Lexus ES (2022 year). Manual in english - page 20

339

5-5. Using the storage features

rior f
eat
ur

Open (press the glove box opener)

Unlock with the mechanical key

Lock with the mechanical key

Glove box light

The glove box light turns on when the tail

lights are on.

Trunk opener main switch



P.139

Press a button to open the console
box.

The console box can be opened from
either side.

Console box light

The console box light turns on when the tail

lights are on.



Front (type A)

To open, press down and release the
cup holder lid.



Front (type B)

Adjust the depth of the cup holder.

Shallow (press the button)

Glove box

Console box

WARNING

Caution while driving

Keep the console box closed. Injuries

may result in the event of an accident or

sudden braking.

NOTICE

To prevent damage to the console

box

When the console box is open, do not

apply excessive force in the direction

that it was opened.

Cup holders

340

5-5. Using the storage features

Deepen



Rear

To open, pull down the armrest and
press in and release the rear cup
holder on the armrest.

Front cup holder (type A)

After closing the USB terminal lid, close

the cup holder lid.

When cleaning the cup holder, the parti-

tion and another parts can be removed

according to the following procedure.

Remove the partition

Remove the plate

When stowing the rear cup holders

Stow the cup holder with the armrest down.

The cup holder cannot be stowed if the

armrest is not down.



Front

Press in the button.



Rear

Pull the armrest down then press the
knob to open the lid.

WARNING

Items unsuitable for the cup holder

Do not place anything other than a cup,

beverage can or bottle (front [type B]) in

the cup holder. Even when the lid is

closed, items must not be stored in the

cup holder.

Other items may be thrown out of the

holder in the event of an accident or sud-

den braking, causing injury. If possible,

cover hot drinks to prevent burns.

NOTICE

To prevent damage to the cup holder

Depending on the size of the cup, bev-

erage can or bottle, do not use the cup

holder in the shallow condition. When

taking out the cup, beverage can or

bottle or in the event of sudden brak-

ing, they may be thrown out of the

holder or the contents may spill.

Stow the rear cup holder before stow-

ing the armrest.

Auxiliary boxes

341

5-5. Using the storage features

rior f
eat
ur

Raise the hooks when needed.

The cargo hooks are provided for securing
loose items.

Lift the luggage mat up.

Trunk features

Cargo hooks

WARNING

When the cargo hooks are not in use

To avoid injury, always return the cargo

hooks to their stowed positions when not

in use.

Grocery bag hooks

Luggage mat

342

5-5. Using the storage features

343

5-6. Using the other interior features

rior f
eat
ur

5-6.Using the other interior features

To set the visor in the forward posi-
tion, flip it down.

To set the visor in the side position,
flip down, unhook, and swing it to
the side.

Slide the cover to open.

The light turns on when the cover is
opened.

The GPS clock’s time is automatically
adjusted by utilizing GPS time infor-
mation.
For details, refer to the “NAVIGA-
TION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

Please use as a power supply for elec-
tronic goods that use less than 12
VDC/10 A (power consumption of
120 W).



Front

Open the lid.



Rear

Open the lid.

Other interior features

Sun visors

Vanity mirrors

NOTICE

To prevent 12-volt battery discharge

Do not leave the lights on longer than

necessary when the hybrid system is off.

Clock

Power outlet

344

5-6. Using the other interior features

The power outlet can be used when

The power switch is in ACCESSORY or

ON mode.

When stopping the hybrid system

Disconnect electrical devices with charging

functions, such as mobile battery packs.
If such devices are left connected, the

hybrid system may not stop normally.

Using the power outlet

The shape of the console box partition

allows power cables to be passed through

when the console box lid is partially closed.

The USB Type-C charging ports are
used to supply 3 A of electricity at 5 V
to external devices.
The USB Type-C charging ports are
for charging only. They are not
designed for data transfer or other
purposes.
Depending on the external device, it
may not charge properly. Refer to the
manual included with the device
before using a USB Type-C charging
port.

Using the USB Type-C charging
ports



Front (if equipped)



Rear

Open the lid.

NOTICE

When the power outlet is not in use

To avoid damaging the power outlet,

close the power outlet lid when the

power outlet is not in use. Foreign

objects or liquids that enter the power

outlet may cause a short circuit.

To prevent 12-volt battery discharge

Do not use the power outlet longer than

necessary when the hybrid system is off.

USB Type-C charging ports

345

5-6. Using the other interior features

rior f
eat
ur

The USB Type-C charging ports can be

used when

The power switch is in ACCESSORY or

ON mode.

Situations in which the USB Type-C

charging ports may not operate cor-

rectly

If a device which consumes more than 3

A at 5 V is connected

If a device designed to communicate with

a personal computer, such as a USB

memory device, is connected

If the connected external device is turned

off (depending on device)

If the temperature inside the vehicle is

high, such as after the vehicle has been

parked in the sun

About connected external devices

Depending on the connected external

device, charging may occasionally be sus-

pended and then start again. This is not a

malfunction.

A portable device can be charged by
just placing Qi standard wireless
charge compatible portable devices
according to the Wireless Power Con-
sortium, such as smart phones and
mobile batteries, etc., on the charge
area.
This function cannot be used with por-
table devices that are larger than the
charging area. Also, depending on the
portable device, it may not operate as
normal. Please read the operation
manual for portable devices to be
used.

The “Qi” logo

The “Qi” logo is a trademark of the
Wireless Power Consortium.

NOTICE

To prevent damage to the USB Type-

C charging ports

Do not insert foreign objects into the

ports.

Do not spill water or other liquids into

the ports.

Rear: When the USB Type-C

charging ports are not in use, close the

lids. If a foreign object or liquid enters a

port may cause a short circuit.

Do not apply excessive force to or

impact the USB Type-C charging

ports.

Do not disassemble or modify the USB

Type-C charging ports.

To prevent damage to external

devices

Do not leave external devices in the

vehicle. The temperature inside the

vehicle may become high, resulting in

damage to an external device.

Do not push down on or apply unnec-

essary force to an external device or

the cable of an external device while it

is connected.

To prevent 12-volt battery discharge

Do not use the USB Type-C charging

ports for a long period of time with the

hybrid system stopped.

Wireless charger (if equipped)

346

5-6. Using the other interior features

Name for all parts

Operation indicator light

Power supply switch

Charge area

Using the wireless charger

Open the console box. (



P.339)

Press the power supply switch of
the wireless charger.

Switches on and off with each press of the

power supply switch.
When turned on, the operation indicator

light (green) comes on.
Even with the engine off, the on/off state of

the power supply switch is memorized.

Place the charging side of the por-
table device down.

When charging, the operation indicator

light (orange) comes on.
If charging is not occurring, try placing the

portable device as close to the center of

the charging area as possible.
When charging is complete, the operation

indicator light (green) comes on.

Recharging function



When charging is complete and
after a fixed time in the charge sus-
pension state, charging restarts.



When the portable device is moved,
charging is stopped for a moment
and then it restarts.

A
B
C

347

5-6. Using the other interior features

rior f
eat
ur

Lighting conditions of operation
indicator light

: Depending on the portable device, there

are cases where the operation indicator
light will continue being lit up orange
even after the charging is complete.



When the operation indicator light
flashes

When an error occurs, the operation indi-
cator light flashes an orange color.
Handle the error based on the following
tables.
• Flashing repeatedly once every second

(Orange)

• Repeatedly flashes 3 times continuously

(Orange)

• Repeatedly flashes 4 times continuously

(Orange)

The wireless charger can be operated

when

The power switch is in ACCESSORY or

ON mode.

Usable portable devices

Qi standard wireless charge standard

can be used on compatible devices.

However, not all Qi standard devices and

compatibility are guaranteed.

Starting with mobile phones and smart

phones, it is aimed for low power electri-

cally supplied portable devices of no

more than 5W.

When covers and accessories are

attached to portable devices

Do not charge in situations where cover

and accessories not able to handle Qi are

attached to the portable device. Depending

on the type of cover and accessory, it may

not be possible to charge. When charging

is not performed even with the portable

Operation

indicator

light

Conditions

Turning off

When the Wireless charger
power supply is off

Green
(comes on)

On Standby (charging pos-
sible state)

When charging is com-
plete

Orange
(comes on)

When placing the portable
device on the charging area
(detecting the portable
device)

Charging

Suspected causes

Handling method

Vehicle to charger
communication fail-
ure.

Contact any autho-
rized Lexus retailer
or Lexus authorized
repairer, or any reli-
able repairer.

Suspected causes

Handling method

A foreign substance
is between the por-
table device and
charge area.

Remove the foreign
substance from
between portable
device and the
charge area.

The portable device
is out of sync due to
the device being
shifted from the cen-
ter of the charge
area.

Place the portable
device near the cen-
ter of the charge
area.

Suspected causes

Handling method

Temperature rising
within the wireless
charger.

Stop charging at
once and start
charging again after
for a while.

348

5-6. Using the other interior features

device placed on the charge area, remove

the cover and accessories.

While charging, noise enters the AM

radio

Turn off the wireless charger and confirm

that the noise has decreased. If the noise

decreases, continuously pushing the power

supply switch of the wireless charger for 2

seconds, the frequency of the charger can

be changed and the noise can be

reduced.Also, on that occasion, the opera-

tion indicator light will flash orange 2 times.

Important points of the wireless charger

If the electronic key cannot be detected

within the vehicle interior, charging can-

not be done. When the door is opened

and closed, charging may be temporarily

suspended.

When charging, the wireless charging

device and portable device will get

warmer, however this is not a malfunc-

tion.

When a portable device gets warm while

charging, charging may stop due to the

protection function on the portable

device side. In this case, when the tem-

perature of the portable device drops

significantly, charge again.

Operation sounds

When the power supply is turned on, while

searching for the portable device a sound

will be produced, however this is not a mal-

function.

WARNING

Caution while driving

When charging a portable device, for

safety reasons, the driver should not

operate the main part of the portable

device while driving.

Caution regarding interference with

electronic devices

People with implantable cardiac pace-

makers, cardiac resynchronization ther-

apy-pacemakers or implantable

cardioverter defibrillators, as well as any

other electrical medical device, should

consult their physician about the usage of

the wireless charger. The operations of

the wireless charger may have an affect

on medical devices.

To prevent damage or burns

Observe the following precautions.

Failure to do so may result in a possibility

of equipment failure and damage, catch

fire, burns due to overheat.

Do not insert any metallic objects

between the charging area and the

portable device while charging

Do not attach stickers, metallic

objects, etc., to the charger area or

portable device

Do not cover with cloth, etc., and

charge

Do not charge portable devices other

than designated

Do not attempt to dismantle for disas-

sembly or modifications

Do not hit or apply a strong force

NOTICE

Conditions in which the function may

not operate correctly

In the following conditions, it may not

operate correctly

The portable device is fully charged

There is foreign matter between the

charge area and portable device

The temperature of the portable

device gets higher from charging

349

5-6. Using the other interior features

rior f
eat
ur

Fold down the armrest for use.

An assist grip installed on the ceiling
can be used to support your body
while sitting on the seat.

NOTICE

The charging surface of the portable

device is facing up

The placement of the portable device

is out of alignment with the charge

area

Near a TV tower, electric power plant,

gas station, radio station, large display,

airport or other facility that generates

strong radio waves or electrical noise

When the electronic key is in contact

with, or is covered by the following

metallic objects

• Cards to which aluminum foil is

attached

• Cigarette boxes that have aluminum

foil inside

• Metallic wallets or bags
• Coins
• Hand warmers made of metal
• Media such as CDs and DVDs

When other wireless keys (that emit

radio waves) are being used nearby

In addition, excluding the above-men-
tioned, when the charger does not per-
form normally or the operation indicator
light is flashing continuously, it is consid-
ered that the wireless charger is malfunc-
tioning. Contact authorized Lexus
dealer.

To prevent failure or damage to data

Do not bring magnetic cards, such as

credit cards, or magnetic recording

media, etc., close to the charger while

charging, otherwise, data may disap-

pear under the influence of magne-

tism. Also, do not bring precision

instruments such as wrist watches, etc.,

close to the charger, as such objects

may break.

Do not leave portable devices in the

cabin. The temperature inside the

cabin may become high, when under

the sun, and cause damage to the

device.

To prevent 12-volt battery discharge

When the hybrid system is stopped, do

not use the wireless charger for a long

time.

Armrest

NOTICE

To prevent damage to the armrest

Do not apply too much load on the arm-

rest.

Assist grips

350

5-6. Using the other interior features

Rear sunshade

The rear sunshade can be raised and
lowered by operating the switch shown
below.



From the front seats

Press the switch. (Raise/lower)



From the rear seats (if equipped)

Press the switch. (Raise/lower)

Rear door sunshades

Pull the tab of the rear door sunshade
and hook the sunshade on the anchors.

To retract the rear door sunshade, unhook
the sunshade and retract it slowly.

WARNING

Assist grips

Do not use the assist grip when getting in

or out of the vehicle or rising from your

seat.

NOTICE

To prevent damage to the assist grip

Do not hang any heavy object or put a

heavy load on the assist grip.

Rear sunshade (if
equipped)/rear door sunshades
(if equipped)

351

5-6. Using the other interior features

rior f
eat
ur

The rear sunshade can be used when

The power switch is in ON mode.

The rear sunshade can be operated for

approximately 1 minute even after the

power switch is turned to ACCESSORY

mode or turned off.

Reverse operation feature

To ensure adequate rear visibility, the rear

sunshade automatically lowers when the

shift lever is shifted to R.
However, the rear sunshade is raised again
if any of the following occurs:

The button is pressed again.

Shift the shift lever to P.

The shift lever is shifted out of R, and the

vehicle reaches a speed of 15 km/h (9

mph).

If the hybrid system is turned off after the

rear sunshade was lowered due to the

reverse operation feature, it will not be

raised even when the hybrid system is

turned on again and the vehicle reaches a

speed of 15 km/h (9 mph). To raise the

sunshade again, press the button.

: Occasionally, the reverse function may

not be carried out after the switch has
been pressed. Repeat the above opera-
tion to operate the function.

WARNING

When the rear sunshade is being

raised or lowered

When the rear sunshade is being oper-

ated, do not place fingers or other

objects in the fastener section or in the

opening. They may get caught, causing

injury.

NOTICE

To prevent 12-volt battery discharge

Do not operate the rear sunshade when

the hybrid system is not operating.

To ensure normal operation of the

sunshades

Do not operate the rear sunshade

when any objects are on top of its

opening/closing part.

The rear sunshade may not operate

properly.

To ensure normal operation of the rear

sunshade and rear door sunshades,

observe the following precautions:

• Do not place excessive load on the

motor or other components of the rear

sunshade.

• Do not attach items to the rear sun-

shade and rear door sunshades.

• Keep the opening clean and clear of

obstructions.

• Do not operate the rear sunshade

continuously for long periods of time.

352

5-6. Using the other interior features

Long objects can be loaded into the
vehicle by utilizing the trunk space and
rear seat area.

Fold down the armrest.

Fold down the handle and open the
armrest door.

The armrest door can be locked and
unlocked using the mechanical key.

Unlock

Lock

The coat hooks are provided with the
rear assist grips.

Trunk storage extension

WARNING

When not in use

Ensure that the armrest door is closed. In

the event of sudden braking, items stored

in the trunk may be thrown forward into

the cabin, resulting in injury.

A
B

Coat hooks

WARNING

Items that should not be hanged

Do not hang coat hangers or other hard

or sharp objects on the hook. If the SRS

curtain shield airbags deploy, these items

may become projectiles, causing death

or serious injury.

353

ain

ten

ce a
nd

Maintenance and care

6-1. Maintenance and care

Cleaning and protecting the vehi-

cle exterior................................

354

Cleaning and protecting the vehi-

cle interior .................................

357

6-2. Maintenance

Maintenance requirements..

360

6-3. Do-it-yourself maintenance

Do-it-yourself service precautions

........................................................

362

Hood ..............................................

364

Positioning a floor jack............

364

Engine compartment...............

366

12-volt battery..............................

371

Tires ................................................

373

Tire inflation pressure...............

381

Wheels ..........................................

382

Air conditioning filter...............

383

Cleaning the hybrid battery (trac-

tion battery) air intake vent and
filter ..............................................

385

Electronic key battery.............

389

Checking and replacing fuses

.........................................................

391

Light bulbs....................................

393

354

6-1. Maintenance and care

6-1.Maintenance and care



Working from top to bottom, liber-
ally apply water to the vehicle body,
wheel wells and underside of the
vehicle to remove any dirt and dust.



Wash the vehicle body using a
sponge or soft cloth, such as a
chamois.



For hard-to-remove marks, use car
wash soap and rinse thoroughly with
water.



Wipe away any water.



Wax the vehicle when the water-
proof coating deteriorates.

If water does not bead on a clean surface,
apply wax when the vehicle body is cool.

Self-restoring coat

The vehicle body has a self-restoring coat-

ing that is resistant to small surface

scratches caused in a car wash etc.

The coating lasts for 5 to 8 years from

when the vehicle is delivered from the

plant.

The restoration time differs depending on

the depth of the scratch and outside tem-

perature.

The restoration time may become

shorter when the coating is warmed by

applying warm water.

Deep scratches caused by keys, coins,

etc. cannot be restored.

Do not use wax that contains abrasives.

Automatic car washes

Before washing the vehicle:

• Fold the mirrors (if equipped) or Digital

Side-view Monitor cameras (if equipped)

• Turn off the power trunk lid (if equipped)
Start washing from the front of the vehicle.
Make sure to extend the mirrors (if
equipped) or Digital Side-view Monitor
cameras (if equipped) before driving.

Brushes used in automatic car washes

may scratch the vehicle surface, parts

(wheel, etc.) and harm your vehicle’s

paint.

Rear spoiler may not be washable in

some automatic car washes. There may

also be an increased risk of damage to

vehicle.

High pressure car washes

As water may enter the cabin, do not bring

the nozzle tip near the gaps around the

doors or perimeter of the windows, or spray

these areas continuously.

Notes for a smart entry & start system

If the door handle becomes wet while the

electronic key is within the effective range,

the door may lock and unlock repeatedly. In

that case, follow the following correction

procedures to wash the vehicle:

Place the key in a position 2 m (6 ft.) or

more separate from the vehicle while the

vehicle is being washed. (Take care to

ensure that the key is not stolen.)

Set the electronic key to battery-saving

mode to disable the smart entry & start

system. (



P.141)

Wheels and wheel ornaments

Remove any dirt immediately by using a

neutral detergent.

Wash detergent off with water immedi-

ately after use.

To protect the paint from damage, make

sure to observe the following precau-

tions.

• Do not use acidic, alkaline or abrasive

Cleaning and protecting the
vehicle exterior

Perform cleaning in a manner
appropriate to each component
and its material.

Cleaning instructions

Content .. 18 19 20 21 ..
