Lexus RX L (2022 year). Manual in english - page 26

541

7-2. Steps to take in an emergency

When trouble

ises

from the tire. Removing the object
may widen the opening and
disenable emergency repair with
the kit.

• To avoid sealant leakage, move the

vehicle until the area of the punc-
ture, if known, is positioned at the
top of the tire.

■

A flat tire that cannot be repaired with

the emergency tire puncture repair kit

In the following cases, the tire cannot be

repaired with the emergency tire puncture

repair kit. Contact any authorized Lexus

retailer or Lexus authorized repairer, or any

reliable repairer.

●

When the tire is damaged due to driving

without sufficient air pressure

●

When the tire lost air pressure due to a

crack or damage in the tire sidewall

●

When the tire is visibly separated from

the wheel

●

When the cut or damage to the tread is 4

mm (0.16 in.) long or more

●

When the wheel is damaged

●

When 2 or more sharp objects, such as

nails or screws, have passed through the

tread on a single tire

●

When there is more than one hole or cut

in the damaged tire

●

When the sealant has expired

542

7-2. Steps to take in an emergency



RX300/350

Towing eyelet
Jack handle
Wheel nut wrench
Emergency tire puncture repair kit

Jack

: Use of the jack (



P.554, 555)

Location of the emergency tire puncture repair kit and towing eyelet

A
B
C
D

543

7-2. Steps to take in an emergency

When trouble

ises



RX350L

Towing eyelet
Jack handle
Wheel nut wrench
Emergency tire puncture repair kit

Jack

: Use of the jack (



P.554, 555)



Bottle

A
B
C
D

Emergency tire puncture repair
kit components

544

7-2. Steps to take in an emergency

Air release cap
Hose
Sticker



Compressor

Air pressure gauge
Rubber stopper
Power plug
Compressor switch

■

Note for checking the emergency tire

puncture repair kit

Check the sealant expiry date occasionally.

The expiry date is shown on the bottle. Do

not use sealant whose expiry date has

already passed. Otherwise, repairs con-

ducted using the emergency tire puncture

repair kit may not be performed properly.

■

Emergency tire puncture repair kit

●

The sealant has a limited life span. The

expiry date is marked on the bottle. The

sealant should be replaced before the

expiry date. Contact any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer for

replacement.

●

The sealant stored in the emergency tire

puncture repair kit can be used only once

to temporarily repair a single tire. If the

sealant has been used and needs to be

purchased, contact any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer. The compressor is

reusable.

●

The sealant can be used when the outside

temperature is from -40°C (-40°F) to

60°C (140°F).

●

The kit is exclusively designed for size

and type of tires originally installed on

your vehicle. Do not use it for tires that a

different size than the original ones, or for

any other purposes.

●

If the sealant gets on your clothes, it may

stain.

●

If the sealant adheres to a wheel or the

surface of the vehicle body, the stain may

not be removable if it is not cleaned at

once. Immediately wipe away the sealant

with a wet cloth.

●

During operation of the kit, a loud opera-

tion noise is produced. This does not indi-

cate a malfunction.

●

Do not use to check or to adjust the tire

pressure.

A
B
C

A
B
C
D

WARNING

■

Caution while driving

Observe the following precautions.

Failure to do so may cause an accident.

●

The emergency tire puncture repair kit

is made exclusively for your vehicle.

Do not use it on other vehicles.

●

Do not use the emergency tire punc-

ture repair kit for tires that are a differ-

ent size than the specified ones or for

any other purpose. Doing so may

cause the tires to not be repaired

properly.

■

Precautions for use of the sealant

●

Ingesting the sealant is hazardous to

your health. If you ingest sealant, con-

sume as much water as possible, then

immediately consult a doctor.

545

7-2. Steps to take in an emergency

When trouble

ises

Secure the deck board using the
hook. (



P.443, 445)

Take out the emergency tire punc-
ture repair kit.

Remove the valve cap from the
valve of the punctured tire.

Extend the hose. Remove the air
release cap from the hose.

Connect the hose to the valve.

Screw the end of hose clockwise as far as

possible.

Make sure that the compressor
switch is off.

WARNING

●

If sealant gets in eyes or adheres to

skin, immediately wash it off with water.

If discomfort persists, consult a doctor.

Taking out the emergency tire
puncture repair kit

Emergency repair method

546

7-2. Steps to take in an emergency

Lift the rubber stopper on the com-
pressor.

Remove the power plug from the
compressor.

Connect the power plug to the
power outlet socket. (



P.453)

Connect the bottle to the compres-
sor.

Make sure that the bottle is securely con-

nected.

Attach the sticker as shown.

Check the specified tire inflation
pressure.

Tire inflation pressure is specified on the

547

7-2. Steps to take in an emergency

When trouble

ises

label as shown. (



P.589)

Start the engine. (



P.259)

To inject the sealant and inflate the
tire, turn the compressor switch on.

Inflate the tire until the recom-
mended pressure is reached.

The sealant will be injected and the
pressure will spike to between 300
kPa (3.0 kgf/cm

or bar, 44 psi)

and 400 kPa (4.0 kgf/cm

or bar,

58 psi), then gradually decrease.
The air pressure gauge will display
the actual tire inflation pressure
about 1 to 5 minutes after the
switch is turned on.

Turn the compressor switch off and then

check the tire inflation pressure. Being

careful not to over inflate, check and

repeat the inflation procedure until the rec-

ommended tire inflation pressure is

reached.
If the tire inflation pressure is still lower than

the recommended level after inflation for

25 minutes with the switch on, the tire is

too damaged to be repaired. Turn the com-

pressor switch off and contact any author-

ized Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

548

7-2. Steps to take in an emergency

If the tire inflation pressure exceeds the

recommended level, let out some air to

adjust the tire inflation pressure. (



P.549,

589)

With the compressor switch off, dis-
connect the hose from the valve on
the tire and then pull out the power
plug from the power outlet socket.

Some sealant may leak when the hose is

removed.

Install the valve cap onto the valve
of the emergency repaired tire.

Attach the air release cap to the
end of the hose.

If the air release cap is not attached, the

sealant may leak and the vehicle may get

dirty.

Temporarily store the bottle in the
luggage compartment while it is
connected to the compressor.

To spread the liquid sealant evenly
within the tire, immediately drive
safety for about 5 km (3 miles)
below 80 km/h (50 mph).

After driving, stop your vehicle in a
safe place on a hard, flat surface
and reconnect the compressor.

Turn the compressor switch on and
wait for several seconds, then turn it
off. Check the tire inflation pres-
sure.

If the tire inflation pressure is below
130 kPa (1.3 kgf/cm2 or bar, 19 psi):
The puncture cannot be repaired.
Contact any authorized Lexus
retailer or Lexus authorized
repairer, or any reliable repairer.
If the tire inflation pressure is
between 130 kPa (1.3 kgf/cm2 or
bar, 19 psi) and a point below the
recommended level: The tire can
be repaired. Proceed to step

If the tire inflation pressure is at the
recommended level: Proceed to
step

549

7-2. Steps to take in an emergency

When trouble

ises

Turn the compressor switch on to
inflate the tire until the recom-
mended tire inflation pressure is
reached. Drive for about 5 km (3
miles) and then perform step

Attach the air release cap to the
end of the hose.

If the air release cap is not attached, the

sealant may leak and the vehicle may get

dirty.

Store the bottle in the luggage
compartment while it is connected
to the compressor.

Taking precautions to avoid sud-
den braking, sudden acceleration
and sharp turns, drive carefully at
under 80 km/h (50 mph) to any
authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer that is less than 100 km
(62 miles) away for tire repair or
replacement.

Make sure to tell any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer when you have them

repair or replace the tire that sealant is

injected.

■

If the tire is inflated to more than the

recommended level

Disconnect the hose from the valve.

Install the air release cap to the end of

the hose and push the protrusion on the

air release cap into the valve to let some

air out.

Disconnect the hose from the valve,

remove the air release cap from the

hose and then reconnect the hose.

Turn the compressor switch on and wait

for several seconds, then turn it off.

Check that the air pressure indicator

shows the recommended level.

(



P.589)

If the air pressure is lower than the recom-

mended level, turn the compressor switch

on again and repeat the inflation procedure

until the recommended pressure is

reached.

WARNING

■

When fixing the flat tire

●

Stop your vehicle in a safe and flat

area.

●

Do not touch the wheels or the area

around the brakes immediately after

the vehicle has been driven.

After the vehicle has been driven, the

wheels and the area around the brakes

may be extremely hot. Touching these

areas with hands, feet or other body

parts may result in burns.

●

Connect the valve and hose securely

with the tire installed on the vehicle. If

the hose is not properly connected to

the valve, air leakage may occur or

sealant may be sprayed out.

550

7-2. Steps to take in an emergency

WARNING

●

If the hose comes off the valve while

inflating the tire, there is a risk that the

hose will move abruptly due to air

pressure.

●

After inflation of the tire has com-

pleted, the sealant may splatter when

the hose is disconnected or some air is

let out of the tire.

●

Follow the operation procedure to

repair the tire. If the procedure is not

followed, the sealant may spray out.

●

Keep back from the tire while it is

being repaired, as there is a chance of

it bursting while the repair operation is

being performed. If you notice any

cracks or deformation of the tire, turn

off the compressor switch and stop the

repair operation immediately.

●

The kit may overheat if operated for a

long period of time. Do not operate

the compressor continuously for more

than 40 minutes.

●

Parts of the kit become hot during

operation. Be careful handling the kit

during and after operation. Do not

touch the metal part around the con-

necting area between the bottle and

compressor. It will be extremely hot.

●

Do not attach the vehicle speed warn-

ing sticker to an area other than the

one indicated. If the sticker is attached

to an area where an SRS airbag is

located, such as the pad of the steering

wheel, it may prevent the SRS airbag

from operating properly.

■

Driving to spread the liquid sealant

evenly

●

Drive the vehicle carefully at a low

speed. Be especially careful when

turning and cornering.

●

If the vehicle does not drive straight or

you feel a pull through the steering

wheel, stop the vehicle and check the

following:

• Tire condition. The tire may have sepa-

rated from the wheel.

• Tire inflation pressure. If tire inflation

pressure is 130 kPa (1.3 kgf/cm2 or

bar, 19 psi) or below, this may indicate

severe tire damage.

NOTICE

■

When performing an emergency

repair

●

Perform the emergency repair with-

out removing the nail or screw that has

punctured the tread of the tire. If the

object that has punctured the tire is

removed, repair by the emergency tire

puncture repair kit may not be possi-

ble.

●

The kit is not waterproof. Make sure

that the kit is not exposed to water,

such as when it is being used in the

rain.

●

Do not put the repair kit directly onto

dusty ground such as sand at the side

of the road. If the repair kit vacuums up

dust etc., a malfunction may occur.

●

Make sure to stand the kit with the bot-

tle vertical. The kit cannot work prop-

erly if it is laid on its side.

■

Handling the emergency tire punc-

ture repair kit

●

The compressor power source should

be 12 V DC suitable for vehicle use.

Do not connect the compressor to any

other source.

●

If gasoline splatters on the kit, the kit

may deteriorate. Take care not to allow

gasoline to contact it.

●

Store the kit in its assigned place out of

reach of children.

551

7-2. Steps to take in an emergency

When trouble

ises



Stop the vehicle in a safe place on a
hard, flat surface.



Set the parking brake.



Shift the shift lever to P.



Stop the engine.



Turn on the emergency flashers.
(



P.518)

NOTICE

●

Do not disassemble or modify the kit.

Do not subject parts such as the air

pressure indicator to impacts. This may

cause a malfunction.

■

To avoid damage to the tire pressure

warning valves and transmitters

When a tire is repaired with liquid seal-

ants, the tire pressure warning valve and

transmitter may not operate properly. If a

liquid sealant is used, contact any author-

ized Lexus retailer or Lexus authorized

repairer, or any reliable repairer or other

qualified service shop as soon as possi-

ble. After use of liquid sealant, make sure

to replace the tire pressure warning valve

and transmitter when repairing or

replacing the tire. (



P.495)

If you have a flat tire (vehi-
cles with a spare tire)

Your vehicle is equipped with a
spare tire. The flat tire can be
replaced with the spare tire.

For details about tires:



P.478

WARNING

■

If you have a flat tire

Do not continue driving with a flat tire.

Driving even a short distance with a flat

tire can damage the tire and the wheel

beyond repair, which could result in an

accident.

Before jacking up the vehicle

552

7-2. Steps to take in an emergency



Type A

Jack handle
Wheel nut wrench
Spare tire
Jack
Towing eyelet

Location of the spare tire, jack and tools

A
B
C
D

553

7-2. Steps to take in an emergency

When trouble

ises



Type B

Jack handle
Wheel nut wrench
Spare tire
Jack
Towing eyelet

A
B
C
D

554

7-2. Steps to take in an emergency



Type C

Jack handle
Wheel nut wrench
Spare tire
Jack
Towing eyelet
Adapter socket

A
B
C
D

E
F

WARNING

■

Using the tire jack

Observe the following precautions.

Improper use of the tire jack may cause

the vehicle to suddenly fall off the jack,

leading to death or serious injury.

●

Do not use the tire jack for any pur-

pose other than replacing tires or

installing and removing tire chains.

●

Only use the tire jack that comes with

this vehicle for replacing a flat tire. Do

not use it on other vehicles, and do not

use other tire jacks for replacing tires

on this vehicle.

●

Put the jack properly in its jack point.

●

Do not put any part of your body under

the vehicle while it is supported by the

jack.

555

7-2. Steps to take in an emergency

When trouble

ises

Secure the deck board using the
hook. (



P.443)

Disengage the hook and take out
the jack.

Type A and B: Remove the wheel nut

wrench and then the jack.

Type C: Remove the jack handle and then

the jack.



Type A

Secure the deck board using the
hook. (



P.443)

Loosen the center fastener that
secures the spare tire.



Type B

Secure the deck board using the
hook. (



P.443)

Remove the spare tire cover.

Loosen the center fastener that
secures the spare tire.

When taking out the spare tire, wear work-

ing gloves, firmly hold the spokes, and take

WARNING

●

Do not start the engine or drive the

vehicle while the vehicle is supported

by the jack.

●

Do not raise the vehicle while some-

one is inside.

●

When raising the vehicle, do not put an

object on or under the jack.

●

Do not raise the vehicle to a height

greater than that required to replace

the tire.

●

Use a jack stand if it is necessary to get

under the vehicle.

●

When lowering the vehicle, make sure

that there is no-one near the vehicle. If

there are people nearby, warn them

vocally before lowering.

Taking out the jack

Taking out the spare tire

556

7-2. Steps to take in an emergency

out the tire with the proper posture.

Spokes



Type C

Remove the deck board.

Remove the cover.

Attach the adapter socket to the
spare tire clamp bolt.

Assemble the jack handle exten-
sion.

Connect the jack handle to the
adapter socket. Turn the jack han-
dle counterclockwise.

The tire will be lowered completely to the

ground.
Turn the jack handle slowly to lower the

spare tire. If the handle is turned quickly,

the wire cable may come off the shaft

inside the unit and the tire may not be low-

ered.
If the spare tire cannot be lowered:



P.558

Content .. 24 25 26 27 ..
