Lexus CT (2021 year). Manual in english - page 34

688

8-2. Steps to take in an emergency

Once

Sounds

once

for 5

sec-

onds

• An attempt was made to lock the

doors using the smart entry &

start system while the electronic

key was still inside the vehicle.

• An attempt was made to lock

either front door by opening a

door and putting the inside lock

button into the lock position, then

closing the door by pulling on the

outside door handle with the elec-

tronic key still inside the vehicle.



Retrieve the electronic key

from the vehicle and lock the

doors again.

Once



• When the doors were unlocked

with the mechanical key and then

the power switch was pressed, the

electronic key could not be

detected in the vehicle.

• The electronic key could not be

detected in the vehicle even after

the power switch was pressed two

consecutive times.



Touch the electronic key to the

power switch while depressing

the brake pedal.

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

(Flashes)

(Flashes)

689

8-2. Steps to take in an emergency

8

W

hen

 tro

ub

le

 ar

ise

s

■

Warning messages



P. 683

■

Warning buzzer



P. 670

Once



The driver’s door was opened and

closed with the power switch turned

off and then the power switch was

put in ACCESSORY mode twice

without the hybrid system being

started.



Press the power switch while

depressing the brake pedal.

During a hybrid system starting pro-

cedure in the event that the elec-

tronic key was not functioning

properly (



P. 716), the power

switch was touched with the elec-

tronic key.



Press the power switch within 10

seconds of the buzzer sounding.

Once



An attempt was made to start the

hybrid system with the shift position

in N.



Shift the shift position to P and

start the hybrid system.

Once



The electronic key has a low battery.



Replace the electronic key bat-

tery. (



P. 636)

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

(Flashes)

(Flashes)

690

8-2. Steps to take in an emergency

If you have a flat tire (vehicles without a spare tire)

Your vehicle is not equipped with a spare tire, but instead is equipped with an
emergency tire puncture repair kit.
A puncture caused by a nail or screw passing through the tire tread can be
repaired temporarily with the emergency tire puncture repair kit.

WARNING

■

If you have a flat tire

Do not continue driving with a flat tire.
Driving even a short distance with a flat tire can damage the tire and the wheel beyond

repair, which could result in an accident.

691

8-2. Steps to take in an emergency

8

W

hen

 tro

ub

le

 ar

ise

s

●

Stop the vehicle in a safe place on a hard, flat surface.

●

Set the parking brake.

●

Shift the shift position to P.

●

Stop the hybrid system.

●

Turn on the emergency flashers.

●

Check the degree of the tire damage.
A tire should only be repaired with
the emergency tire puncture repair
kit if the damage is caused by a nail
or screw passing through the tire
tread.

• Do not remove the nail or screw

from the tire. Removing the
object may widen the opening
and disenable emergency repair
with the kit.

• To avoid sealant leakage, move the vehicle until the area of the puncture, if

known, is positioned at the top of the tire.

■

A flat tire that cannot be repaired with the emergency tire puncture repair kit

In the following cases, the tire cannot be repaired with the emergency tire puncture

repair kit. Contact any authorized Lexus retailer or Lexus authorized repairer, or any reli-

able repairer.

●

When the tire is damaged due to driving without sufficient air pressure

●

When the tire lost air pressure due to a crack or damage in the tire sidewall

●

When the tire is visibly separated from the wheel

●

When the cut or damage to the tread is 4 mm (0.16 in.) long or more

●

When the wheel is damaged

●

When two or more tires have been punctured

●

When there is more than one hole or cut in the damaged tire

Before repairing the vehicle

692

8-2. Steps to take in an emergency

*

: Use of the jack (



P. 707)

Location of the emergency tire puncture repair kit, jack and tools

Towing eyelet
Emergency tire puncture repair kit
Jack

*

Wheel nut wrench
Jack handle

1

2
3

4
5

693

8-2. Steps to take in an emergency

8

W

hen

 tro

ub

le

 ar

ise

s

Remove the center deck board.

Remove the center auxiliary box.

Emergency tire puncture repair kit components

Bottle
Air pressure gauge
Compressor switch
Air release cap

Stickers
Hose
Power plug
Insertion key

Taking out the emergency tire puncture repair kit

1

2
3
4

5
6
7
8

1

2

694

8-2. Steps to take in an emergency

Take out the emergency tire punc-
ture repair kit.

Remove the center deck board and center auxiliary box. (



P. 693)

Remove the hook and then loosen
and take out the jack.

For loosening
For tightening

When storing the jack, put it into the

tray and tighten it until fixed to the

tray.
Use of the jack:



P. 707

3

Taking out the jack

1

2

1

2

695

8-2. Steps to take in an emergency

8

W

hen

 tro

ub

le

 ar

ise

s

Pull the insertion key out of the kit.

Place the kit with the bottom facing
upward.

Peel off the label, and push in the inser-

tion key until a click is heard.

Return the kit to an upright position
and make sure that the compressor
switch is off.

Use the kit with the top facing upward.

Connect the power plug to the
power outlet socket. (



P. 576)

Emergency repair method

1

2

3

4

696

8-2. Steps to take in an emergency

Remove the valve cap from the valve
of the punctured tire.

Remove the air release cap from the
hose.

Connect the hose to the valve.

Screw the end of the hose clockwise as

far as possible.

Check the specified tire inflation
pressure.

Tire inflation pressure is specified on the

label as shown. (



P. 738)

Start the hybrid system. (



P. 265)

5

6

7

8

9

697

8-2. Steps to take in an emergency

8

W

hen

 tro

ub

le

 ar

ise

s

To inject the sealant and inflate the
tire, turn the compressor switch on.

Use the kit with the top facing upward.

Inflate the tire until the recom-
mended pressure is reached.

The sealant will be injected and
the pressure will spike to 300 kPa
(3.0 kgf/cm

2

 or bar, 44 psi) or

400 kPa (4.0 kgf/cm

2

 or bar, 58

psi), then gradually decrease.
The air pressure gauge will dis-
play the actual tire inflation pres-
sure about 1 minute after the
switch is turned on.

• Turn the compressor switch off

and then check the tire infla-
tion pressure. Being careful
not to over inflate, check and
repeat the inflation procedure
until the recommended tire
inflation pressure is reached.

• If the needle of the air pressure gauge reaches the red zone (450 kPa

[4.5 kgf/cm

2

 or bar, 65 psi] or more), there may be a malfunction in the

tire or in the kit itself. Stop operation immediately.

• If the tire inflation pressure is still lower than the recommended level

after inflation for 10 minutes with the switch on, the tire is too damaged
to be repaired. Turn the compressor switch off and contact any autho-
rized Lexus retailer or Lexus authorized repairer, or any reliable
repairer.

• If the tire inflation pressure exceeds the recommended level, let out

some air to adjust the tire inflation pressure. (



P. 700)

10

11

1

2

698

8-2. Steps to take in an emergency

Disconnect the hose from the valve on the tire and then pull out the power
plug from the power outlet socket.
To spread the liquid sealant evenly within the tire, immediately drive for about
5 km (3 miles).
After driving for about 5 km
(3 miles), stop your vehicle in a safe
place on a hard, flat surface and
reconnect the compressor.

Turn the compressor switch on and
wait for several seconds, then turn it
off. Check the tire inflation pressure.

If the tire inflation pressure is
below 130 kPa (1.3 kgf/cm

2

 or

bar, 19 psi): The puncture cannot
be repaired. Contact any autho-
rized Lexus retailer or Lexus
authorized repairer, or any reli-
able repairer.
If the tire inflation pressure is between 130 kPa (1.3 kgf/cm

2

 or bar, 19 psi)

and a point below the recommended level: The tire can be repaired. Pro-
ceed to step  .
If the tire inflation pressure is at the recommended level: Proceed to step

.

12

13

14

15

1

2

16

3

17

699

8-2. Steps to take in an emergency

8

W

hen

 tro

ub

le

 ar

ise

s

Turn the compressor switch on to inflate the tire until the recommended tire
inflation pressure is reached. Drive for about 5 km (3 miles) and then perform
step .
Store the kit and then attach the 2
stickers as shown.

Taking precautions to avoid sudden

braking and sharp turns, drive carefully

at  under  80  km/h  (50  mph)  to  the

nearest authorized Lexus retailer or

Lexus authorized repairer, or any reli-

able repairer for tire repair or replace-

ment.

16

14

17

700

8-2. Steps to take in an emergency

■

Emergency tire puncture repair kit

●

The sealant has a limited lifespan. The expiry date is marked on the bottle. The sealant

should be replaced before the expiry date. Contact any authorized Lexus retailer or

Lexus authorized repairer, or any reliable repairer for replacement.

●

The sealant stored in the emergency tire puncture repair kit can be used only once to

temporarily repair a single tire. If the sealant in the bottle and other parts of the kit have

been used and need to be replaced, contact any authorized Lexus retailer or Lexus

authorized repairer, or any reliable repairer.

●

The sealant can be used when the outside temperature is from -30



C (-22



F) to 60



C

(140



F).

●

The kit is exclusively designed for size and type of tires originally installed on your vehi-

cle. Do not use it for tires that a different size than the original ones, or for any other

purposes.

●

If the sealant gets on your clothes, it may stain.

●

If the sealant adheres to a wheel or the surface of the vehicle body, the stain may not be

removable if it is not cleaned at once. Immediately wipe away the sealant with a wet

cloth.

●

During operation of the kit, a loud operation noise is produced. This does not indicate a

malfunction.

■

If the tire is inflated to more than the recommended level

Disconnect the hose from the valve.

Disconnect the hose from the valve, remove the air release cap from the hose and then

reconnect the hose.
Turn the compressor switch on and wait for several seconds, then turn it off. Check that

the air pressure indicator shows the recommended level. (



P. 738)

If the air pressure is lower than the recommended level, turn the compressor switch on

again and repeat the inflation procedure until the recommended pressure is reached.

Install the air release cap to the end of the

hose and push the protrusion on the air

release cap into the valve to let some air out.

1

2

3

4

701

8-2. Steps to take in an emergency

8

W

hen

 tro

ub

le

 ar

ise

s

WARNING

■

Precautions for use of the sealant

●

Ingesting the sealant is hazardous to your health. If you ingest sealant, consume as

much water as possible, then immediately consult a doctor.

●

If sealant gets in eyes or adheres to skin, immediately wash it off with water. If discom-

fort persists, consult a doctor.

■

When fixing the flat tire

●

Stop your vehicle in a safe and flat area.

●

Connect the valve and hose securely with the tire installed on the vehicle.

●

If the hose is not properly connected to the valve, air leakage may occur or sealant

may be sprayed out.

●

If the hose comes off the valve while inflating the tire, there is a risk that the hose will

move abruptly due to air pressure.

●

After inflation of the tire has completed, the sealant may splatter when the hose is dis-

connected or some air is let out of the tire.

●

Keep back from the tire while it is being repaired, as there is a chance of it bursting

while the repair operation is being performed. If you notice any cracks or deforma-

tion of the tire, turn off the compressor switch and stop the repair operation immedi-

ately.

●

The kit may overheat if operated for a long period of time. Do not operate the com-

pressor continuously for more than 10 minutes.

●

Parts of the kit become hot during operation. Be careful handling the kit during and

after operation.

●

Do not attach the vehicle speed warning sticker to an area other than the one indi-

cated. If the sticker is attached to an area where an SRS airbag is located, such as the

pad of the steering wheel, it may prevent the SRS air bag from operating properly.

■

Driving to spread the liquid sealant evenly

●

Drive the vehicle carefully at a low speed. Be especially careful when turning and cor-

nering.

●

If the vehicle does not drive straight or you feel a pull through the steering wheel, stop

the vehicle and check the following:
• Tire condition. The tire may have separated from the wheel.

• Tire inflation pressure. If tire inflation pressure is 130 kPa (1.3 kgf/cm

2

 or bar, 19 psi)

or below, this may indicate severe tire damage.

702

8-2. Steps to take in an emergency

NOTICE

■

When performing an emergency repair

●

Perform the emergency repair without removing the nail or screw that has punctured

the tread of the tire. If the object that has punctured the tire is removed, repair by the

emergency tire puncture repair kit may not be possible.

●

The kit is not waterproof. Make sure that the kit is not exposed to water, such as when

it is being used in the rain.

●

Do not put the kit directly onto dusty ground such as sand at the side of the road. If the

kit vacuums up dust etc., a malfunction may occur.

●

Use the kit with the top facing upward. The kit cannot work properly if it is laid on its

side.

■

Handling the emergency tire puncture repair kit

●

The compressor power source should be 12 V DC suitable for vehicle use. Do not

connect the compressor to any other source.

●

If gasoline splatters on the kit, the kit may deteriorate. Take care not to allow gasoline

to contact it.

●

Store the kit in its assigned place out of reach of children.

●

Do not disassemble or modify the kit. Do not subject parts such as the air pressure

indicator to impacts. This may cause a malfunction.

■

To avoid damage to the tire pressure warning valves and transmitters

When a tire is repaired with liquid sealants, the tire pressure warning valve and trans-

mitter may not operate properly. If a liquid sealant is used, contact any authorized

Lexus retailer or Lexus authorized repairer, or any reliable repairer or other qualified

service shop as soon as possible. After use of liquid sealant, make sure to replace the

tire pressure warning valve and transmitter when repairing or replacing the tire.

(



P. 612)

703

8-2. Steps to take in an emergency

8

W

hen

 tro

ub

le

 ar

ise

s

If you have a flat tire (vehicles with a spare tire)

●

Stop the vehicle in a safe place on a hard, flat surface.

●

Set the parking brake.

●

Shift the shift position to P.

●

Stop the hybrid system.

●

Turn on the emergency flashers. (



P. 656)

Your vehicle is equipped with a spare tire. The flat tire can be replaced with
the spare tire.
For details about tires:



P. 611

WARNING

■

If you have a flat tire

Do not continue driving with a flat tire.
Driving even a short distance with a flat tire can damage the tire and the wheel beyond

repair, which could result in an accident.

Before jacking up the vehicle
