187

4-2. Driving procedures

Driving

Turns EV drive mode on/off

When EV drive mode is turned on, the EV
drive mode indicator will come on. Press-
ing the switch when in EV drive mode will
return the vehicle to normal driving (using
the gasoline engine and electric motor
[traction motor]).

■

Situations in which EV drive mode can-

not be turned on

It may not be possible to turn EV drive

mode on in the following situations. If it can-

not be turned on, a buzzer will sound and a

message will be shown on the multi-infor-

mation display.

●

The temperature of the hybrid system is

high.

The vehicle has been left in the sun,

driven on a hill, driven at high speeds, etc.

●

The temperature of the hybrid system is

low.

The vehicle has been left in temperatures

lower than about 32°F (0 °C) for a long

period of time, etc.

●

The gasoline engine is warming up.

●

The hybrid battery (traction battery) is

low.

The remaining battery level indicated in

the “Energy Monitor” display is low.

(



P.99)

●

Vehicle speed is high.

●

The accelerator pedal is depressed firmly

or the vehicle is on a hill, etc.

●

The windshield defogger is in use.

■

Switching to EV drive mode when the

gasoline engine is cold

If the hybrid system is started while the gas-

oline engine is cold, the gasoline engine will

start automatically after a short period of

time in order to warm up. In this case, you

will become unable to switch to EV drive

mode.
After the hybrid system has started and the

“READY” indicator has illuminated, press

the EV drive mode switch before the gaso-

line engine starts to switch to EV drive

mode.

■

Automatic cancelation of EV drive

mode

When driving in EV drive mode, the gaso-

line engine may automatically restart in the

following situations. When EV drive mode

is canceled, a buzzer will sound, the EV

drive mode indicator will go off after flash-

ing, and a message is displayed on the

multi-information display.

●

The hybrid battery (traction battery)

becomes low.

The remaining battery level indicated in

the “Energy Monitor” display is low.

(



P.99)

●

Vehicle speed is high.

●

The accelerator pedal is depressed firmly

or the vehicle is on a hill, etc.

EV drive mode

In EV drive mode, electric power is
supplied by the hybrid battery
(traction battery), and only the
electric motor (traction motor) is
used to drive the vehicle.

This mode allows you to drive in res-
idential areas early in the morning
and late at night, or in indoor park-
ing lots, etc., without concern for
noises and gas emissions.

Operating instructions

188

4-2. Driving procedures

■

Possible driving distance when driving in

EV drive mode

EV drive mode’s possible driving distance

ranges from a few hundred meters to

approximately 0.6 mile (1 km). However,

depending on vehicle conditions, there are

situations when EV drive mode cannot be

used.

(The distance that is possible depends on

the hybrid battery [traction battery] level

and driving conditions.)

■

Fuel economy

The hybrid system is designed to achieve

the best possible fuel economy during nor-

mal driving (using the gasoline engine and

electric motor [traction motor]). Driving in

EV drive mode more than necessary may

lower fuel economy.

■

If “EV Mode Unavailable” is shown on

the multi-information display

The EV drive mode is not available. The rea-

son the EV drive mode is not available (the

vehicle is idling, battery charge is low, vehi-

cle speed is higher than the EV drive mode

operating speed range or accelerator pedal

is depressed too much) may be displayed.

Use the EV drive mode when it becomes

available.

■

If “EV Mode Deactivated” is shown on

the multi-information display

The EV drive mode has been automatically

canceled. The reason the EV drive mode is

not available (the battery charge is low,

vehicle speed is higher than the EV drive

mode operating speed range or accelera-

tor pedal is depressed too much) may be

displayed. Drive the vehicle for a while

before attempting to turn on the EV drive

mode again.

WARNING

■

Caution while driving

When driving in EV drive mode no

engine noise is made. As such, pedestri-

ans, people riding bicycles or other peo-

ple and vehicles in the surrounding area

may not be aware of the vehicle starting

off or approaching them. Therefore, take

extra care while driving even if the

Acoustic Vehicle Alerting System is

active.

189

4-2. Driving procedures

Driving

: To improve fuel efficiency and reduce

noise, shift the shift lever to D for normal
driving.

: By selecting shift ranges using S mode,

you can control accelerating force and
engine braking force.

■

When driving with dynamic radar cruise

control with full-speed range activated

Even when performing the following

actions with the intent of enabling engine

braking, engine braking will not occur

because dynamic radar cruise control with

full-speed range will not be canceled.

●

While driving in D or S mode, downshift-

ing to 5 or 4. (



P.236)

●

When switching the driving mode to

sport mode while driving in the D position

(



P.276)

■

Restraining sudden start (Drive-Start

Control)



P.163

While the power switch is in ON

mode, move the shift lever with the
brake pedal depressed.

When shifting the shift lever between P

Hybrid transmission

Select the shift position depending
on your purpose and situation.

Shift position purpose and func-
tions

Shift posi-

tion

Objective or function

Parking the vehicle/starting

the hybrid system

Reversing

Neutral

Normal driving

S mode driving

(



P.191)

WARNING

■

When driving on slippery road sur-

faces

Be careful of downshifting and sudden

acceleration, as this could result in the

vehicle skidding to the side or spinning.

NOTICE

■

Hybrid battery (traction battery)

charge

If the shift lever is in N, the hybrid battery

(traction battery) will not be charged

even when the engine is running. There-

fore, if the vehicle is left with the shift

lever in N for a long period of time, the

hybrid battery (traction battery) will dis-

charge, and this may result in the vehicle

not being able to start.

Shifting the shift lever

190

4-2. Driving procedures

and D, make sure that the vehicle is com-
pletely stopped.

■

Shift lock system

The shift lock system is a system to prevent

accidental operation of the shift lever in

starting.
The shift lever can be shifted from P only

when the power switch is in ON mode and

the brake pedal is being depressed.

■

If the shift lever cannot be shifted from P

First, check whether the brake pedal is

being depressed.
If the shift lever cannot be shifted with your

foot on the brake pedal, there may be a

problem with the shift lock system. Have the

vehicle inspected by your Lexus dealer

immediately.
The following steps may be used as an

emergency measure to ensure that the shift

lever can be shifted.
Releasing the shift lock:

Turn the power switch to ON mode and

check that the parking brake is set.

(



P.185, 193)

Turn the power switch to off.

Depress the brake pedal.

Pry the cover up with a flathead screw-

driver or equivalent tool.

To prevent damage to the cover, cover the

tip of the screwdriver with a rag.

Press the shift lock override button.

The shift lever can be shifted while the but-

ton is pressed.



P.276

To drive using temporary shift range
selection, operate the “-” paddle shift
switch. Changing the shift range
enables the level of engine braking
force to be selected. The shift range
can then be selected by operating the
“-” and “+” paddle shift switches.

WARNING

■

To prevent an accident when releas-

ing the shift lock

Before pressing the shift lock override

button, make sure to set the parking

brake and depress the brake pedal.

If the accelerator pedal is accidentally

depressed instead of the brake pedal

when the shift lock override button is

pressed and the shift lever is shifted out

of P, the vehicle may suddenly start, pos-

sibly leading to an accident resulting in

death or serious injury.

Selecting the driving mode

Selecting shift ranges in the D
position

191

4-2. Driving procedures

Driving

Upshifting

Downshifting

The selected shift range, from D1 to D6,
will be displayed on the meters.
The initial shift range when the “-” paddle
shift switch is operated is automatically set
to D4 or D5 according to the vehicle
speed.
To return to normal D position driving, the
“+” paddle shift switch must be held down
for a period of time.

■

Shift ranges and their functions



You can choose from 6 levels of
engine braking force.



A lower shift range will provide
greater engine braking force than a
higher shift range, and the engine
revolutions will also increase.

■

When the “-” paddle shift switch is oper-

ated with the shift lever in the D position

The shift range is downshifted to a range

that enables engine braking force that is

suitable to driving conditions.

■

Automatic deactivation of shift range

selection in the D position

Shift range selection in the D position will

be deactivated in the following situations:

●

When the vehicle comes to a stop

●

If the accelerator pedal is depressed for

more than a certain period of time

●

When the shift lever is shifted to a posi-

tion other than D

■

Downshifting restriction warning

buzzer

To help ensure safety and driving perfor-

mance, downshifting operation may some-

times be restricted. In some circumstances,

downshifting may not be possible even

when the paddle shift switch is operated. (A

buzzer will sound twice.)

To enter S mode, shift the shift lever to
S. Shift ranges can be selected by
operating the shift lever or paddle shift
switches, allowing you to drive in the
shift range of your choice. The shift
range can be selected by operating the
shift lever or the “-” and “+” paddle shift
switches.

Upshifting

Downshifting

The selected shift range, from S1 to S6, will
be displayed on the meters.
The initial shift range in S mode is automat-

Selecting shift ranges in the S
position

192

4-2. Driving procedures

ically set to S4 or S5 according to the vehi-
cle speed.

■

Shift ranges and their functions



You can choose from 6 levels of
accelerating force and engine brak-
ing force.



A lower shift range will provide
greater accelerating force and
engine braking force than a higher
shift range, and the engine revolu-
tions will also increase.



If you accelerate while in ranges 1 to
4, the shift range may automatically
increase in accordance with the
vehicle speed.

■

S mode

●

When the shift range is S4 or lower, hold-

ing the shift lever toward “+” sets the shift

range to S6.

●

Automatically selects a higher shift range

before the engine speed becomes too

high.

Right turn

Lane change to the right (move the
lever partway and release it)

The right hand signals will flash 3 times.

Lane change to the left (move the
lever partway and release it)

The left hand signals will flash 3 times.

Left turn

■

Turn signals can be operated when

The power switch is in ON mode.

■

If the indicator flashes faster than usual

Check that a light bulb in the front or rear

turn signal lights has not burned out.

■

If the turn signals stop flashing before a

lane change has been performed

Operate the lever again.

■

Customization

Some functions can be customized.

Turn signal lever

Operating instructions

193

4-2. Driving procedures

Driving

(



P.472)

■

Using the manual mode

The parking brake can be set and
released manually.

U.S.A.
Canada
Parking brake light

Pull the parking brake switch to set
the parking brake

Parking brake

The parking brake can be set or
released automatically or manually.

In automatic mode, the parking
brake can be set or released auto-
matically according to the shift
lever operation. Also, even in auto-
matic mode, the parking brake can
be set or released manually.

Operating instructions

A
B
C

194

4-2. Driving procedures

The parking brake indicator light and park-
ing brake light will turn on.
Pull and hold the parking brake switch if an
emergency occurs and it is necessary to
operate the parking brake while driving.

Push the parking brake switch to
release the parking brake

Operate the switch while depressing the
brake pedal or slowly depressing the
accelerator pedal.
Make sure that the parking brake indicator
light and parking brake light turn off.

If the parking brake indicator light and
parking brake light flashes, operate the
switch again. (



P.416)

■

Turns automatic mode on

While the vehicle is stopped, pull and
hold the parking brake switch until
“Automatic Mode On” will be dis-
played on the multi-information dis-
play.

When the automatic mode is turned
on, the parking brake operates as fol-
lows.



When the shift lever is moved out of
P, the parking brake will be released,
and the parking brake indicator light
and parking brake light turn off.



When the shift lever is moved into P,
the parking brake will be set, and the

parking brake indicator light and
parking brake light turn on.

Operate the shift lever with the brake
pedal depressed.

■

Turns automatic mode off

While the vehicle is stopped, press and
hold the parking brake switch until
“Automatic Mode Off” will be dis-
played on the multi-information dis-
play.

■

Parking brake operation

●

When the power switch is not in ON

mode, the parking brake cannot be

released using the parking brake switch.

●

When the power switch is not in ON

mode, automatic mode (automatic brake

setting and releasing) is not available.

■

Parking brake automatic release func-

tion

The parking brake is automatically released

when slowly depress the accelerator pedal.
The parking brake will be released auto-

matically under the following conditions:
• The driver’s door is closed.
• The driver’s seatbelt is fastened.
• Shift the shift lever is in a forward or

reverse position.

• The malfunction indicator lamp or brake

system warning light is not illuminated.

If the automatic release function does not

operate, manually release the parking

brake.

195

4-2. Driving procedures

Driving

■

If “Parking Brake Overheated Parking

Brake Unavailable” is displayed on the

multi-information display

If the parking brake is operated repeatedly

over a short period of time, the system may

restrict operation to prevent overheating. If

this happens, refrain from operating the

parking brake. Normal operation will return

after about 1 minute.

■

If “EPB Activation Stopped Incom-

pletely” or “Parking Brake Unavailable”

is displayed on the multi-information

display

Operate the parking brake switch. If the

message does not disappear after operat-

ing the switch several times, the system may

be malfunctioning. Have the vehicle

inspected by your Lexus dealer immedi-

ately.

■

Parking brake operation sound

When the parking brake operates, a motor

sound (whirring sound) may be heard. This

does not indicate a malfunction.

■

Parking brake indicator light and park-

ing brake light

●

Depending on the power switch mode,

the parking brake indicator light and

parking brake light will turn on and stay

on as described below:

ON mode: Comes on until the parking

brake is released.

Not in ON mode: Stays on for approxi-

mately 15 seconds.

●

When the power switch is turned off with

the parking brake set, the parking brake

indicator light and parking brake light will

stay on for about 15 seconds. This does

not indicate a malfunction.

■

Changing the mode

When changing the automatic mode on/off,

the message will be shown on the

multi-information display and the buzzer

sounds.

■

Parking the vehicle



P.162

■

Parking brake engaged warning buzzer

A buzzer will sound if the vehicle is driven

with the parking brake engaged. “Release

Parking Brake” is displayed on the

multi-information display.

■

Warning messages and buzzers

Warning messages and buzzers are used to

indicate a system malfunction or to inform

the driver of the need for caution. If a warn-

ing message is shown on the multi-informa-

tion display, read the message and follow

the instructions.

■

If the brake system warning light comes



P.410

■

Usage in winter time



P.288

WARNING

■

When parking the vehicle

Do not leave a child in the vehicle alone.

The parking brake may be released unin-

tentionally and there is the danger of the

vehicle moving that may lead to an acci-

dent resulting in death or serious injury.

■

Parking brake switch

Do not set any objects near the parking

brake switch. Objects may interfere with

the switch and may lead the parking

brake to unexpectedly operate.

NOTICE

■

When parking the vehicle

Before you leave the vehicle, shift the

shift lever to P, set the parking brake and

make sure that the vehicle does not

move.

■

When the system malfunctions

Stop the vehicle in a safe place and

check the warning messages.

196

4-2. Driving procedures

Turns the brake hold system on

The brake hold standby indicator (green)

comes on. While the system is holding

the brake, the brake hold operated indica-
tor (yellow)

comes on.

■

Brake hold system operating conditions

The brake hold system cannot be turned on

in the following conditions:

●

The driver’s door is not closed.

●

The driver is not wearing the seat belt.

If any of the conditions above are detected

when the brake hold system is enabled, the

system will turn off and the brake hold

standby indicator light will go off. In addi-

tion, if any of the conditions are detected

while the system is holding the brake, a

warning buzzer will sound and a message

will be shown on the multi-information dis-

NOTICE

■

When the parking brake cannot be

released due to a malfunction

Driving the vehicle with the parking

brake set will lead to brake components

overheating, which may affect braking

performance and increase brake wear.
Have the vehicle inspected by your

Lexus dealer immediately if this occurs.

Brake Hold

The brake hold system keeps the
brake applied when the shift lever is
in D, S or N with the system on and
the brake pedal has been
depressed to stop the vehicle. The
system releases the brake when the
accelerator pedal is depressed with
the shift lever in D or S to allow
smooth start off.

Enabling the system

197

4-2. Driving procedures

Driving

play. The parking brake will then be set

automatically.

■

Brake hold function

●

If the brake pedal is left released for a

period of about 3 minutes after the sys-

tem has started holding the brake, the

parking brake will be set automatically. In

this case, a warning buzzer sounds and a

message is shown on the multi-informa-

tion display.

●

To turn the system off while the system is

holding the brake, firmly depress the

brake pedal and press the button again.

●

The brake hold function may not hold the

vehicle when the vehicle is on a steep

incline. In this situation, it may be neces-

sary for the driver to apply the brakes. A

warning buzzer will sound and the

multi-information display will inform the

driver of this situation. If a warning mes-

sage is shown on the multi-information

display, read the message and follow the

instructions.

■

When the parking brake is set automati-

cally while the system is holding the

brakes

Perform any of the following operations to

release the parking brake.

●

Depress the accelerator pedal. (The

parking brake will not be released auto-

matically if the seat belt is not fastened.)

●

Operate the parking brake switch with

the brake pedal depressed.

Make sure that the parking brake indicator

light goes off. (



P.193)

■

When an inspection at your Lexus

dealer is necessary

When the brake hold standby indicator

(green) does not illuminate even when the

brake hold switch is pressed with the brake

hold system operating conditions met, the

system may be malfunctioning. Have the

vehicle inspected at your Lexus dealer.

■

If “Brake Hold Fault Depress Brake to

Deactivate Visit Your Dealer” or “Brake

Hold Malfunction Visit Your Dealer” is

displayed on the multi-information dis-

play

The system may be malfunctioning. Have

the vehicle inspected by your Lexus dealer.

■

Warning messages and buzzers

Warning messages and buzzers are used to

indicate a system malfunction or to inform

the driver of the need for caution. If a warn-

ing message is shown on the multi-informa-

tion display, read the message and follow

the instructions.

■

If the brake hold operated indicator

flashes



P.417

WARNING

■

When the vehicle is on a steep incline

When using the brake hold system on a

steep incline exercise caution. The brake

hold function may not hold the vehicle in

such a situation.

■

When stopped on a slippery road

The system cannot stop the vehicle when

the gripping ability of the tires has been

exceeded. Do not use the system when

stopped on a slippery road.

NOTICE

■

When parking the vehicle

The brake hold system is not designed

for use when parking the vehicle for a

long period of time. Turning the power

switch off while the system is holding the

brake may release the brake, which

would cause the vehicle to move. When

operating the power switch, depress the

brake pedal, shift the shift lever to P and

set the parking brake.

198

4-3. Operating the lights and wipers

4-3.Operating the lights and wipers

Operating the

switch turns on

the lights as follows:

U.S.A.
Canada

The side marker, parking, tail,

license plate, instrument panel
lights, and daytime running lights
(



P.198) turn on.

The headlights and all lights

listed above (except daytime run-
ning lights) turn on.

The headlights, daytime run-

ning lights (



P.198) and all the

lights listed above turn on and off
automatically.
(When the power switch is in ON
mode.)

(U.S.A.) Off

■

Daytime running light system

●

The daytime running lights illuminate

using the same lights as the parking lights

and illuminate brighter than the parking

lights.

●

To make your vehicle more visible to

other drivers during daytime driving, the

daytime running lights turn on automati-

cally when all of the following conditions

are met. (The daytime running lights are

not designed for use at night.)

• The hybrid system is started

• The parking brake is released
• The headlight switch is in the

position

: When the surroundings are bright

The daytime running lights remain on after

they illuminate, even if the parking brake is

set again.

●

For the U.S.A.: Daytime running lights

can be turned off by operating the switch.

●

Compared to turning on the headlights,

the daytime running light system offers

greater durability and consumes less

electricity, so it can help improve fuel

economy.

■

Headlight control sensor

The sensor may not function properly if an

object is placed on the sensor, or anything

that blocks the sensor is affixed to the wind-

shield.

Headlight switch

The headlights can be operated
manually or automatically.

Operating instructions

A
B

199

4-3. Operating the lights and wipers

Driving

Doing so interferes with the sensor detect-

ing the level of ambient light and may cause

the automatic headlight system to malfunc-

tion.

■

Automatic light off system

●

When the headlights are on: The head-

lights and tail lights turn off 30 seconds

after the driver’s door is opened and

closed if the power switch is turned to

ACCESSORY mode or turned off. (The
lights turn off immediately if

on the

key is pressed after all the doors are

closed.)

●

When only the tail lights are on: The tail

lights turn off automatically if the power

switch is turned to ACCESSORY mode

or turned off and the driver’s door is

opened.

■

Automatic headlight leveling system (if

equipped)

The level of the headlights is automatically

adjusted according to the number of pas-

sengers and the loading condition of the

vehicle to ensure that the headlights do not

interfere with other road users.

■

Light reminder buzzer

A buzzer sounds when the power switch is

turned off or turned to ACCESSORY

mode and the driver’s door is opened while

the lights are turned on.

■

Welcome lighting

If the headlight switch is turned to

and

the surrounding area is dark, unlocking the

doors using the smart access system with

push-button start or wireless remote con-

trol will turn the parking lights and tail lights

on automatically.

■

Windshield wiper linked headlight illu-

mination

When driving during daytime with the
headlight switch turned to

, if the wind-

shield wipers are used, the headlights will

turn on automatically after several seconds

to help enhance the visibility of your vehicle.

■

12-volt battery-saving function

In order to prevent the 12-volt battery of the

vehicle from discharging, if the headlights

and/or tail lights are on when the power

switch is turned off the 12-volt battery sav-

ing function will operate and automatically

turn off all the lights after approximately 20

minutes. When the power switch is turned

to ON mode, the 12-volt battery-saving

function will be disabled.

When any of the following are performed,

the 12-volt battery-saving function is can-

celed once and then reactivated. All the

lights will turn off automatically 20 minutes

after the 12-volt battery-saving function has

been reactivated:

●

When the headlight switch is operated

●

When a door is opened or closed

■

Customization

Some functions can be customized.

(



P.472)

With the headlights on, push the
lever away from you to turn on the
high beams.

Pull the lever toward you to the center
position to turn the high beams off.

Pull the lever toward you and
release it to flash the high beams

NOTICE

■

To prevent 12-volt battery discharge

Do not leave the lights on longer than

necessary when the hybrid system is off.

Turning on the high beam head-
lights

200

4-3. Operating the lights and wipers

once.

You can flash the high beams with the
headlights on or off.

AFS (Adaptive Front-lighting System)
secures excellent visibility at intersec-
tions and on curves by automatically
adjusting the direction of the light axis
of the headlights according to vehicle
speed and the degree of the tire’s angle
as controlled by steering input.

AFS operates at speeds of 6 mph (10
km/h) or higher.

■

Customization

Some functions can be customized.

(



P.472)



When the steering wheel or turn
signal lever is operated while the
headlights are on (low beam), a cor-
nering light will turn on and light up
the direction of movement of the
vehicle. The cornering lights are
designed to ensure excellent visibil-
ity when making a turn at an inter-
section.

However, when vehicle speed is approxi-
mately 22 mph (35 km/h) or higher, the
cornering lights will not turn on.



When the shift lever is in R while the
headlights are on (low beam), both
cornering lights will turn on. This is
designed to enhance visibility when
parking.

■

Cornering lights (if equipped)

When the cornering lights are on for more

than 30 minutes, they will turn off automati-

cally.

AFS (Adaptive Front-lighting
System) (if equipped)

Cornering lights (if equipped)

201

4-3. Operating the lights and wipers

Driving

Press the Automatic High Beam
switch.

Turn the headlight switch to the

position.

The Automatic High Beam indicator will

come on when the system is operating.

■

Conditions to turn the high beams on/off

automatically

●

When all of the following conditions are

met, the high beams will be turned on

automatically (after approximately 1 sec-

ond):

• The vehicle speed is approximately 21

mph (34 km/h) or more.

• The area ahead of the vehicle is dark.

• There are no vehicles ahead with head-

lights or tail lights turned on.

• There are few streetlights on the road

ahead.

●

If any of the following conditions is met,

the high beams will turn off automatically:

• The vehicle speed is below approxi-

mately 17 mph (27 km/h).

• The area ahead of the vehicle is not dark.

• Vehicles ahead have their headlights or

tail lights turned on.

• There are many streetlights on the road

ahead.

■

Camera sensor detection information

●

The high beams may not be automatically

turned off in the following situations:

• When a vehicle suddenly appears from

around a curve

• When the vehicle is cut in front of by

another vehicle

• When vehicles ahead cannot be

detected due to repeated curves, road

dividers or roadside trees

• When vehicles ahead appear in a far-

away lane on a wide road

• When the lights of vehicles ahead are not

●

The high beams may be turned off if a

vehicle ahead that is using fog lights with-

AHB (Automatic High
Beam)

The Automatic High Beam uses a
camera sensor located behind the
upper portion of the windshield to
assess the brightness of the lights of
vehicles ahead, streetlights, etc.,
and automatically turns the high
beams on or off as necessary.

WARNING

■

Limitations of the Automatic High

Beam

Do not overly rely on the Automatic High

Beam. Always drive safely, taking care to

observe your surroundings and turning

the high beams on or off manually if nec-

essary.

■

To prevent incorrect operation of the

Automatic High Beam system

Do not overload the vehicle.

Activating the Automatic High
Beam

202

4-3. Operating the lights and wipers

out its headlights turned on is detected.

●

House lights, street lights, traffic signals,

and illuminated billboards or signs and

other reflective objects may cause the

high beams to change to the low beams,

or the low beams to remain on.

●

The following factors may affect the

amount of time taken for the high beams

to turn on or off:

• The brightness of the headlights, fog

lights, and tail lights of vehicles ahead

• The movement and direction of vehicles

ahead

• When a vehicle ahead only has opera-

tional lights on one side

• When a vehicle ahead is a two-wheeled

vehicle

• The condition of the road (gradient,

curve, condition of the road surface, etc.)

• The number of passengers and amount of

luggage in the vehicle

●

The high beams may turn on or off unex-

pectedly.

●

Bicycles or similar vehicles may not be

detected.

●

In the following situations the system may

not be able to correctly detect the sur-

rounding brightness level. This may cause

the low beams to remain on or the high

beams to flash or dazzle pedestrians or

vehicles ahead. In such a case, it is neces-

sary to manually switch between the high

and low beams.

• When driving in inclement weather

(heavy rain, snow, fog, sandstorms, etc.)

• When the windshield is obscured by fog,

mist, ice, dirt, etc.

• When the windshield is cracked or dam-

aged

• When the camera sensor is deformed or

dirty

• When the temperature of the camera

sensor is extremely high

• When the surrounding brightness level is

equal to that of headlights, tail lights or

fog lights

• When headlights or tail lights of vehicles

ahead are turned off, dirty, changing

color, or not aimed properly

• When the vehicle is hit by water, snow,

dust, etc. from a preceding vehicle

• When driving through an area of inter-

mittently changing brightness and dark-

ness

• When frequently and repeatedly driving

ascending/descending roads, or roads

with rough, bumpy or uneven surfaces

(such as stone-paved roads, gravel roads,

etc.)

• When frequently and repeatedly taking

curves or driving on a winding road

• When there is a highly reflective object

ahead of the vehicle, such as a sign or

mirror

• When the back of a preceding vehicle is

highly reflective, such as a container on a

truck

• When the vehicle’s headlights are dam-

aged or dirty, or are not aimed properly

• When the vehicle is listing or titling due to

a flat tire, a trailer being towed, etc.

• When the headlights are changed

between the high beams and low beams

repeatedly in an abnormal manner

• When the driver believes that the high

beams may be flashing or dazzling

pedestrians or other drivers

■

Temporarily lowering sensor sensitivity

The sensitivity of the sensor can be tempo-

rarily lowered.

Turn the power switch off while the fol-

lowing conditions are met.

●

The headlight switch is in

●

The headlight switch lever is in high beam

position.

●

Automatic High Beam switch is on.

Turn the power switch to ON mode.

Within 60 seconds after step

, repeat

pulling the headlight switch lever to the

original position then pushing it to the

high beam position quickly 10 times,

then leave the lever in high beam posi-

tion.

If the sensitivity is changed, the Auto-

matic High Beam indicator is turn on

and off 3 times.

Automatic High Beam (headlights) may

turn on even when the vehicle is stopped.

Content .. 9 10 11 12 ..
