Lexus NX350 (2022 year). Manual in english - page 13

▶

Type A

Off

Intermittent operation

Normal operation

▶

Type B

Off

Intermittent operation

Normal operation

Using the rear washer

NOTICE

If a washer nozzle is blocked, contact your Lexus dealer.
Do not try to clear it with a pin or other object. The nozzle will be damaged.

3-3. Driving in the rain

219

Driving accor

ding to the conditions

Push the lever.

The rear wiper and washer will operate.
The washer will automatically operate and clean
the camera for Lexus parking assist monitor.
The rear wiper will automatically operate a cou-
ple of times after the rear washer operates.

NOTICE

If washer fluid does not spray, do not operate the switch continuously as doing so may
damage the rear washer fluid pump.

INFORMATION

■

The rear window wiper and washer can be operated when

The engine switch is in ON.

■

If no windshield washer fluid sprays

If there is washer fluid in the washer fluid tank, check if the washer nozzles are blocked.

■

Using the voice control system

The rear washer can be operated using the voice control system. (Operation is possible
only when the vehicle is stopped.)
For details, refer to the .

* :

If equipped

3-3. Driving in the rain

220

Driving when the windows or mirrors are fogged up

Defog the windshield

Defoggers are used to defog the windshield and front side windows.

WARNING

●

Do not use the windshield defogger in extremely humid areas when the air condition-
ing system is set to a low temperature.
The difference between the temperature of the outside air and that of the windshield
can cause the outer surface of the windshield to fog up, blocking your vision.

●

Do not place anything on the instrument panel which may cover the air outlets.
Otherwise, air flow may be obstructed, preventing the windshield defoggers from
defogging.

Press the windshield defogger switch.

The dehumidification function will operate and the air flow will increase.
Set the outside/recirculated air mode switch to outside air mode if the recirculated air
mode is used. (It may switch automatically.)
To defog the windshield and the side windows quickly, turn the air flow and temperature up.
To return to the previous mode, press the front windshield defogger switch again when the
windshield is defogged.

3-4. Driving when the windows or mirrors are fogged up

221

Driving accor

ding to the conditions

INFORMATION

■

Fogging up of the windows

●

The windows will easily fog up when the humidity in the vehicle is high.
Pressing “A/C” button or selecting “A/C” will dehumidify the air from the outlets and
defog the windshield effectively.

●

If you turn “A/C” off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

3-4. Driving when the windows or mirrors are fogged up

222

Defog the rear window

Press the rear windshield and outside rear view mirror defogger switch.
The rear window defogger and outside rear view mirror defoggers will operate and defog
the rear window and outside rear view mirrors.
The defoggers will automatically turn off after a period of time.

WARNING

Do not touch the surface of the outside rear view mirrors when the rear window
defogger and outside rear view mirror defoggers are operating, as the surface of the
mirrors will become extremely hot and may cause burns.

3-4. Driving when the windows or mirrors are fogged up

223

Driving accor

ding to the conditions

Defog the outside rear view mirrors

Press the rear windshield and outside rear view mirror defogger switch.

The rear window defogger and outside rear view mirror defoggers will operate and defog
the rear window and outside rear view mirrors.
The defoggers will automatically turn off after a period of time.

WARNING

3-4. Driving when the windows or mirrors are fogged up

224

Driving when it is cold

Preparing for cold weather

Carry out the necessary preparations and inspections before driving the vehicle in
cold weather. Always drive the vehicle in a manner appropriate to the prevailing
weather conditions.

Necessary inspection items

●

Use fluids that are appropriate to the prevailing outside temperatures.

•

Engine oil

•

Engine coolant

•

Washer fluid

●

Have a service technician inspect the condition of the battery.

Mounting winter tires

Have the vehicle fitted with four winter tires.
Ensure that all of the tires are the same size and brand.

WARNING

Observe the following precautions when winter tires are mounted to the vehicle.
Failure to do so may lead to loss of control of the vehicle.

●

Use tires of the specified size.

●

Maintain the recommended level of air pressure.

●

Do not drive in excess of 75 mph (120 km/h), regardless of the type of winter tires
mounted.

●

When using winter tires, mount them to all four wheels.

NOTICE

When having winter tires repaired or replaced, contact your Lexus dealer or a legitimate
tire retailer.
This is because the removal and mounting of winter tires affects the operation of the tire
pressure warning valves and transmitters.

When using tire chains

Install the tire chains to the front two tires.

Make sure to use tire chains which match the tire size.

*1 :

Tire chains cannot be mounted on 235/50R20 tires.

3-5. Driving when it is cold

225

Driving accor

ding to the conditions

INFORMATION

Observe the following precautions when installing, removing, and handling tire chains:

●

Install and remove tire chains in a safe location.

●

Install tire chains to the front tires only.
Do not install tire chains to the rear tires.

●

Install tire chains following the instructions provided with the tire chains.

●

Install tire chains to the front tires as tightly as possible. Retighten the chains after
driving 1/4 - 1/2 mile (0.5 - 1.0 km).

WARNING

Observe the following precautions when tire chains are installed to the vehicle.
Failure to do so may lead to the vehicle not being able to be driven safely.

●

Do not drive in excess of the speed limit specified for the tire chains being used, or 30
mph (50 km/h), whichever is lower.

●

Avoid driving on bumpy road surfaces or over potholes.

●

Avoid sudden acceleration, abrupt steering, sudden braking and shifting operations
that cause sudden engine braking.

●

Slow down sufficiently before entering a curve to ensure that vehicle control is
maintained.

●

Do not use LTA (Lane Tracing Assist).

●

Do not use LDA (Lane Departure Alert).

NOTICE

■

Fitting tire chains

The tire pressure warning valves and transmitters may not function correctly when tire
chains are fitted.

■

Selecting tire chains

Use the correct tire chain size when mounting the tire chains. Chain size is
regulated for each tire size.

●

Vehicles with 235/60R18 tires

3-5. Driving when it is cold

226

Side chain (0.12 in. [3 mm] in diameter)

Side chain (0.39 in. [10 mm] in width)

Side chain (0.98 in. [25 mm] in length)

Cross chain (0.16 in. [4 mm] in diameter)

Cross chain (0.55 in. [14 mm] in width)

Cross chain (0.98 in. [25 mm] in length)

●

Vehicles with 235/50R20 tires
Tire chains cannot be mounted on the 235/50R20 tires.
Snow tires should be used instead.

■

Regulations on the use of tire chains

Regulations regarding the use of tire chains vary depending on location and type of
road. Always check local regulations before installing chains.

3-5. Driving when it is cold

227

Driving accor

ding to the conditions

Cold weather driving tips

Things to check before driving in cold weather

Perform the following according to the driving conditions:

●

Do not try to forcibly open a window or move a wiper that is frozen. Pour warm
water over the frozen area to melt the ice. Wipe away the water immediately to
prevent it from freezing.

●

To ensure proper operation of the climate control system fan, remove any snow
that has accumulated on the air inlet vents in front of the windshield.

●

Check for and remove any excess ice or snow that may have accumulated on
the exterior lights, vehicle’s roof, chassis, around the tires or on the brakes.

●

Remove any snow or mud from the bottom of your shoes before getting in the
vehicle.

Precautions for driving in cold weather

Accelerate the vehicle slowly, keep a safe distance between you and the vehicle
ahead, and drive at a reduced speed suitable to road conditions.

Precautions for parking in cold weather

●

Turn automatic mode of the parking brake off. Otherwise, the parking brake
may freeze and not be able to be released automatically.
Also, avoid using the following as the parking brake may operate automatically,
even if automatic mode is off.

•

Brake hold system

●

Park the vehicle and shift the shift position to P without setting the parking
brake. The parking brake may freeze up, preventing it from being released. If
the vehicle is parked without setting the parking brake, make sure to block the
wheels.

Failure to do so may be dangerous because it may cause the vehicle to move unexpect-
edly, possibly leading to an accident.

●

When the parking brake is in automatic mode, release the parking brake after
change the shift position to P.

●

If the vehicle is parked without setting the parking brake, confirm that the shift
lever cannot be moved out of P.

●

Park the vehicle and change the shift podition to P without setting the parking
brake.

3-5. Driving when it is cold

228

If the vehicle is parked without setting the parking brake, make sure to block the
wheels. Failure to do so may be dangerous because it may cause the vehicle to
move unexpectedly, possibly leading to an accident.

●

If the vehicle is left parked with the brakes damp in cold temperatures, there is a
possibility of the brakes freezing.

INFORMATION

■

Linked mirror function when reversing

When used in cold weather during reverse driving, the door mirror could be frozen and
may not automatically point the mirror surface downward. In this event, remove any ice
and snow from the mirror surface.

Warming the windshield to allow frozen wipers to be moved

Use the windshield wiper de-icer to help prevent the windshield wiper blades from
freezing to the windshield.
Select the [Deicer] switch on the option screen.

The windshield wiper de-icer will automatically turn off after a period of time.

WARNING

Do not touch the lower part of the windshield or parts along the front pillars when the
windshield wiper de-icer is on, as they will be hot and may cause burns.

* :

If equipped

3-5. Driving when it is cold

229

Driving accor

ding to the conditions

Driving when in the fog or on a mountain road and visibility is poor

Fog light illumination

When driving in inclement weather, such as in rain and fog, turn on the front fog
lights to ensure forward visibility.

Using the fog lights

NOTICE

To prevent battery discharge, do not leave the lights on longer than necessary with the
engine stopped.

Turns the front fog lights off

Turns the front fog lights on

INFORMATION

■

Fog lights can be used when

The low beam headlights are on.

3-6. Driving when in the fog or on a mountain road and visibility is poor

230

Sounding the horn

Press on or close to the

mark.

3-6. Driving when in the fog or on a mountain road and visibility is poor

231

Driving accor

ding to the conditions

Utility vehicle precautions

This vehicle belongs to the utility vehicle class, which has higher ground clearance
and narrower tread in relation to the height of its center of gravity.

Utility vehicle feature

●

Specific design characteristics give it a higher center of gravity than ordinary
passenger cars. This vehicle design feature causes this type of vehicle to be
more likely to rollover. Utility vehicles have a significantly higher rollover rate
than other types of vehicles.

●

An advantage of the higher ground clearance is a better view of the road
allowing you to anticipate problems.

●

It is not designed for cornering at the same speeds as ordinary passenger
cars any more than low-slung sports cars designed to perform satisfactorily
under off-road conditions. Therefore, sharp turns at excessive speeds may cause
rollover.

WARNING

■

Utility vehicle precautions

Always observe the following precautions to minimize the risk of death or serious injury
or damage to your vehicle:

●

In a rollover crash, an unbelted person is significantly more likely to die than a person
wearing a seat belt. Therefore, the driver and all passengers should always fasten their
seat belts.

●

Avoid sharp turns or abrupt maneuvers, if at all possible. Failure to operate this vehicle
correctly may result in loss of control or vehicle rollover causing death or serious
injury.

●

Loading cargo on the roof luggage carrier (if equipped) will make the center of the
vehicle gravity higher. Avoid high speeds, sudden starts, sharp turns, sudden braking
or abrupt maneuvers, otherwise it may result in loss of control or vehicle rollover due
to failure to operate this vehicle correctly.

●

Always slow down in gusty crosswinds. Because of its profile and higher center of
gravity, your vehicle is more sensitive to side winds than an ordinary passenger car.
Slowing down will allow you to have better control.

●

Do not drive horizontally across steep slopes. Driving straight up or straight down is
preferred. Your vehicle (or any similar off-road vehicle) can tip over sideways much
more easily than forward or backward.

3-7. Utility vehicle precautions

232

Off-road driving

Your vehicle is not designed to be driven off-road. However, in the event that
off-road driving cannot be avoided, please observe the following precautions to
help avoid the areas prohibited to vehicles.

●

Drive your vehicle only in areas where off-road vehicles are permitted to travel.

●

Respect private property. Get owner’s permission before entering private prop-
erty.

●

Do not enter areas that are closed. Honor gates, barriers and signs that restrict
travel.

●

Stay on established roads. When conditions are wet, driving techniques should
be changed or travel delayed to prevent damage to roads.

INFORMATION

■

Additional information for off-road driving

For owners in U.S. mainland, Hawaii and Puerto Rico:
To obtain additional information pertaining to driving your vehicle off-road, consult the
following organizations.

●

State and Local Parks and Recreation Departments

●

State Motor Vehicle Bureau

●

Recreational Vehicle Clubs

●

U.S. Forest Service and Bureau of Land Management

WARNING

■

Off-road driving precautions

Always observe the following precautions to minimize the risk of death or serious injury
or damage to your vehicle:

●

Drive carefully when off the road. Do not take unnecessary risks by driving in danger-
ous places.

●

Do not grip the steering wheel spokes when driving off-road. A bad bump could jerk
the wheel and injure your hands. Keep both hands and especially your thumbs on the
outside of the rim.

●

Always check your brakes for effectiveness immediately after driving in sand, mud,
water or snow.

●

After driving through tall grass, mud, rock, sand, water, etc., check that there is no
grass, bush, paper, rags, stone, sand, etc. adhering or trapped to the underbody. Clear

3-7. Utility vehicle precautions

233

Driving accor

ding to the conditions

WARNING

off any such matter from the underbody. If the vehicle is used with these materials
trapped or adhering to the underbody, a breakdown or fire could occur.

●

When driving off-road or in rugged terrain, do not drive at excessive speeds, jump,
make sharp turns, strike objects, etc. This may cause loss of control or vehicle rollover
causing death or serious injury. You are also risking expensive damage to your
vehicle’s suspension and chassis.

NOTICE

■

To prevent water damage

Take all necessary safety measures to ensure that water damage to the engine or other
components does not occur.

●

Water entering the engine air intake will cause severe engine damage.

●

Water entering the automatic transmission will cause deterioration in shift quality,
locking up of your transmission accompanied by vibration, and ultimately damage.

●

Water can wash the grease from wheel bearings, causing rusting and premature
failure, and may also enter the differentials, transmission and transfer case, reducing
the gear oil’s lubricating qualities.

■

When you drive through water

If driving through water, such as when crossing shallow streams, first check the depth of
the water and the bottom of the riverbed for firmness. Drive slowly and avoid deep water.

■

Inspection after off-road driving

●

Sand and mud that has accumulated around brake discs may affect braking efficiency
and may damage brake system components.

●

Always perform a maintenance inspection after each day of off-road driving that has
taken you through rough terrain, sand, mud, or water. For scheduled maintenance
information, refer to the "Warranty and Services Guide/Owner’s Manual Supple-
ment/Scheduled Maintenance".

3-7. Utility vehicle precautions

234

Content .. 11 12 13 14 ..
