Lexus LC Cabriolet (2021 year). Manual in english

377

6-3. Do-it-yourself maintenance

ain

ten

ce a
nd

inserting it and turning the bulb
base clockwise.

Reconnect the connector.

After reconnecting the connector, turn on

the rear fog light to visually check that

there is no light leaking from the bulb base.

WARNING

Replacing light bulb

Turn off the light. Do not attempt to

replace the bulb immediately after

turning off the light.

The bulb become very hot and may

cause burns.

Do not touch the glass portion of the

light bulb with bare hands. When it is

unavoidable to hold the glass portion,

use and hold with a clean dry cloth to

avoid getting moisture and oils on the

bulb.

Also, if the bulb is scratched or

dropped, it may blow out or crack.

Fully install light bulb and any parts

used to secure it. Failure to do so may

result in heat damage, fire, or water

entering the light unit. This may dam-

age the light or cause condensation to

build up on the lens.

To prevent damage or fire

Make sure bulb is fully seated and

locked.

Check the wattage of the bulb before

installing to prevent heat damage.

379

Wh
en

troubl
e ar
ises

When trouble arises

7-1. Essential information

Emergency flashers .................

380

If your vehicle has to be stopped

in an emergency.....................

380

If the vehicle is trapped in rising

water.............................................

381

7-2. Steps to take in an emergency

If your vehicle needs to be towed

........................................................

383

If you think something is wrong

........................................................

386

Fuel pump shut off system .....

387

If a warning light turns on or a

warning buzzer sounds .......

388

If a warning message is displayed

........................................................

396

If you have a flat tire..................

400

If the engine will not start ........

401

If you lose your keys.................

402

If the fuel filler door cannot be

opened .......................................

403

If the electronic key does not

operate properly ....................

403

If the battery is discharged....

405

If the soft top roof cannot be

closed...........................................

412

If your vehicle overheats........

420

If the vehicle becomes stuck

422

380

7-1. Essential information

7-1.Essential information

Press the switch to flash all of the turn
signal lights.
To turn them off, press the switch once
again.

Emergency flashers

If the emergency flashers are used for a

long time while the engine is not running,

the battery may discharge.

If any of the SRS airbags deploy (inflate)

or in the event of a strong rear impact, the

emergency flashers will turn on automati-

cally. The emergency flashers will turn off

automatically after operating for approxi-

mately 20 minutes. To manually turn the

emergency flashers off, press the switch

twice. (The emergency flashers may not

turn on automatically depending on the

force of the impact and conditions of the

collision.)

Steadily step on the brake pedal
with both feet and firmly depress it.

Do not pump the brake pedal repeatedly

as this will increase the effort required to

slow the vehicle.

Shift the shift position to N.



If the shift position is shifted to N

After slowing down, stop the vehi-
cle in a safe place by the road.

Stop the engine.



If the shift position cannot be shifted
to N

Keep depressing the brake pedal
with both feet to reduce vehicle
speed as much as possible.

To stop the engine, press and hold
the engine switch for 2 consecutive

Emergency flashers

The emergency flashers are used to
warn other drivers when the vehi-
cle has to be stopped in the road
due to a breakdown, etc.

Operating instructions

If your vehicle has to be
stopped in an emergency

Only in an emergency, such as if it
becomes impossible to stop the
vehicle in the normal way, stop the
vehicle using the following proce-
dure:

Stopping the vehicle

381

7-1. Essential information

Wh
en

troubl
e ar
ises

seconds or more, or press it briefly
3 times or more in succession.

Stop the vehicle in a safe place by
the road.



Remove the seat belt first.



If the door can be opened, open the
door and exit the vehicle.



If the door can not be opened, open
the window using the power win-
dow switch and exit the vehicle
through the window.



If the window can not be opened
using the power window switch,
remain calm, wait until the water
level inside the vehicle rises to the
point that the water pressure inside
of the vehicle equals the water pres-
sure outside of the vehicle, and then
open the door and exit the vehicle.

WARNING

If the engine has to be turned off while

driving

Power assist for the steering wheel will

be lost, making the steering wheel

heavier to turn. Decelerate as much as

possible before turning off the engine.

If the vehicle is trapped in
rising water

In the event the vehicle is sub-
merged in water, remain calm and
perform the following.

WARNING

Using an emergency hammer

for

emergency escape

The front side windows and rear side

windows, as well as the rear window can
be shattered by an emergency hammer

used for emergency escape.
However, an emergency hammer can

not shatter the windshield as it is lami-

nated glass.

: Contact any authorized Lexus retailer

or Lexus authorized repairer, or any
reliable repairer, or aftermarket
accessory manufacturer for further
information about an emergency ham-
mer.

383

7-2. Steps to take in an emergency

Wh
en

troubl
e ar
ises

7-2.Steps to take in an emergency

If your vehicle needs to be
towed

If towing is necessary, we recom-
mend having your vehicle towed by
any authorized Lexus retailer or
Lexus authorized repairer, or any
reliable repairer or commercial
towing service, using a wheel-lift
type truck or flatbed truck.
Use a safety chain system for all
towing, and abide by all state/pro-
vincial and local laws.

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

When towing the vehicle

Be sure to transport the vehicle with all

four wheels raised off the ground. If the

vehicle is towed with the tires contacting

the ground, the drivetrain and related

parts may be damaged or an accident

may occur due to a change in direction

of the vehicle.

While towing

When towing using cables or chains,

avoid sudden starts, etc. which place

excessive stress on the towing eyelets,

cables or chains. The towing eyelets,

cables or chains may become dam-

aged, broken debris may hit people,

and cause serious damage.

Do not turn the engine switch off.

This may lead to an accident as the

rear wheels will be locked by the park-

ing lock. Also, there is a possibility that

the steering wheel is locked and can-

not be operated.

Installing towing eyelets to the vehi-

cle

Make sure that towing eyelets are

installed securely.

If not securely installed, towing eyelets

may come loose during towing.

NOTICE

To prevent damage to the vehicle

when towing using a wheel-lift type

truck

Do not tow the vehicle from the rear

when the engine switch is OFF. The

steering lock mechanism is not strong

enough to hold the front wheels

straight.

When raising the vehicle, ensure ade-

quate ground clearance for towing at

the opposite end of the raised vehicle.

Without adequate clearance, the vehi-

cle could be damaged while being

towed.

To prevent damage to the vehicle

when towing with a sling-type truck

Do not tow with a sling-type truck, either

from the front or rear.

To prevent damage to the vehicle

during emergency towing

Do not secure cables or chains to the

suspension components.

384

7-2. Steps to take in an emergency

In the following situations, it is not pos-
sible to be towed by another vehicle
using cables or chains, as the rear
wheels may be locked due to the park-
ing lock. Contact any authorized Lexus
retailer or Lexus authorized repairer,
or any reliable repairer or commercial
towing service.



There is a malfunction in the shift
control system. (



P.195, 398)



There is a malfunction in the engine
immobilizer system. (



P.64)



There is a malfunction in the smart
entry & start system. (



P.403)



The battery is discharged.
(



P.405)

The following may indicate a problem
with your transmission. Contact any
authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer or commercial towing service
before towing.



The engine is running but the vehi-
cle does not move.



The vehicle makes an abnormal
sound.



From the front

Use a towing dolly under the rear
wheels.



From the rear

Use a towing dolly under the front
wheels.

Situations when it is not possible
to be towed by another vehicle

Situations when it is necessary to
contact dealers before towing

Towing with a wheel-lift type
truck

NOTICE

Towing with a sling-type truck

Do not tow with a sling-type truck to pre-

vent body damage.

385

7-2. Steps to take in an emergency

Wh
en

troubl
e ar
ises

When using a flat-bed truck to trans-
port the vehicle, use tire strapping
belts. Refer to the owner’s manual of
the flat-bed truck for the tire strapping
method.
In order to suppress vehicle movement
during transportation, set the parking
brake and turn the engine switch off.

If a tow truck is not available in an
emergency, your vehicle may be tem-
porarily towed using cables or chains
secured to the emergency towing eye-
lets. This should only be attempted on
hard surfaced roads for short distances
at under 30 km/h (18 mph).
A driver must be in the vehicle to steer
and operate the brakes. The vehicle’s
wheels, drive train, axles, steering and
brakes must be in good condition.

To have your vehicle towed by another
vehicle, the towing eyelet must be
installed to your vehicle. Install the tow-
ing eyelet using the following proce-
dure.

Take out the screwdriver and the
towing eyelet. (



P.360)

Remove the eyelet cover using a
flathead screwdriver.

To protect the bodywork, place a rag

between the screwdriver and the vehicle

body as shown in the illustration.

Insert the towing eyelet into the
hole and tighten partially by hand.

Tighten down the towing eyelet
securely using the screwdriver or
hard metal bar.

Securely attach cables or chains to
the towing eyelet.

Take care not to damage the vehicle body.

Enter the vehicle being towed and
start the engine.

If the engine does not start, turn the engine

switch to ON.

Using a flatbed truck

Emergency towing

Emergency towing procedure

386

7-2. Steps to take in an emergency

Shift the shift position to N and
release the parking brake.

Turn automatic mode off. (



P.205)

While towing

If the engine is not running, the power assist

for the brakes and steering will not function,

making steering and braking more difficult.

Wheel nut wrench

Wheel nut wrench can be purchased at any

authorized Lexus retailer or Lexus autho-

rized repairer, or any reliable repairer.



Fluid leaks under the vehicle.
(Water dripping from the air condi-
tioning after use is normal.)



Flat-looking tires or uneven tire
wear



Engine coolant temperature gauge
continually points higher than nor-
mal.



Changes in exhaust sound



Excessive tire squeal when corner-
ing



Strange noises related to the sus-
pension system



Pinging or other noises related to
the engine



Engine missing, stumbling or run-
ning roughly



Appreciable loss of power

If you think something is
wrong

If you notice any of the following
symptoms, your vehicle probably
needs adjustment or repair. Con-
tact any authorized Lexus retailer
or Lexus authorized repairer, or
any reliable repairer as soon as pos-
sible.

Visible symptoms

Audible symptoms

Operational symptoms

387

7-2. Steps to take in an emergency

Wh
en

troubl
e ar
ises



Vehicle pulls heavily to one side
when braking



Vehicle pulls heavily to one side
when driving on a level road



Loss of brake effectiveness, spongy
feeling, pedal almost touches the
floor

Follow the procedure below to restart
the engine after the system is activated.

Turn the engine switch to ACC or
turn it off.

Restart the engine.

Fuel pump shut off system

To minimize the risk of fuel leakage
when the engine stalls or when an
airbag inflates upon collision, the
fuel pump shut off system stops the
supply of fuel to the engine.

Restarting the engine

NOTICE

Before starting the engine

Inspect the ground under the vehicle.

If you find that fuel has leaked onto the

ground, the fuel system has been dam-

aged and is in need of repair. Do not

restart the engine.

388

7-2. Steps to take in an emergency

Brake system warning light (warning buzzer)

Charging system warning light

: This light illuminates on the multi-information display.

If a warning light turns on or a warning buzzer sounds

Calmly perform the following actions if any of the warning lights comes on or
flashes. If a light comes on or flashes, but then goes off, this does not necessar-
ily indicate a malfunction in the system. However, if this continues to occur,
have the vehicle inspected by any authorized Lexus retailer or Lexus autho-
rized repairer, or any reliable repairer.

Actions to the warning lights or warning buzzers

Warning

light

Details/Actions

(red)

Indicates that:



The brake fluid level is low; or



The brake system is malfunctioning

This light also comes on when the parking brake is not released. If the light
turns off after the parking brake is fully released the system is operating nor-
mally.



Immediately stop the vehicle in a safe place and contact any authorized
Lexus retailer or Lexus authorized repairer, or any reliable repairer.
Continuing to drive the vehicle may be dangerous.



Indicates that the brake pads are worn out (only the right-side pads can be
detected)



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer.

Warning

light

Details/Actions

Indicates a malfunction in the vehicle’s charging system



Immediately stop the vehicle in a safe place and contact any authorized
Lexus retailer or Lexus authorized repairer, or any reliable repairer.

389

7-2. Steps to take in an emergency

Wh
en

troubl
e ar
ises

Low engine oil pressure warning light (warning buzzer)

: This light illuminates on the multi-information display.

Malfunction indicator lamp (warning buzzer)

: If equipped

SRS warning light

ABS warning light (warning buzzer)

Warning

light

Details/Actions

Indicates that the engine oil pressure is too low



Immediately stop the vehicle in a safe place and contact any authorized
Lexus retailer or Lexus authorized repairer, or any reliable repairer.

Warning

light

Details/Actions

Indicates a malfunction in:



The electronic engine control system;



The electronic throttle control system;



The electronic automatic transmission control system; or



The Exhaust Gas Filter system



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

Warning

light

Details/Actions

Indicates a malfunction in:



The SRS airbag system; or



The seat belt pretensioner system



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

Warning

light

Details/Actions

Indicates a malfunction in:



The ABS; or



The brake assist system



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

390

7-2. Steps to take in an emergency

Electric power steering system warning light (warning buzzer)

PCS warning light (warning buzzer)

LKA indicator

: This light illuminates on the multi-information display.

Warning

light

Details/Actions

(red)

(yellow)

Indicates a malfunction in the EPS (Electric Power Steering) system



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

Warning

light

Details/Actions

(Flashes or

illuminates)

When a buzzer sounds simultaneously:
Indicates a malfunction has occurred in the PCS (Pre-Collision System).



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

When a buzzer does not sound:
The PCS (Pre-Collision System) has become temporarily unavailable, cor-
rective action may be necessary.



Follow the instructions displayed on the multi-information display.
(



P.230, 396)

If the PCS (Pre-Collision System) or VSC (Vehicle Stability Control) system
is disabled, the PCS warning light will illuminate.



P.239

Warning

light

Details/Actions

(orange)

Indicates a malfunction in the LKA (Lane-Keeping Assist)



When “Lane Keeping Assist Unavailable” is displayed on the multi-
information display, turn the LKA (Lane-Keeping Assist) system off,
drive the vehicle for a short time, and then turn the LKA (Lane-Keeping
Assist) system back on. (



P.243)

When a message other than above is displayed, follow the instructions
displayed in the message.

391

7-2. Steps to take in an emergency

Wh
en

troubl
e ar
ises

Slip indicator

Brake Override System warning light/Drive-Start Control warning light
(warning buzzer)

: This light illuminates on the multi-information display.

Brake hold operated indicator

Warning

light

Details/Actions

Indicates a malfunction in:



The VSC (Vehicle Stability Control) system;



The TRC (Traction Control) system; or



The hill-start assist control system



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

The light will flash when the VSC, TRC or ABS system is operating.

Warning

light

Details/Actions

When the warning light flashes (and a buzzer sounds):
Indicates a malfunction in the Brake Override System or Drive-Start Control



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

Indicates that the shift position was changed while depressing the accelera-
tor pedal and Drive-Start Control was operated



Momentarily release the accelerator pedal.

When the warning light flashes (and a buzzer does not sound):
Indicates that the accelerator and brake pedals are being depressed simul-
taneously



Release the accelerator pedal and depress the brake pedal.

Warning

light

Details/Actions

(flashes)

Indicates a malfunction in the brake hold system



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

392

7-2. Steps to take in an emergency

Parking brake indicator

Brake system warning light

Low fuel level warning light

Driver’s and front passenger’s seat belt reminder light (warning buzzer)

: Driver’s and front passenger’s seat belt warning buzzer:

The driver’s and front passenger’s seat belt warning buzzer sounds to alert the driver and
front passenger that his or her seat belt is not fastened. If the seat belt is unfastened, the
buzzer sounds intermittently for a certain period of time after the vehicle reaches a certain
speed.

Warning

light

Details/Actions

(flashes)

Indicates a malfunction in the parking brake system



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

Warning

light

Details/Actions

(yellow)

Indicates a malfunction in:



The electronically controlled brake system



The parking brake system



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

Warning

light

Details/Actions

Indicates that remaining fuel is approximately 12.1L [3.2 gal., 2.7 Imp.gal.] or
less



Refuel the vehicle.

Warning

light

Details/Actions

Warns the driver and/or front passenger to fasten their seat belts



Fasten the seat belt.
If the front passenger’s seat is occupied, the front passenger’s seat belt
also needs to be fastened to make the warning light (warning buzzer)
turn off.

393

7-2. Steps to take in an emergency

Wh
en

troubl
e ar
ises

Rear passengers’ seat belt reminder lights (warning buzzer

)

: Rear passenger’s seat belt warning buzzer:

The rear passengers’ seat belt warning buzzer sounds to alert the rear passenger that his
or her seat belt is not fastened. If the seat belt is unfastened, the buzzer sounds intermit-
tently for a certain period of time, after the seat belt is fastened and unfastened and the
vehicle reaches a certain speed.

: This light illuminates on the center panel.

Master warning light (warning buzzer)

Tire pressure warning light

Warning

light

Details/Actions

Warns the rear passengers to fasten their seat belts



Fasten the seat belt.

Warning

light

Details/Actions

A buzzer sounds and the warning light comes on and flashes to indicate that
the master warning system has detected a malfunction.



P.396

Warning

light

Details/Actions

When the light comes on:
Low tire inflation pressure such as



Natural causes (



P.394)



Flat tire (



P.400)



Adjust the tire inflation pressure to the specified level.
The light will turn off after a few minutes. In case the light does not turn
off even if the tire inflation pressure is adjusted, have the system
checked by any authorized Lexus retailer or Lexus authorized
repairer, or any reliable repairer.

When the light comes on after blinking for 1 minute:
Malfunction in the tire pressure warning system



Have the system checked by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer.

Lexus LC Cabriolet (2021 year). Manual in english - page 18
