Lexus RC F (2022 year). Manual in english - page 19

312

7-2. Steps to take in an emergency

screw passing through the tire tread.
• Do not remove the nail or screw

from the tire. Removing the object
may widen the opening and disen-
able emergency repair with the kit.

• To avoid sealant leakage, move the

vehicle until the area of the punc-
ture, if known, is positioned at the
top of the tire.

■

A flat tire that cannot be repaired with

the emergency tire puncture repair kit

In the following cases, the tire cannot be

repaired with the emergency tire puncture

repair kit. Contact your Lexus dealer.

●

When the tire is damaged due to driving

without sufficient air pressure

●

When the tire lost air pressure due to a

crack or damage in the tire sidewall

●

When the tire is visibly separated from

the wheel

●

When the cut or damage to the tread is

0.16 in. (4 mm) long or more

●

When the wheel is damaged

●

When 2 or more sharp objects, such as

nails or screws, have passed through the

tread on a single tire

●

When there is more than one hole or cut

in the damaged tire

●

When the sealant has expired

Wheel nut wrench

Jack handle

Location of the emergency tire puncture repair kit and tools

A
B

313

7-2. Steps to take in an emergency

When trouble

ari

ses

Screwdriver
Emergency tire puncture repair kits
Towing eyelet

Jack

(Use of the jack:



P.324)

: They can be purchased at your Lexus dealer.



Bottle

Hose
Air release cap
Stickers

Emergency tire puncture repair kit components

C
D

E
F

A
B
C

314

7-2. Steps to take in an emergency



Compressor

Compressor switch
Air pressure gauge
Power plug

■

Emergency tire puncture repair kit

●

The sealant has a limited lifespan. The

expiry date is marked on the bottle. The

sealant should be replaced before the

expiry date. Contact your Lexus dealer

for replacement.

●

The sealant stored in the emergency tire

puncture repair kit can be used only once

to temporarily repair a single tire. If the

sealant has been used and needs to be

purchased, contact your Lexus dealer.

The compressor is reusable.

●

The sealant can be used when the outside

temperature is from -40°F (-40°C) to

140°F (60°C).

●

The kit is exclusively designed for size

and type of tires originally installed on

your vehicle. Do not use it for tires that a

different size than the original ones, or for

any other purposes.

●

If the sealant gets on your clothes, it may

stain.

●

If the sealant adheres to a wheel or the

surface of the vehicle body, the stain may

not be removable if it is not cleaned at

once. Immediately wipe away the sealant

with a wet cloth.

●

During operation of the kit, a loud opera-

tion noise is produced. This does not indi-

cate a malfunction.

●

Do not use the emergency tire puncture

repair kit to check or to adjust the tire

pressure.

■

Note for checking the emergency tire

puncture repair kit

Check the sealant expiry date occasionally.

The expiry date is shown on the bottle. Do

not use sealant whose expiry date has

already passed. Otherwise, repairs con-

ducted using the emergency tire puncture

repair kit may not be performed properly.

WARNING

■

Caution while driving

Observe the following precautions.

Failure to do so may cause an accident.

●

The emergency tire puncture repair kit

is made exclusively for your vehicle.

Do not use it on other vehicles.

315

7-2. Steps to take in an emergency

n t

ris

Hold the hook and lift up the lug-
gage mat.

Secure the luggage mat using the
hook.

Take out the emergency tire punc-
ture repair kits.

Remove the valve cap from the
valve of the punctured tire.

Extend the hose. Remove the air
release cap from the hose.

WARNING

●

Do not use the emergency tire punc-

ture repair kit for tires that are a differ-

ent size than the specified ones or for

any other purpose. Doing so may

cause the tires to not be repaired

properly.

■

Precautions for use of the sealant

●

Ingesting the sealant is hazardous to

your health. If you ingest sealant, con-

sume as much water as possible, then

immediately consult a doctor.

●

If sealant gets in eyes or adheres to

skin, immediately wash it off with water.

If discomfort persists, consult a doctor.

Taking out the emergency tire
puncture repair kits

NOTICE

■

To prevent damage to luggage mat

When closing the trunk lid, do not leave

the luggage mat lever hooked onthe

edge of the trunk.

Emergency repair method

316

7-2. Steps to take in an emergency

You will use the air release cap again.

Therefore keep it in a safe place.

Connect the hose to the valve.

Screw the end of the hose clockwise as far

as possible.

Make sure that the compressor
switch is off.

Lift the rubber stopper on the com-
pressor.

Remove the power plug from the
compressor.

Connect the power plug to the
power outlet socket. (



P.226)

Connect the bottle to the compres-
sor.

Make sure that the bottle is securely con-

nected.

Attach the 2 stickers as shown.

Remove any dirt and moisture from the

wheel before attaching the label. If it is

impossible to attach the label, make sure to

tell your Lexus dealer when you have them

repair and replace the tire that sealant is

317

7-2. Steps to take in an emergency

When trouble

ari

ses

injected.

Check the specified tire inflation
pressure.

Tire inflation pressure is specified on the

label as shown. (

Start the engine. (

To inject the sealant and inflate the
tire, turn the compressor switch on.

Inflate the tire until the recom-
mended pressure is reached.

The sealant will be injected and the
pressure will spike to 44 psi (300
kPa, 3.0 kgf/cm

or bar) or 58 psi

(400 kPa, 4.0 kgf/cm

or bar), then

gradually decrease.
The air pressure gauge will display
the actual tire inflation pressure
about 1 minute (15 minutes at low
temperature) after the switch is
turned on.

318

7-2. Steps to take in an emergency

Turn the compressor switch off and then

check the tire inflation pressure. Being

careful not to over inflate, check and

repeat the inflation procedure until the rec-

ommended tire inflation pressure is

reached.
If the tire inflation pressure is still lower than

the recommended level after inflation for

10 minutes (35 minutes at low tempera-

ture) with the switch on, the tire is too dam-

aged to be repaired. Turn the compressor

switch off and contact your Lexus dealer.
If the tire inflation pressure exceeds the

recommended level, let out some air to

adjust the tire inflation pressure. (



P.319,

345)

With the compressor switch off, dis-
connect the hose from the valve on
the tire and then pull out the power
plug from the power outlet socket.

Some sealant may leak when the hose is

removed.

Install the valve cap onto the valve
of the emergency repaired tire.

Attach the air release cap to the
end of the hose.

If the air release cap is not attached, the

sealant may leak and the vehicle may get

dirty.

Temporarily store the bottle in the
trunk while it is connected to the
compressor.

To spread the liquid sealant evenly
within the tire, immediately drive

safely for about 3 miles (5 km)
below 50 mph (80 km/h).

After driving, stop your vehicle in a
safe place on a hard, flat surface
and reconnect the compressor.

Turn the compressor switch on and
wait for several seconds, then turn it
off. Check the tire inflation pres-
sure.

If the tire inflation pressure is below
19 psi (130 kPa, 1.3 kgf/cm

or bar):

The puncture cannot be repaired.
Contact your Lexus dealer.
If the tire inflation pressure is
between 19 psi (130 kPa, 1.3
kgf/cm

or bar) and a point below

the recommended level: The tire
can be repaired. Proceed to step

If the tire inflation pressure is at the
recommended level: Proceed to

319

7-2. Steps to take in an emergency

n t

ris

step

Turn the compressor switch on to
inflate the tire until the recom-
mended tire inflation pressure is
reached. Drive for about 3 miles (5
km) and then perform step

Attach the air release cap to the
end of the hose.

If the air release cap is not attached, the

sealant may leak and the vehicle may get

dirty.

Store the bottle in the trunk while it
is connected to the compressor.

Taking precautions to avoid sud-
den braking, sudden acceleration
and sharp turns, drive carefully at
under 50 mph (80 km/h) to your

Lexus dealer that is less than 62

miles (100 km) away for tire repair
or replacement.

■

After a tire is repaired with the emer-

gency tire puncture repair kit

●

The tire pressure warning valve and

transmitter should be replaced.

●

Even if the tire inflation pressure is at the

recommended level, the tire pressure

warning light may come on/flash.

■

If the tire is inflated to more than the

recommended level

Disconnect the hose from the valve.

Install the air release cap to the end of

the hose and push the protrusion on the

air release cap into the valve to let some

air out.

Disconnect the hose from the valve,

remove the air release cap from the

hose and then reconnect the hose.

Turn the compressor switch on and wait

for several seconds, then turn it off.

Check that the air pressure indicator

shows the recommended level.

(



P.345)

If the air pressure is lower than the rec-

ommended level, turn the compressor

switch on again and repeat the inflation

procedure until the recommended

pressure is reached.

WARNING

■

When fixing the flat tire

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Stop your vehicle in a safe and flat

area.

●

Do not touch the wheels or the area

around the brakes immediately after

the vehicle has been driven.

After the vehicle has been driven, the

wheels and the area around the brakes

may be extremely hot. Touching these

areas with hands, feet or other body

parts may result in burns.

●

Connect the valve and hose securely

with the tire installed on the vehicle.

• If the hose is not properly connected to

the valve, air leakage may occur or

sealant may be sprayed out.

320

7-2. Steps to take in an emergency

WARNING

• If the hose comes off the valve while

inflating the tire, there is a risk that the

hose will move abruptly due to air

pressure.

• After inflation of the tire has com-

pleted, the sealant may splatter when

the hose is disconnected or some air is

let out of the tire.

●

Follow the operation procedure to

repair the tire. If the procedure is not

followed, the sealant may spray out.

●

Keep back from the tire while it is

being repaired, as there is a chance of

it bursting while the repair operation is

being performed. If you notice any

cracks or deformation of the tire, turn

off the compressor switch and stop the

repair operation immediately.

●

The kit may overheat if operated for a

long period of time. Do not operate

the compressor continuously for more

than 35 minutes.

●

Parts of the kit become hot during

operation. Be careful handling the kit

during and after operation. Do not

touch the metal part around the con-

necting area between the bottle and

compressor. It will be extremely hot.

●

Do not attach the vehicle speed warn-

ing sticker to an area other than the

one indicated. If the sticker is attached

to an area where an SRS airbag is

located, such as the pad of the steering

wheel, it may prevent the SRS airbag

from operating properly.

■

Driving to spread the liquid sealant

evenly

●

Drive the vehicle carefully at a low

speed. Be especially careful when

turning and cornering.

●

If the vehicle does not drive straight or

you feel a pull through the steering

wheel, stop the vehicle and check the

following:

• Tire condition. The tire may have sepa-

rated from the wheel.

• Tire inflation pressure. If tire inflation

pressure is 19 psi (130 kPa, 1.3 kgf/cm

or bar) or below, this may indicate

severe tire damage.

NOTICE

■

When performing an emergency

repair

●

Perform the emergency repair with-

out removing the nail or screw that has

punctured the tread of the tire. If the

object that has punctured the tire is

removed, repair by the emergency tire

puncture repair kit may not be possi-

ble.

●

The kit is not waterproof. Make sure

that the kit is not exposed to water,

such as when it is being used in the

rain.

●

Do not put the kit directly onto dusty

ground such as sand at the side of the

road. If the kit vacuums up dust etc., a

malfunction may occur.

●

Make sure to stand the kit with the bot-

tle vertical. The kit cannot work prop-

erly if it is laid on its side.

■

Handling the emergency tire punc-

ture repair kit

●

The compressor power source should

be 12 V DC suitable for vehicle use.

Do not connect the compressor to any

other source.

●

If gasoline splatters on the kit, the kit

may deteriorate. Take care not to allow

gasoline to contact it.

321

7-2. Steps to take in an emergency

n t

ris



Stop the vehicle in a safe place on a
hard, flat surface.



Set the parking brake.



Shift the shift lever to P.



Stop the engine.



Turn on the emergency flashers.
(



P.292)

NOTICE

●

Store the emergency tire puncture

repair kit in the trunk. The kit may be

thrown around during sudden braking

and so forth, damaging the kit.

●

Store the kit in its assigned place out of

reach of children.

●

Do not disassemble or modify the kit.

Do not subject parts such as the air

pressure indicator to impacts. This may

cause a malfunction.

■

To avoid damage to the tire pressure

warning valves and transmitters

When a tire is repaired with liquid seal-

ants, the tire pressure warning valve and

transmitter may not operate properly. If a

liquid sealant is used, contact your Lexus

dealer as soon as possible. After use of

liquid sealant, make sure to replace the

tire pressure warning valve and transmit-

ter when repairing or replacing the tire.

(



P.275)

If you have a flat tire (vehi-
cles with a spare tire)

Your vehicle is equipped with a
spare tire. The flat tire can be
replaced with the spare tire.

For details about tires:



P.271

WARNING

■

If you have a flat tire

Do not continue driving with a flat tire.

Driving even a short distance with a flat

tire can damage the tire and the wheel

beyond repair, which could result in an

accident.

Before jacking up the vehicle

322

7-2. Steps to take in an emergency

Spare tire
Tool bags
Wheel nut wrench
Towing eyelet
Screwdriver
Jack handle
Jack

Location of the spare tire, jack and tools

WARNING

■

Using the tire jack

Observe the following precautions.

Improper use of the tire jack may cause

the vehicle to suddenly fall off the jack,

leading to death or serious injury.

●

Do not use the tire jack for any pur-

pose other than replacing tires or

installing and removing tire chains.

●

Only use the tire jack that comes with

this vehicle or a jack designed for this

vehicle, purchased from a lexus dealer,

when replacing a flat tire.

Do not use it on other vehicles, and do

not use other tire jacks for replacing

tires on this vehicle.

●

Put the jack properly in its jack point.

●

Do not put any part of your body under

the vehicle while it is supported by the

jack.

323

7-2. Steps to take in an emergency

n t

ris

Remove the luggage mat.

Take out the jack.

For tightening

For loosening

If the jack is too tightly installed to be
removed by hand, insert a tool, such as the
screwdriver included with the vehicle, into
the hole of the jack (portion

) and

loosen the jack.

Remove the luggage mat.

Loosen the center fastener that
secures the spare tire.

If the center fastener cannot be turned by

hand, use the wheel nut wrench that is

stored in the trunk. (To secure the tire,

tighten the center fastener by hand. Do not

use the wrench or other tools.)

WARNING

●

Do not start the engine or drive the

vehicle while the vehicle is supported

by the jack.

●

Do not raise the vehicle while some-

one is inside.

●

When raising the vehicle, do not put an

object on or under the jack.

●

Do not raise the vehicle to a height

greater than that required to replace

the tire.

●

Use a jack stand if it is necessary to get

under the vehicle.

●

When lowering the vehicle, make sure

that there is no-one near the vehicle. If

there are people nearby, warn them

vocally before lowering.

Taking out the jack

NOTICE

■

To prevent damage to luggage mat

When closing the trunk lid, do not leave

the luggage mat lever hooked onthe

edge of the trunk.

Taking out the spare tire

324

7-2. Steps to take in an emergency

Chock the tires.

Slightly loosen the wheel nuts (one
turn).

Turn the tire jack portion by
hand until the notch of the jack is in
contact with the jack point.

The jack point guides are located under

the rocker panel. They indicate the jack

point positions.

Raise the vehicle until the tire is
slightly raised off the ground.

Remove all the wheel nuts and the
tire.

When resting the tire on the ground, place

the tire so that the wheel design faces up to

avoid scratching the wheel surface.

WARNING

■

When storing the spare tire

Be careful not to catch fingers or other

body parts between the spare tire and

the body of the vehicle.

Replacing a flat tire

Flat tire

Wheel chock posi-

tions

Front left-hand side

Behind the rear
right-hand side tire

Front right-hand
side

Behind the rear
left-hand side tire

Rear left-hand side

In front of the front
right-hand side tire

Rear right-hand side

In front of the front
left-hand side tire

325

7-2. Steps to take in an emergency

n t

ris

Remove any dirt or foreign matter
from the wheel contact surface.

If foreign matter is on the wheel contact

surface, the wheel nuts may loosen while

the vehicle is in motion, causing the tire to

come off.

Install the spare tire and loosely
tighten each wheel nut by hand by
approximately the same amount.

When replacing an aluminum wheel with

an aluminum wheel, turn the wheel nuts
until the washers

come into contact

with the disc wheel

WARNING

■

Replacing a flat tire

●

Do not touch the disc wheels or the

area around the brakes immediately

after the vehicle has been driven.

After the vehicle has been driven the

disc wheels and the area around the

brakes will be extremely hot. Touching

these areas with hands, feet or other

body parts while changing a tire, etc.

may result in burns.

●

Failure to follow these precautions

could cause the wheel nuts to loosen

and the tire to fall off, resulting in death

or serious injury.

• Never use oil or grease on the wheel

bolts or wheel nuts.Oil and grease may

cause the wheel nuts to be excessively

tightened, leading to bolt or disc wheel

damage. In addition, the oil or grease

can cause the wheel nuts to loosen and

the wheel may fall off, causing a serious

accident. Remove any oil or grease

from the wheel bolts or wheel nuts.

• Have the wheel nuts tightened with a

torque wrench to 76 ft•lbf (103 N•m,

10.5 kgf•m) as soon as possible after

changing wheels.

• Do not attach a heavily damaged

wheel ornament, as it may fly off the

wheel while the vehicle is moving.

• When installing a tire, only use wheel

nuts that have been specifically

designed for that wheel.

• If there are any cracks or deformations

in the bolt screws, nut threads or bolt

holes of the wheel, have the vehicle

inspected by your Lexus dealer.

NOTICE

■

Precaution for CCB (Carbon

Ceramic Brake) discs (if equipped)

Do not subject the carbon ceramic brake

disc to strong impact.
It the carbon ceramic brake disc has

been subjected to a strong impact, even

if there is no obvious damage, have the

vehicle inspected by your Lexus dealer.

Installing the spare tire

326

7-2. Steps to take in an emergency

Lower the vehicle.

Firmly tighten each wheel nut two
or three times in the order shown in
the illustration.

Tightening torque:

76 ft•lbf (103 N•m, 10.5 kgf•m)

Stow the flat tire, tire jack and all
tools.

■

The spare tire

●

Use the spare tire temporarily, and only in

an emergency.

●

Make sure to check the tire inflation pres-

sure of the spare tire. (



P.345)

■

When using the spare tire

As the spare tire is not equipped with a tire

pressure warning valve and transmitter, low

inflation pressure of the spare tire will not be

indicated by the tire pressure warning sys-

tem. Also, if you replace the spare tire after

the tire pressure warning light comes on,

the light remains on.

: If equipped

■

When the spare tire is equipped

The vehicle becomes lower when driving

with the spare tire compared to when driv-

ing with standard tires.

WARNING

■

When using the spare tire

●

Remember that the spare tire provided

is specifically designed for use with

your vehicle. Do not use your spare

tire on another vehicle.

●

Do not use more than one spare tire

simultaneously.

●

Replace the spare tire with a standard

tire as soon as possible.

●

Avoid sudden acceleration, abrupt

steering, sudden braking and shifting

operations that cause sudden engine

braking.

■

When the spare tire is attached

The vehicle speed may not be correctly

detected, and the following systems may

not operate correctly:

• ABS & Brake assist

• VSC

• TRAC

• Dynamic radar cruise control

• PCS

• EPS

• Adaptive Variable Suspension System

• LDA (Lane Departure Alert with

steering control)

• VDIM (Vehicle Dynamics Integrated

Management)

• Tire pressure warning system

• Lexus parking assist monitor

• Intuitive parking a

ssist (if equipped)

• Navigation system (if equipped)

327

7-2. Steps to take in an emergency

n t

ris

One of the following may be the cause
of the problem:



There may not be sufficient fuel in
the vehicle’s tank.
Refuel the vehicle.



The engine may be flooded.
Try to restart the engine again fol-
lowing correct starting procedures.
(



P.128)



There may be a malfunction in the
engine immobilizer system.
(



P.57)

One of the following may be the cause
of the problem:



The battery may be discharged.
(



P.332)



The battery terminal connections
may be loose or corroded.
(



P.269)

WARNING

■

Speed limit when using the spare tire

Do not drive at speeds in excess of 50

mph (80 km/h) when a spare tire is

installed on the vehicle.
The spare tire is not designed for driving

at high speeds. Failure to observe this

precaution may lead to an accident caus-

ing death or serious injury.

■

After using the tools and jack

Before driving, make sure all the tools

and jack are securely in place in their

storage location to reduce the possibility

of personal injury during a collision or

sudden braking.

NOTICE

■

Driving with tire chains and the spare

tire

Do not fit tire chains to the spare tire.

Tire chains may damage the vehicle body

and adversely affect driving perfor-

mance.

■

When replacing the tires

When removing or fitting the wheels,

tires or the tire pressure warning valve

and transmitter, contact your Lexus

dealer as the tire pressure warning valve

and transmitter may be damaged if not

handled correctly.

■

Precaution for CCB (Carbon

Ceramic Brake) discs (if equipped)



P.325

If the engine will not start

If the engine will not start even
though correct starting procedures
are being followed (



P.128), con-

sider each of the following points:

The engine will not start even
though the starter motor oper-
ates normally.

The starter motor turns over
slowly, the interior lights and
headlights are dim, or the horn
does not sound or sounds at a low
volume.

Content .. 17 18 19 20 ..
