Temperature A, B, C

The temperature grades are A (the highest), B, and C, representing the tire’s
resistance to the generation of heat and its ability to dissipate heat when
tested under controlled conditions on a specified indoor laboratory test
wheel.

Sustained high temperature can cause the material of the tire to degenerate and

reduce tire life, and excessive temperature can lead to sudden tire failure.
Grade C corresponds to a level of performance which all passenger car tires must

meet under the Federal Motor Vehicle Safety Standard No. 109.
Grades B and A represent higher levels of performance on the laboratory test

wheel than the minimum required by law.
Warning: The temperature grades of a tire assume that it is properly inflated and

not overloaded.

Excessive speed, underinflation, or excessive loading, either separately or in com-

bination, can cause heat buildup and possible tire failure.

579

Glossary of tire terminology

Tire related term

Meaning

Cold tire inflation pressure

Tire pressure when the vehicle has been parked for

three hours or more, or has not been driven more than 1

mile or 1.5 km under that condition

Maximum inflation pres-

sure

The maximum cold inflated pressure to which a tire may

be inflated, shown on the sidewall of the tire

Recommended inflation

pressure

Cold tire inflation pressure recommended by a manu-

facturer

Accessory weight

The combined weight (in excess of those standard items

which may be replaced) of automatic transmission,

power steering, power brakes, power windows, power

seats, radio and heater, to the extent that these items are

available as factory-installed equipment (whether

installed or not)

Curb weight

The weight of a motor vehicle with standard equipment,

including the maximum capacity of fuel, oil and coolant,

and if so equipped, air conditioning and additional

weight optional engine

Maximum loaded vehicle

weight

The sum of:

(a) Curb weight

(b) Accessory weight

(d) Production options weight

Normal occupant weight

150 lb. (68 kg) times the number of occupants specified

in the second column of Table 1

that follows

Occupant distribution

Distribution of occupants in a vehicle as specified in the

third column of Table 1

below

Production options weight

The combined weight of installed regular production

options weighing over 5 lb. (2.3 kg) in excess of the

standard items which they replace, not previously con-

sidered in curb weight or accessory weight, including

heavy duty brakes, ride levelers, roof rack, heavy duty

battery, and special trim

Rim

A metal support for a tire or a tire and tube assembly

upon which the tire beads are seated

580

8-1. Specifications

Rim diameter

(Wheel diameter)

Nominal diameter of the bead seat

Rim size designation

Rim diameter and width

Rim type designation

The industry manufacturer’s designation for a rim by

style or code

Rim width

Nominal distance between rim flanges

Vehicle capacity weight

(Total load capacity)

The rated cargo and luggage load plus 150 lb. (68 kg)

times the vehicle’s designated seating capacity

Vehicle maximum load on

the tire

The load on an individual tire that is determined by dis-

tributing to each axle its share of the maximum loaded

vehicle weight, and dividing by two

Vehicle normal load on the

tire

The load on an individual tire that is determined by dis-

tributing to each axle its share of curb weight, accessory

weight, and normal occupant weight (distributed in

accordance with Table 1

below), and dividing by two

Weather side

The surface area of the rim not covered by the inflated

tire

Bead

The part of the tire that is made of steel wires, wrapped

or reinforced by ply cords and that is shaped to fit the

rim

Bead separation

A breakdown of the bond between components in the

bead

Bias ply tire

A pneumatic tire in which the ply cords that extend to

the beads are laid at alternate angles substantially less

than 90 degrees to the centerline of the tread

Carcass

The tire structure, except tread and sidewall rubber

which, when inflated, bears the load

Chunking

The breaking away of pieces of the tread or sidewall

Cord

The strands forming the plies in the tire

Cord separation

The parting of cords from adjacent rubber compounds

Cracking

Any parting within the tread, sidewall, or innerliner of

the tire extending to cord material

Tire related term

Meaning

581

A pneumatic tire with an inverted flange tire and rim

system in which the rim is designed with rim flanges

pointed radially inward and the tire is designed to fit on

the underside of the rim in a manner that encloses the

rim flanges inside the air cavity of the tire

Extra load tire

A tire designed to operate at higher loads and at higher

inflation pressures than the corresponding standard tire

Groove

The space between two adjacent tread ribs

Innerliner

The layer(s) forming the inside surface of a tubeless tire

that contains the inflating medium within the tire

Innerliner separation

The parting of the innerliner from cord material in the

carcass

Intended outboard sidewall

(a) The sidewall that contains a whitewall, bears white

lettering, or bears manufacturer, brand, and/or

model name molding that is higher or deeper than

the same molding on the other sidewall of the tire,

(b) The outward facing sidewall of an asymmetrical tire

that has a particular side that must always face out-

ward when mounted on a vehicle

Light truck (LT) tire

A tire designated by its manufacturer as primarily

intended for use on lightweight trucks or multipurpose

passenger vehicles

Load rating

The maximum load that a tire is rated to carry for a given

inflation pressure

Maximum load rating

The load rating for a tire at the maximum permissible

inflation pressure for that tire

Maximum permissible infla-

tion pressure

The maximum cold inflation pressure to which a tire may

be inflated

Measuring rim

The rim on which a tire is fitted for physical dimension

requirements

Open splice

Any parting at any junction of tread, sidewall, or inner-

liner that extends to cord material

Outer diameter

The overall diameter of an inflated new tire

Tire related term

Meaning

582

8-1. Specifications

Overall width

The linear distance between the exteriors of the side-

walls of an inflated tire, including elevations due to label-

ing, decorations, or protective bands or ribs

Passenger car tire

A tire intended for use on passenger cars, multipurpose

passenger vehicles, and trucks, that have a gross vehicle

weight rating (GVWR) of 10,000 lb. or less.

Ply

A layer of rubber-coated parallel cords

Ply separation

A parting of rubber compound between adjacent plies

Pneumatic tire

A mechanical device made of rubber, chemicals, fabric

and steel or other materials, that, when mounted on an

automotive wheel, provides the traction and contains

the gas or fluid that sustains the load

Radial ply tire

A pneumatic tire in which the ply cords that extend to

the beads are laid at substantially 90 degrees to the

centerline of the tread

Reinforced tire

A tire designed to operate at higher loads and at higher

inflation pressures than the corresponding standard tire

Section width

The linear distance between the exteriors of the side-

walls of an inflated tire, excluding elevations due to

labeling, decoration, or protective bands

Sidewall

That portion of a tire between the tread and bead

Sidewall separation

The parting of the rubber compound from the cord

material in the sidewall

Snow tire

A tire that attains a traction index equal to or greater

than 110, compared to the ASTM E-1136 Standard Ref-

erence Test Tire, when using the snow traction test as

described in ASTM F-1805-00, Standard Test Method

for Single Wheel Driving Traction in a Straight Line on

Snow-and Ice-Covered Surfaces, and which is marked
with an Alpine Symbol (

) on at least one sidewall

Tire related term

Meaning

583

: Table 1



Occupant loading and distribution for vehicle normal load for various des-

ignated seating capacities

Test rim

The rim on which a tire is fitted for testing, and may be

any rim listed as appropriate for use with that tire

Tread

That portion of a tire that comes into contact with the

road

Tread rib

A tread section running circumferentially around a tire

Tread separation

Pulling away of the tread from the tire carcass

Treadwear indicators (TWI)

The projections within the principal grooves designed

to give a visual indication of the degrees of wear of the

tread

Wheel-holding fixture

The fixture used to hold the wheel and tire assembly

securely during testing

Tire related term

Meaning

Designated seating capac-

ity, Number of occupants

Vehicle normal load, Num-

ber of occupants

Occupant distribution in a

normally loaded vehicle

2 through 4

2 in front

5 through 10

2 in front, 1 in second seat

11 through 15

2 in front, 1 in second seat, 1

in third seat, 1 in fourth seat

16 through 20

2 in front, 2 in second seat,

2 in third seat, 1 in fourth

seat

584

8-2. Customization

Customizable features

■

Changing by using the Remote Touch screen

Press the “MENU” button on the Remote Touch.
Select “Setup” on the “Menu” screen and select “Vehicle”.

Various setting can be changed. Refer to the list of settings that can be
changed for details.

■

Changing by using the multi-information display

Press

of the meter control switches, select

Press

of the meter control switches, select the item or the

desired setting, and then press

To go back to the previous screen, press

Your vehicle includes a variety of electronic features that can be personalized
to suit your preferences. The settings of these features can be changed by
using the multi-information display, by using the Remote Touch screen or at
your Lexus dealer.

Customizing vehicle features

585

Some function settings are changed simultaneously with other functions being
customized. Contact your Lexus dealer for further details.

Settings that can be changed using the Remote Touch screen
Settings that can be changed using the multi-information display
Settings that can be changed by your Lexus dealer

Definition of symbols: O = Available, – =Not available

■

Smart access system with push-button start (



P. 138)

Customizable features

2
3

Function

Default setting

Customized

setting

Smart access system with

push-button start

Off

—

Smart door unlocking

Driver’s door

All the doors

—

586

8-2. Customization

■

Wireless remote control (



P. 116)

: This setting enables opening of the power back door when it is locked or unlocked.

: This function is available only when a customized setting that enables opening of the

power back door when it is either locked or unlocked is selected. (See

above.)

Function

Default setting

Customized

setting

Wireless remote control

Off

—

Unlocking operation

Driver’s door

unlocked in one

step, all doors

unlocked in two

steps

All doors unlocked

in one step

—

Opening/closing of the

power back door using the

switch of the wire-

less remote control

Open: Press for 1
second

Close: Press for 1

second

Off

—

Open: Press for 1

second with the

back door

unlocked

Close: Press for 1

second

Open: One short

press with the

back door

unlocked

Close: One short

press

Open: Press twice

with the back

door unlocked

Close: Press twice

Open: Press
twice

Close: Press twice

Door unlocked when the

power back door is opened
using the

switch of

the wireless remote con-
trol

All the doors

Back door

—

Alarm (panic mode)

Off

—

587

■

Smart access system with push-button start (



P. 138) and wireless remote

control (



P. 116)

■

Door lock (



P. 121)

Function

Default setting

Customized

setting

Operation signal (Emer-

gency flashers)

Off

—

Adjust the volume of confir-

mation buzzer sounds

when the vehicle is locked

or unlocked

Off

—

1 to 7

Open door warning func-

tion (when locking the vehi-

cle)

Off

—

Time elapsed before auto-

matic door lock function is

activated if door is not

opened after being

unlocked

60 seconds

Off

—

30 seconds

120 seconds

Function

Default setting

Customized

setting

Unlocking using a mechan-

ical key

Driver’s door

unlocked in one

step, all doors

unlocked in two

steps

All doors unlocked

in one step

—

Automatic door lock

Shifting the shift

lever to position

other than P

Off

—

Vehicle speed is

approximately

12 mph (20 km/h)

or higher

Automatic door unlock

Shifting the shift

lever to P

Off

—

Driver’s door is

opened

588

8-2. Customization

■

Power back door (



P. 128)

: The operation start buzzer sounds.

■

Power windows (



P. 171)

: The settings of the moon roof are changed in conjunction with the settings of the

power windows.

Function

Default setting

Customized

setting

Power back door switch

operation

Push and hold

One short push

—

Operation signal

Off

—

Back door opener switch

automatic open function

Off

—

Function

Default setting

Customized

setting

Mechanical key linked
operation (close)

Off

—

Mechanical key linked
operation (open)

Off

—

Wireless remote control
linked operation (open)

Off

—

Power windows open warn-

ing buzzer

Off

—

Buzzer sounds if operated

using wireless remote con-

trol

Off

—

589

■

Moon roof (



P. 174)

: The settings of the power windows are changed in conjunction with the settings of the

moon roof.

■

Automatic light control system (



P. 228)

: Vehicles sold outside Canada

Function

Default setting

Customized

setting

Mechanical key linked

operation (open)

Off

—

Mechanical key linked

operation (close)

Off

—

Linked operation of com-

ponents when mechanical

key is used

Slide only

Tilt only

—

Wireless remote control

linked operation (open)

Off

—

Linked operation of com-

ponents when wireless

remote control is used

Slide only

Tilt only

—

Moon roof open warning

buzzer

Off

—

Function

Default setting

Customized

setting

Light sensor sensitivity

Standard

-2 to 2

—

Daytime running light sys-

tem

Off

—

Time elapsed before head-

lights automatically turn off

after doors are closed

30 seconds

Off

—

60 seconds

90 seconds

Welcome lighting illumina-

tion control

Off

—

590

8-2. Customization

■

Illumination (



P. 425)

Function

Default setting

Customized

setting

Interior lights illumination

control

Off

—

Time period before the inte-

rior lights turn off

15 seconds

Off

—

7.5 seconds

30 seconds

Operation after the engine

switch is turned off

Off

—

Operation when the doors

are unlocked

Off

—

Operation when you

approach the vehicle with

the electronic key on your

person (when the interior

light switch is door position)

Off

—

Shift lever light

Off

—

Footwell lights

Off

—

Door trim lights and foot-

well lights illumination con-

trol

Off

—

Door trim lights

Off

—

Operation of the outer foot

lights when you approach

the vehicle with the elec-

tronic key on your person

Off

—

Operation of the outer foot

lights when the doors are

unlocked with the power

door lock switch

Off

—

Operation of the running

board lights when you

approach the vehicle with

the electronic key on your

person

Off

—

Operation of the running

board lights the doors are

unlocked with the power

door lock switch

Off

—

591

■

Intuitive parking assist (



P. 294)

■

Automatic air conditioning system (



P. 407)

Operation of the running

board lights when a door is

opened

Off

—

Sensitivity of the ambient

light sensor used for dim-

ming the meter lights etc.

Standard

-2 to 2

—

Sensitivity of the ambient

light sensor used for bright-

ening the meter lights etc.

Standard

-2 to 2

—

Function

Default setting

Customized

setting

Function

Default setting

Customized

setting

Detection distance of the

front center sensor

Far

Near

—

Detection distance of the

rear center sensor

Far

Near

—

Alert Volume (alert volume

can be adjusted)

1 to 5

—

Display setting (when intui-

tive parking assist is operat-

ing)

All sensors dis-

played

Display off

—

Function

Default setting

Customized

setting

Exhaust gas sensor sensitiv-

ity

Standard

-3 to 3

—

A/C Auto switch operation

Auto

Manual

—

592

8-2. Customization

■

Rear window wiper and washer (



P. 242)

■

Driving position memory (



P. 157)

■

Outside rear view mirrors (



P. 168)

Function

Default setting

Customized

setting

Drip prevention function

Off

—

Rear window wiper opera-

tion linked with washer

Off

—

Linked operation when the

shift lever in R position

Off

—

Times of the linked opera-

tion when the shift lever in R

position

Once

Continuously

—

Function

Default setting

Customized

setting

Driver’s seat movement

when exiting the vehicle

Standard

Off

—

Partial

Selection the door linking

driving position memory

with door unlock operation

Driver’s door

All doors

—

Function

Default setting

Customized

setting

Automatic folding/extend-

ing operation

Linked to locking/

unlocking of the

doors

Off

—

Linked to engine

switch operation

593

■

Seat heaters and ventilators

(



P. 421)

: If equipped

■

Heated steering wheel

(



P. 421)

: If equipped

Function

Default setting

Customized

setting

Adjustment of the front seat

heater temperature or the

ventilator fan speed during

automatic operation (indi-

vidual seat adjustment

available)

Level 3 (standard)

Level 1 (low) to

level 5 (high)

—

Adjustment of the second

seat heater temperature or

the ventilator fan speed

during automatic operation

(individual seat adjustment

available)

Level 3 (standard)

Level 1 (low) to

level 5 (high)

—

Function

Default setting

Customized

setting

Automatic steering wheel

heating

Off

—

Time until automatic steer-

ing wheel heating turns off

Level 3 (standard)

Level 1 (short) to

level 5 (long)

—

Lexus LX570 (2021 year). Manual in english - page 35
