Remove the remaining wheel bolts and the
tire.

When resting the tire on the ground, place the
tire so that the wheel design faces up, to avoid
scratching the wheel surface.

Installing the spare tire

INFORMATION

■

The compact spare tire

Observe the following precautions when installing a spare tire.

●

The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the
tire sidewall.
Use the compact spare tire temporarily, and only in an emergency.

●

Make sure to check the tire inflation pressure of the compact spare tire.

WARNING

Observe the following precautions when using a spare tire.

●

Remember that the compact spare tire provided is specifically designed for use with
your vehicle. Do not use your spare tire on another vehicle.

●

Do not use more than one compact spare tire simultaneously.

Remove any dirt or foreign matter from the wheel contact surfaces and wheel
bolts.

If foreign matter is not removed, the wheel bolts may loosen while the vehicle is in
motion, and the wheel may come off.

9-4. If a tire is flat

570

Align a wheel bolt hole on the spare tire with the guide pin, and set the spare
tire on the guide pin.

Securely set the spare tire so that its wheel is touching the contact surface.

WARNING

When removing or installing a tire, make sure to use the guide pin.
Also, the guide pin is made of resin. It may be damaged if the wheel is placed
anywhere other than

or if a large amount of force is applied to the guide pin.

Loosely tighten each wheel bolt by hand or using a wheel bolt socket .

Push the spare tire to prevent it from falling.
Do not use the wheel bolt socket for anything other than loosely tightening the wheel
bolts by hand.

9-4. If a tire is flat

571

When tr

ouble arises

WARNING

Observe the following precautions. Failure to do so may lead to the wheel bolts
loosening and the tire falling off.

●

Never apply oil or grease to the wheel bolts or their contact surface on the wheel

Doing so may cause the wheel bolts to be tightened excessively, leading to
damage to the wheel bolts, the threaded portion the wheel bolts install to

, or

the wheel.
Also, the wheel bolts may come loose, possibly leading to the wheel coming off,
causing a serious accident.
If oil or grease is attached to either of these parts, remove it.

●

When installing a wheel, use the same wheel bolts that were removed with the
wheel. Also, do not use any wheel bolts other than Lexus Genuine wheel bolts.

●

If a wheel bolt hole in a wheel or the threads of a wheel bolt or the wheel hub
are deformed, cracked, rusty or otherwise damaged, have the vehicle inspected
by any authorized Lexus retailer or Lexus authorized repairer, or any reliable
repairer.

●

Do not install the wheel ornament if it is damaged, as it may fly off the wheel while
the vehicle is being driven.

Remove the guide pin and loosely tighten the wheel bolt as in step

9-4. If a tire is flat

572

Lower the vehicle.

WARNING

When lowering the vehicle, make sure that no one is near the vehicle. If there are
people nearby, warn them vocally before lowering the vehicle.

Firmly tighten each wheel bolt in the order shown in the illustration two or
three times.

Tightening torque: 140 N•m (14.3 kgf•m, 103 ft•lbf)

WARNING

●

When tightening the wheel bolts, do not tighten them excessively. Doing so may
cause the wheel bolts, the threads of the wheel hub, or the wheel to be damaged.

●

Have the wheel bolts tightened with a torque wrench to 140 N•m (14.3 kgf•m,
103 ft•lbf) as soon as possible after changing wheels.

Stow the flat tire, tire jack and all tools.

INFORMATION

■

When using the compact spare tire

As the compact spare tire is not equipped with a tire pressure warning valve and
transmitter, low inflation pressure of the spare tire will not be indicated by the tire

9-4. If a tire is flat

573

When tr

ouble arises

pressure warning system. Also, if you replace the compact spare tire after the tire
pressure warning light comes on, the light remains on.

■

When a compact spare tire is installed

The vehicle becomes lower when driving with the compact spare tire compared to
when driving with standard tires.

WARNING

■

When using the compact spare tire

●

Replace the compact spare tire with a standard tire as soon as possible.

●

Avoid sudden acceleration, abrupt steering, sudden braking and shifting opera-
tions that cause sudden engine braking.

■

When the compact spare tire is attached

The vehicle speed may not be correctly detected, and the following systems may not
operate correctly:

●

ABS & Brake assist

●

VSC

●

TRC

●

Trailer Sway Control

●

EPS

●

Dynamic radar cruise control

●

PCS (Pre-Collision System)

●

LTA (Lane Tracing Assist)

●

LDA (Lane Departure Alert)

●

Lexus parking assist monitor

●

RSA (Road Sign Assist)

●

Panoramic view monitor

●

Lexus parking assist-sensor

●

PKSB (Parking Support Brake)

●

Navigation system

●

BSM (Blind Spot Monitor)

●

Automatic High Beam

* :

If equipped

9-4. If a tire is flat

574

WARNING

●

AHS (Adaptive High-beam System)

●

AFS (Adaptive Front-lighting System)

●

Tire pressure warning system

Also, not only can the following system not be utilized fully, but it may even negatively
affect the drive-train components:

●

AWD system (AWD models)

■

Speed limit when using the compact spare tire

Do not drive at speeds in excess of 80 km/h (50 mph) when a compact spare tire is
installed on the vehicle.
The compact spare tire is not designed for driving at high speeds. Failure to observe
this precaution may lead to an accident causing death or serious injury.

■

After using the tools and jack

After using the tools and jack, before driving, make sure that the tools and jack are
securely stored. Failure to do so may result in injury during a collision or sudden
braking.

NOTICE

■

Be careful when driving over bumps with the compact spare tire installed on the
vehicle

The vehicle becomes lower when driving with the compact spare tire compared to
when driving with standard tires. Be careful when driving over uneven road surfaces.

■

When replacing the tires

When removing or fitting the wheels, tires or the tire pressure warning valve and
transmitter, contact any authorized Lexus retailer or Lexus authorized repairer, or
any reliable repairer as the tire pressure warning valve and transmitter may be
damaged if not handled correctly.

9-4. If a tire is flat

575

When tr

ouble arises

If you get a flat front tire on a snowy or icy road (vehicles with a spare
tire)

NOTICE

Do not install tire chains to a compact spare tire.
Tire chains may damage the vehicle body and adversely affect driving performance.

Install the compact spare tire on the rear of the vehicle. Perform the following steps
and install tire chains to the front tires:

Replace a rear tire with the compact spare tire.

Replace the flat front tire with the tire removed from the rear of the vehicle.

Install tire chains to the front tires.

9-4. If a tire is flat

576

Precautions for when you have a flat tire (vehicles with run-flat tires)

Your vehicle is not equipped with a spare tire, but instead you can continue driving
the vehicle with run-flat tires even if any tire goes flat. In this case, slow down and
drive with extra caution.
Take your vehicle to the nearest authorized Lexus retailer or Lexus authorized
repairer, or any reliable repairer, or authorized tire dealer as soon as possible if any
tire goes flat.
The vehicle can be driven for a maximum of 80 km (50 miles) at a speed below
80 km/h (50 mph) after the tire pressure warning light comes on.

A run-flat tire has a

mark on the side wall.

INFORMATION

■

In some conditions (such as at high temperatures)

You cannot continue driving for up to 80 km (50 miles).

NOTICE

■

When replacing the tires

When removing or fitting the wheels, tires or the tire pressure warning valve and
transmitter, contact any authorized Lexus retailer or Lexus authorized repairer, or any
reliable repairer as the tire pressure warning valve and transmitter may be damaged if not
handled correctly.

■

When driving over bumps

If a vehicle has a flat tire, the vehicle height will be lower than usual. Ensure that nothing
strikes the bottom of the vehicle.

■

To avoid damage to the tire pressure warning valves and transmitters

When a tire is repaired with liquid sealants, the tire pressure warning valve and transmit-
ter may not operate properly. If a liquid sealant is used, contact any authorized Lexus
retailer or Lexus authorized repairer, or any reliable repairer or other qualified service
shop as soon as possible. Make sure to replace the tire pressure warning valve and
transmitter when replacing the tire.

9-4. If a tire is flat

577

When tr

ouble arises

If a door cannot be opened or locked

If a key has been lost

New genuine mechanical keys can be made by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer using another mechanical key
and the key number stamped on your key number plate.
Keep the plate in a safe place such as your wallet, not in the vehicle.

NOTICE

If the electronic key remains lost, the risk of vehicle theft increases significantly. Visit
any authorized Lexus retailer or Lexus authorized repairer, or any reliable repairer
immediately with all remaining electronic keys and the card key

that were provided

with your vehicle.

* :

If equipped

9-5. If a door cannot be opened or locked

578

When the doors/windows/moon roof cannot be operated using an elec-
tronic key

If communication between the electronic key and vehicle is interrupted or the
electronic key cannot be used because the battery is depleted, the smart entry &
start system and wireless remote control cannot be used.

The smart entry & start system may have been disabled by a customize setting.
In this case, change the customize setting to enable the smart entry & start
system.

NOTICE

When taking the vehicle to any authorized Lexus retailer or Lexus authorized repairer,
or any reliable repairer due to a malfunction of the smart entry & start system, make
sure to bring all registered electronic keys (including the card key).

The electronic key may have been set to battery saving mode.
battery saving mode has been set, cancel it.
The battery of the electronic key may be discharged.

●

Replace the battery.

●

Using the mechanical key.

The battery may be discharged.
Restarting the engine using the jumper (or booster) cables.

Replace the electronic key battery

Replace the battery with a new one if it is depleted.
The battery for the card key is available only at any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer. Your Lexus retailer or Lexus
authorized repairer, or any reliable repairer can replace the battery for you.
Prepare the following before replacing the battery:

●

Flathead screwdriver

●

Small flathead screwdriver

●

Lithium battery CR2032

9-5. If a door cannot be opened or locked

579

When tr

ouble arises

INFORMATION

■

Use a CR2032 lithium battery

Batteries can be purchased at any authorized Lexus retailer or Lexus authorized repairer,
or any reliable repairer, local electrical appliance shops or camera stores.

■

If the electronic key battery is depleted

The following symptoms may occur:

●

The smart entry & start system and wireless remote control will not function properly.

●

The operational range will be reduced.

Take out the mechanical key.

Remove the cover.

To prevent damage to the key, cover the tip of the
flathead screwdriver with a tape.

Remove the depleted battery.

Insert a new battery with the “+” terminal facing
up.

WARNING

■

Battery precautions

Observe the following precautions. Failure to do so may result in death or serious
injury.

9-5. If a door cannot be opened or locked

580

WARNING

●

Do not swallow the battery. Doing so may cause chemical burns.

●

A coin battery or button battery is used in the electronic key. If a battery is
swallowed, it may cause severe chemical burns in as little as 2 hours and may
result in death or serious injury.

●

Keep away new and removed batteries from children.

●

If the cover cannot be firmly closed, stop using the electronic key and stow the key
in the place where children cannot reach, and then contact any authorized Lexus
retailer or Lexus authorized repairer, or any reliable repairer.

●

If you accidentally swallow a battery or put a battery into a part of your body, get
emergency medical attention immediately.

■

To prevent battery explosion or leakage of flammable liquid or gas

●

Replace the battery with a new battery of the same type. If a wrong type of battery
is used, it may explode.

●

Do not expose batteries to extremely low pressure due to high altitude or ex-
tremely high temperatures.

●

Do not burn, break or cut a battery.

■

Lithium battery precautions

CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS

NOTICE

■

When replacing the battery

Use a flathead screwdriver of appropriate size. Applying excessive force may de-
form or damage the cover.

■

For normal operation after replacing the battery

Observe the following precautions to prevent accidents:

●

Always work with dry hands.
Moisture may cause the battery to rust.

●

Do not touch or move any other component inside the remote control.

●

Do not bend either of the battery terminals.

9-5. If a door cannot be opened or locked

581

When tr

ouble arises

Using the mechanical key

To take out the mechanical key, push the release
button and take the key out.
The mechanical key can only be inserted in one
direction, as the key only has a groove on one
side. If the key cannot be inserted in a lock cylin-
der, turn it over and attempt to insert it again.
After using the mechanical key, return it to its
original position and carry it with the electronic
key. If the electronic key battery is depleted, the
entry function is not operating properly, or the
vehicle battery is discharged, you will need the
mechanical key.

NOTICE

Do not apply excess force when inserting the mechanical key into the card key. Doing so
may damage the card key.

INFORMATION

■

If the incorrect key is used

The key cylinder rotates freely to isolate inside mechanism.

■

Card key

●

If it is difficult to take out the mechanical key, push down the release button using a pen
tip, etc. If it is still difficult to pull it out, use a coin, etc.

●

To store the mechanical key in the card key, insert it while pressing the release button.

9-5. If a door cannot be opened or locked

582

■

Alarm

Using the mechanical key to lock the doors will not set the alarm system. If a door is
unlocked using the mechanical key when the alarm system is set, the alarm may be
triggered.

Locking/unlocking the doors

Insert a plastic card, etc. into the gap in the
door handle and remove the cover.

To avoid damage, do not apply excessive force to
the cover.

Use the mechanical key in order to perform the following operations:

Unlocks all the doors

Locks all the doors

INFORMATION

■

Key linked functions

Opens the windows and the moon roof

panoramic moon roof

(turn and hold)

Closes the windows and the moon roof

panoramic moon roof

(turn and hold)

* :

If equipped

*1 :

These settings must be customized at any authorized Lexus retailer or Lexus author-

ized repairer, or any reliable repairer.

9-5. If a door cannot be opened or locked

583

When tr

ouble arises

WARNING

Operate the power window and moon roof or panoramic moon roof after checking
to make sure that there is no possibility of any passenger having any of their body
parts caught in the window or moon roof or panoramic moon roof.. Also, do not
allow children to operate the mechanical key. It is possible for children and other
passengers to get caught in the power window or moon roof or panoramic moon
roof.

Restarting the engine when the battery is discharged

If you have a set of jumper (or booster) cables and a second vehicle with a battery,
you can jump start your vehicle by following the steps below.

INFORMATION

The engine cannot be started by push-starting.

WARNING

■

Avoiding battery fires or explosions

Observe the following precautions to prevent accidentally igniting the flammable gas that
may be emitted from the battery:

●

Make sure each jumper cable is connected to the correct terminal and that it is not
unintentionally in contact with any other than the intended terminal.

●

Do not allow the + and - clamps of the jumper cables to come into contact with each
other.

●

Do not allow the other end of the jumper cable connected to the “+” terminal to come
into contact with any other parts or metal surfaces in the area, such as brackets or
unpainted metal.

●

Do not smoke, use matches, cigarette lighters or allow open flame near the battery.

■

Battery precautions

The battery contains poisonous and corrosive acidic electrolyte, while related parts
contain lead and lead compounds. Observe the following precautions when handling the
battery:

●

When working with the battery, always wear safety glasses and take care not to allow
any battery fluids (acid) to come into contact with skin, clothing or the vehicle body.

●

Do not lean over the battery.

●

In the event that battery fluid comes into contact with the skin or eyes, immediately
wash the affected area with water and seek medical attention. Place a wet sponge or
cloth over the affected area until medical attention can be received.

9-5. If a door cannot be opened or locked

584

WARNING

●

Always wash your hands after handling the battery support, terminals, and other
battery-related parts.

●

Do not allow children near the battery.

Confirm that the electronic key is being car-
ried.

When connecting the jumper (or booster) cables,
depending on the situation, the alarm may acti-
vate and the doors may lock.

Open the hood.

Remove the positive (+) battery terminal
cover.

▶

NX250

▶

NX350

▶

NX200

9-5. If a door cannot be opened or locked

585

When tr

ouble arises

Lexus NX (2022 year). Manual in english - page 35
