Lexus RX L (2022 year). Manual in english - page 17

382

4-5. Using the driving support systems

■

When the accelerator pedal is depressed excessively

■

When the vehicle moves in the unintended direction due to the wrong shift
lever position



P.363

Types of sensors

WARNING

■

To ensure the Parking Support Brake

can operate properly

Observe the following precautions

regarding the sensors (



P.363). Failure

to do so may cause a sensor to not oper-

ate properly, and may cause an accident.

●

Do not modify, disassemble or paint

the sensors.

●

Do not replace a sensor with a part

other than a genuine part.

●

Do not subject a sensor or its sur-

rounding area to a strong impact.

●

Do not damage the sensors, and

always keep them clean.

383

4

4-5. Using the driving support systems

Driving

■

The Parking Support Brake function

(static object) will operate when

The function will operate when the PKSB

OFF indicator is not illuminated or flashing

(



P.83, 84) and all of the following condi-

tions are met:

●

Engine output restriction control

• The Parking Support Brake is enabled.

• The vehicle speed is 15 km/h (9 mph) or

less.

• There is a static object in the traveling

direction of the vehicle and 2 to 4 m (6 to

13 ft.) away.

• The Parking Support Brake determines

that a stronger-than-normal brake opera-

tion is necessary to avoid a collision.

●

Brake control

• Engine output restriction control is oper-

ating.

• The Parking Support Brake determines

that an immediate brake operation is nec-

essary to avoid a collision.

■

The Parking Support Brake function

(static objects) will stop operating when

The function will stop operating if any of the

following conditions are met:

●

Engine output restriction control

• The Parking Support Brake is disabled.

• The system determines that the collision

has become avoidable with normal brake

operation.

WARNING

■

Handling the suspension

Do not modify the suspension, as

changes to the height or inclination of the

vehicle may prevent the sensors from

detecting objects correctly or cause the

system to not operate or operate unnec-

essarily.

■

If the Parking Support Brake function

(static objects) operates unnecessar-

ily, such as at a railroad crossing

In the event that the Parking Support

Brake function (static objects) operates

unnecessarily, such as at a railroad cross-

ing, brake control will be canceled after

approximately 2 seconds, allowing you

to proceed forward and leave the area,

brake control can also be canceled by

depressing the brake pedal. Depressing

the accelerator pedal after brake control

is canceled will allow you to proceed for-

ward and leave the area.

■

Notes when washing the vehicle

Do not apply intensive bursts of water or

steam to the sensor area.
Doing so may result in the sensor mal-

functioning.

●

When using a high pressure washer to

wash the vehicle, do not spray the sen-

sors directly, as doing so may cause a

sensor to malfunction.

●

When using steam to clean the vehicle,

do not direct steam too close to the

sensors as doing so may cause a sen-

sor to malfunction.

■

When to disable the Parking Support

Brake

In the following situations, disable the

Parking Support Brake as the system

may operate even though there is no

possibility of a collision.

●

When inspecting the vehicle using a

chassis roller, chassis dynamo or free

roller

●

When loading the vehicle onto a boat,

truck or other transport vessel

●

If the suspension has been modified or

tires of a size other than specified are

installed

●

If the front of the vehicle is raised or

lowered due to the carried load

●

When equipment that may obstruct a

sensor is installed, such as a towing

eyelet, bumper protector (an addi-

tional trim strip, etc.), bicycle carrier, or

snow plow

●

When using an automatic car wash

384

4-5. Using the driving support systems

• The static object is no longer 2 to 4 m (6

to 13 ft.) away from the vehicle or in the

traveling direction of the vehicle.

●

Brake control

• The Parking Support Brake is disabled.

• Approximately 2 seconds have elapsed

since the vehicle was stopped by brake

control.

• The brake pedal is depressed after the

vehicle is stopped by brake control.

• The static object is no longer 2 to 4 m (6

to 13 ft.) away from the vehicle or in the

traveling direction of the vehicle.

■

Re-enabling the Parking Support Brake

function (static objects)



P.379

■

Detection range of the Parking Support

Brake function (static objects)

The detection range of the Parking Support

Brake function (static objects) differs from

the detection range of the Lexus parking

assist-sensor. (



P.367) Therefore, even if

the Lexus parking assist-sensor detects an

object and provides a warning, the Parking

Support Brake function (static objects) may

not start operating.

■

Objects that the Parking Support Brake

function (static objects) may not detect

The sensors may not be able to detect cer-

tain objects, such as the following:

●

Pedestrian

●

Cotton cloth, snow, and other materials

that are poor reflectors of ultrasonic

waves

●

Objects which are not perpendicular to

the ground, are not perpendicular to the

traveling direction of the vehicle, are une-

ven or are waving

●

Low objects

●

Thin objects such as wires, fences, ropes

and signposts

●

Objects that are extremely close to the

bumper

●

Sharply-angled objects

●

Tall objects with upper sections project-

ing outwards in the direction of your vehi-

cle

■

Situation in which the Parking Support

Brake function (static objects) may not

operate

When driving with the shift lever in N.

■

Lexus parking assist-sensor buzzer

Regardless of whether the Lexus parking

assist-sensor buzzer is enabled or not

(



P.364), if the Parking Support Brake

function (static objects) is enabled

(



P.375), the front or rear sensors detect

an object and brake control is performed,

the Lexus parking assist-sensor buzzer will

sound to notify the driver of the approxi-

mate distance to the object.

■

Situations in which the Parking Support

Brake function (static objects) may

operate even if there is no possibility of a

collision

In some situations, such as the following, the

Parking Support Brake function (static

objects) may operate even though there is

no possibility of a collision.

●

Vehicle surroundings

• When driving on a narrow road

• When driving on a gravel road or in an

area with tall grass

• When driving toward a banner, flag,

low-hanging branch or boom barrier

(such as those used at railroad crossings,

385

4

4-5. Using the driving support systems

Driving

toll gates and parking lots)

• When driving on a narrow path sur-

rounded by a structure, such as in a tun-

nel or on an iron bridge

• When parallel parking

• When there is a rut or hole in the surface

of the road

• When driving on a metal cover (grating),

such as those used for drainage ditches

• When driving on a steep slope

• If a sensor is hit by a large amount of

water, such as when driving on a flooded

road

●

Weather

• If a sensor is covered with ice, snow, dirt,

etc. (when cleared, the system will return

to normal)

• If heavy rain or water strikes a sensor

• When driving in inclement weather such

as fog, snow or a sandstorm

• When strong winds are blowing

●

Other ultrasonic wave sources

• When vehicle horns, vehicle detectors,

motorcycle engines, air brakes of large

vehicles, the clearance sonar of other

vehicles or other devices which produce

ultrasonic waves are near the vehicle

• If a sticker or an electronic component,

such as a backlit license plate (especially

fluorescent type), fog lights, fender pole

or wireless antenna is installed near a

sensor

●

Changes in the vehicle posture

• If the vehicle is significantly tilted

• If the front of the vehicle is raised or low-

ered due to the carried load

• If the orientation of a sensor has been

changed due to a collision or other

impact

■

Situations in which the Parking Support

Brake function (static objects) may not

operate properly

In some situations, such as the following, this

function may not operate properly.

●

Weather

• When a sensor or the area around a sen-

sor is extremely hot or cold

• When strong winds are blowing

• If a sensor is covered with ice, snow, dirt,

etc. (when cleared, the system will return

to normal)

• If heavy rain or water strikes a sensor

• When driving in inclement weather such

as fog, snow or a sandstorm

• When the sensor is frozen (Once the

sensor thaws, the system will return to

normal)

●

Vehicle surroundings

• When an object that cannot be detected

is between the vehicle and a detected

object

• If an object such as a vehicle, motorcycle,

bicycle or pedestrian cuts in front of the

vehicle or runs out from the side of the

vehicle

• The vehicle is approaching a tall or

curved curb.

• On an extremely bumpy road, on an

incline, on gravel, or on grass.

• If objects draw too close to the sensor.

●

Other ultrasonic waves sources

• When vehicle horns, vehicle detectors,

motorcycle engines, air brakes of large

vehicles, the clearance sonar of other

vehicles or other devices which produce

ultrasonic waves are near the vehicle

• If a sticker or an electronic component,

such as a backlit license plate (especially

fluorescent type), fog lights, fender pole

or wireless antenna is installed near a

386

4-5. Using the driving support systems

sensor

●

Changes in the vehicle posture

• If the vehicle is significantly tilted

• If the front of the vehicle is raised or low-

ered due to the carried load

• If the orientation of a sensor has been

changed due to a collision or other

impact

• When equipment that may obstruct a

sensor is installed, such as a bumper pro-

tector (an additional trim strip, etc.), bicy-

cle carrier, or snow plow

• If the suspension has been modified or

tires of a size other than specified are

installed

• If a sensor has been painted or covered

with a sticker, etc.

387

4

4-5. Using the driving support systems

Driving

*

: If  equipped

This function will operate in situations such as the following if a vehicle is detected
in the traveling direction of the vehicle.

■

When reversing, a vehicle is approaching and the brake pedal is not
depressed, or is depressed late



P.357

Parking Support Brake function (rear-crossing vehicles)

*

If a rear radar sensor detects a vehicle approaching from the right or left at the
rear of the vehicle and the system determines that the possibility of a collision
is high, this function will perform brake control to reduce the likelihood of an
impact with the approaching vehicle.

Examples of function operation

Types of sensors

WARNING

■

To ensure the Parking Support Brake

function (rear-crossing vehicles) can

operate properly

Observe the following precautions

regarding the rear side radar sensors

(



P.357). Failure to do so may cause a

sensor to not operate properly, and may

cause an accident.

●

Do not modify, disassemble or paint

the sensors.

388

4-5. Using the driving support systems

■

The Parking Support Brake function

(rear-crossing vehicles) will operate

when

The function will operate when the PKSB

OFF indicator is not illuminated or flashing

(



P.83, 84) and all of the following condi-

tions are met:

●

Engine output restriction control

• The Parking Support Brake is enabled.

• The vehicle speed is 15 km/h (9 mph) or

less.

• Vehicles which are approaching from the

right or left at the rear of the vehicle at a

traveling speed of less than approxi-

mately 8 km/h (5 mph)

• The shift lever is in R.

• The Parking Support Brake determines

that a stronger than normal brake opera-

tion is necessary to avoid a collision with

an approaching vehicle.

●

Brake control

• Engine  output  restriction control is oper-

ating.

• The Parking Support Brake determines

that an emergency brake operation is

necessary to avoid a collision with an

approaching vehicle.

■

The Parking Support Brake function

(rear-crossing vehicles) will stop operat-

ing when

The function will stop operating if any of the

following conditions are met:

●

Engine output restriction control

• The Parking Support Brake is disabled.

• The collision becomes avoidable with

normal brake operation.

• A vehicle is no longer approaching from

the right or left at the rear of the vehicle.

●

Brake control

• The Parking Support Brake is disabled.

• Approximately 2 seconds have elapsed

since the vehicle was stopped by brake

control.

• The brake pedal is depressed after the

vehicle is stopped by brake control.

• A vehicle is no longer approaching from

the right or left at the rear of the vehicle.

■

Re-enabling the Parking Support Brake

function (rear-crossing vehicles)



P.379

■

Detection area of the Parking Support

Brake function (rear-crossing vehicles)

The detection area of the Parking Support

Brake function (rear-crossing vehicles) dif-

fers from the detection area of the RCTA

function (



P.372). Therefore, even if the

RCTA function detects a vehicle and pro-

vides an alert, the Parking Support Brake

function (rear-crossing vehicles) may not

start operating.

■

Conditions under which the Parking

Support Brake function (rear-crossing

vehicles) will not detect a vehicle

The Parking Support Brake function

(rear-crossing vehicles) is not designed to

detect the following types of vehicles and/or

objects:

●

Vehicles approaching from directly

behind

●

Vehicles backing up in a parking space

next to your vehicle

●

Vehicles that the sensors cannot detect

due to obstructions

WARNING

●

Do not replace a rear side radar sen-

sor with a part other than a genuine

part.

●

Do not damage the rear side radar

sensors, and always keep the radar

sensors and their surrounding area on

the bumper clean.

●

If the area around a rear side radar

sensor is subjected to an impact, the

system may not operate properly due

to a sensor malfunction. Have the vehi-

cle inspected by any authorized Lexus

retailer or Lexus authorized repairer,

or any reliable repairer.

389

4

4-5. Using the driving support systems

Driving

●

Vehicles which suddenly accelerate or

decelerate near your vehicle

●

Guardrails, walls, signs, parked vehicles

and similar stationary objects

●

Small motorcycles, bicycles, pedestrians,
etc.

*

●

Vehicles moving away from your vehicle

●

Vehicles approaching from the parking
spaces next to your vehicle

*

●

Objects which are extremely close to a
radar sensor

*

●

Vehicles which are approaching from the

right or left at the rear of the vehicle at a

traveling speed of less than approxi-

mately 8 km/h (5 mph)

●

Vehicles which are approaching from the

right or left at the rear of the vehicle at a

traveling speed of more than approxi-

mately 24 km/h (15 mph)

*

: Depending on the conditions, detection

of a vehicle and/or object may occur.

■

PKSB buzzer

If the Parking Support Brake is enabled and

brake control is performed, a buzzer will

sound to notify the driver.

■

Situations in which the system may

operate even though there is no possi-

bility of a collision

In some situations such as the following, the

Parking Support Brake function

(rear-crossing vehicles) may operate even

though there is no possibility of a collision.

●

When the parking space faces a street

and vehicles are being driven on the

street

●

When a detected vehicle turns while

approaching the vehicle

●

When a vehicle passes by the side of your

vehicle

●

When the distance between your vehicle

and metal objects, such as a guardrail,

wall, sign, or parked vehicle, which may

reflect electrical waves toward the rear of

the vehicle, is short

●

When there are spinning objects near

your vehicle such as the fan of an air con-

ditioning unit

●

When water is splashed or sprayed

toward the rear bumper, such as from a

390

4-5. Using the driving support systems

sprinkler

■

Situations in which the Parking Support

Brake function (rear-crossing vehicles)

may not operate properly

In some situations, such as the following, the

radar sensors may not detect an object and

this function may not operate properly

●

Stationary objects

●

When a sensor or the area around a sen-

sor is extremely hot or cold

●

If the rear bumper is covered with ice,

snow, dirt, etc.

●

When it is raining heavily or water strikes

the vehicle

●

If the vehicle is significantly tilted

●

When equipment that may obstruct a

sensor is installed, such as a towing eye-

let, bumper protector (an additional trim

strip, etc.), bicycle carrier, or snow plow

●

If the suspension has been modified or

tires of a size other than specified are

installed

●

If the front of the vehicle is raised or low-

ered due to the carried load

●

If an electronic component, such as a

backlit license plate (especially fluores-

cent type), fog lights, fender pole or wire-

less antenna is installed near a radar

sensor

●

If the orientation of a radar sensor has

been changed

●

When multiple vehicles are approaching

with only a small gap between each vehi-

cle

●

If a vehicle is approaching the rear of

your vehicle rapidly

●

Situations in which the radar sensor may

not detect a vehicle

• When a vehicle approaches from the

right or left at the rear of the vehicle while

you are turning while backing up

• When turning while backing up

• When backing out of a shallow angle

parking spot

• When backing up on a slope with a sharp

change in grade

• When a vehicle turns into the detection

area

391

4

4-5. Using the driving support systems

Driving



Vehicles without Adaptive Variable
Suspension System

1

Normal mode

Provides an optimal balance of fuel econ-
omy, quietness, and dynamic performance.
Suitable for city driving.
Press the switch to change the driving
mode to normal mode when Eco drive
mode or sport mode is selected.

2

Eco drive mode

Helps the driver accelerate in an
eco-friendly manner and improve fuel
economy through moderate throttle char-
acteristics and by controlling the operation
of the air conditioning system (heat-

ing/cooling).
When not in Eco drive mode, if the driving
mode select switch is turned to the left, the
Eco drive mode indicator will come on.

3

Sport mode

Controls the transmission and engine to
provide quick, powerful acceleration. This
mode also changes the steering feel, mak-
ing it suitable for when agile driving
response is desired, such as when driving
on roads with many curves.
When not in sport mode, if the driving
mode select switch is turned to the right,
the “Sport” indicator will comes on.



Vehicles with Adaptive Variable
Suspension System

Except F SPORT models
F SPORT models

1

Normal mode/Custom mode

Normal mode and custom mode are
selected by pressing the driving mode
select switch. Each time the switch is

Driving mode select switch

The driving modes can be selected
to suit driving conditions.

Selecting a drive mode

A
B

392

4-5. Using the driving support systems

pressed, the driving mode changes
between normal mode and custom mode.
When custom mode is selected, the “Cus-
tom” indicator will be illuminated.
When Eco drive mode or sport mode is
selected, pressing the switch changes the
driving mode to normal mode.
• Normal  mode
Provides an optimal balance of fuel econ-
omy, quietness, and dynamic performance.
Suitable for city driving.
• Custom  mode
Allows you to drive with the following func-
tions set to your preferred settings. Cus-
tom mode settings can only be changed on
the drive mode customization display of
the Center Display. (



P.592)

2

Eco drive mode

Helps the driver accelerate in an
eco-friendly manner and improve fuel
economy through moderate throttle char-
acteristics and by controlling the operation
of the air conditioning system (heat-
ing/cooling).
When not in Eco drive mode, if the driving
mode select switch is turned to the left, the
Eco drive mode indicator will come on.

3

Sport mode

• Sport  S  mode

Controls the transmission and engine to
provide quick, powerful acceleration. This
mode is suitable for when agile driving
response is desired, such as when driving
on roads with many curves.
When not in Sport S mode, if the driving
mode select switch is turned to the right,
the “Sport S” indicator will come on.
• Sport S+ mode
Helps to ensure steering performance and
driving stability by simultaneously con-
trolling the steering and suspension in
addition to the transmission and engine.
Suitable for sportier driving.
When in Sport S mode, if the driving mode
select switch is turned to the right, the
“Sport S+” indicator will come on.

■

Operation of the air conditioning sys-

tem in Eco drive mode

Eco drive mode controls the heating/cool-

ing operations and fan speed of the air con-

ditioning system to enhance fuel efficiency.

To improve air conditioning performance,

adjust the fan speed or turn off Eco drive

mode.

■

Automatic deactivation of sport mode

and custom mode

If the engine switch is turned off after driv-

ing in sport mode or custom mode, the

drive mode will be changed to normal

mode.

■

Driving mode pop-up display (12.3-inch

display only)

When the driving mode is changed, the

selected driving mode will be temporarily

displayed on the side display. (



P.410)

Function

Setting

Powertrain

Normal

Power

Eco

Chassis

Normal

Sport

Air conditioning sys-
tem

Normal

Eco

393

4

4-5. Using the driving support systems

Driving

Press the switch.
The torque of the engine is distributed
to the rear wheels to the maximum
extent possible in accordance with
driving conditions.
Pressing the switch again cancels
all-wheel drive lock mode and returns
the Dynamic Torque Control AWD
system to normal mode. (



P.395)



RX300



RX350/RX350L

■

All-wheel drive lock mode can be oper-

ated when

The engine switch is in IGNITION ON

mode.

■

Automatic release for the all-wheel

drive lock mode

●

All-wheel drive lock mode is canceled

when the brakes are applied to ensure

the ABS and VSC systems operate effec-

tively.

●

All-wheel drive lock mode is canceled

when the vehicle speed exceeds 40

km/h (25 mph).

All-wheel drive lock switch
(AWD models)

All-wheel drive lock mode can be
used when a large amount of drive
power needs to be applied to all the
wheels, such as when the vehicle
gets stuck in mud and you need to
free it.

Using All-wheel drive lock mode

394

4-5. Using the driving support systems

*

: If  equipped

■

If “Exhaust Filter Full See Owner's Man-

ual” is shown on the multi-information

display

●

The message may be displayed while

high load driving with particulate matter

accumulating.

●

Engine output (engine speed) is

restricted when a certain amount of par-

ticulate matter accumulates, however, it is

possible to drive the vehicle unless the

malfunction indicator lamp comes on.

●

Particulate matter can accumulate more

quickly if the vehicle is frequently driven

short trips or at low speeds, or if the

engine is regularly started in an

extremely cold environment. Excessive

accumulation of particulate matter can

be prevented by periodically driving long

distances continuously with intermittent

releasing of the accelerator pedal, such

as when driving on highways and free-

ways.

■

If the malfunction indicator lamp comes

on or “Engine Maintenance Required

Visit Your Dealer” is shown on the

multi-information display

The amount of accumulated particulate

matter has exceeded a certain level. Have

the vehicle inspected by any authorized

Lexus retailer or Lexus authorized repairer,

or any reliable repairer immediately.

GPF (Gasoline Particulate
Filter) system

*

The GPF system collects particu-
late matter in the exhaust gas by
using an exhaust gas filter. The sys-
tem will operate to regenerate the
filter automatically, depending on
the vehicle conditions.

NOTICE

■

To prevent the GPF system from not

operating properly

●

Do not use fuel other than the speci-

fied type

●

Do not modify the exhaust pipes

395

4

4-5. Using the driving support systems

Driving

■

ABS (Anti-lock Brake System)

Helps to prevent wheel lock when the
brakes are applied suddenly, or if the
brakes are applied while driving on a
slippery road surface

■

Brake assist

Generates an increased level of brak-
ing force after the brake pedal is
depressed when the system detects a
panic stop situation

■

VSC (Vehicle Stability Control)

Helps the driver to control skidding
when swerving suddenly or turning on
slippery road surfaces

■

VSC+ (Vehicle Stability Control+)

Provides cooperative control of the
ABS, TRC, VSC and EPS.
Helps to maintain directional stability
when swerving on slippery road sur-
faces by controlling steering perfor-
mance.

■

Trailer Sway Control (if equipped)

Helps the driver to control trailer sway
by selectively applying brake pressure
for individual wheels and reducing
driving torque when trailer sway is
detected.

■

TRC (Traction Control)

Helps to maintain drive power and pre-
vent the drive wheels from spinning
when starting the vehicle or accelerat-
ing on slippery roads

■

Active Cornering Assist (ACA)

Helps to prevent the vehicle from drift-
ing to the outer side by performing
inner wheel brake control when
attempting to accelerate while turning

■

Hill-start assist control

Helps to reduce the backward move-
ment of the vehicle when starting on an
uphill

■

EPS (Electric Power Steering)

Employs an electric motor to reduce
the amount of effort needed to turn the
steering wheel

■

Dynamic Torque Control AWD
system (AWD models)

Automatically switches from
front-wheel drive to all-wheel drive
(AWD) according to the driving condi-
tions, helping to ensure reliable han-
dling and stability. Examples of
conditions where the system will switch
to AWD are when cornering, going
uphill, starting off or accelerating, and
when the road surface is slippery due
to snow, rain, etc.

Driving assist systems

To keep driving safety and perfor-
mance, the following systems oper-
ate automatically in response to
various driving situations. Be aware,
however, that these systems are
supplementary and should not be
relied upon too heavily when oper-
ating the vehicle.

Summary of the driving assist
systems

396

4-5. Using the driving support systems

■

Adaptive Variable Suspension Sys-
tem (if equipped)

Controls the damping force of the
shock absorber of each wheel accord-
ing to the road and driving conditions,
helping achieve a comfortable ride,
excellent driveability and a high level of
stability.
If Sport S+ mode is selected using the
driving mode select switch, the damp-
ing force will become more suitable for
sporty driving. (



P.391)

■

VDIM (Vehicle Dynamics Inte-
grated Management) (if equipped)

Provides integrated control of the
ABS, brake assist, TRC, VSC, hill-start
assist control and EPS systems
Helps to maintain vehicle stability when
swerving on slippery road surfaces by
controlling the brakes, engine output
and steering assist.

■

Emergency brake signal

When the brakes are applied suddenly,
the stop lights automatically flash to
alert the vehicle behind.

■

The Secondary Collision Brake

When the SRS airbag sensor detects a
collision and the system operates, the
brakes and brake lights are automati-
cally controlled to reduce the vehicle
speed and help reduce the possibility
of further damage due to a secondary
collision.

■

When the TRC/VSC/Trailer Sway Con-

trol systems are operating

The slip indicator light will flash while the

TRC/VSC/Trailer Sway Control systems

are operating.

■

Disabling the TRC system

If the vehicle gets stuck in mud, dirt or snow,

the TRC system may reduce power from
the engine to the wheels. Pressing the



switch to turn the system off may make it

easier for you to rock the vehicle in order to

free it.
To turn the TRC system off, quickly press
and release the

 switch.

The “Traction Control Turned Off” will be
shown on the multi-information display.

Press the

 switch again to turn the sys-

tem back on.

■

Turning off both TRC, VSC and Trailer

Sway Control systems

To turn the TRC, VSC and Trailer Sway

Control systems off, press and hold the

 switch for more than 3 seconds while

the vehicle is stopped.
The VSC OFF indicator light will come on
and the “Traction Control Turned Off” will
be shown on the multi-information display.

*

397

4

4-5. Using the driving support systems

Driving

Press the

 switch again to turn the sys-

tem back on.

*

: On vehicles with PCS (Pre-Collision

System), PCS will also be disabled (only
Pre-Collision warning is available). The
PCS warning light will come on and a
message will be displayed on the
multi-information display. (



P.304)

■

When the message is displayed on the

multi-information display showing that
TRC has been disabled even if the



switch has not been pressed

TRC is temporary deactivated. If the infor-

mation continues to show, contact any

authorized Lexus retailer or Lexus author-

ized repairer, or any reliable repairer.

■

Operating conditions of hill-start assist

control

When the following four conditions are met,

the hill-start assist control will operate:

●

The shift lever is in a position other than P

or N (when starting off forward/back-

ward on an upward incline)

●

The vehicle is stopped

●

The accelerator pedal is not depressed

●

The parking brake is not engaged

■

Automatic system cancelation of

hill-start assist control

The hill-start assist control will turn off in any

of the following situations:

●

The shift lever is shifted to P or N

●

The accelerator pedal is depressed

●

The parking brake is engaged

●

2 seconds at maximum elapsed after the

brake pedal is released

■

Sounds and vibrations caused by the

ABS, brake assist, VSC, Trailer Sway

Control, TRC and hill-start assist control

systems

●

A sound may be heard from the engine

compartment when the brake pedal is

depressed repeatedly, when the engine is

started or just after the vehicle begins to

move. This sound does not indicate that a

malfunction has occurred in any of these

systems.

●

Any of the following conditions may

occur when the above systems are oper-

ating. None of these indicates that a mal-

function has occurred.

• Vibrations may be felt through the vehicle

body and steering.

• A motor sound may be heard also after

the vehicle comes to a stop.

• The brake pedal may pulsate slightly after

the ABS is activated.

• The brake pedal may move down slightly

after the ABS is activated.

■

Active Cornering Assist operation

sounds and vibrations

When the Active Cornering Assist is oper-

ated, operation sounds and vibrations may

be generated from the brake system, but

this is not a malfunction.

■

EPS operation sound

When the steering wheel is operated, a

motor sound (whirring sound) may be

heard. This does not indicate a malfunction.

■

Reduced effectiveness of the EPS sys-

tem

The effectiveness of the EPS system is

reduced to prevent the system from over-

heating when there is frequent steering

input over an extended period of time. The

steering wheel may feel heavy as a result.

Should this occur, refrain from excessive

steering input or stop the vehicle and turn

the engine off. The EPS system should

return to normal within 10 minutes.

■

Automatic reactivation of TRC, Trailer

Sway Control and VSC systems

After turning the TRC, Trailer Sway Control

and VSC systems off, the systems will be

automatically re-enabled in the following

situations:

●

When the engine switch is turned off

●

If only the TRC system is turned off, the

TRC will turn on when vehicle speed

increases

If both the TRC and VSC systems are
