1-1. For safe use

SRS warning light
Driver’s and front passenger’s seat belt reminder light



For the U.S.A.

“AIR BAG OFF” indicator light
“AIR BAG ON” indicator light



For Canada

“AIR BAG OFF” indicator light
“AIR BAG ON” indicator light

System components

A
B

C
D

E
F

WARNING

■

Front passenger occupant classifica-

tion system precautions

Observe the following precautions

regarding the front passenger occupant

classification system.

Failure to do so may cause death or seri-

ous injury.

●

Wear the seat belt properly.

●

Make sure the front passenger’s seat

belt plate has not been left inserted

into the buckle before someone sits in

the front passenger seat.

●

Make sure the “AIR BAG OFF” indica-

tor light is not illuminated when using

the seat belt extender for the front pas-

senger seat. If the “AIR BAG OFF”

indicator light is illuminated, discon-

nect the extender tongue from the seat

belt buckle, and reconnect the seat

belt. Reconnect the seat belt extender

after making sure the “AIR BAG ON”

indicator light is illuminated. If you use

the seat belt extender while the “AIR

BAG OFF” indicator light is illumi-

nated, the SRS airbags for the front

passenger will not activate, which

could cause death or serious injury in

the event of a collision.

●

Do not apply a heavy load to the front

passenger seat or equipment (e.g.

seatback pocket).

1-1. For safe use

For safety and security

WARNING

●

Do not put weight on the front passen-

ger seat by putting your hands or feet

on the front passenger seat seatback

from the rear passenger seat.

●

Do not let a rear passenger lift the

front passenger seat with their feet or

press on the seatback with their legs.

●

Do not put objects under the front pas-

senger seat.

●

Do not recline the front passenger

seatback so far that it touches a rear

seat. This may cause the “AIR BAG

OFF” indicator light to be illuminated,

which indicates that the SRS airbags

for the front passenger will not activate

in the event of a severe accident. If the

seatback touches the rear seat, return

the seatback to a position where it

does not touch the rear seat. Keep the

front passenger seatback as upright as

possible when the vehicle is moving.

Reclining the seatback excessively

may lessen the effectiveness of the

seat belt system.

●

If an adult sits in the front passenger

seat, the “AIR BAG ON” indicator light

is illuminated. If the “AIR BAG OFF”

indicator is illuminated, ask the passen-

ger to sit up straight, well back in the

seat, feet on the floor, and with the seat

belt worn correctly. If the “AIR BAG

OFF” indicator still remains illumi-

nated, either ask the passenger to

move to the rear seat, or if that is not

possible, move the front passenger

seat fully rearward.

●

When it is unavoidable to install a for-

ward-facing child restraint system on

the front passenger seat, install the

child restraint system on the front pas-

senger seat in the proper order.

(



P.46)

●

Do not modify or remove the front

seats.

●

Do not kick the front passenger seat or

subject it to severe impact. Otherwise,

the SRS warning light may come on to

indicate a malfunction of the front pas-

senger occupant classification system.

In this case, contact your Lexus dealer

immediately.

●

Child restraint systems installed on the

rear seat should not contact the front

seatbacks.

●

Do not use a seat accessory, such as a

cushion and seat cover, that covers the

seat cushion surface.

●

Do not modify or replace the uphol-

stery of the front seat.

1-1. For safe use

■

Adult

■

Child

■

Child restraint system with infant

Condition and operation in the front passenger occupant classification
system

Indicator/warning light

“AIR BAG ON” and “AIR BAG OFF” indi-

cator lights

“AIR BAG ON”

SRS warning light

Off

Driver’s and front passenger’s seat belt

reminder light

Off

or flashing

Devices

Front passenger airbag

Activated

Seat cushion airbag in the front passenger

side

Activated

or deacti-

vated

Indicator/warning light

“AIR BAG ON” and “AIR BAG OFF” indi-

cator lights

“AIR BAG OFF” or

“AIR BAG ON”

SRS warning light

Off

Driver’s and front passenger’s seat belt

reminder light

Off

or flashing

Devices

Front passenger airbag

Deactivated or acti-

vated

Seat cushion airbag in the front passenger

side

Deactivated or acti-

vated

*4, 2

Indicator/warning light

“AIR BAG ON” and “AIR BAG OFF” indi-

cator lights

“AIR BAG OFF”

SRS warning light

Off

Driver’s and front passenger’s seat belt

reminder light

Off

or flashing

Devices

Front passenger airbag

Deactivated

Seat cushion airbag in the front passenger

side

1-1. For safe use

For safety and security

■

Unoccupied

■

There is a malfunction in the system

: The system judges a person of adult size as an adult. When a smaller adult sits in the

front passenger seat, the system may not recognize him/her as an adult depending on
his/her physique and posture.

: In the event the front passenger is wearing a seat belt.

: In the event the front passenger does not wear a seat belt.

: For some children, child in seat, child in booster seat or child in convertible seat, the sys-

tem may not recognize him/her as a child. Factors which may affect this can be the phy-
sique or posture.

: Never install a rear-facing child restraint system on the front passenger seat. A for-

ward-facing child restraint system should only be installed on the front passenger seat
when it is unavoidable. (



P.45)

: In case the indicator light is not illuminated, consult this manual on how to install the child

restraint system properly. (



P.46)

Indicator/warning light

“AIR BAG ON” and “AIR BAG OFF” indi-

cator lights

“AIR BAG OFF”

SRS warning light

Off

Driver’s and front passenger’s seat belt

reminder light

Devices

Front passenger airbag

Deactivated

Seat cushion airbag in the front passenger

side

Indicator/warning light

“AIR BAG ON” and “AIR BAG OFF” indi-

cator lights

“AIR BAG OFF”

SRS warning light

Driver’s and front passenger’s seat belt

reminder light

Off

Devices

Front passenger airbag

Deactivated

Seat cushion airbag in the front passenger

side

1-1. For safe use

Exhaust gas precautions

Harmful substance to the human
body is included in exhaust gases if
inhaled.

WARNING

Exhaust gases include harmful carbon

monoxide (CO), which is colorless and

odorless. Observe the following precau-

tions.

Failure to do so may cause exhaust gases

enter the vehicle and may lead to an

accident caused by light-headedness, or

may lead to death or a serious health

hazard.

■

Important points while driving

●

Keep the back door closed.

●

If you smell exhaust gases in the vehi-

cle even when the back door is closed,

open the windows and have the vehi-

cle inspected at your Lexus dealer as

soon as possible.

■

When parking

●

If the vehicle is in a poorly ventilated

area or a closed area, such as a

garage, stop the hybrid system.

●

Do not leave the vehicle with the

hybrid system on for a long time.

If such a situation cannot be avoided,

park the vehicle in an open space and

ensure that exhaust fumes do not enter

the vehicle interior.

●

Do not leave the hybrid system operat-

ing in an area with snow build-up, or

where it is snowing. If snowbanks build

up around the vehicle while the hybrid

system is operating, exhaust gases

may collect and enter the vehicle.

■

Exhaust pipe

The exhaust system needs to be checked

periodically. If there is a hole or crack

caused by corrosion, damage to a joint

or abnormal exhaust noise, be sure to

have the vehicle inspected and repaired

by your Lexus dealer.

1-2. Child safety

For safety and security

1-2.Child safety

Points to remember: P.45
Child restraint system: P.46
When using a child restraint system:
P.48
Child restraint system installation
method
• Fixed with a seat belt: P.50
• Fixed with a child restraint LATCH

anchor: P.54

• Using an anchor bracket (for top

tether strap): P.57

The laws of all 50 states of the U.S.A.
as well as Canada now require the use
of child restraint systems.



Prioritize and observe the warn-

Riding with children

Observe the following precautions
when children are in the vehicle.
Use a child restraint system appro-
priate for the child, until the child
becomes large enough to properly
wear the vehicle’s seat belt.



It is recommended that children
sit in the rear seats to avoid acci-
dental contact with the shift lever,
wiper switch, etc.



Use the rear door child-protector
lock or the window lock switch to
avoid children opening the door
while driving or operating the
power window accidentally.
(



P.112, 153)



Do not let small children operate
equipment which may catch or
pinch body parts, such as the
power window, hood, back door,
seats etc.

WARNING

■

When children are in the vehicle

Never leave children unattended in the

vehicle, and never allow children to have

or use the key.
Children may be able to start the vehicle

or shift the vehicle into neutral. There is

also a danger that children may injure

themselves by playing with the windows,

the moon roof or panoramic moon roof,

or other features of the vehicle. In addi-

tion, heat build-up or extremely cold

temperatures inside the vehicle can be

fatal to children.

Child restraint systems

Before installing a child restraint
system in the vehicle, there are pre-
cautions that need to be observed,
different types of child restraint sys-
tems, as well as installation meth-
ods, etc., written in this manual.

Use a child restraint system when
riding with a small child that cannot
properly use a seat belt. For the
child’s safety, install the child
restraint system to a second-row
seat. Be sure to follow the installa-
tion method that is in the operation
manual enclosed with the restraint
system.

Table of contents

Points to remember

1-2. Child safety

ings, as well as the laws and regula-
tions for child restraint systems.



Use a child restraint system until the
child becomes large enough to
properly wear the vehicle’s seat belt.



Choose a child restraint system that
suits your vehicle and is appropriate
to the age and size of the child.

■

Types of child restraint system installation methods

Confirm with the operation manual enclosed with the child restraint system about
the installation of the child restraint system.

WARNING

■

When a child is riding

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

For effective protection in automobile

accidents and sudden stops, a child

must be properly restrained, using a

seat belt or child restraint system

which is correctly installed. For installa-

tion details, refer to the operation man-

ual enclosed with the child restraint

system. General installation instruction

is provided in this manual.

●

Lexus strongly urges the use of a

proper child restraint system that con-

forms to the weight and size of the

child, installed on the second-row seat.

According to accident statistics, the

child is safer when properly restrained

in the second-row seat than in the front

seat.

●

Holding a child in your or someone

else’s arms is not a substitute for a child

restraint system. In an accident, the

child can be crushed against the wind-

shield or between the holder and the

interior of the vehicle.

■

Handling the child restraint system

If the child restraint system is not prop-

erly fixed in place, the child or other pas-

sengers may be seriously injured or even

killed in the event of sudden braking, sud-

den swerving, or an accident.

●

If the vehicle were to receive a strong

impact from an accident, etc., it is pos-

sible that the child restraint system has

damage that is not readily visible. In

such cases, do not reuse the restraint

system.

●

Make sure you have complied with all

installation instructions provided with

the child restraint system manufac-

turer and that the system is properly

secured.

●

Keep the child restraint system prop-

erly secured on the seat even if it is not

in use. Do not store the child restraint

system unsecured in the passenger

compartment.

●

If it is necessary to detach the child

restraint system, remove it from the

vehicle or store it securely in the lug-

gage compartment.

Child restraint system

1-2. Child safety

For safety and security

Installation method

Page

Seat belt attachment

P.50

Child restraint LATCH

anchors attachment

P.54

1-2. Child safety

: The third-row seats are not equipped with Child restraint LATCH anchors.

■

When installing a child restraint
system to a front passenger seat

For the safety of a child, install child

restraint systems to second-row seats.
When installing child restraint system
to a front passenger seat is unavoid-
able, adjust the seat as follows and
install the child restraint system.



Move the seat to the rearmost posi-

Anchor brackets (for top

tether strap) attachment

Second-row seats (RX450h):

P.57

Second-row seats (RX450hL):

Third-row seats (RX450hL)

Installation method

Page

When using a child restraint sys-
tem

1-2. Child safety

For safety and security

tion



Raise the seatback as much as pos-
sible



Raise the seat to the highest position



If the head restraint interferes with
the installation of the child restraint
system, and the head restraint can
be removed, remove the head
restraint

If the head restraint cannot be removed,
raise it to the uppermost position.

WARNING

■

When using a child restraint system

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Never install a rear-facing child

restraint system on the front passenger

seat even if the “AIR BAG OFF” indi-

cator light is illuminated. In the event of

an accident, the force of the rapid infla-

tion of the front passenger airbag can

cause death or serious injury to the

child if the rear-facing child restraint

system is installed on the front passen-

ger seat.

●

A forward-facing child restraint system

may be installed on the front passen-

ger seat only when it is unavoidable. A

child restraint system that requires a

top tether strap should not be used in

the front passenger seat since there is

no top tether strap anchor for the front

passenger seat.

●

A forward-facing child restraint system

may be installed on the front passen-

ger seat only when it is unavoidable.

When installing a forward-facing child

restraint system on the front passenger

seat, raise the seatback as much as

possible, move the seat to the rear-

most position, and raise the seat to the

highest position, even if the “AIR BAG

OFF” indicator light is illuminated.

If the head restraint interferes with the
installation of the child restraint system,
and the head restraint can be removed,
remove the head restraint.
If the head restraint cannot be removed,
raise it to the uppermost position.

1-2. Child safety

A child restraint system for a small
child or baby must itself be properly
restrained on the seat with the lap por-
tion of the lap/shoulder belt.

■

Installing child restraint system
using a seat belt (child restraint
lock function belt)

Install the child restraint system in
accordance to the operation manual
enclosed with the child restraint sys-
tem.

■

Rear-facing



Infant seat/con-

vertible seat

Adjust the rear seat

If there is a gap between the child seat and

the seatback, adjust the seatback angle

until good contact is achieved.

Place the child restraint system on
the rear seat facing the rear of the
vehicle.

Run the seat belt through the child
restraint system and insert the plate

WARNING

●

Do not allow the child to lean his/her

head or any part of his/her body

against the door or the area of the seat,

front or rear pillars, or roof side rails

from which the SRS side airbags or

SRS curtain shield airbags deploy even

if the child is seated in the child

restraint system. It is dangerous if the

SRS side airbags and curtain shield air-

bags inflate, and the impact could

cause death or serious injury to the

child.

●

When a booster seat is installed,

always ensure that the shoulder belt is

positioned across the center of the

child’s shoulder. The belt should be

kept away from the child’s neck, but

not so that it could fall off the child’s

shoulder.

●

Use child restraint system suitable to

the age and size of the child and install

it to the rear seat.

●

If the driver’s seat interferes with the

child restraint system and prevents it

from being attached correctly, attach

the child restraint system to the

right-hand rear seat.

●

Adjust the front passenger seat so that

it does not interfere with the child

restraint system.

Child restraint system fixed with
a seat belt

1-2. Child safety

For safety and security

into the buckle. Make sure that the
belt is not twisted.

Fully extend the shoulder belt and
allow it to retract to put it in lock
mode. In lock mode, the belt cannot
be extended.

While pushing the child restraint
system down into the rear seat,
allow the shoulder belt to retract
until the child restraint system is
securely in place.

After the shoulder belt has retracted to a

point where there is no slack in the belt,

pull the belt to check that it cannot be

extended.

After installing the child restraint
system, rock it back and forth to
ensure that it is installed securely.
(



P.54)

■

Forward-facing



Convertible

seat

Adjust the seat



When using the front passenger
seat

If installing the child restraint system to the
front passenger seat is unavoidable, refer
to P.48for the front passenger seat adjust-
ment.



When using the rear seat

If there is a gap between the child seat and
the seatback, adjust the seatback angle
until good contact is achieved.

Remove the head restraint if it inter-
feres with your child restraint sys-
tem. (



P.143)

If the head restraint cannot be removed,

raise it to the uppermost position.

1-2. Child safety

Place the child restraint system on
the seat facing the front of the vehi-
cle.

Run the seat belt through the child
restraint system and insert the plate
into the buckle. Make sure that the
belt is not twisted.

Fully extend the shoulder belt and
allow it to retract to put it in lock
mode. In lock mode, the belt cannot
be extended.

While pushing the child restraint
system into the rear seat, allow the
shoulder belt to retract until the

child restraint system is securely in
place.

After the shoulder belt has retracted to a

point where there is no slack in the belt,

pull the belt to check that it cannot be

extended.

If the child restraint has a top tether
strap, follow the child restraint man-
ufacturer’s operation manual
regarding the installation, using the
top tether strap to latch onto the
top tether strap anchor. (



P.57)

After installing the child restraint
system, rock it back and forth to
ensure that it is installed securely.
(



P.54)

■

Booster seat

If installing the child restraint sys-
tem to the front passenger seat is
unavoidable, refer to P.48for the
front passenger seat adjustment.

High back type: Remove the head
restraint if it interferes with your
child restraint system. (



P.143)

If the head restraint cannot be removed,

1-2. Child safety

For safety and security

raise it to the uppermost position.

Place the child restraint system on
the seat facing the front of the vehi-
cle.



Booster type



High back type

Sit the child in the child restraint
system. Fit the seat belt to the child
restraint system according to the
manufacturer’s instructions and
insert the plate into the buckle.
Make sure that the belt is not
twisted.

Check that the shoulder belt is correctly

positioned over the child’s shoulder and

that the lap belt is as low as possible.

(



P.26)

■

Removing a child restraint system
installed with a seat belt

Press the buckle release button and
fully retract the seat belt.

When releasing the buckle, the child
restraint system may spring up due to the
rebound of the seat cushion. Release the
buckle while holding down the child
restraint system.
Since the seat belt automatically reels itself,
slowly return it to the stowing position.

WARNING

■

When installing a child restraint sys-

tem

Observe the following precautions.

Failure to do so may result in death or

serious injury.

1-2. Child safety

■

Child restraint LATCH anchors

LATCH anchors are provided for the
outboard second-row seats. (Buttons
displaying the location of the anchors
are attached to the seats.)

WARNING

●

Do not allow children to play with the

seat belt. If the seat belt becomes

twisted around a child’s neck, it may

lead to choking or other serious inju-

ries that could result in death.

If this occurs and the buckle cannot be

unfastened, scissors should be used to

cut the belt.

●

Ensure that the belt and plate are

securely locked and the seat belt is not

twisted.

●

Shake the child restraint system left

and right, and forward and backward

to ensure that it has been securely

installed.

●

After securing a child restraint system,

never adjust the seat.

●

When a booster seat is installed,

always ensure that the shoulder belt is

positioned across the center of the

child’s shoulder. The belt should be

kept away from the child’s neck, but

not so that it could fall off the child’s

shoulder.

●

Follow all installation instructions pro-

vided by the child restraint system

manufacturer.

●

When securing some types of child

restraint systems in rear seats, it may

not be possible to properly use the

seat belts in positions next to the child

restraint without interfering with it or

affecting seat belt effectiveness. Be

sure your seat belt fits snugly across

your shoulder and low on your hips. If it

does not, or if it interferes with the

child restraint, move to a different posi-

tion. Failure to do so may result in

death or serious injury.

●

When installing a child restraint system

in the rear center seat, adjust both seat

cushions to the same position and

align both seatbacks at the same

angle. The seatbacks must be adjusted

to the same angle. Otherwise, the

child restraint system cannot be

securely restrained and this may cause

death or serious injuries in the event of

sudden braking, sudden swerving or

an accident.

■

When installing a booster seat

To prevent the belt from going into ALR

lock mode, do not fully extend the shoul-

der belt. ALR mode causes the belt to

tighten only. This could cause injury or

discomfort to the child. (



P.28)

■

Do not use a seat belt extender

If a seat belt extender is used when

installing a child restraint system, the seat

belt will not securely hold the child

restraint system, which could cause

death or serious injury to the child or

other passengers in the event of sudden

braking, sudden swerving or an accident.

Child restraint system fixed with
a child restraint LATCH anchor

1-2. Child safety

For safety and security

■

When installing in the rear out-
board seats

Install the child restraint system in
accordance to the operation manual
enclosed with the child restraint sys-
tem.

Adjust the seat

If there is a gap between the child seat and

the seatback, adjust the seatback angle

until good contact is achieved.

Remove the head restraint if it inter-
feres with your child restraint sys-
tem. (



P.143)

If the head restraint cannot be removed,

raise it to the uppermost position.

Widen the gap between the seat
cushion and seatback slightly.



With flexible lower attachments

Latch the hooks of the lower
attachments onto the LATCH
anchors.
For owners in Canada:
The symbol on a child restraint sys-

tem indicates the presence of a
lower connector system.

Canada only



With rigid lower attachments

Latch the buckles onto the LATCH
anchors.
For owners in Canada:
The symbol on a child restraint sys-

Content .. 1 2 3 ..
