Lexus NX350 (2022 year). Manual in english - page 33

Rotating the tires

To equalize tire wear and extend tire life, Lexus recommends that tire rotation be
performed at the same interval as tire inspection.
Rotate the tires as shown in the illustration.
Make sure to perform wheel position registration procedure after rotating the tires.

Front

8-5. Tire maintenance

547

Maintenance and car

Wheels

If a wheel is bent, cracked or heavily corroded, it should be replaced. Otherwise,
the tire may separate from the wheel, causing a loss of handling control.

Wheel selection

When replacing wheels, care should be taken to ensure that they are equivalent to
those removed in load capacity, diameter, rim width and inset

Replacement wheels are available at your Lexus dealer.
Lexus does not recommend using the following:

●

Wheels of different sizes or types

●

Used wheels

●

Bent wheels that have been straightened

INFORMATION

■

When replacing wheels

The wheels of your vehicle are equipped with tire pressure warning valves and transmit-
ters that allow the tire pressure warning system to provide advance warning in the event
of a loss in tire inflation pressure.
Whenever wheels are replaced, tire pressure warning valves and transmitters must be
installed.

WARNING

■

When replacing wheels

●

Do not use wheels that are a different size from those recommended in the Owner’s
Manual, as this may result in a loss of handling control.

●

Never use an inner tube in a leaking wheel which is designed for a tubeless tire. Doing
so may result in an accident, causing death or serious injury.

●

Use the correct wheel bolts for the wheels to be installed.
For details, contact your Lexus dealer.

■

Wheel bolts

Observe the following precautions to reduce the risk of death or serious injury:

●

Do not over tighten.

●

Never use oil or grease on the wheel bolts. Oil and grease may cause the wheel bolts
to be excessively tightened, leading to bolt or disc wheel damage. In addition, the oil

*1 :

Conventionally referred to as offset.

8-5. Tire maintenance

548

WARNING

or grease can cause the wheel bolts to loosen and the wheel may fall off, causing a
serious accident. Remove any oil or grease from the wheel bolts.

●

If there are any cracks or deformations in the wheel bolts, or if the surface treatment
becomes worn, have the wheel bolts replaced at your Lexus dealer. Failure to follow
these precautions could cause the wheel bolts to loosen and the tire to fall off, resulting
in death or serious injury.

■

Use of defective wheels prohibited

Do not use cracked or deformed wheels.
Doing so could cause the tire to leak air during driving, possibly causing an accident.

NOTICE

■

Replacing tire pressure warning valves and transmitters

●

Because tire repair or replacement may affect the tire pressure warning valves and
transmitters, make sure to have tires serviced by your Lexus dealer or other qualified
service shop. In addition, make sure to purchase your tire pressure warning valves and
transmitters at your Lexus dealer.

●

Ensure that only genuine Lexus wheels are used on your vehicle.
Tire pressure warning valves and transmitters may not work properly with non-genuine
wheels.

Aluminum wheel precautions

Observe the following precautions when handling the aluminum wheels.

●

Use only Lexus wheel bolts and wrenches designed for use with your aluminum
wheels.

●

When rotating, repairing or changing your tires, check that the wheel bolts are
still tight after driving 621 miles (1000 km).

●

Be careful not to damage the aluminum wheels when using tire chains.

●

Use only Lexus genuine balance weights or equivalent and a plastic or rubber
hammer when balancing your wheels.

8-5. Tire maintenance

549

Maintenance and car

Headlight aim

Vertical movement adjusting bolts

▶

Type A

Adjustment bolt A

Adjustment bolt B

▶

Type B

Adjustment bolt A

Adjustment bolt B

Checking the headlight aim

Before checking the headlight aim, confirm the following.

●

The vehicle has a full tank of gasoline and the area around the headlight is not
deformed.

●

The vehicle is parked on level ground.

●

The tire inflation pressure is at the specified level.

●

Someone is sitting in the driver's seat.

●

The vehicle has been bounced several times after being parked.

8-5. Tire maintenance

550

Adjusting the headlight aim

Using a Phillips-head screwdriver, turn bolt A
in either direction. Remember the turning di-
rection and the number of turns.

Turn bolt B the same number of turns and in
the same direction as step 1.

If the headlight cannot be adjusted using this pro-
cedure, take the vehicle to your Lexus dealer to
adjust the headlight aim.

▶

Type A

▶

Type B

▶

Type A

▶

Type B

8-5. Tire maintenance

551

Maintenance and car

When trouble arises

9-1. What to do if a problem occurs

while driving

What to do if a problem oc-

curs while driving..................

555

9-2. If a warning light illumi-

nates/flashes or a warning
message is displayed on the
meter

If a warning light turns on/

flashes........................................

559

If a warning message is dis-

played........................................

572

9-3. If the engine will not start

When the engine will not

start even though the
starter operates....................

585

When the starter operates

slowly and the engine can-
not be started........................

586

When the starter does not

operate and the engine
cannot be started .................

587

When the interior lights or

headlights are dim and the
engine cannot be started .

589

When the interior lights or

headlights do not illumi-
nate and the engine can-
not be started.........................

595

When the horn sounds at a

low volume and the engine
cannot be started .................

596

When the horn does not

sound and the engine
cannot be started .................

597

9-4. If a tire is flat

Repairing a tire with the

emergency tire puncture
repair kit (vehicles with an
emergency tire puncture
repair kit).................................

598

Replacing a tire with a spare

tire (vehicles with a spare
tire) ...............................................

611

If you get a flat front tire on a

snowy or icy road (vehi-
cles with a spare tire) ..........

622

Precautions for when you

have a flat tire (vehicles
with run-flat tires)..................

623

9-5. If a door cannot be opened or

locked

If a key has been lost...............

624

When the doors/windows/

moon roof cannot be op-
erated using an electronic
key...............................................

625

If a door cannot be opened

using the door opener
switch.........................................

634

If the rear doors cannot be

opened from the inside ......

637

If the back door cannot be

opened.....................................

638

553

When tr

ouble arises

9-6. If the moon roof or electronic

sunshade does not operate
correctly

If the moon roof does not

operate correctly.................

640

If the panoramic moon roof/

electronic sunshade does
not operate correctly...........

641

9-7. If the rear seats does not oper-

ate correctly

Initialize rear seats (Vehi-

cles with a power back
door)..........................................

642

9-8. If refueling cannot be per-

formed

If the fuel filler door cannot

be opened ..............................

643

9-9. If an indicator on an interior fea-

ture illuminates or flashes

When the wireless charger

operation indicator light
(on the charging tray)
flashes........................................

644

9-10. If the vehicle cannot move

When the engine can be

started but the vehicle
does not move ......................

646

If the transmission makes

abnormal sounds..................

647

Towing with a tow truck........

648

Using a flatbed truck..............

652

Towing with another vehicle

......................................................

653

Getting unstuck from mud,

sand, or snow..........................

656

9-11. If you think something is wrong

If a vehicle abnormality is

found..........................................

657

If abnormal sounds are

emitted from the vehicle...

658

If the vehicle behaves ab-

normally....................................

659

9-12. Items to check before contact-

ing a dealership

The steering wheel cannot

be turned after the engine
is stopped................................

660

If the windows do not open

or close by operating the
power window switches......

661

The engine switch is turned

off automatically....................

663

If your vehicle overheats......

664

If electrical components

cannot be used or do not
operate when a switch is
operated..................................

668

If a light does not illuminate

......................................................

669

554

What to do if a problem occurs while driving

Using the emergency flashers to warn other drivers

Use the emergency flashers to inform other drivers of the presence of your vehicle
when it is stopped on the road, such as if the vehicle has broke down.
Press the switch.

All the turn signal lights will flash. To turn them off,
press the switch once again.

INFORMATION

■

Emergency flashers

●

If the emergency flashers are used for a long time with the engine stopped, the battery
may become discharged.

●

If any of the SRS airbags deploy (inflate) or in the event of a strong rear impact, the
emergency flashers will turn on automatically.
The emergency flashers will turn off automatically after operating for approximately
20 minutes. To manually turn the emergency flashers off, press the switch twice. (The
emergency flashers may not turn on automatically depending on the force of the
impact and conditions of the collision.)

Stopping the vehicle in an emergency

Stop the vehicle using the following procedure only in an emergency, such as if it
becomes impossible to stop the vehicle in the normal way:

WARNING

■

If the engine has to be stopped while driving

Power assist for the brakes and steering wheel will be lost, making the brake pedal harder
to depress and the steering wheel heavier to turn. Decelerate as much as possible before
stopping the engine.

Steadily step on the brake pedal with both feet and firmly depress it.

Do not pump the brake pedal repeatedly as this will increase the effort required to slow
the vehicle.

9-1. What to do if a problem occurs while driving

555

When tr

ouble arises

Change the shift position to N.

●

If the shift position is changed to N:
After slowing down, stop the vehicle in a safe place by the road.
Stop the engine.

●

If the shift position cannnot be changed to N:
Keep depressing the brake pedal with both feet to reduce vehicle speed as much as
possible.
To stop the engine, press and hold the engine switch for 2 consecutive seconds or
more, or press it briefly 3 times or more in succession.

Stop the vehicle in a safe place by the road.

WARNING

To restart the engine after performing an emergency shutdown, change the shift
position to N and then press the engine switch.

If the vehicle is submerged or water on the road is rising

This vehicle is not designed to be able to drive on roads that are deeply flooded
with water. Do not drive on roads where the roads may be submerged or the water
may be rising. It is dangerous to remain in the vehicle, if it anticipated that the
vehicle will be flooded or set a drift.
Remain calm and follow the following.

●

If the door can be opened, open the door and exit the vehicle.

●

If the door cannot be opened, open the window using the power window switch
and ensure an escape route.

●

If the window can be opened, exit the vehicle through the window.

●

If the door and window cannot be opened due to the rising water, remain calm,
wait until the water level inside the vehicle rises to the point that the water
pressure inside of the vehicle equals the water pressure outside of the vehicle
and then open the door after waiting for the rising water to enter the vehicle, and
exit the vehicle.

9-1. What to do if a problem occurs while driving

556

When the outside water level exceeds half the height of the door, the door cannot be
opened from the inside due to water pressure.

INFORMATION

■

Water level exceeds the floor

When the water level exceeds the floor and time has passed, the electrical equipment will
get damaged, the power windows will not operate, the engine stop, and the vehicle may
not be able to get moving.

■

Using an emergency escape hammer

Laminated glass

is used in the windshield and the windows on this vehicle. Laminated

glass cannot be shattered with an emergency hammer

■

How to distinguish laminated glass

When looking from the cross-sectional view point, laminated glass is two sheets of glass
pasted together.

Laminated glass

Tempered glass

WARNING

■

Caution while driving

Do not drive on roads where the roads may be submerged or the water may be rising.
Otherwise the vehicle may be damaged and cannot move, as well as become flooded
and set a drift, which may lead to death.

Operation of the fuel pump shut off system

When a certain level of impact is detected by an impact sensor due to a collision
and an airbag deploys or the engine is stopped, the fuel pump shut off system
operates to stop the supply of fuel and minimize the risk of fuel leakage.

* :

If equipped

*1 :

Contact your Lexus dealer or aftermarket accessory manufacturer for further infor-

mation about an emergency hammer.

9-1. What to do if a problem occurs while driving

557

When tr

ouble arises

Restarting the engine

NOTICE

Before starting the engine, make sure to thoroughly check the area under the vehicle. If
leaked fuel is found on the ground, the fuel system is damaged and needs to be repaired.
In this situation, do not restart the engine.

Perform the following procedure to restart the engine after the fuel pump shut off
system has operated.

Turn the engine switch to ACC or OFF.

Restart the engine.

9-1. What to do if a problem occurs while driving

558

If a warning light illuminates/flashes or a warning message is displayed on the meter

If a warning light turns on/flashes

Calmly perform the following actions if any of the warning lights comes on or
flashes. If a light comes on or flashes, but then goes off, this does not necessarily
indicate a malfunction in the system. However, if this continues to occur, have the
vehicle inspected by your Lexus dealer.

INFORMATION

■

Warning buzzer

In some cases, the buzzer may not be heard due to being in a noisy location or audio
sound.

Brake system warning light (warning buzzer)

Condition

Cause / Remedy

(U.S.A.)

(red)

(Canada)

Indicates that:

●

The brake fluid level is low; or

●

The brake system is malfunctioning

Immediately stop the vehicle and contact your Lexus dealer.
Continuing to drive the vehicle may be dangerous.

WARNING

If both the ABS and the brake system warning lights remain on, stop your vehicle in a safe
place immediately and contact your Lexus dealer.
The vehicle will become extremely unstable during braking, and the ABS system may fail,
which could cause an accident resulting in death or serious injury.

Brake system warning light (warning buzzer)

Condition

Cause / Remedy

(yellow)

Indicates a malfunction in the electric parking brake
Have the vehicle checked by your Lexus dealer immediately.

WARNING

9-2. If a warning light illuminates/flashes or a warning message is displayed on the meter

559

When tr

ouble arises
