138

3-3. Adjusting the seats

*

: If  equipped

When all of the following have been
performed, the driver’s seat and steer-
ing wheel are automatically adjusted to
a position that allows driver to enter
and exit the vehicle easily.
• The shift lever has been shifted to P.
• The power switch has been turned

off.

• The driver’s seat belt has been

unfastened.

When any of the following has been
performed, the driver’s seat and steer-

ing wheel automatically return to their
original positions.
• The power switch has been turned

to ACCESSORY mode or ON
mode.

• The driver’s seat belt has been fas-

tened.

■

Operation of the power easy access sys-

tem

When exiting the vehicle, the power easy

access system may not operate if the seat is

already close to the rearmost position, etc.

■

Customization

The seat movement amount settings of the

power easy access system can be custom-

ized. (Customizable features:



P.443)

1

Check that the shift lever is in P.

2

Turn the power switch to ON
mode.

3

Adjust the driver’s seat, steering
wheel and outside rear view mir-
rors to the desired positions.

4

While pressing the “SET” button, or
within 3 seconds after the “SET”
button is pressed, press button “1”,
“2” or “3” until the buzzer sounds.

If the selected button has already been

preset, the previously recorded position

Driving position memory

*

This feature automatically adjusts
the front seats, steering wheel and
outside rear view mirrors to make
entering and exiting the vehicle
easier or to suit your preferences.
Three different driving positions
can be recorded into memory.
Each electronic key (including a
card key) can be registered to
recall your preferred driving posi-
tion.

Enabling easier driver entry and
exit (Power easy access system)

Recording a driving position into
memory

139

3-3. Adjusting the seats

3

Be

fore
 dri
ving

will be overwritten.

■

Seat positions that can be memorized

(



P.132)

The adjusted positions other than the posi-

tion adjusted by lumbar support switch can

be recorded.

■

In order to correctly use the driving

position memory function

If a seat position is already in the furthest

possible position and the seat is operated in

the same direction, the recorded position

may be slightly different when it is recalled.

1

Check that the shift lever is in P.

2

Turn the power switch to ON
mode.

3

Press one of the buttons for the
driving position you want to recall
until the buzzer sounds.

■

To stop the position recall operation

part-way through

Perform any of the following:

●

Press the “SET” button.

●

Press button “1”, “2” or “3”.

●

Operate any of the seat adjustment

switches (only cancels seat position

recall).

●

Operate the tilt and telescopic steering

control switch (only cancels steering

wheel position recall).

■

Operating the driving position memory

after turning the power switch off

Recorded seat positions can be activated

up to 180 seconds after the driver’s door is

opened and another 60 seconds after it is

closed again.

■

Registering procedure

Record your driving position to button
“1”, “2” or “3” before performing the
following:
Carry only the key you want to register,
and then close the driver’s door.
If 2 or more keys are in the vehicle, the

WARNING

■

Seat adjustment caution

Take care during seat adjustment so that

the seat does not strike the rear passen-

ger or squeeze your body against the

steering wheel.

Recalling a driving position

Registering/canceling/recall a
driving position to an electronic
key (memory recall function)

140

3-3. Adjusting the seats

driving position cannot be recorded
properly.

1

Check that the shift lever is in P.

2

Turn the power switch to ON
mode.

3

Recall the driving position that you
want to record.

4

While pressing the recalled button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds.

If the driving position could not be regis-

tered, the buzzer sounds continuously for

approximately 3 seconds.

■

Cancelation procedure

1

Carry only the key you want to can-
cel and then close the driver’s door.
If 2 or more keys are in the vehicle,
the driving position cannot be can-
celed properly.

2

Turn the power switch to ON
mode.

3

While pressing the “SET” button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds twice.

If it could not be canceled, the buzzer

sounds continuously for approximately 3

seconds.

■

Recall procedure

1

Make sure that the doors are
locked before recalling the driving
position. Carry the electronic key
that has been registered to the driv-
ing position, and then unlock and
open the driver’s door using the
smart access system with push-but-
ton start or wireless remote control.

The driving position will move to the

recorded position (not including the steer-

ing wheel). However, the seat will move to

a position slightly behind the recorded

position in order to make entering the vehi-

cle easier.

If the driving position is in a position that

has already been recorded, the seat and

outside rear view mirrors will not move.

2

Turn the power switch to ACCES-
SORY mode or ON mode, or fas-
ten a seat belt.

The seat and steering wheel will move to

the recorded position.

■

Recalling the driving position using the

memory recall function

●

Different driving positions can be regis-

tered for each electronic key. Therefore,

the driving position that is recalled may

be different depending on the key being

carried.

●

If a door other than the driver’s door is

unlocked with the smart access system

with push-button start, the driving posi-

tion cannot be recalled. In this case, press

the driving position button which has

been set.

■

Customization

The unlock door settings of the memory

recall function can be customized. (Cus-

tomizable features:



P.443)

141

3-3. Adjusting the seats

3

Be

fore
 dri
ving

■

Front seats

1

Up

Pull the head restraints up.

2

Down

Push the head restraint down while press-
ing the lock release button

.

■

Rear seats

1

Up

Pull the head restraints up.

2

Down

Push the head restraint down while press-
ing the lock release button

.

■

Adjusting the height of the head

restraints

Make sure that the head restraints are

adjusted so that the center of the head

restraint is closest to the top of your ears.

■

Adjusting the center rear seat head

restraint

Always raise the head restraint one level

from the stowed position when using.

The position of the front head restraint
can be adjusted forward in 4 stages.

If the head restraint is pulled forward from
the foremost position, it will return to the
rearmost position.

Head restraints

Head restraints are provided for all
seats.

WARNING

■

Head restraint precautions

Observe the following precautions

regarding the head restraints.

Failure to do so may result in death or

serious injury.

●

Use the head restraints designed for

each respective seat.

●

Adjust the head restraints to the cor-

rect position at all times.

●

After adjusting the head restraints,

push down on them and make sure

they are locked in position.

●

Do not drive with the head restraints

removed.

Vertical adjustment

A

Horizontal adjustment (if
equipped)

A

142

3-3. Adjusting the seats

Pull the head restraint up while press-
ing the lock release button  .
If the head restraint touches the ceiling,
making the removal difficult, change
the seat height or angle. (



P.132, 133)

Align the head restraint with the instal-
lation holes and push it down to the
lock position.

Press and hold the lock release button



when lowering the head restraint.

Removing the head restraints

Installing the head restraints

A

A

143

3-4. Adjusting the steering wheel and mirrors

3

Be

fore
 dri
ving

3-4.Adjusting the steering wheel and mirrors



Manual type

1

Hold the steering wheel and push
the lever down.

2

Adjust to the ideal position by mov-
ing the steering wheel horizontally
and vertically.

After adjustment, pull the lever up to

secure the steering wheel.



Power type

Operating the switch moves the steer-
ing wheel in the following directions:

1

Up

2

Down

3

Toward the driver

4

Away from the driver

■

The steering wheel can be adjusted

when (power type)

The power switch is in ACCESSORY or
ON mode

*

.

*

: If the driver’s seat belt is fastened, the

steering wheel can be adjusted regard-
less of power switch mode.

■

Automatic adjustment of the steering

position (if equipped)

A desired steering position can be entered

to memory and recalled automatically by

the driving position memory system.

(



P.138)

■

Power easy access system (if equipped)

The steering wheel and driver’s seat move

in accordance with power switch mode and

the driver’s seat belt condition. (



P.138)

■

After adjusting the steering wheel

(manual type)

Make sure that the steering wheel is

securely locked.
The horn may not sound if the steering

wheel is not securely locked.

Steering wheel

Adjustment procedure

144

3-4. Adjusting the steering wheel and mirrors

To sound the horn, press on or close to
the

mark.

The height of the rear view mirror can
be adjusted to suit your driving pos-
ture.
Adjust the height of the rear view mir-
ror by moving it up and down.

Responding to the level of brightness
of the headlights of vehicles behind, the
reflected light is automatically
reduced.



Type A

Changing automatic anti-glare func-
tion mode on/off

WARNING

■

Caution while driving

Do not adjust the steering wheel while

driving.

Doing so may cause the driver to mis-

handle the vehicle and cause an acci-

dent, resulting in death or serious injury.

■

After adjusting the steering wheel

(manual type)

Make sure that the steering wheel is

securely locked.
Otherwise, the steering wheel may move

suddenly, possibly causing an accident,

resulting in death or serious injury.

Sounding the horn

Inside rear view mirror

The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.

Adjusting the height of rear view
mirror

WARNING

■

Caution while driving

Do not adjust the position of the mirror

while driving.

Doing so may lead to mishandling of the

vehicle and cause an accident, resulting

in death or serious injury.

Anti-glare function

145

3-4. Adjusting the steering wheel and mirrors

3

Be

fore
 dri
ving

When the automatic anti-glare function is
in ON mode, the indicator

 illuminates.

The function will set to ON mode each
time the power switch is turned to ON
mode.
Pressing the button turns the function to
OFF mode. (The indicator

 also turns

off.)



Type B

Changing automatic anti-glare func-
tion mode on/off

When the automatic anti-glare function is
in ON mode, the indicator

 illuminates.

The function will set to ON mode each
time the power switch is turned to ON
mode.
Pressing the button turns the function to
OFF mode. (The indicator

 also turns

off.)

■

To prevent sensor error

To ensure that the sensors operate properly,

do not touch or cover them.



Type A



Type B

A

A

A

A

146

3-4. Adjusting the steering wheel and mirrors

1

To select a mirror to adjust, press
the switch.

Left

Right

2

To adjust the mirror, press the
switch.

Up

Right

Down

Left

■

Mirror angle can be adjusted when

The power switch is in ACCESSORY or

ON mode.

■

When using in cold weather

Vehicles with driving position memory:

When used in cold weather during reverse

driving, the door mirror could be frozen and

may not automatically point the mirror sur-

face downward. In this event, remove any

ice and snow from the mirror surface.

■

Defogging the mirrors

The outside rear view mirrors can be

cleared using the mirror defoggers. Turn on

the rear window defogger to turn on the

outside rear view mirror defoggers.

(



P.292)

■

Auto anti-glare function

When the anti-glare inside rear view mirror

is set to automatic mode, the outside rear

view mirrors will activate in conjunction with

the anti-glare inside rear view mirror to

reduce reflected light. (



P.144)

■

Automatic adjustment of the mirror

angle (vehicles with driving position

memory)

A desired mirror face angle can be entered

to memory and recalled automatically by

Outside rear view mirrors

For safe driving, adjust the mirror
angles to secure visibility before
driving.

WARNING

■

When driving the vehicle

Observe the following precautions while

driving.
Failure to do so may result in loss of con-

trol of the vehicle and cause an accident,

resulting in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side

mirrors must be extended and prop-

erly adjusted before driving.

■

When the mirror defoggers are oper-

ating

Do not touch the rear view mirror sur-

faces, as they can become very hot and

burn you.

Adjustment procedure

A
B

A
B
C
D

147

3-4. Adjusting the steering wheel and mirrors

3

Be

fore
 dri
ving

the driving position memory. (



P.138)

■

Linked mirror function when reversing

(vehicles with driving position memory)

When the mirror select switch is in the “L”

or “R” position, the outside rear view mir-

rors will automatically angle downwards

when the vehicle is reversing in order to

give a better view of the ground.

To disable this function, move the mirror

select switch to the neutral position

(between “L” or “R”)
With the shift lever in R, adjust the mirror

angle to a desired position to set the mirror

angle used when the vehicle is reversing.
The adjusted angle will be memorized and

the mirror will automatically tilt to the mem-

orized angle whenever the shift lever is

shifted to R from next time.
The memorized downward tilt position of

the mirror is linked to the normal position

(angle adjusted with the shift lever in other

than R). Therefore, if the normal position is

changed after adjustment, the tilt position

will also change.
When the normal position is changed, read-

just the angle in reversing.
When used in cold weather, the door mirror

could be frozen and may not automatically

point the mirror surface downward. In this

event, remove any ice and snow from the

mirror surface.

1

Folds the mirrors

2

Extends the mirrors

Putting the outside rear view mirror folding
switch in the neutral position sets the mir-
rors to automatic mode. Automatic mode
allows the folding or extending of the mir-
rors to be linked to locking/unlocking of
the doors.

■

When using in cold weather

When automatic mode is used in cold

weather, the door mirror could freeze up

and automatic stowing and return may not

be possible. In this event, after removing any

ice and snow from the door mirror, operate

the mirror using manual mode or move it by

hand.

■

Customization

The automatic mirror folding and extending

operation can be changed. (Customizable

features:



P.443)

Folding and extending the mir-
rors

WARNING

■

When a mirror is moving

To avoid personal injury and mirror mal-

function, be careful not to get your hand

caught by the moving mirror.

148

3-5. Opening, closing the windows and moon roof

3-5.Opening, closing the windows and moon roof

The power windows can be opened
and closed by a one-touch operation of
the switches.

1

Closing

2

One-touch closing

*

3

Opening

4

One-touch opening

*

*

: To stop the window partway, operate the

switch in the opposite direction.

■

The power windows can be operated

when

The power switch is in ON mode.

■

Operating the power windows after

turning the hybrid system off

The power windows can be operated for

approximately 45 seconds even after the

power switch is turned to ACCESSORY

mode or turned off. They cannot, however,

be operated once either front door is

opened.

■

Jam protection function

If an object becomes jammed between the

window and the window frame while the

window is closing, window movement is

stopped and the window is opened slightly.

■

Catch protection function

If an object becomes caught between the

door and window while the window is open-

ing, window movement is stopped.

■

When the window cannot be opened or

closed

When the jam protection function or catch

protection function operates unusually and

the door window cannot be opened or

closed, perform the following operations

with the power window switch of that door.

●

Stop the vehicle. With the power switch in

ON mode, within 4 seconds of the jam

protection function or catch protection

function activating, continuously operate

the power window switch in the one-

touch closing direction or one-touch

opening direction so that the door win-

dow can be opened and closed.

●

If the door window cannot be opened

and closed even when performing the

above operations, perform the following

procedure for function initialization.

1

Turn the power switch to ON mode.

2

Pull and hold the power window switch

in the one-touch closing direction and

completely close the door window.

3

Release the power window switch for a

moment, resume pulling the switch in

the one-touch closing direction, and

hold it there for approximately 6 sec-

onds or more.

4

Press and hold the power window

switch in the one-touch opening direc-

tion. After the door window is com-

pletely opened, continue holding the

switch fan additional 1 second or more.

5

Release the power window switch for a

moment, resume pushing the switch in

the one-touch opening direction, and

hold it there for approximately 4 sec-

onds or more.

6

Pull and hold the power window switch

in the one-touch closing direction

again. After the door window is com-

pletely closed, continue holding the

switch for a further 1 second or more.

If you release the switch while the window is

moving, start again from the beginning.

If the window reverses and cannot be fully

Power windows

Opening and closing the power
windows

149

3-5. Opening, closing the windows and moon roof

3

Be

fore
 dri
ving

closed or opened, have the vehicle

inspected by your Lexus dealer.

■

Door lock linked window operation

●

The power windows can be opened and
closed using the mechanical key.

*



(



P.413)

●

The power windows can be opened using
the wireless remote control.

*

 (



P.110)

*

: These settings must be customized at

your Lexus dealer.

■

Power windows open warning buzzer

The buzzer sounds and a message is shown

on the multi-information display in the

instrument cluster when the power switch is

turned off and the driver’s door is opened

with the power windows open.

■

Customization

Setting (e.g. linked door lock operation) can

be changed.

(Customizable features:



P.443)

This function is designed to prevent
children from accidentally opening or
closing a passenger window.
Press the switch down to lock the pas-
senger window.

WARNING

Observe the following precautions.
Failure to do so may result in death or

serious injury.

■

Closing the windows

●

The driver is responsible for all the

power window operations, including

the operation for the passengers. In

order to prevent accidental operation,

especially by a child, do not let a child

operate the power windows. It is possi-

ble for children and other passengers

to have body parts caught in the power

window. Also, when riding with a child,

it is recommended to use the window

lock switch. (



P.149)

●

Check to make sure that all passen-

gers do not have any part of their body

in a position where it could be caught

when a window is being operated.

●

When using the wireless remote con-

trol or mechanical key and operating

the power windows, operate the

power window after checking to make

sure that there is no possibility of any

passenger having any of their body

parts caught in the window. Also do

not let a child operate window by the

mechanical key. It is possible for chil-

dren and other passengers to get

caught in the power window.

●

When exiting the vehicle, turn the

power switch off, carry the key and exit

the vehicle along with the child. There

may be accidental operation, due to

mischief, etc., that may possibly lead to

an accident.

■

Jam protection function

●

Never use any part of your body to

intentionally activate the jam protec-

tion function.

●

The jam protection function may not

work if something gets jammed just

before the window is fully closed. Be

careful not to get any part of your body

jammed in the window.

■

Catch protection function

●

Never use any part of your body or

clothing to intentionally activate the

catch protection function.

●

The catch protection function may not

work if something gets caught just

before the window is fully opened. Be

careful not to get any part of your body

or clothing caught in the window.

Preventing accidental operation
(window lock switch)

150

3-5. Opening, closing the windows and moon roof

*

: If equipped

■

Opening and closing

1

Open

Press and hold the “OPEN” switch. The
moon roof tilts up and then fully opens
automatically.

*

2

Close

Press and hold the “CLOSE” switch. The
moon roof fully closes automatically.

*

*

: Lightly press either end of the moon roof

open/close switch to stop the moon roof
while it is operating.

Moon roof

*

For comfortable cabin experience,
the ceiling (moon roof) can be
opened or tilted up.

WARNING

■

Opening the moon roof

Observe the following precautions.
Failure to do so may cause death or seri-

ous injury.

●

Do not allow any passengers to put

their hands or heads outside the vehi-

cle while it is moving.

●

Do not sit on top of the moon roof.

Operation instructions

151

3-5. Opening, closing the windows and moon roof

3

Be

fore
 dri
ving

■

Tilting up and down

1

Tilt up

Press and hold the “UP” switch. It automat-
ically opens until the tilt up stop position.

*

2

Tilt down

Press and hold the “DOWN” switch. The
moon roof full close automatically.

*

*

: Lightly press either end of the moon roof

switch to stop the moon roof while it is
operating.

■

The moon roof can be operated when

The power switch is in ON mode.

■

Jam protection function

If an object is detected between the moon

roof and the frame while the moon roof is

closing or tilting down, travel is stopped and

the moon roof opens slightly.

■

Sunshade

The sunshade can be opened and closed

manually. However, the sunshade will open

automatically when the moon roof is

opened.

■

When the moon roof does not close nor-

mally

Perform the following procedure:

●

If the moon roof closes but then re-opens

slightly

1

Stop the vehicle.

2

Press and hold the “CLOSE” switch.

*1

The moon roof will close, reopen and pause
for approximately 10 seconds.

*2



Then it will close again and tilt down. Finally

it will stop.

3

Check to make sure that the moon roof

completely stops and then release the

switch.

●

If the moon roof tilts down but then tilts

back up

1

Stop the vehicle.

2

Press and hold the “DOWN” switch.

*1

The moon roof will close, reopen and pause

for approximately 10 seconds in the tilt up
position.

*2



Then it will close again. Finally it will stop.

3

Check to make sure that the moon roof

has completely stopped and then

release the switch.

*1

: If the switch is released at the incorrect

time, the procedure will have to be per-
formed again from the beginning.

*2

: If the switch is released after the above

mentioned 10 second pause, automatic
operation will be disabled. In that case,
perform the moon roof initialization by
referring to “When tilt up/down or moon
roof opening and closing can be done
but automatic full opening and closing
cannot be done” on P.151.

If the moon roof does not fully close even

after performing the above procedure cor-

rectly, have the vehicle inspected by your

Lexus dealer.

■

When the moon roof does not move

normally

When the opening and closing operation or

automatic opening function of the moon

roof does not move normally, perform the

following initialization procedures.

1

Turn the power switch to ON mode.

2

Operate the moon roof.

The initialization method changes depend-

ing on the contents that can be operated.

●

If only the tilt up operations can be done

when the moon roof is closed

3

Press and hold the “DOWN” or

“CLOSE” switch.

Open until the tilt up stop position. After

that the moon roof opens and completely

152

3-5. Opening, closing the windows and moon roof

closes.

After that tilt up once again and stop at the

completely closed position.

4

Confirm that moon roof has completely

stopped and release the switch.

●

If the moon roof can only be closed when

the moon roof is partially opened

3

Press and hold the “DOWN” or

“CLOSE” switch.

Fully close the moon roof, tilt up and open it

close to the fully open position. After that,

fully close the moon roof and tilt up once

again, then stop the moon roof in the fully

closed position.

4

Confirm that moon roof has completely

stopped and release the switch.

●

When tilt up/down or moon roof opening

and closing can be done but automatic

full opening and closing cannot be done

3

Press the “OPEN” switch and fully

open.

4

Press the “CLOSE” switch and fully

close.

5

Press the “UP” switch and tilt up until

the tilt up stop position.

6

Press the “DOWN” switch and tilt

down.

If the switch is released before any step is

completes, the procedure will have to be

performed again from the beginning.
If the opening and closing operations or

automatic opening function does not move

as normal, even after performing the above

mentioned operations, have the vehicle

inspected by your Lexus dealer.

■

Moon roof open warning buzzer

The buzzer sounds and a message is shown

on the multi-information display in the

instrument cluster when the power switch is

turned off and the driver’s door is opened

with the moon roof open.

■

Door lock linked moon roof operation

●

The moon roof can be opened and
closed using the mechanical key.

*



(



P.413)

●

The moon roof can be opened using the
wireless remote control.

*

 (



P.110)

*

: These settings must be customized at

your Lexus dealer.

WARNING

Observe the following precautions.
Failure to do so may cause death or seri-

ous injury.

■

Closing the moon roof

●

The driver is responsible for moon roof

opening and closing operations.

In order to prevent accidental opera-

tion, especially by a child, do not let a

child operate the moon roof. It is possi-

ble for children and other passengers

to have body parts caught in the moon

roof.

●

Check to make sure that all passen-

gers do not have any part of their body

in a position where it could be caught

when the moon roof is being operated.

●

When using the wireless remote con-

trol or mechanical key and operating

the moon roof, operate the moon roof

after checking to make sure that there

is no possibility of any passenger hav-

ing any of their body parts caught in

the moon roof. Also, do not let a child

operate moon roof by the mechanical

key. It is possible for children and other

passengers to get caught in the moon

roof.

●

When exiting the vehicle, turn the

power switch off, carry the key and exit

the vehicle along with the child. There

may be accidental operation, due to

mischief, etc., that may possibly lead to

an accident.

■

Jam protection function

●

Never use any part of your body to

intentionally activate the jam protec-

tion function.

153

3-5. Opening, closing the windows and moon roof

3

Be

fore
 dri
ving

WARNING

●

The jam protection function may not

work if something gets caught just

before the moon roof is fully closed.

Also, the jam protection function is not

designed to operate while the moon

roof switch is being pressed. Take care

so that your fingers, etc. do not get

caught.
