Lexus NX300 (2021 year). Manual in english - page 6

105

3-2. Opening, closing and locking the doors

fore
dri
ving

■

Opening/closing the back door
using the wireless remote control

Press the

for 1 second.

■

Opening/closing the back door
from the inside

Press the

for 1 second.

A buzzer sounds and the back door auto-
matically opens and closes.
Pressing the

while the back door is

opening/closing stops the operation.
When the

is pressed again for 1 sec-

ond during the halted operation, the back
door will perform the reverse operation.

■

Opening/closing the back door
from the outside



Open

When the back door is unlocked: Press the
back door opener switch.
When the back door is locked: While car-
rying the electronic key on your person,
press the back door opener switch.
A buzzer sounds and the back door auto-
matically opens.
Pressing the switch while the back door is
opening stops the operation.



Pressing the

A buzzer sounds and the back door auto-
matically closes.
Pressing the

while the back door is

closing stops the operation.
Pressing the

again will reverse the

operation.



Close the back door and lock all
doors (close & lock function)

Press the

Opening/closing the back door
(vehicles with power back door)

106

3-2. Opening, closing and locking the doors

A different buzzer than the normal one will
sound and the power back door will begin
closing automatically. When the power
back door is closed, all of the doors will
lock simultaneously and operation signals
will indicate that all of the doors have been
locked.

If the

is pressed while the power

back door is closing, the operation will
stop.

Pressing the

again will close the

power back door automatically.

■

Closing the back door using the
back door handle

Lower the back door using the back
door handle, then a buzzer sounds and
the back door automatically closes.

■

Opening/closing the back door
using the kick sensor (vehicles with
Hands Free Power Back Door)

While carrying an electronic key,
stand within the smart access sys-
tem with push-button start opera-
tion range, approximately 19.7 to
27.6 in. (50 to 70 cm) from the rear
bumper.

Kick sensor

Kick sensor detection area

Smart access system with push-
button start operation detection
area (



P.115)

Perform a kick operation by mov-
ing your foot to within approxi-
mately 3.9 in. (10 cm) of the rear
bumper and then pulling it back.

• Perform the entire kick operation

within 1 second.

• The back door will not start operat-

ing while a foot is detected under
the rear bumper.

• Operate the back door without

contacting the rear bumper with
your foot.

• If another electronic key is in the

cabin or luggage compartment, it
may take slightly longer than normal
for the operation to occur.

A
B
C

107

3-2. Opening, closing and locking the doors

fore
dri
ving

When all of the doors are locked: If the

movement is detected by the kick sensor,

all of the doors will be unlocked.

Kick sensor

Kick sensor detection area

When the kick sensor detects that
your foot is pulled back, a buzzer
will sound and the back door will
automatically fully open/close.

If kick operation is performed again in the

middle of back door operating, the opera-

tion will stop.

■

Luggage compartment light

●

The luggage compartment light turns on

when the back door is opened.

●

If the luggage compartment light is left on

when the engine switch is turned off, the

light will go off automatically after 20

minutes.

■

Power back door operating conditions

With the power back door operations set to

ON, it can automatically open and close for

the following conditions:

●

When the electronic key is being carried

and the power back door switch is
pushed

●

When the wireless remote control is
used

●

When the engine switch is in IGNITION

ON mode, in addition to the above for

the opening operations, the back door

operates for any of the following condi-

tions:

• Parking brake is engaged

• The brake pedal is depressed

• The shift lever is in P

: When configured with the customization

function so that it can be operated after
being unlocked, operate the back door
after it has been unlocked.

■

Kick sensor operating conditions (vehi-

cles with Hands Free Power Back Door)

●

When the kick sensor operation setting is

turned on

●

The electronic key is within the opera-

tional range. (



P.115)

■

Back door closer

In the event that the back door is left slightly

open, the back door closer will automati-

cally close it to the fully closed position.

Whatever the state of the engine switch, the

back door closer operates.

■

Operation of the power back door

●

A buzzer sounds and the emergency

flashers flash twice to indicate that the

back door is opening/closing.

●

When the power back door operations

are OFF, the power back door does not

operate but it can be opened and closed

by hand.

●

When the power back door automati-

cally opens, if an abnormality due to peo-

ple or objects is detected, operation will

stop.

■

Close & lock function

When the power back door is open, this

function closes the power back door and

then locks all of the doors simultaneously.
When the following procedures are per-

formed and there are no electronic keys for

the vehicle within the vehicle, all of the

doors will lock when the power back door is

completely closed.

Close all of the doors except the power

back door.

While carrying an electronic key, press
the

switch on the lower part of

the power back door.

A different buzzer than the normal one will

A
B

108

3-2. Opening, closing and locking the doors

sound and then the power back door will

begin closing automatically. When the

power back door is closed, all of the doors

will lock simultaneously and operation sig-

nals will indicate that all of the doors have

been locked.

■

Situations in which the close & lock

function may not operate properly

(vehicles with Hands Free Power Back

Door)

In the following situations, the close & lock

function may not operate properly:

●

If the

switch on the lower part of

the power back door is pressed by a hand
which is holding an electronic key

●

If the

switch on the lower part of

the power back door is pressed when the
electronic key is in a bag, etc. that is
placed on the ground

●

If the

switch on the lower part of

the power back door is pressed with the
electronic key not near the vehicle.

■

Situations in which the kick sensor does

not operate properly (vehicles with

Hands Free Power Back Door)

In the following situations, the kick sensor

may not operate properly:

●

When a foot remains under the rear

bumper

●

If the rear bumper is strongly hit with a

foot or is touched for a while

If the rear bumper has been touched for a
while, wait for a short time before attempt-
ing to operate the back door again.

●

When operated while a person is too

close to the rear bumper

●

When an external radio wave source

interferes with the communication

between the vehicle and electronic key

(



P.116)

●

When the vehicle is parked near an elec-

trical noise source which affects the sen-

sitivity of the kick sensor, such as a pay

parking spot, gas station, electrically

heated road, or fluorescent light

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When mud, snow, ice, etc. is attached to

the rear bumper

●

When the vehicle has been parked for a

while near objects that may move and

contact the rear bumper, such as plants

●

When an accessory is installed to the rear

bumper

If an accessory has been installed, turn the
kick sensor operation setting off.

■

Preventing unintentional operation of

the kick sensor (vehicles with Hands

Free Power Back Door)

When an electronic key is in the operation

range, the kick sensor may operate unin-

tentionally, so be careful in the following sit-

uations.

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When dirt is wiped off the rear bumper

●

When a small animal or small object, such

as a ball, moves under the rear bumper

●

When an object is moved from under the

rear bumper

●

If someone is swinging their legs while sit-

ting on the rear bumper

●

If the legs or another part of someone’s

body contacts the rear bumper while

passing by the vehicle

●

When the vehicle is parked near an elec-

trical noise source which affects the sen-

sitivity of the kick sensor, such as a pay

parking spot, gas station, electrically

heated road, or fluorescent light

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

109

3-2. Opening, closing and locking the doors

fore
dri
ving

●

When the vehicle is parked in a place

where objects such as plants are near the

rear bumper

●

If luggage, etc. is set near the rear

bumper

●

If accessories or a vehicle cover is

installed/removed near the rear bumper

●

When the vehicle is being towed

To prevent unintentional operation, turn the
kick sensor operation setting off.

■

When reconnecting the battery

To enable the power back door to operate

properly, close the back door manually.

■

Jam protection function

Sensors are installed in the right and left

sides of the power back door. When the

door is automatically closing and the sen-

sors are pushed due to an object being

clamped, etc., the jam protection function

operates.
From that position the door automatically
moves a little in the opposite direction and
then the function stops.

■

If the back door opener is inoperative

The back door can be unlocked from the

inside.

Remove the cover.

To protect the cover, place a rag between

the flathead screwdriver and the cover as

shown in the illustration.

Move the lever.

■

Customization

Settings (e.g. back door automatic open

and stop position) can be changed. (Cus-

tomizable features:



P.425)

WARNING

■

Back door closer

●

In the event that the back door is left

slightly open, the back door closer will

automatically close it to the fully closed

position. It takes several seconds

before the back door closer begins to

operate. Be careful not to catch fingers

or anything else in the back door, as

this may cause bone fractures or other

serious injuries.

●

Use caution when using the back door

closer as it still operates when the

power back door system is canceled.

110

3-2. Opening, closing and locking the doors

WARNING

■

Power back door

Observe the following precautions when

operating the power back door.

Failure to do so may cause death or seri-

ous injury.

●

Check the safety of the surrounding

area to make sure there are no obsta-

cles or anything that could cause any

of your belongings to get caught.

●

If anyone is in the vicinity, make sure

they are safe and let them know that

the back door is about to open or

close.

●

If the power back door system is

turned off with the main switch while

the back door is operating automati-

cally, the automatic operation is

stopped. The back door then has to be

operated manually. Take extra care

when on an incline, as the back door

may open or close unexpectedly.

●

If the operating conditions of the

power back door are no longer met, a

buzzer may sound and the back door

may stop opening or closing. The back

door then has to be operated manu-

ally. Take extra care when on an incline,

as the back door may open or close

abruptly.

●

On an incline, the back door may sud-

denly shut after it opens. Make sure

the back door is fully open and secure.

●

In the following situations, the power

back door may detect an abnormality

and automatic operation may be

stopped. In this case, the back door

has to be operated manually. Take

extra care when on an incline, as the

back door may open or close abruptly.

• When the back door contacts an

obstacle

• When the battery voltage suddenly

drops, such as when the engine switch

is turned to IGNITION ON mode or

the engine is started during automatic

operation

●

If a bicycle carrier or similar heavy

object is attached to the back door, the

power back door may not operate,

causing itself to malfunction, or the

back door may suddenly shut again

after being opened, causing some-

one’s hands, head or neck to be caught

and injured. When installing an acces-

sory part to the back door, using a

genuine Lexus part is recommended.

■

Jam protection function

Observe the following precautions.

Failure to do so may cause death or seri-

ous injury.

●

Never use any part of your body to

intentionally activate the jam protec-

tion function.

●

The jam protection function may not

work if something gets caught just

before the back door fully closes. Be

careful not to catch fingers caught or

anything else.

●

The jam protection function may not

work depending on the shape of the

object that is caught. Be careful not to

catch fingers or anything else.

■

Kick sensor (vehicles with Hands

Free Power Back Door)

Observe the following precautions when

operating the power back door.

Failure to do so may cause death or seri-

ous injury.

●

Check the safety of the surrounding

area to make sure there are no obsta-

cles or anything that could cause any

of your belongings to get caught.

●

When putting your foot near the lower

center part of the rear bumper and

moving it from the rear bumper, be

careful not to touch the exhaust pipes

until they have cooled down suffi-

ciently, as touching hot exhaust pipes

can cause burns.

●

Do not operate the Hands Free Power

Back Door if there is little space under

the rear bumper.

111

3-2. Opening, closing and locking the doors

fore
dri
ving

NOTICE

■

Back door spindles

The back door is equipped with spindles

that hold the back door in place.

Observe the following precautions.
Failure to do so may cause damage to
the back door spindle

, resulting in

malfunction.

●

Do not attach any foreign objects, such

as stickers, plastic sheets, or adhesives

to the spindle rod.

●

Do not touch the spindle rod with

gloves or other fabric items.

●

Do not attach heavy accessories to the

back door. When attaching, ask your

Lexus dealer for details.

●

Do not place your hand on the spindle

or apply lateral forces to it.

■

To prevent back door closer malfunc-

tion

Do not apply excessive force to the back

door while the back door closer is oper-

ating.

■

To prevent damage to the power back

door

●

Make sure that there is no ice between

the back door and frame that would

prevent movement of the back door.

Operating the power back door when

excessive load is present on the back

door may cause a malfunction.

●

Do not apply excessive force to the

back door while the power back door

is operating.

●

Take care not to damage the sensors

(installed on the right and left edges of

the power back door) with a knife or

other sharp object. If the sensor is dis-

connected, the power back door will

not close automatically.

■

Close & lock function

When closing the power back door using

the close & lock function, a different

buzzer than the normal one will sound

before the operation begins.
To check that the operation has started

correctly, check that a different buzzer

than the normal one has sounded.
Additionally, when the power back door

is fully closed and locked, operation sig-

nals will indicate that all of the doors have

been locked.
Before leaving the vehicle, make sure

that the operational signals have oper-

ated and that all of the doors are locked.

■

Kick sensor precautions (vehicles

with Hands Free Power Back Door)

The kick sensor is located behind lower

center part of the rear bumper. Observe

the following to ensure that the power

back door function operates properly:

●

Keep the lower center part of the rear

bumper clean at all times.

If the lower center part of the rear

bumper is dirty or covered with snow,

the kick sensor may not operate. In this

situation, clean off the dirt or snow,

move the vehicle from the current

position and then check if the kick sen-

sor operates.

If it does not operate, have the vehicle

inspected by your Lexus dealer.

●

Do not apply coatings that have a rain

clearing (hydrophilic) effect, or other

coatings, to the lower center part of

the rear bumper.

112

3-2. Opening, closing and locking the doors

ON (operate) and OFF (stop) can be
switched between by the

of the

multi-information display. (



P.80)

Press

of the meter con-

trol switches and select

Press

of the meter con-

trol switches, select the “Vehicle
Settings” and then press

Press

of the meter con-

trol switches, select

and

then press

Press

of the meter con-

trol switches, and then select
“PBD”.

ON and OFF will be switched over
with presses of

on the meter

control switches.

When OFF is selected and the operations
of the power back door is made to stop
from the

of multi-information display,

unless it is set to ON, the operation of the
power back door will not return. (No
return in the engine switch operation)

NOTICE

●

Do not park the vehicle near objects

that may move and contact the lower

center part of the rear bumper, such as

grass or trees.

If the vehicle has been parked for a

while near objects that may move and

contact the lower center part of the

rear bumper, such as grass or trees,

the kick sensor may not operate. In this

situation, move the vehicle from the

current position and then check if the

kick sensor operates. If it does not

operate, have the vehicle inspected by

your Lexus dealer.

●

Do not subject the kick sensor or its

surrounding area to a strong impact.

If the kick sensor or its surrounding

area has been subjected to a strong

impact, the kick sensor may not oper-

ate properly. If the kick sensor does

not operate in the following situations,

have the vehicle inspected by your

Lexus dealer.

• The kick sensor or its surrounding area

has been subjected to a strong impact.

• The lower center part of the rear

bumper is scratched or damaged.

●

Do not disassemble the rear bumper.

●

Do not attach stickers to the rear

bumper.

●

Do not paint the rear bumper.

●

If a bicycle carrier or similar heavy

object is attached to the power back

door, disable the kick sensor.

Canceling the power back door
system (vehicles with power
back door)

113

3-2. Opening, closing and locking the doors

fore
dri
ving

ON (enable) and OFF (disable) can be
switched between by the

of the

multi-information display. (



P.80)

Press

of the meter con-

trol switches and select

Press

of the meter con-

trol switches, select the “Vehicle
Settings” and then press

Press

of the meter con-

trol switches, select

and

then press

Press

of the meter con-

trol switches, and then select “Kick
Sensor”.

ON and OFF will be switched over
with presses of

on the meter

control switches.

When OFF is selected and the operations
of the kick sensor is made to stop from the

of multi-information display, unless it is

set to ON, the operation of the kick sensor
will not return. (No return in the engine
switch operation)

The open position of the power back
door can be adjusted.

Stop the back door in the desirable
position. (



P.105)

Press and hold the power back
door switch on the back door for 2
seconds.

• When the settings are completed,

the buzzer sounds 4 times.

• When opening the back door the

next time, the back door will stop at
that position.

■

Returning the back door automatic stop

position to the initial settings

Press and hold the power back door switch

on the back door for 7 seconds.
After the buzzer sounds 4 times, it sounds
twice more. When the power back door
does the opening operation the next time,
the door will open to the initial settings posi-
tion.

Canceling the kick sensor (vehi-
cles with Hands Free Power
Back Door)

Adjusting the open position of
the back door (vehicles with
power back door)

114

3-2. Opening, closing and locking the doors

■

When setting the open position of the

back door by the navigation system or

multimedia system

The opening position can be set with the
navigation system or multimedia system.
(



P.425)

Priority for the stop position is given to the
last position set by either the

switch,

navigation system or multimedia system.

■

Antenna location

Antennas outside the cabin

Antennas inside the cabin

Antenna inside the luggage compart-
ment

Antenna outside the luggage compart-
ment

Smart access system with
push-button start

The following operations can be
performed simply by carrying the
electronic key (including the card
key) on your person, for example in
your pocket. The driver should
always carry the electronic key.



Locks and unlocks the doors
(



P.98)



Locks and unlocks the back door
(



P.103)



Starts and stops the engine
(



P.163)

115

3-2. Opening, closing and locking the doors

fore
dri
ving

■

Effective range (areas within which the

electronic key is detected)

When locking or unlocking the doors
The system can be operated when the
electronic key is within about 2.3 ft. (0.7
m) of an outside door handle. (Only the
doors detecting the key can be oper-
ated.)

When starting the engine or changing
engine switch modes
The system can be operated when the
electronic key is inside the vehicle.

■

If an alarm sounds or a warning message

is displayed

A combination of exterior and interior

alarms as well as warning messages shown

on the multi-information display are used to

prevent theft of the vehicle and accidents

resulting from erroneous operation. Take

appropriate measures in response to any

warning message on the multi-information

display. (



P.382)

When only an alarm sounds, circumstances

and correction procedures are as follows.

●

When an exterior alarm sounds once for

5 seconds

●

When an Interior alarm pings repeatedly

■

When “Smart Access System Malfunc-

tion See Owner’s Manual” will be dis-

played on the multi-information display

The system may be malfunctioning. Have

the vehicle inspected by your Lexus dealer

immediately.

■

Battery-saving function

The battery-saving function will be acti-

vated in order to prevent the electronic key

battery and the battery from being dis-

charged while the vehicle is not in operation

for a long time.

●

In the following situations, the smart

access system with push-button start may

take some time to unlock the doors.

• The electronic key has been left in an

area of approximately 6 ft. (2 m) of the

outside of the vehicle for 10 minutes or

longer.

• The smart access system with push-but-

ton start has not been used for 5 days or

longer.

●

If the smart access system with push-but-

ton start has not been used for 14 days or

longer, the doors cannot be unlocked at

any doors except the driver’s door. In this

case, take hold of the driver’s door han-

dle, or use the wireless remote control or

the mechanical key, to unlock the doors.

■

Turning an electronic key to battery-

saving mode

When battery-saving mode is set, battery

depletion is minimized by stopping the elec-

Situation

Correction proce-

dure

An attempt was

made to lock the

vehicle while a door

was open.

Close all of the

doors and lock the

doors again.

Situation

Correction proce-

dure

The engine switch

was turned to

ACCESSORY
mode while the

driver’s door was

open (The driver’s

door was opened

when the engine

switch was in

ACCESSORY

mode).

Turn the engine

switch off and close

the driver’s door.

116

3-2. Opening, closing and locking the doors

tronic key from receiving radio waves.

Press

twice while pressing and

holding .
Confirm that the electronic key indicator
flashes 4 times. While the battery-saving
mode is set, the smart access system with
push-button start cannot be used. To cancel
the function, press any of the electronic key
buttons.

■

Conditions affecting operation

The smart access system with push-button

start, wireless remote control and immobi-

lizer system use weak radio waves. In the

following situations, the communication

between the electronic key and the vehicle

may be affected, preventing the smart

access system with push-button start, wire-

less remote control and immobilizer system

from operating properly. (Ways of coping:



P.395)

●

When the electronic key battery is

depleted

●

Near a TV tower, electric power plant,

gas station, radio station, large display,

airport or other facility that generates

strong radio waves or electrical noise

●

When the electronic key is in contact

with, or is covered by the following metal-

lic objects

• Cards to which aluminum foil is attached

• Cigarette boxes that have aluminum foil

inside

• Metallic wallets or bags

• Coins

• Hand warmers made of metal

• Media such as CDs and DVDs

●

When other wireless keys (that emit radio

waves) are being used nearby

●

When carrying the electronic key

together with the following devices that

emit radio waves

• Portable radio, cellular phone, cordless

phone or other wireless communication

devices

• Another vehicle’s electronic key or a

wireless key that emits radio waves

• Personal computers or personal digital

assistants (PDAs)

• Digital audio players

• Portable game systems

●

If window tint with a metallic content or

metallic objects are attached to the rear

window

●

When the electronic key is placed near a

battery charger or electronic devices

■

Note for the entry function

●

Even when the electronic key is within the

effective range (detection areas), the sys-

tem may not operate properly in the fol-

lowing cases:

• The electronic key is too close to the win-

dow or outside door handle, near the

ground, or in a high place when the doors

are locked or unlocked.

• The electronic key is near the ground or

in a high place, or too close to the rear

bumper center when the back door is

opened.

• The electronic key is on the instrument

panel, luggage room, floor, or in the door

pockets or glove box when the engine is

started or engine switch modes are

changed.

●

Do not leave the electronic key on top of

the instrument panel or near the door

pockets when exiting the vehicle.

Depending on the radio wave reception

conditions, it may be detected by the

antenna outside the cabin and the door

will become lockable from the outside,

possibly trapping the electronic key

inside the vehicle.

●

As long as the electronic key is within the

effective range, the doors may be locked

or unlocked by anyone.

●

Even if the electronic key is not inside the

vehicle, it may be possible to start the

engine if the electronic key is near the

window.

●

The doors may unlock if a large amount

117

3-2. Opening, closing and locking the doors

fore
dri
ving

of water splashes on the door handle,

such as in the rain or in a car wash when

the electronic key is within the effective

range. (The door will automatically be

locked after approximately 60 seconds if

the doors are not opened and closed.)

●

If the wireless remote control is used to

lock the doors when the electronic key is

near the vehicle, there is a possibility that

the door may not be unlocked by the

entry function. (Use the wireless remote

control to unlock the doors.)

●

Touching the door lock sensor while

wearing gloves may delay or prevent lock

operation. Remove the gloves and touch

the lock sensor again.

●

When the lock operation is performed

using the lock sensor, recognition signals

will be shown up to two consecutive

times. After this, no recognition signals

will be given.

●

If the door handle becomes wet while the

electronic key is within the effective

range, the door may lock and unlock

repeatedly. In that case, follow the follow-

ing correction procedures to wash the

vehicle:

• Place the electronic key in a location 6 ft.

(2 m) or more away from the vehicle.

(Take care to ensure that the key is not

stolen.)

• Set the electronic key to battery-saving

mode to disable the smart access system

with push-button start. (



P.115)

●

If the electronic key is inside the vehicle

and a door handle becomes wet during a

car wash, a message may be shown on

the multi-information display and a

buzzer will sound outside the vehicle. To

turn off the alarm, lock all the doors.

●

The lock sensor may not work properly if

it comes into contact with ice, snow, mud,

etc. Clean the lock sensor and attempt to

operate it again.

●

A sudden approach to the effective

range or door handle may prevent the

doors from being unlocked. In this case,

return the door handle to the original

position and check that the doors unlock

before pulling the door handle again.

●

If there is another electronic key in the

detection area, it may take slightly longer

to unlock the doors after the door handle

is gripped.

■

When the vehicle is not driven for

extended periods

●

To prevent theft of the vehicle, do not

leave the electronic key within 6 ft. (2 m)

of the vehicle.

●

The smart access system with push-but-

ton start can be deactivated in advance.

■

To operate the system properly

Make sure to carry the electronic key when

operating the system. Do not get the elec-

tronic key too close to the vehicle when

operating the system from the outside of the

vehicle.
Depending on the position and holding

condition of the electronic key, the key may

not be detected correctly and the system

may not operate properly. (The alarm may

go off accidentally, or the door lock preven-

tion may not operate.)

■

If the smart access system with push but-

ton start does not operate properly

●

Locking and unlocking the doors: Use

the mechanical key. (



P.396)

●

Starting the engine:



P.396

■

Customization

Settings (e.g. smart access system with

push-button start) can be changed. (Cus-

tomizable features:



P.425)

If the smart access system with push-button

start has been deactivated by a customized

setting, refer to the explanations for the fol-

lowing operations.

●

Locking and unlocking the doors:

Use the wireless remote control or

mechanical key. (



P.98, 396)

●

Starting the engine and changing engine

switch modes:



P.396

●

Stopping the engine:



P.164

118

3-2. Opening, closing and locking the doors

■

Certification for the smart access system with push-button start



For vehicles sold in the U.S.A.



For vehicles sold in Canada

119

3-2. Opening, closing and locking the doors

fore
dri
ving

WARNING

■

Caution regarding interference with

electronic devices

●

People with implantable cardiac pace-

makers, cardiac resynchronization

therapy-pacemakers or implantable

cardioverter defibrillators should keep

away from the smart access system

with push-button start antennas.

(



P.114)

The radio waves may affect the opera-

tion of such devices. If necessary, the

entry function can be disabled. Ask

your Lexus dealer for details, such as

the frequency of radio waves and tim-

ing of the emitted radio waves. Then,

consult your doctor to see if you

should disable the entry function.

●

Users of any electrical medical device

other than implantable cardiac pace-

makers, cardiac resynchronization

therapy-pacemakers or implantable

cardioverter defibrillators should con-

sult the manufacturer of the device for

information about its operation under

the influence of radio waves.

Radio waves could have unexpected

effects on the operation of such medi-

cal devices.

Ask your Lexus dealer for details on dis-

abling the entry function.

120

3-3. Adjusting the seats

3-3.Adjusting the seats

Seat position adjustment switch

Seat cushion (front) angle adjust-
ment switch

Vertical height adjustment switch

Seatback angle adjustment switch

Lumbar support adjustment switch
(for driver’s side)

■

Power easy access system (if equipped)

The driver’s seat and steering wheel move

in accordance with engine switch mode and

the driver’s seat belt condition. (



P.126)

Front seats

The seats can be adjusted (longitu-
dinally, vertically, etc.). Adjust the
seat to ensure the correct driving
posture.

Adjustment procedure

A
B

C
D

WARNING

■

When adjusting the seat position

●

Take care when adjusting the seat

position to ensure that other passen-

gers are not injured by the moving

seat.

●

Do not put your hands under the seat

or near the moving parts to avoid

injury.

Fingers or hands may become

jammed in the seat mechanism.

■

Seat adjustment

To reduce the risk of sliding under the lap

belt during a collision, do not recline the

seat more than necessary.

If the seat is too reclined, the lap belt may

slide past the hips and apply restraint

forces directly to the abdomen, or your

neck may contact the shoulder belt,

increasing the risk of death or serious

injury in the event of an accident.

Adjustments should not be made while

driving as the seat may unexpectedly

move and cause the driver to lose control

of the vehicle.

Content .. 4 5 6 7 ..
