WARNING

●

Securely install the child restraint system according to the user's manual of the child
restraint system.

If a head restraint interferes with a child restraint system

When installing a child restraint system, if a head restraint interferes with the child
restraint system, remove the head restraint or adjust its position.

●

Remove the head restraint.

If a head restraint cannot be removed, move it to the uppermost position.

Installing a child restraint system with a seat belt

When installing a child restraint system which is not ISOFIX/i-Size compatible, use
a seat belt to install it.
Install the child restraint system according to the user’s manual included with it.

WARNING

Observe the following when installing a child restraint system with a seat belt.

●

Do not allow children to play with the seat belt. If the seat belt becomes twisted around
a child’s neck, it may lead to choking or other serious injuries that could result in death.
If this occurs and the buckle cannot be unfastened, scissors should be used to cut the
belt.

●

When using a junior seat, make sure that the shoulder belt is securely positioned over
the child’s shoulder.

●

After installing a child restraint system, do not adjust the seat.

●

Make sure that the seat belt plate and buckle are securely fastened.

●

Make sure that the seat belt is not twisted.

●

Securely install the child restraint system according to the procedure in the user’s
manual of the child restraint system.

1-2. Preparations for safe driving with children in the vehicle

WARNING

●

Shake the child restraint system left and right, and forward and backward to ensure
that it has been securely installed.

Pass the seat belt through the child restraint system.

Install the child restraint system according to the user’s manual included with it.

Insert the plate into buckle until a sound is heard.

Make sure that the belt is not twisted.

Check that the seat belt is secure.

You may need a locking clip to install the child
restraint system. Follow the instructions provided
by the manufacturer of the system. If your child
restraint system does not provide a locking clip,
you can purchase the following item from any
authorized Lexus retailer or Lexus authorized re-
pairer, or any reliable repairer: Locking clip for
child restraint system (Part No. 73119-22010)

After installing the child restraint system, rock it back and forth to ensure that it
is installed securely.

Make sure that the child restraint system is securely installed.

Removing a child restraint system that is installed with a seat belt

If a child restraint system is installed with a seat belt, release the seat belt to remove
it.

Press the buckle release button.

When the buckle is released, the child restraint system may spring up. Make sure to
hold down the child restraint system when releasing the buckle.

Remove the seat belt from the child restraint system.

The seat belt will be retracted automatically.

1-2. Preparations for safe driving with children in the vehicle

Befor

e driving

Installing a child restraint system to the front passenger's seat

Do not install a child restraint system to the front passenger's seat unless it is
unavoidable. In the event of an accident, the force of deployment of an SRS airbag
can cause death or serious injury to a child.
If installation of a child restraint system to the front passenger's seat is unavoidable,
adjust the front passenger's seat as follows:

●

Move the seat to the rearmost position

●

Move the seat to the uppermost position

●

Adjust the seatback angle to the most upright position.
Adjust the seatback angle of the front passenger's seat until good contact is
achieved.

●

Remove the head restraint
If the head restraint cannot be removed, move it to the uppermost position.

WARNING

●

There is a label(s) on the passenger side sun visor, indicating it is forbidden to attach a
rear-facing child restraint system to the front passenger seat.

●

When installing a child restraint system to the front passenger's seat, move the seat as
far back as possible. In the event of an accident, the force of deployment of an SRS
airbag can cause death or serious injury to a child.

1-2. Preparations for safe driving with children in the vehicle

WARNING

●

Make sure that the child's body will not contact the doors, roof side rails, or pillars. In
the event of an accident, the force of deployment of an SRS airbag can cause death or
serious injury to a child.

●

When using a junior seat, make sure that the seat belt is worn correctly.

●

Choose a child restraint system appropriate to the age and size of the child.

Installing a child restraint system to the front passenger's seat

●

Make sure to appropriately adjust the front passenger's seat before installing the
child restraint system.

Install the child restraint system according to the user's manual included with it.

1-2. Preparations for safe driving with children in the vehicle

Befor

e driving

Airbag manual on-off system

This system deactivates the following airbags.

●

SRS front passenger airbag

Only deactivate the airbags when using a child restraint system on the front
passenger seat.

"PASSENGER AIR BAG" indicator
"PASSENGER AIR BAG" and "ON" indi-
cator light turns on when the airbag system
is on, and about after 60 seconds they go
off. (only when the engine switch is in ON).

Airbag manual on-off switch

INFORMATION

■

"PASSENGER AIR BAG" indicator information

If any of the following problems occur, it is possible that there is a malfunction in the
system.
Have the vehicle checked by any authorized Lexus retailer or Lexus authorized repairer,
or any reliable repairer.

●

The "OFF" indicator does not illuminate when the airbag manual on-off switch is set to
"OFF".

●

The indicator light does not change when the airbag manual on-off switch is switched
to "ON" or "OFF".

WARNING

■

When installing a child restraint system

For safety reasons, always install a child restraint system in a rear seat. In the event that the
rear seat cannot be used, the front seat can be used as long as the airbag manual on-off
system is set to "OFF". If the airbag manual on-off system is left on, the strong impact of
the airbag deployment (inflation) may cause serious injury or even death.

1-2. Preparations for safe driving with children in the vehicle

WARNING

■

When a child restraint system is not installed on the front passenger seat

Ensure that the airbag manual on-off system is set to "ON". If it is left off, the airbag may
not deploy in the event of an accident, which may result in serious injury or even death.

Deactivating the airbags for the front passenger

●

Insert the mechanical key into the cylinder and
turn to the "OFF" position.

The "OFF" indicator light turns on (only when the
engine switch is in ON).

1-2. Preparations for safe driving with children in the vehicle

Befor

e driving

Entering/exiting the vehicle and loading luggage

Key types

The following keys are provided with the vehicle.

Electronic keys

●

Operating the smart entry & start system

●

Operating the wireless remote control
function

Mechanical keys

Key number plate

Card key (electronic key)

Operating the smart entry & start system

NOTICE

■

To prevent key damage

Observe the following precautions

●

Do not drop the keys, subject them to strong shocks or bend them.

●

Do not expose the keys to high temperatures for long periods of time.

●

Do not get the keys wet or wash them in an ultrasonic washer, etc.

●

Do not attach metallic or magnetic materials to the keys or place the keys close to
such materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or anything else to the surface of the electronic key.

●

Do not place the keys near objects that produce magnetic fields, such as TVs, audio
systems and induction cookers, or medical electrical equipment, such as low-frequen-
cy therapy equipment.

■

Carrying the electronic key on your person

Carry the electronic key 10 cm (3.9 in.) or more away from electric appliances that are
turned on. Radio waves emitted from electric appliances within 10 cm (3.9 in.) of the
electronic key may interfere with the key, causing the key to not function properly.

■

Handling the card key

●

If the battery or card key terminals get wet, the battery may corrode and the card key
may stop working.If the key is dropped into water, or if drinking water, etc., is spilled on
the key, immediately remove the battery cover and wipe the battery and terminals. (To
remove the battery cover, lightly grasp and pull it.) If the battery is corroded, have any

* :

If equipped

1-3. Entering/exiting the vehicle and loading luggage

NOTICE

authorized Lexus retailer or Lexus authorized repairer, or any reliable repairer replace
the battery.

●

Do not crush the battery cover or use a screwdriver to remove the battery cover.
Forcibly removing the battery cover may bend or damage the key.

●

If the battery cover is frequently removed, the battery cover may become loose.

●

When installing the battery, make sure to check the direction of the battery.Installing
the battery in the wrong direction may cause the battery to deplete rapidly.

●

The surface of the card key may be damaged, or its coating may peel off in the
following situations:

•

The card key is carried together with hard objects, such as coins and keys.

•

The card key is scraped with a sharp object, such as the tip of a mechanical pencil.

•

The surface of the card key is wiped with thinner or benzene.

INFORMATION

■

Handling the card key

●

The mechanical key that is stored inside the card key should be used only if a problem
arises, such as when the card key does not operate properly.

●

If the battery cover is not installed and the battery
falls out or if the battery was removed because the
key got wet, reinstall the battery with the positive
terminal facing the Lexus emblem.

●

The card key is not waterproof.

■

When riding in an aircraft

When bringing an electronic key onto an aircraft, make sure you do not press any buttons
on the electronic key while inside the aircraft cabin. If you are carrying an electronic key
in your bag, etc., ensure that the buttons are not likely to be pressed accidentally. Pressing
a button may cause the electronic key to emit radio waves that could interfere with the
operation of the aircraft.

■

Electronic key battery depletion

●

The standard battery life is 1 to 2 years (The card key battery life is about 1 year.).

●

If the battery becomes low, an alarm will sound in the cabin when the engine stops.

1-3. Entering/exiting the vehicle and loading luggage

Befor

e driving

●

As the electronic key always receives radio waves, the battery will become depleted
even if the electronic key is not used. The following symptoms indicate that the
electronic key battery may be depleted. Replace the battery when necessary.

•

The smart entry & start system or the wireless remote control does not operate.

•

The detection area becomes smaller.

•

The LED indicator on the key surface does not turn on.

●

To avoid serious deterioration, do not leave the electronic key within 1 m (3 ft.) of the
following electrical appliances that produce a magnetic field:

•

TVs

•

Personal computers

•

Cellular phones, cordless phones and battery chargers

•

Table lamps

•

Induction cookers

•

Table lamps

■

Battery-saving function

The battery-saving function will be activated in order to prevent the electronic key
battery and the battery from being discharged while the vehicle is not in operation for a
long time.

●

In the following situations, the smart entry & start system may take some time to unlock
the doors.

•

The electronic key has been left in an area of approximately 3.5 m (11 ft.) of the
outside of the vehicle for 10 minutes or longer.

•

The smart entry & start system has not been used for 5 days or longer.

●

If the smart entry & start system has not been used for 14 days or longer, the doors
cannot be unlocked at any doors except the driver’s door. In this case, take hold of
the driver’s door handle, or use the wireless remote control or the mechanical key, to
unlock the doors.

■

Electronic key battery-saving mode

When battery-saving mode is set, battery depletion is minimized by stopping the elec-
tronic key from receiving radio waves.

While pressing and holding

on the electronic key, press

twice. The indicator on

the electronic key will flash 4 times and battery-saving mode will be entered.

1-3. Entering/exiting the vehicle and loading luggage

The smart entry & start system cannot be used while the electronic key is in battery-sav-
ing mode. Battery saving mode can be cancelled by pressing any switch on the electronic
key.

■

Confirmation of the registered key number

The number of keys already registered to the vehicle can be confirmed. Ask any author-
ized Lexus retailer or Lexus authorized repairer, or any reliable repairer for details.

■

When required to leave the vehicle’s key with a parking attendant

Lock the glove box as circumstances demand. Remove the mechanical key for your own
use and provide the attendant with the electronic key only.

1-3. Entering/exiting the vehicle and loading luggage

Befor

e driving

Smart entry & start system

WARNING

■

Affects influenced by the radio wave (Affect from the Smart entry & start system
antennas)

●

People with implantable cardiac pacemakers, cardiac resynchronization therapy-
pacemakers or implantable cardioverter defibrillators should maintain a reasonable
distance between themselves and the smart entry & start system antennas. The radio
waves may affect the operation of such devices. If necessary, the entry function can
be disabled. Ask any authorized Lexus retailer or Lexus authorized repairer, or any
reliable repairer for details, such as the frequency of radio waves and timing of the
emitted radio waves. Then, consult your doctor to see if you should disable the entry
function.

●

Users of any electrical medical device other than implantable cardiac pacemakers,
cardiac resynchronization therapy-pacemakers or implantable cardioverter defibrilla-
tors should consult the manufacturer of the device for information about its operation
under the influence of radio waves. Radio waves could have unexpected effects on the
operation of such medical devices.

Ask any authorized Lexus retailer or Lexus authorized repairer, or any reliable repairer
for details on disabling the entry function.

INFORMATION

■

Antenna location

Antennas outside the cabin (vehicles with
entry function)

Antennas inside the cabin

Antenna outside the luggage compart-
ment (vehicles with entry function)

1-3. Entering/exiting the vehicle and loading luggage

■

Effective range (areas within which the electronic key is detected)

When locking or unlocking the doors (ve-
hicles with entry function)

The system can be operated when the elec-
tronic key is within about 0.7 m (2.3 ft.) of an
outside door handle. (Only the doors detecting
the key can be operated.)

When starting the engine or changing en-
gine switch modes

The system can be operated when the elec-
tronic key is inside the vehicle.

■

If an alarm sounds or a warning message is displayed

A combination of exterior and interior alarms as well as warning messages shown on
the multi-information display are used to prevent theft of the vehicle and accidents result-
ing from erroneous operation. Take appropriate measures in response to any warning
message on the multi-information display.
The following table describes situations and correction procedures when only an alarm
sounds.

●

When an interior alarm pings repeatedly
Situation: The engine switch was turned to ACC while the driver’s door was open (The
driver’s door was opened when the engine switch was in ACC).
Correction procedure: Turn the engine switch off and close the driver’s door.

■

Conditions affecting operation

The smart entry & start system, wireless remote control and immobilizer system use weak
radio waves. In the following situations, the communication between the electronic key
and the vehicle may be affected, preventing the smart entry & start system, wireless
remote control and immobilizer system from operating properly.

●

When the electronic key battery is depleted

●

Near a TV tower, electric power plant, gas station, radio station, large display, airport
or other facility that generates strong radio waves or electrical noise

●

When the electronic key is in contact with, or is covered by the following metallic
objects

•

Cards to which aluminum foil is attached

•

Cigarette boxes that have aluminum foil inside

•

Metallic wallets or bags

•

Coins

1-3. Entering/exiting the vehicle and loading luggage

Befor

e driving

•

Hand warmers made of metal

•

Media such as CDs and DVDs

●

When other wireless keys (that emit radio waves) are being used nearby

●

When carrying the electronic key together with the following devices that emit radio
waves

•

Portable radio, cellular phone, cordless phone or other wireless communication
devices

•

Another vehicle’s electronic key or a wireless key that emits radio waves

•

Personal computers or personal digital assistants (PDAs)

•

Digital audio players

•

Portable game systems

●

If window tint with a metallic content or metallic objects are attached to the rear
window

●

When the electronic key is placed near a battery charger or electronic devices

●

When the vehicle is parked in a pay parking spot where radio waves are emitted

Even when the electronic key is within the effective range (detection areas), the system
may not operate properly in the following cases:

●

The electronic key is too close to the window or outside door handle, near the ground,
or in a high place when the doors are locked or unlocked.

●

The electronic key is near the ground or in a high place, or too close to the rear
bumper center when the back door is opened.

●

The electronic key is on the instrument panel, rear package tray or floor, or in the door
pockets or glove box when the engine is started or engine switch modes are changed.

■

Note for the entry function

●

Do not leave the electronic key on top of the instrument panel or near the door
pockets when exiting the vehicle. Depending on the radio wave reception conditions,
it may be detected by the antenna outside the cabin and the door will become
lockable from the outside, possibly trapping the electronic key inside the vehicle.

●

As long as the electronic key is within the effective range, the doors may be locked or
unlocked by anyone.

●

Even if the electronic key is not inside the vehicle, it may be possible to start the hybrid
system if the electronic key is near the window.

●

The doors may unlock if a large amount of water splashes on the door handle, such as
in the rain or in a car wash when the electronic key is within the effective range. (The
door will automatically be locked after approximately 30 seconds if the doors are not
opened and closed.)

1-3. Entering/exiting the vehicle and loading luggage

●

If the wireless remote control is used to lock the doors when the electronic key is
near the vehicle, there is a possibility that the door may not be unlocked by the entry
function. (Use the wireless remote control to unlock the doors.)

●

Touching the door lock sensor while wearing gloves may delay or prevent lock
operation. Remove the gloves and touch the lock sensor again.

●

When the lock operation is performed using the lock sensor, recognition signals will
be shown up to two consecutive times. After this, no recognition signals will be given.

●

If the door handle becomes wet while the electronic key is within the effective range,
the door may lock and unlock repeatedly. In that case, follow the following correction
procedures to wash the vehicle:

•

Place the electronic key in a location 2 m (6 ft.) or more away from the vehicle.
(Take care to ensure that the key is not stolen.)

•

Set the electronic key to battery-saving mode to disable the smart entry & start
system.

●

If the electronic key is inside the vehicle and a door handle becomes wet during a
car wash, a message may be shown on the multi-information display and a buzzer will
sound outside the vehicle. To turn off the alarm, lock all the doors.

●

The lock sensor may not work properly if it comes into contact with ice, snow, mud.
Clean the lock sensor and attempt to operate it again.

●

A sudden approach to the effective range or door handle may prevent the doors from
being unlocked. In this case, return the door handle to the original position and check
that the doors unlock before pulling the door handle again.

●

If there is another electronic key in the detection area, it may take slightly longer to
unlock the doors after the door handle is gripped.

■

When the vehicle is not driven for extended periods

●

To prevent theft of the vehicle, do not leave the electronic key within 2 m (6 ft.) of the
vehicle.

●

The smart entry & start system can be deactivated in advance.

●

Setting the electronic key to battery-saving mode helps to reduce key battery deple-
tion.

■

To operate the system properly

Make sure to carry the electronic key when operating the system. Do not get the
electronic key too close to the vehicle when operating the system from the outside of the
vehicle.
Depending on the position and holding condition of the electronic key, the key may not
be detected correctly and the system may not operate properly. (The alarm may go off
accidentally, or the door lock prevention may not operate.)

1-3. Entering/exiting the vehicle and loading luggage

Befor

e driving

Opening/closing the doors

WARNING

■

Precautions for when driving

Observe the following precautions while driving.

●

Make sure that all of the doors are closed and locked.

●

Do not press an inside door opener switch while driving.
Be especially careful with the driver’s door, as it can be opened even when the doors
are locked.

●

When a child is riding in a rear seat, set the child protector locks to prevent the rear
doors from being opened from inside the vehicle.

■

Precautions for when opening or closing a door

When opening or closing a door, check the surrounding area and hold the door handle
tightly.

●

When on a slope

●

When the space between a door and a wall, etc. is small

●

When in an area with strong winds

INFORMATION

■

Door lock buzzer

If an attempt to lock the doors is made when a door is not fully closed, a buzzer sounds
continuously for 5 seconds. Fully close the door to stop the buzzer, and lock the vehicle
once more.

■

Open door warning buzzer

If the vehicle speed reaches 5 km/h (3 mph), the master warning light flashes and a
buzzer sounds to indicate that door(s) or the hood in not fully closed.The open door(s) or
hood is displayed on the multi-information display.

■

Rear seat reminder function

In order to remind you not to forget luggage, etc. in the rear seat, when the engine switch
is turned off after any of the following conditions are met, a buzzer will sound and a
message will be displayed on the multi-information display for approximately 6 seconds.

●

The engine is started within 10 minutes after opening and closing a rear door.

●

A rear door has been opened and closed after the engine was started.
However, if a rear door is opened and then closed within approximately 2 seconds, the
rear seat reminder function may not operate.

1-3. Entering/exiting the vehicle and loading luggage

Befor

e driving

The rear seat reminder function determines that luggage, etc. has been placed in a
rear seat based on opening and closing of a rear door. Therefore, depending on the
situation, the rear seat reminder function may not operate and you may still forget
luggage, etc. in the rear seat, or it may operate unnecessarily.

●

The rear seat reminder function can be enabled/disabled.

Lexus NX (2022 year). Manual in english - page 2
