Fog light switch



Turns the fog lights off

Turns the fog lights on

: For the U.S.A.

: For Canada

■

Fog lights can be used when

The headlights are on in low beam.



: If equipped

The fog lights secure excellent visibility in difficult driving conditions, such as
in rain and fog.

NOTICE

■

To prevent battery discharge

Do not leave the lights on longer than necessary when the engine is not running.

221

Windshield wipers and washer

Operating the

lever operates the wipers or washer as follows.



Intermittent windshield wipers with interval adjuster

Off

Intermittent operation

Low speed operation

High speed operation

Temporary operation

Wiper intervals can be adjusted when intermittent operation is selected.

Increases the intermittent windshield
wiper frequency
Decreases the intermittent wind-
shield wiper frequency

Operating the wiper lever

222

Washer/wiper dual opera-
tion

Pulling the lever operates the wipers

and washer.
The wipers will automatically operate a

couple of times after the washer squirts.
Vehicles with headlight cleaners: If the

headlights are on, the headlight cleaners

will operate once.



Rain-sensing windshield wipers

Off

Rain-sensing operation

Low speed operation

High speed operation

: For the U.S.A.

: For Canada

When “AUTO” is selected, the wipers will operate automatically when the sensor

detects falling rain. The system automatically adjusts wiper timing in accordance with

rain volume and vehicle speed.

223

The sensor sensitivity can be adjusted when “AUTO” is selected.

Increases the sensitivity
Decreases the sensitivity

Washer/wiper dual opera-
tion

Pulling the lever operates the wipers

and washer.
The wipers operate automatically. (After

operating several times, the wipers

operate one more time after a short

delay to prevent dripping.)

Vehicles with headlight cleaners: If the

headlights are on, the headlight cleaners

will operate once.

■

The windshield wiper and washer can be operated when

The engine switch is in IGNITION ON mode.

■

Raindrop sensor (vehicles with rain-sensing windshield wipers)

●

If the wiper switch is turned to the “AUTO” position while the engine switch is in

IGNITION ON mode, the wipers will operate once to show that “AUTO” mode is acti-

vated.

●

When the sensor sensitivity ring is turned toward high while in “AUTO” mode, the wip-

ers will operate once to indicate that the sensor sensitivity is enhanced.

●

If the temperature of the rain drop sensor is 194



F (90



C) or higher, or 5



F (-15



C) or

lower, the automatic operation may not occur. In this case, operate the wipers in any

mode other than “AUTO”.

6
7

●

The raindrop sensor judges the amount of

raindrops.
An optical sensor is adopted. It may not oper-

ate properly when sunlight from the rising or

setting of the sun intermittently strikes the

windshield, or if bugs etc. are present on the

windshield.

224

■

Effects of vehicle speed on wiper operation (vehicles with rain-sensing windshield wip-

ers)

With the settings other than “AUTO” also, the time until drip prevention wiper sweep

occurs is changed depending on vehicle speed.

With the low speed wiper operation selected, wiper operation will be switched from low

speed to intermittent wiper operation only when the vehicle is stationary. (However,

when the sensor sensitivity is adjusted to the highest level, the mode cannot be switched.)

■

If no windshield washer fluid sprays

Check that the washer nozzles are not blocked if there is washer fluid in the windshield

washer fluid reservoir.

WARNING

■

Caution regarding the use of windshield wipers in “AUTO” mode (vehicles with rain-

sensing windshield wipers)

The windshield wipers may operate unexpectedly if the sensor is touched or the wind-

shield is subject to vibration in “AUTO” mode. Take care that your fingers etc. anything

else does not become caught in the windshield wipers.

■

Caution regarding the use of washer fluid

When it is cold, do not use the washer fluid until the windshield becomes warm. The

fluid may freeze on the windshield and cause low visibility. This may lead to an accident,

resulting in death or serious injury.

NOTICE

■

When the windshield is dry

Do not use the wipers, as they may damage the windshield.

■

When the washer fluid tank is empty

Do not operate the switch continually as the washer fluid pump may overheat.

■

When there is no washer fluid spray from the nozzle

Damage to the washer fluid pump may be caused if the lever is pulled toward you and

held continually.

■

When a nozzle becomes blocked

In this case, contact your Lexus dealer.

Do not try to clear it with a pin or other object. The nozzle will be damaged.

225

Rear window wiper and washer

Operating the

switch operates the rear wiper as follows.

Off

Intermittent operation

Normal operation

: For the U.S.A.

: For Canada

Washer/wiper dual opera-
tion

Pushing the lever operates the wiper

and washer.
The wipers will automatically operate a

couple of times after the washer squirts.

■

The rear window wiper and washer can be operated when

●

The engine switch is in IGNITION ON mode.

●

The glass hatch is closed.

■

If no windshield washer fluid sprays

Check that the washer nozzles are not blocked if there is washer fluid in the windshield

washer fluid reservoir.

226

NOTICE

■

When the rear window is dry

Do not use the wiper, as it may damage the rear window.

■

When the washer fluid tank is empty

Do not operate the switch continually as the washer fluid pump may overheat.

227

Headlight cleaner switch



Press the switch to clean the headlights.

■

The headlight cleaners can be operated when

The engine switch is in IGNITION ON mode and the headlight switch is turned on.

■

Windshield washer linked operation

When the windshield washer is operated with the engine switch in IGNITION ON mode

and the headlights on, the headlight cleaners will operate once. (



P. 221)



: If equipped

Washer fluid can be sprayed on the headlights.

NOTICE

■

When the washer fluid tank is empty

Do not press the switch continually as the washer fluid pump may overheat.

228

Opening the fuel tank cap

●

Turn the engine switch off and ensure that all the doors and windows are
closed.

●

Confirm the type of fuel.

■

Fuel types



P. 586

■

Fuel tank opening for unleaded gasoline

To help prevent incorrect fueling, your Lexus has a fuel tank opening that only accommo-

dates the special nozzle on unleaded fuel pumps.

■

If the malfunction indicator lamp illuminates

The malfunction indicator lamp may illuminate erroneously if refueling is performed

repeatedly when the fuel tank is nearly full.

Perform the following steps to open the fuel tank cap.

Before refueling the vehicle

229

WARNING

■

When refueling the vehicle

Observe the following precautions while refueling the vehicle. Failure to do so may

result in death or serious injury.

●

After exiting the vehicle and before opening the fuel door, touch an unpainted metal

surface to discharge any static electricity. It is important to discharge static electricity

before refueling because sparks resulting from static electricity can cause fuel vapors

to ignite while refueling.

●

Always hold the grips on the fuel tank cap and turn it slowly to remove it.

A whooshing sound may be heard when the fuel tank cap is loosened. Wait until the

sound cannot be heard before fully removing the cap. In hot weather, pressurized fuel

may spray out of the filler neck and cause injury.

●

Do not allow anyone that has not discharged static electricity from their body to come

close to an open fuel tank.

●

Do not inhale vaporized fuel.

Fuel contains substances that are harmful if inhaled.

●

Do not smoke while refueling the vehicle.

Doing so may cause the fuel to ignite and cause a fire.

●

Do not return to the vehicle or touch any person or object that is statically charged.

This may cause static electricity to build up, resulting in a possible ignition hazard.

■

When refueling

Observe the following precautions to prevent fuel overflowing from the fuel tank:

●

Securely insert the fuel nozzle into the fuel filler neck.

●

Stop filling the tank after the fuel nozzle automatically clicks off.

●

Do not top off the fuel tank.

NOTICE

■

Refueling

Do not spill fuel during refueling.

Doing so may damage the vehicle, such as causing the emission control systems to

operate abnormally or damaging fuel system components or the vehicle’s painted sur-

face.

230

Press the opener to open the fuel
filler door.

Turn the fuel tank cap slowly to open,
and hang the fuel tank cap on the
back of the fuel filler door.

Opening the fuel tank cap

231

■

When the fuel filler door cannot be opened by pressing the inside switch

After refueling, turn the fuel tank cap
until you hear a click. Once the cap is
released, it will turn slightly in the oppo-
site direction.

Remove the cover inside the luggage compart-

ment and pull the lever.

Closing the fuel tank cap

WARNING

■

When replacing the fuel tank cap

Do not use anything but a genuine Lexus fuel tank cap designed for your vehicle. Doing

so may cause a fire or other incident which may result in death or serious injury.

232

Lexus Safety System +

◆

PCS (Pre-Collision System)



P. 237

◆

LDA (Lane Departure Alert)



P. 247

◆

AHB (Automatic High Beam)



P. 216

◆

Dynamic radar cruise control



P. 255

The Lexus Safety System + consists of the following drive assist systems and
contributes to a safe and comfortable driving experience:

Driving assist system

WARNING

■

Lexus Safety System +

The Lexus Safety System + is designed to operate under the assumption that the driver

will drive safely, and is designed to help reduce the impact to the occupants and the

vehicle in the case of a collision or assist the driver in normal driving conditions.
As there is a limit to the degree of recognition accuracy and control performance that

this system can provide, do not overly rely on this system. The driver is always responsi-

ble for paying attention to the vehicle’s surroundings and driving safely.

233

Two types of sensors, located behind the front grille and windshield, detect infor-
mation necessary to operate the drive assist systems.

Radar sensor
Front camera

Sensors

WARNING

■

To avoid malfunction of the radar sensor

Observe the following precautions.
Otherwise, the radar sensor may not operate properly, possibly leading to an accident

resulting in death or serious injury.

●

Keep the radar sensor and the radar sensor cover clean at all times.

●

Do not attach accessories, stickers (including transparent stickers) or other items to

the radar sensor, radar sensor cover or surrounding area.

●

Do not subject the radar sensor or its surrounding area to a strong impact.

If the radar sensor, front grille, or front bumper has been subjected to a strong impact,

have the vehicle inspected by your Lexus dealer.

●

Do not disassemble the radar sensor.

●

Do not modify or paint the radar sensor or radar sensor cover.

●

In the following cases, the radar sensor must be recalibrated. Contact your Lexus

dealer for details.
• When the radar sensor or front grille are removed and installed, or replaced

• When the front bumper is replaced

Radar sensor
Radar sensor cover

If the front of the radar sensor or the front or

back of the radar sensor cover is dirty or

covered with water droplets, snow, etc., clean

it.

Clean the radar sensor and radar sensor

cover with a soft cloth to avoid damaging

them.

234

WARNING

■

To avoid malfunction of the front camera

Observe the following precautions.
Otherwise, the front camera may not operate properly, possibly leading to an accident

resulting in death or serious injury.

●

Keep the windshield clean at all times.
• If the windshield is dirty or covered with an oily film, water droplets, snow, etc.,

clean the windshield.

• If a glass coating agent is applied to the windshield, it will still be necessary to use

the windshield wipers to remove water droplets, etc. from the area of the wind-

shield in front of the front camera.

• If the inner side of the windshield where the front camera is installed is dirty, con-

tact your Lexus dealer.

●

If the part of the windshield in front of the front camera is fogged up or covered with

condensation or ice, use the windshield defogger to remove the fog, condensation or

ice. (



P. 408)

●

If water droplets cannot be properly removed from the area of the windshield in front

of the front camera by the windshield wipers, replace the wiper insert or wiper blade.

●

Do not attach window tint to the windshield.

●

Replace the windshield if it is damaged or cracked.

After replacing the windshield, the front camera must be recalibrated. Contact your

Lexus dealer for details.

●

Do not allow liquids to contact the front camera.

●

Do not allow bright lights to shine into the front camera.

●

Do not dirty or damage the front camera.

When cleaning the inside of the windshield, do not allow glass cleaner to contact the

lens of the front camera. Also, do not touch the lens.

If the lens is dirty or damaged, contact your Lexus dealer.

●

Do not subject the front camera to a strong impact.

●

Do not change the installation position or direction of the front camera or remove it.

●

Do not disassemble the front camera.

●

Do not attach objects, such as stickers, trans-

parent stickers, etc., to the outer side of the

windshield in front of the front camera

(shaded area in the illustration).
A: From the top of the windshield to approxi-

mately 0.4 in. (1 cm) below the bottom of the

front camera
B: Approximately 7.9 in. (20 cm) (Approxi-

mately 4.0 in. [10 cm] to the right and left

from the center of the front camera)

235
