the radar sensor or its

surrounding area to a strong impact.

If the radar sensor, front grille, or front

bumper has been subjected to a

strong impact, have the vehicle

inspected by any authorized Lexus

retailer or Lexus authorized repairer,

or any reliable repairer.

Do not disassemble the radar sensor.

Do not modify or paint the radar sen-

sor or radar sensor cover.

In the following cases, the radar sensor

must be recalibrated. Contact any

authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer for details.

• When the radar sensor or front grille

are removed and installed, or replaced

• When the front bumper is replaced

To avoid malfunction of the front

camera

Observe the following precautions.
Otherwise, the front camera may not

operate properly, possibly leading to an

accident resulting in death or serious

injury.

Keep the windshield clean at all times.

• If the windshield is dirty or covered

with an oily film, water droplets, snow,

etc., clean the windshield.

• If a glass coating agent is applied to the

windshield, it will still be necessary to

use the windshield wipers to remove

water droplets, etc. from the area of

the windshield in front of the front

camera.

• If the inner side of the windshield

where the front camera is installed is

dirty, contact any authorized Lexus

retailer or Lexus authorized repairer,

or any reliable repairer.

222

4-5. Using the driving support systems

WARNING

Do not attach objects, such as stickers,

transparent stickers, etc., to the outer

side of the windshield in front of the

front camera (shaded area in the illus-

tration).

From the top of the windshield to
approximately 1 cm (0.4 in.) below
the bottom of the front camera

Approximately 20 cm (7.9 in.)
(Approximately 10 cm [4.0 in.] to the
right and left from the center of the
front camera)

If the part of the windshield in front of

the front camera is fogged up or cov-

ered with condensation, or ice, use the

windshield defogger to remove the

fog, condensation, or ice. (



P.327)

If water droplets cannot be properly

removed from the area of the wind-

shield in front of the front camera by

the windshield wipers, replace the

wiper insert or wiper blade.

Do not attach window tint to the wind-

shield.

Replace the windshield if it is damaged

or cracked.

After replacing the windshield, the

front camera must be recalibrated.

Contact any authorized Lexus retailer

or Lexus authorized repairer, or any

reliable repairer for details.

Do not allow liquids to contact the

front camera.

Do not allow bright lights to shine into

the front camera.

Do not dirty or damage the front cam-

era.

When cleaning the inside of the wind-

shield, do not allow glass cleaner to

contact the lens of the front camera.

Also, do not touch the lens.

If the lens is dirty or damaged, contact

any authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer.

Do not subject the front camera to a

strong impact.

Do not change the installation position

or direction of the front camera or

remove it.

Do not disassemble the front camera.

Do not modify any components of the

vehicle around the front camera

(inside rear view mirror, etc.) or ceil-

ing.

Do not attach any accessories to the

hood, front grille or front bumper that

may obstruct the front camera. Con-

tact any authorized Lexus retailer or

Lexus authorized repairer, or any reli-

able repairer for details.

If a surfboard or other long object is to

be mounted on the roof, make sure

that it will not obstruct the front cam-

era.

Do not modify the headlights or other

lights.

230

4-5. Using the driving support systems

In the following situations, if the situation has changed (or the vehicle has been driven for

some time) and the normal operating conditions are detected, the message will disap-

pear and the system will become operational.

If the message does not disappear, contact any authorized Lexus retailer or Lexus autho-
rized repairer, or any reliable repairer.
• When the temperature around the radar sensor is outside of the operational range, such

as when the vehicle is in the sun or in an extremely cold environment

• When the front camera cannot detect objects in front of the vehicle, such as when driving

in the dark, snow, or fog, or when bright lights are shining into the front camera

• Depending on the conditions in the vicinity of the vehicle, the radar may judge the sur-

rounding environment can not be properly recognized. In that case, “Pre-Collision Sys-

tem Unavailable” is displayed.

Situation

Actions

When the area around a camera is covered
with dirt, moisture (fogged up, covered with
condensation, ice, etc.), or other foreign
matter

Using the wiper and A/C function, remove
the dirt and other attached matter.
(



P.327)

When the temperature around the front
camera is outside of the operational range,
such as when the vehicle is in the sun or in an
extremely cold environment

If the front camera is hot, such as after the
vehicle had been parked in the sun, use the
air conditioning system to decrease the tem-
perature around the front camera.
If a sunshade was used when the vehicle was
parked, depending on its type, the sunlight
reflected from the surface of the sunshade
may cause the temperature of the front cam-
era to become excessively high.

If the front camera is cold, such after the
vehicle is parked in an extremely cold envi-
ronment, use the air conditioning system to
increase the temperature around the front
camera.

The area in front of the front camera is
obstructed, such as when the hood is open
or a sticker is attached to the part of the
windshield in front of the front camera.

Close the hood, remove the sticker, etc. to
clear the obstruction.

When “Pre-Collision System Unavailable” is
displayed.

Check whether there is attached materials
on the radar sensor and radar sensor cover,
and if there is, remove it.

231

4-5. Using the driving support systems

ivin
g

: If equipped

The countries and areas for each region listed in the table are current as of August
2021. However, depending on when the vehicle was sold, the countries and areas
of each region may be different. Contact your Lexus dealer for details.

Pre-collision warning

When the system determines that the
possibility of a frontal collision is high, a
buzzer will sound and a warning mes-
sage will be displayed on the multi-
information display to urge the driver

to take evasive action.

PCS (Pre-Collision System)

The pre-collision system uses a radar sensor and front camera to detect
objects (



P.231) in front of the vehicle. When the system determines that the

possibility of a frontal collision with an object is high, a warning operates to
urge the driver to take evasive action and the potential brake pressure is
increased to help the driver avoid the collision. If the system determines that
the possibility of a frontal collision with an object is extremely high, the brakes
are automatically applied to help avoid the collision or help reduce the impact
of the collision.

The pre-collision system can be disabled/enabled and the warning timing can be
changed. (



P.233)

Detectable objects

Regions

Detectable objects

Countries/areas



Vehicles



Bicyclists



Pedestrians

Iceland, Ireland, United Kingdom, Italy, Ukraine, Esto-

nia, Austria, Netherlands, Kazakhstan, Cyprus,

Greece, Switzerland, Sweden, Spain, Slovakia, Slove-

nia, Czech Republic, Denmark, Germany, Norway,

Hungary, Finland, France, Bulgaria, Belgium, Poland,
Portugal, Malta, Monaco, Latvia, Lithuania, Romania,

Russia, Israel, Turkey, Canary Islands

Vehicles

Azerbaijan, Georgia

System functions

Lexus UX (2022 year). Manual in english - page 12
