Lexus LC (2021 year). Manual in english

192

3-5. Opening, closing the windows

again. After the door window is com-

pletely closed, continue holding the

switch for a further 1 second or more.

If you release the switch while the window is

moving, start again from the beginning.

If the window reverses and cannot be fully

closed or opened, have the vehicle

inspected by any authorized Lexus retailer

or Lexus authorized repairer, or any reliable

repairer.

Door lock linked window operation

The power windows can be opened and
closed using the mechanical key.

(



P.462)

The power windows can be opened and

closed using the wireless remote con-
trol.

(



P.130)

: These settings must be customized at any

authorized Lexus retailer or Lexus autho-
rized repairer, or any reliable repairer.

Power windows open warning buzzer

The buzzer sounds and “Window Open” is

shown on the multi-information display in

the instrument cluster when the engine

switch <power switch> is turned off and the

driver’s door is opened with the power win-

dows open.

Customization

Settings (e.g. linked door lock operation)

can be changed.

(Customizable features:



P.495)

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

Closing the windows

The driver is responsible for all the

power window operations, including

the operation for the passengers. In

order to prevent accidental operation,

especially by a child, do not let a child

operate the power windows. It is possi-

ble for children and other passengers

to have body parts caught in the power

window. Also, when riding with a child,

it is recommended to use the window

lock switch. (



P.193)

Check to make sure that all passen-

gers do not have any part of their body

in a position where it could be caught

when a window is being operated.

When using the wireless remote con-

trol or mechanical key and operating

the power windows, operate the

power window after checking to make

sure that there is no possibility of any

passenger having any of their body

parts caught in the window. Also do

not let a child operate window by the

wireless remote control or mechanical

key. It is possible for children and other

passengers to get caught in the power

window.

When exiting the vehicle, turn the

engine switch <power switch> off, carry

the key and exit the vehicle along with

the child. There may be accidental

operation, due to mischief, etc., that

may possibly lead to an accident.

Jam protection function

Never use any part of your body to

intentionally activate the jam protec-

tion function.

The jam protection function may not

work if something gets jammed just

before the window is fully closed. Be

careful not to get any part of your body

jammed in the window.

193

3-5. Opening, closing the windows

Before drivi

This function can be used to prevent
children from accidentally opening or
closing a passenger window.
Press the switch.

The indicator

will come on and the

passenger window will be locked.

The power windows can be operated

when

The engine switch <power switch> is in

IGNITION ON mode <ON mode>.

When the 12-volt battery is discon-

nected

The window lock switch is disabled. If nec-

essary, press the window lock switch after

reconnecting the 12-volt battery.

WARNING

Catch protection function

Never use any part of your body or

clothing to intentionally activate the

catch protection function.

The catch protection function may not

work if something gets caught just

before the window is fully opened. Be

careful not to get any part of your body

or clothing caught in the window.

Preventing accidental operation
(window lock switch)

195

ivin
g

Driving

4-1. Before driving

Driving the vehicle.....................

196

Cargo and luggage..................

203

Trailer towing..............................

204

4-2. Driving procedures

Engine (ignition) switch (LC500)

........................................................

205

Power (ignition) switch (LC500h)

........................................................

209

EV drive mode (LC500h).....

213

Automatic transmission (LC500)

.........................................................

215

Hybrid transmission (LC500h)

........................................................

223

Turn signal lever ........................

230

Parking brake ..............................

231

Brake Hold...................................

234

4-3. Operating the lights and wipers

Headlight switch........................

236

Automatic High Beam............

238

Fog light switch ...........................

241

Windshield wipers and washer

........................................................

242

4-4. Refueling

Opening the fuel tank cap.....

246

4-5. Using the driving support sys-

tems

Lexus Safety System + ............

248

PCS (Pre-Collision System)

259

LKA (Lane-Keeping Assist) .

267

RSA (Road Sign Assist)..........

275

Dynamic radar cruise control with

full-speed range ......................

279

Cruise control ............................

289

Driving mode select switch ...

292

Lexus parking assist-sensor .

293

BSM (Blind Spot Monitor)....

298

Active rear wing........................

320

Exhaust Gas Filter system

(LC500) ....................................

322

GPF (Gasoline Particulate Filter)

system (LC500h) .................

323

Driving assist systems ..............

324

4-6. Driving tips

Hybrid vehicle driving tips

(LC500h).................................

330

Winter driving tips....................

332

196

4-1. Before driving

4-1.Before driving

Starting the engine <hybrid sys-
tem>



P.205, 209

Driving

With the brake pedal depressed,
shift the shift position to D.
(



P.217, 225)

Check that the shift position indicator

shows D.

If the parking brake is in manual
mode, release the parking brake.
(



P.231)

Gradually release the brake pedal
and gently depress the accelerator
pedal to accelerate the vehicle.

Stopping

With the shift position in D, depress
the brake pedal.

If necessary, set the parking brake.

If the vehicle is to be stopped for an

extended period of time, shift the shift posi-

tion to P. (



P.217, 225)

Parking the vehicle

Stop the vehicle completely.

If the parking brake is in manual
mode, set the parking brake.
(



P.231)

Shift the shift position to P.
(



P.218, 225)

Check that the shift position indicator

shows P.

Press the engine switch <power
switch> to stop the engine <hybrid
system>.

Slowly release the brake pedal.

Lock the door, making sure that you
have the electronic key on your
person.

If parking on a hill, block the wheels as

needed.

Starting off on a steep uphill

Firmly depress the brake pedal and
shift the shift position to D.

The hill-start assist control will activate.

(



P.324)

Set the parking brake. (



P.231)

Release the brake pedal and gently
depress the accelerator pedal to
accelerate the vehicle.

Release the parking brake.
(



P.231)

For fuel-efficient driving (LC500h)

Keep in mind that hybrid vehicles are similar

to conventional vehicles, and it is necessary

to refrain from activities such as sudden

acceleration. (



P.330)

Driving in the rain

Drive carefully when it is raining, because

visibility will be reduced, the windows

may become fogged-up, and the road

will be slippery.

Drive carefully when it starts to rain,

because the road surface will be espe-

cially slippery.

Refrain from high speeds when driving on

an expressway in the rain, because there

may be a layer of water between the tires

and the road surface, preventing the

steering and brakes from operating prop-

Driving the vehicle

The following procedures should be
observed to ensure safe driving:

Driving procedure

197

4-1. Before driving

ivin
g

erly.

Engine speed while driving

In the following conditions, the engine

speed may become high while driving. This

is due to automatic up-shifting control or

down-shifting implementation to meet driv-

ing conditions. It does not indicate sudden

acceleration.

The vehicle is judged to be driving uphill

or downhill

When the accelerator pedal is released

When the brake pedal is firmly or quickly

depressed

Restraining the engine <hybrid system>

output (Brake Override System)

When the accelerator and brake pedals

are depressed at the same time, the

engine <hybrid system> output may be

restrained.

A warning message is displayed on the

multi-information display while the sys-

tem is operating. If a warning message is

shown on the multi-information display,

read the message and follow the instruc-

tions.

Restraining sudden start (Drive-Start

Control)

When the following unusual operation is

performed, the engine <hybrid system>

output may be restrained.

• When the shift position is shifted from R

to D, D to R, N to R, P to D

, or P to R

includes M) with the accelerator pedal

depressed, a warning message appears

on the multi-information display. If a

warning message is shown on the multi-

information display, read the message

and follow the instructions.

• When the accelerator pedal is depressed

too much while the vehicle is in reverse.

: Depending on the situation, the shift posi-

tion may not be changed.

While Drive-Start Control is being acti-

vated, your vehicle may have trouble

escaping from the mud or fresh snow. In

such case, deactivate TRC (



P.325) to

cancel Drive Start Control so that the

vehicle may become able to escape from

the mud or fresh snow.

Breaking in your new Lexus

To extend the life of the vehicle, observing

the following precautions is recommended:

For the first 300 km (186 miles):

Avoid sudden stops.

For the first 1000 km (621 miles):

• Do not drive at extremely high speeds.

• Avoid sudden acceleration.

• Do not drive continuously in low gears.

• Do not drive at a constant speed for

extended periods.

Drum-in-disc type parking brake system

Your vehicle has a drum-in-disc type park-

ing brake system. This type of brake system

needs bedding-down of the brake shoes

periodically or whenever the parking brake

shoes and/or drum are replaced. Have any

authorized Lexus retailer or Lexus autho-

rized repairer, or any reliable repairer, per-

form the bedding down operation.

Operating your vehicle in a foreign

country

Comply with the relevant vehicle registra-

tion laws and confirm the availability of the

correct fuel. (



P.484)

Brake pads and discs

The brake pads and discs are designed for

use under high load conditions. Therefore,

brake noise may be generated depending

on the vehicle speed, braking force and

vehicle environment (temperature, humid-

ity, etc.).

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

198

4-1. Before driving

WARNING

When starting the vehicle

LC500: Always keep your foot on the

brake pedal while stopped with the

engine running. This prevents the vehicle

from creeping.
LC500h: Always keep your foot on the

brake pedal while stopped with the

“READY” indicator is illuminated. This

prevents the vehicle from creeping.

When driving the vehicle

Do not drive if you are unfamiliar with

the location of the brake and accelera-

tor pedals to avoid depressing the

wrong pedal.

• Accidentally depressing the accelera-

tor pedal instead of the brake pedal

will result in sudden acceleration that

may lead to an accident.

• When backing up, you may twist your

body around, leading to a difficulty in

operating the pedals. Make sure to

operate the pedals properly.

• Make sure to keep a correct driving

posture even when moving the vehicle

only slightly. This allows you to depress

the brake and accelerator pedals

properly.

• Depress the brake pedal using your

right foot. Depressing the brake pedal

using your left foot may delay

response in an emergency, resulting in

an accident.

LC500h: The driver should pay extra

attention to pedestrians when the vehi-

cle is powered only by the electric

motor (traction motor). As there is no

engine noise, the pedestrians may mis-

judge the vehicle’s movement. Even

though the vehicle is equipped with the

vehicle proximity notification system,

drive with care as pedestrians in the

vicinity may still not notice the vehicle if

the surrounding area is noisy.

Do not drive the vehicle over or stop

the vehicle near flammable materials.

The exhaust system and exhaust gases

can be extremely hot. These hot parts

may cause a fire if there is any flamma-

ble material nearby.

During normal driving, do not turn off

the engine <hybrid system>. Turning

the engine <hybrid system> off while

driving will not cause loss of steering

or braking control, however, power

assist to the steering will be lost. This

will make it more difficult to steer

smoothly, so you should pull over and

stop the vehicle as soon as it is safe to

do so.

In the event of an emergency, such as if

it becomes impossible to stop the vehi-

cle in the normal way:



P.433

Use engine braking (downshift) to

maintain a safe speed when driving

down a steep hill.

Using the brakes continuously may

cause the brakes to overheat and lose

effectiveness. (



P.215, 223)

Do not adjust the positions of the

steering wheel, the seat, or the inside

or outside rear view mirrors while driv-

ing.

Doing so may result in a loss of vehicle

control.

Always check that all passengers’

arms, heads or other parts of their

body are not outside the vehicle.

When driving on slippery road sur-

faces

Sudden braking, acceleration and

steering may cause tire slippage and

reduce your ability to control the vehi-

cle.

Sudden acceleration, engine braking

due to shifting, or changes in engine

speed could cause the vehicle to skid,

resulting in an accident.

199

4-1. Before driving

ivin
g

WARNING

After driving through a puddle, lightly

depress the brake pedal to make sure

that the brakes are functioning prop-

erly. Wet brake pads may prevent the

brakes from functioning properly. If the

brakes on only one side are wet and

not functioning properly, steering con-

trol may be affected.

When shifting the shift position

LC500: Do not let the vehicle roll

backward while a forward driving posi-

tion is selected, or roll forward while

the shift position is in R.

Doing so may cause the engine to stall

or lead to poor brake and steering

performance, resulting in an accident

or damage to the vehicle.

LC500h: Do not let the vehicle roll

backward while a forward driving posi-

tion is selected, or roll forward while

the shift position is in R.

Doing so may result in an accident or

damage to the vehicle.

Do not shift the shift position to P while

the vehicle is moving.

Doing so can damage the transmission

and may result in a loss of vehicle con-

trol.

Do not shift the shift position to R while

the vehicle is moving forward.

Doing so can damage the transmission

and may result in a loss of vehicle con-

trol.

Do not shift the shift position to a driv-

ing position while the vehicle is moving

backward.

Doing so can damage the transmission

and may result in a loss of vehicle con-

trol.

LC500: Changing the shift position to

N while the vehicle is moving will dis-

engage the engine from the transmis-

sion. Engine braking is not available

when N is selected.

LC500h: Changing the shift position

to N while the vehicle is moving will

disengage the hybrid system. Engine

braking is not available with the hybrid

system disengaged.

Be careful not to change the shift posi-

tion with the accelerator pedal

depressed.

Changing the shift position to any

positions other than P or N may lead to

unexpected rapid acceleration of the

vehicle that may cause an accident

and result in death or serious injury.

After changing the shift position, make

sure to confirm the current shift posi-

tion displayed on the shift position indi-

cator inside the meter.

Brake pad wear

If any of the following situations occur,

have the brake pads checked and

replaced by any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer as soon as possible.

If the thickness of the brake pads

exceeds the brake pad wear limit when

visually checking all four brake pads

(for the brake pad wear limit, refer to

P.490)

If “Brake Pad Wear Visit Your Dealer”

is displayed (only the right-side pads

can be detected)

Rotor damage may result if the pads are

not replaced when needed. Moderate

levels of the brake pad and disc wear

allow enhanced braking power. As a

result, the discs may wear more quickly

than conventional brake discs. Therefore,

when replacing the brake pads, Lexus

recommends that you also have the

thickness of the discs measured. It is dan-

gerous to drive the vehicle when the

wear limits of the brake pads and/or

those of the brake discs are exceeded.

200

4-1. Before driving

WARNING

When the vehicle is stopped

LC500: Do not race the engine.

If the shift position is any position other

than P or N, the vehicle may acceler-

ate suddenly and unexpectedly, caus-

ing an accident.

LC500h: Do not depress the acceler-

ator pedal unnecessarily.

If the shift position is any position other

than P or N, the vehicle may acceler-

ate suddenly and unexpectedly, caus-

ing an accident.

LC500: In order to prevent accidents

due to the vehicle rolling away, always

keep depressing the brake pedal while

the engine is running, and apply the

parking brake as necessary.

LC500h: In order to prevent acci-

dents due to the vehicle rolling away,

always keep depressing the brake

pedal while stopped with the

“READY” indicator is illuminated, and

apply the parking brake as necessary.

If the vehicle is stopped on an incline,

in order to prevent accidents caused

by the vehicle rolling forward or back-

ward, always depress the brake pedal

and securely apply the parking brake

as needed.

Avoid revving or racing the engine.

Running the engine at high speed

while the vehicle is stopped may cause

the exhaust system to overheat, which

could result in a fire if combustible

material is nearby.

When the vehicle is parked

Do not leave glasses, cigarette lighters,

spray cans, or soft drink cans in the

vehicle when it is in the sun.

Doing so may result in the following:

• Gas may leak from a cigarette lighter

or spray can, and may lead to a fire.

• The temperature inside the vehicle

may cause the plastic lenses and plas-

tic material of glasses to deform or

crack.

• Soft drink cans may fracture, causing

the contents to spray over the interior

of the vehicle, and may also cause a

short circuit in the vehicle’s electrical

components.

Do not leave cigarette lighters in the

vehicle. If a cigarette lighter is in a

place such as the glove box or on the

floor, it may be lit accidentally when

luggage is loaded or the seat is

adjusted, causing a fire.

Do not attach adhesive discs to the

windshield or windows. Do not place

containers such as air fresheners on

the instrument panel or dashboard.

Adhesive discs or containers may act

as lenses, causing a fire in the vehicle.

Do not leave a door or window open if

the curved glass is coated with a met-

allized film such as a silver-colored

one. Reflected sunlight may cause the

glass to act as a lens, causing a fire.

201

4-1. Before driving

ivin
g

WARNING

LC500:Always apply the parking

brake, shift the shift position to P, stop

the engine and lock the vehicle.

Do not leave the vehicle unattended

while the engine is running.

If the vehicle is parked with the shift

position in P but the parking brake is

not set, the vehicle may start to move,

possibly leading to an accident.

LC500h:Always apply the parking

brake, shift the shift position to P, stop

the hybrid system and lock the vehicle.

Do not leave the vehicle unattended

while the “READY” indicator is illumi-

nated.

If the vehicle is parked with the shift

position in P but the parking brake is

not set, the vehicle may start to move,

possibly leading to an accident.

LC500: Do not touch the exhaust

pipes while the engine is running or

immediately after turning the engine

off.

Doing so may cause burns.

LC500h: Do not touch the exhaust

pipes while the “READY” indicator is

illuminated or immediately after turn-

ing the hybrid system off.

Doing so may cause burns.

When taking a nap in the vehicle

Always turn the engine <hybrid system>

off. Otherwise, if you accidentally move

the shift lever or depress the accelerator

pedal, this could cause an accident or fire

due to engine <hybrid system> overheat-

ing. Additionally, if the vehicle is parked

in a poorly ventilated area, exhaust gases

may collect and enter the vehicle, lead-

ing to death or a serious health hazard.

When braking

When the brakes are wet, drive more

cautiously.

Braking distance increases when the

brakes are wet, and this may cause one

side of the vehicle to brake differently

than the other side. Also, the parking

brake may not securely hold the vehi-

cle.

If the electronically controlled brake

system does not operate, do not follow

other vehicles closely and avoid hills or

sharp turns that require braking.

In this case, braking is still possible, but

the brake pedal should be depressed

more firmly than usual. Also, the brak-

ing distance will increase. Have your

brakes fixed immediately.

The brake system consists of 2 or more

individual hydraulic systems; if one of

the systems fails, the other(s) will still

operate. In this case, the brake pedal

should be depressed more firmly than

usual and the braking distance will

increase. Have your brakes fixed

immediately.

NOTICE

When driving the vehicle

Do not depress the accelerator and

brake pedals at the same time while

driving, as this may restrain the engine

<hybrid system> output.

Do not use the accelerator pedal or

depress the accelerator and brake

pedals at the same time to hold the

vehicle on a hill.

Avoiding damage to vehicle parts

Do not turn the steering wheel fully in

either direction and hold it there for an

extended period of time.

Doing so may damage the power

steering motor.

202

4-1. Before driving

NOTICE

When driving over bumps in the road,

drive as slowly as possible to avoid

damaging the wheels, underside of the

vehicle, etc.

If you get a flat tire while driving

A flat or damaged tire may cause the fol-

lowing situations. Hold the steering

wheel firmly and gradually depress the

brake pedal to slow down the vehicle.

It may be difficult to control your vehi-

cle.

The vehicle will make abnormal

sounds or vibrations.

The vehicle will lean abnormally.

Information on what to do in case of a flat

tire (



P.457)

When encountering flooded roads

Do not drive on a road that has flooded

after heavy rain etc. Doing so may cause

the following serious damage to the vehi-

cle:

Engine stalling

Short in electrical components

Engine damage caused by water

immersion

In the event that you drive on a flooded

road and the vehicle is flooded, be sure

to have any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer check the following:

Brake function

Changes in quantity and quality of oil

and fluid used for the engine, transmis-

sion, differentials, etc.

Lubricant condition for the propeller

shaft, bearings and suspension joints

(where possible), and the function of

all joints, bearings, etc.

If the shift control system is damaged by

flooding, it may not be possible to shift

the shift position to P, or from P to other

positions. In this case, contact any autho-

rized Lexus retailer or Lexus authorized

repairer, or any reliable repairer immedi-

ately.

When parking the vehicle

Always set the parking brake, and shift

the shift position to P. Failure to do so

may cause the vehicle to move or the

vehicle may accelerate suddenly if the

accelerator pedal is accidentally

depressed.

203

4-1. Before driving

ivin
g

Cargo and luggage

Take notice of the following infor-
mation about storage precautions,
cargo capacity and load:

WARNING

Things that must not be carried in the

trunk

The following things may cause a fire if

loaded in the trunk:

Receptacles containing gasoline

Aerosol cans

Storage precautions

Observe the following precautions.

Failure to do so may prevent the pedals

from being depressed properly, may

block the driver’s vision, or may result in

items hitting the driver or passengers,

possibly causing an accident.

Stow cargo and luggage in the trunk

whenever possible.

Do not place cargo or luggage in or on

the following locations.

• At the feet of the driver
• On the front passenger or rear seats

(when stacking items)

• On the package tray
• On the instrument panel
• On the dashboard
• In front of Center Display

Secure all items in the occupant com-

partment.

Load and distribution

Do not overload your vehicle.

Do not apply loads unevenly.

Improper loading may cause deterio-

ration of steering or braking control

which may cause death or serious

injury.

205

4-2. Driving procedures

ivin
g

4-2.Driving procedures

Press the parking brake switch to
check that the parking brake is set.
(



P.231)

The parking brake indicator will come on.

Firmly depress the brake pedal.

and a message will be displayed on

the multi-information display.
If it is not displayed, the engine cannot be

started.

Press the engine switch shortly and
firmly.

When operating the engine switch, one

short, firm press is enough. It is not neces-

sary to press and hold the switch.
The engine will crank until it starts or for up

to 30 seconds, whichever is less.
Continue depressing the brake pedal until

the engine is completely started.
The engine can be started from any engine

switch mode.

Engine switch illumination

According to the situation, the engine

switch illumination operates as follows.

When a door is opened, or the engine

switch mode is changed from ACCES-

SORY or IGNITION ON mode to off,

the engine switch illumination slowly

blinks.

When depressing the brake pedal with

carrying the electronic key on your per-

son, the engine switch illumination rapidly

blinks.

When the engine switch is in ACCES-

SORY or IGNITION ON mode, the

engine switch illumination illuminates.

If the engine does not start

The engine immobilizer system may not

have been deactivated. (



P.77)

Contact any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer.

If a message related to start-up is shown

on the multi-information display, read the

message and follow the instructions.

If the door is unlocked with the mechani-

cal key, the engine cannot be started

using the smart entry & start system.

Refer to P.463 to start the engine. How-

ever, if the electronic key is carried inside

the vehicle and the doors are locked

Engine (ignition) switch
(LC500)

Performing the following opera-
tions when carrying the electronic
key on your person starts the
engine or changes engine switch
modes.

Starting the engine

206

4-2. Driving procedures

(



P.132), the engine can be started.

If the 12-volt battery is discharged

The engine cannot be started using the

smart entry & start system. Refer to P.466

to restart the engine.

Electronic key battery depletion



P.126

Conditions affecting operation



P.139

Notes for the entry function



P.140

Steering lock function

After turning the engine switch off and

opening and closing the doors, the steer-

ing wheel will be locked due to the steer-

ing lock function. Operating the engine

switch again automatically cancels the

steering lock.

When the steering lock cannot be

released, “Push engine switch while turn-

ing steering wheel in either direction” will

be displayed on the multi-information dis-

play.

Press the engine switch shortly and firmly

while turning the steering wheel left and

right.

To prevent the steering lock motor from

overheating, operation of the motor may

be suspended if the engine is turned on

and off repeatedly in a short period of

time. In this case, refrain from operating

the engine switch. After about 10 sec-

onds, the steering lock motor will resume

functioning.

If there is a malfunction in the smart

entry & start system

If “Entry & Start System Malfunction See

Owner’s Manual” is displayed on the multi-

information display, the system may be mal-

functioning. Have the vehicle inspected by

any authorized Lexus retailer or Lexus

authorized repairer, or any reliable repairer

immediately.

Electronic key battery



P.421

Operation of the engine switch

If the switch is not pressed shortly and

firmly, the engine switch mode may not

change or the engine may not start.

If attempting to restart the engine imme-

diately after turning the engine switch off,

the engine may not start in some cases.

After turning the engine switch off, please

wait a few seconds before restarting the

engine.

Customization

If the smart entry & start system has been

deactivated in a customized setting, refer to

P.462.

WARNING

When starting the engine

Always start the engine while sitting in

the driver’s seat. Do not depress the

accelerator pedal while starting the

engine under any circumstances.

Doing so may cause an accident result-

ing in death or serious injury.

Caution while driving

If engine failure occurs while the vehicle

is moving, do not lock or open the doors

until the vehicle reaches a safe and com-

plete stop. Activation of the steering lock

in this circumstance may lead to an acci-

dent, resulting in death or serious injury.

NOTICE

When starting the engine

Do not race a cold engine.

207

4-2. Driving procedures

ivin
g

Stop the vehicle completely.

If the parking brake is in manual
mode, set the parking brake.
(



P.231)

Shift the shift position to P.
(



P.218)

Check that the shift position indicator

shows P. (



P.217)

Press the engine switch.

The engine will stop, and the meter display

will be extinguished (the shift position indi-

cator will be extinguished a few seconds

after the meter display).

Check that “ACCESSORY” or
“IGNITION ON” is not shown on
the meter.

Automatic P position selection function



P.218

Modes can be changed by pressing
the engine switch with the brake pedal
released. (The mode changes each
time the switch is pressed.)

NOTICE

If the engine becomes difficult to start

or stalls frequently, have your vehicle

checked by any authorized Lexus

retailer or Lexus authorized repairer,

or any reliable repairer immediately.

Symptoms indicating a malfunction

with the engine switch

If the engine switch seems to be operat-

ing somewhat differently than usual, such

as the switch sticking slightly, there may

be a malfunction. Contact any autho-

rized Lexus retailer or Lexus authorized

repairer, or any reliable repairer immedi-

ately.

Stopping the engine

WARNING

Stopping the engine in an emergency

If you want to stop the engine in an

emergency while driving the vehicle,

press and hold the engine switch for

more than 2 seconds, or press it briefly

3 times or more in succession.

(



P.433)

However, do not touch the engine

switch while driving except in an emer-

gency. Turning the engine off while

driving will not cause loss of steering

or braking control, however, power

assist to the steering will be lost. This

will make it more difficult to steer

smoothly, so you should pull over and

stop the vehicle as soon as it is safe to

do so.

If the engine switch is operated while

the vehicle is running, a warning mes-

sage is shown on the multi-information

display and a buzzer sounds.

When restarting the engine after an

emergency shutdown, press the

engine switch.

Changing engine switch modes

208

4-2. Driving procedures

Off

The emergency flashers can be used.

ACCESSORY mode

Some electrical components such as the
audio system can be used.
“ACCESSORY” will be displayed on the
meter.

IGNITION ON mode

All electrical components can be used.
“IGNITION ON” will be displayed on the
meter.

Auto power off function

If the vehicle is left in ACCESSORY mode

for more than 20 minutes or IGNITION

ON mode (the engine is not running) for

more than an hour with the shift position in

P, the engine switch will automatically turn

off. However, this function cannot entirely

prevent the 12-volt battery discharge. Do

not leave the vehicle with the engine switch

in ACCESSORY or IGNITION ON mode

for long periods of time when the engine is

not running.

When the shift control system malfunc-

tions

When attempting to turn the engine switch

off while there is a malfunction in the shift

control system, the engine switch mode

may change to ACCESSORY mode. In this

case, ACCESSORY mode may be turned

off by applying the parking brake and press-

ing the engine switch again. If there is a mal-

function in the system, have the vehicle

inspected by any authorized Lexus retailer

or Lexus authorized repairer, or any reliable

repairer immediately.

NOTICE

To prevent 12-volt battery discharge

Do not leave the engine switch in

ACCESSORY or IGNITION ON

mode for long periods of time without

the engine running.

If “ACCESSORY” or “IGNITION

ON” is displayed on the meter, the

engine switch is not off. Exit the vehicle

after turning the engine switch off.

209

4-2. Driving procedures

ivin
g

Press the parking brake switch to
check that the parking brake is set.
(



P.231)

The parking brake indicator will come on.

Firmly depress the brake pedal.

and a message will be displayed on

the multi-information display.
If it is not displayed, the hybrid system can-

not be started.
When the shift position is N, the hybrid sys-

tem cannot start. Shift the shift position to P

when starting the hybrid system. (



P.225)

Press the power switch shortly and
firmly.

When operating the power switch, one

short, firm press is enough. It is not neces-

sary to press and hold the switch.
If the “READY” indicator turns on, the

hybrid system will operate normally.
Continue depressing the brake pedal until

the “READY” indicator is illuminated.
The hybrid system can be started from any

power switch mode.

Check that the “READY” indicator
is illuminated.

If the “READY” indicator changes from a

flashing light to a solid light and the buzzer

sounds, the hybrid system is starting nor-

mally.
The vehicle will not move when the

“READY” indicator is off.

The vehicle can move when the “READY”

indicator is on even if the engine is

stopped. (The gasoline engine starts or

stops automatically in accordance with the

state of the vehicle.)

Power switch illumination

According to the situation, the power

switch illumination operates as follows.

When a door is opened, or the power

switch mode is changed from ACCES-

SORY or ON mode to off, the power

switch illumination slowly blinks.

When depressing the brake pedal with

carrying the electronic key on your per-

son, the power switch illumination rapidly

blinks.

When the power switch is in ACCES-

SORY or ON mode, the power switch

illumination illuminates.

If the hybrid system does not start

The immobilizer system may not have

been deactivated. (



P.77)

Contact any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer.

If a message related to start-up is shown

Power (ignition) switch
(LC500h)

Performing the following opera-
tions when carrying the electronic
key on your person starts the hybrid
system or changes power switch
modes.

Starting the hybrid system

Lexus LC (2021 year). Manual in english - page 8
