LEXUS RX 350 L (2019 year). Instruction

685

8-2. Steps to take in an emergency

When trouble

ari

ses

RX350/RX350L_U

■

Locking the door

With the door open, push down
the inside lock button.

Close the door.

■

Key linked functions

Ensure that the shift lever is in P and depress the brake pedal.
Touch the Lexus emblem side of the
electronic key to the engine switch.

When the electronic key is detected, a

buzzer sounds and the engine switch

will turn to IGNITION ON mode.
When the smart access system with

push-button start is deactivated in

customization setting, the engine switch

will turn to ACCESSORY mode.

Firmly depress the brake pedal and check that

is shown on the multi-

information display.
Press the engine switch shortly and firmly.

In the event that the engine still cannot be started, contact your Lexus dealer.

Closes the windows and the moon roof

panoramic moon roof

(turn and hold)

Opens the windows and the moon roof

panoramic moon roof

(turn and hold)

These settings must be customized at your

Lexus dealer.

: If equipped

Starting the engine

686

8-2. Steps to take in an emergency

RX350/RX350L_U

■

Stopping the engine
Shift the shift lever to P, set the parking brake, and press the engine switch as you nor-

mally do when stopping the engine.

■

Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the electronic

key battery be replaced immediately when the battery is depleted. (

P. 623)

■

Changing engine switch modes
Release the brake pedal and press the engine switch in step above.

The engine does not start and modes will be changed each time the switch is pressed.

(

P. 232)

■

When the electronic key does not work properly

●

Make sure that the smart access system with push-button start has not been deacti-

vated in the customization setting. If it is off, turn the function on.

(Customizable features

P. 722)

●

Check if battery-saving mode is set. If it is set, cancel the function. (

P. 148)

WARNING

■

When using the mechanical key and operating the power windows or the moon roof

or panoramic moon roof
Operate the power window or the moon roof or panoramic moon roof after checking

to make sure that there is no possibility of any passenger having any of their body parts

caught in the window or the moon roof or panoramic moon roof.

Also, do not allow children to operate the mechanical key. It is possible for children and

other passengers to get caught in the power window or the moon roof or panoramic

moon roof.

687

8-2. Steps to take in an emergency

When trouble

ari

ses

RX350/RX350L_U

If you have a set of jumper (or booster) cables and a second vehicle with a bat-
tery, you can jump start your vehicle by following the steps below.

Confirm that the electronic key is
being carried.

When connecting the jumper (or

booster) cables, depending on the situa-

tion, the alarm may activate and doors

locked. (



P. 78)

Open the hood (

P. 592)

If the vehicle battery is discharged

The following procedures may be used to start the engine if the vehicle’s bat-
tery is discharged.
You can also call your Lexus dealer or a qualified repair shop.

688

8-2. Steps to take in an emergency

RX350/RX350L_U

Connect the jumper cables according to the following procedure:

Connect a positive jumper cable clamp to the positive (+) battery terminal
on your vehicle.
Connect the clamp on the other end of the positive cable to the positive (+)
battery terminal on the second vehicle.
Connect a negative cable clamp to the negative (-) battery terminal on the
second vehicle.
Connect the clamp at the other end of the negative cable to a solid, station-
ary, unpainted metallic point away from the battery and any moving parts,
as shown in the illustration.

Start the engine of the second vehicle. Increase the engine speed slightly and
maintain at that level for approximately 5 minutes to recharge the battery of
your vehicle.
Open and close any of the doors of your vehicle with the engine switch off.
Maintain the engine speed of the second vehicle and start the engine of your
vehicle by turning the engine switch to IGNITION ON mode.
Once the vehicle’s engine has started, remove the jumper cables in the exact
reverse order from which they were connected.

Once the engine starts, have the vehicle inspected at your Lexus dealer as soon
as possible.

5
6

689

8-2. Steps to take in an emergency

When trouble

ari

ses

RX350/RX350L_U

■

Starting the engine when the battery is discharged
The engine cannot be started by push-starting.

■

To prevent battery discharge

●

Turn off the headlights and the audio system while the engine is off.

●

Turn off any unnecessary electrical components when the vehicle is running at a low

speed for an extended period, such as in heavy traffic.

■

When removing the battery terminals
When the battery terminals are removed, the information stored in the ECU is cleared.

Before removing the battery terminals, contact your Lexus dealer.

■

Charging the battery
The electricity stored in the battery will discharge gradually even when the vehicle is not

in use, due to natural discharge and the draining effects of certain electrical appliances. If

the vehicle is left for a long time, the battery may discharge, and the engine may be

unable to start. (The battery recharges automatically during driving.)

■

When the battery is removed or discharged

●

In some cases, it may not be possible to unlock the doors using the smart access system

with push-button start when the battery is discharged. Use the wireless remote control

or the mechanical key to lock or unlock the doors.

●

The engine may not start on the first attempt after the battery has recharged but will

start normally after the second attempt. This is not a malfunction.

●

The engine switch mode is memorized by the vehicle. When the battery is recon-

nected, the system will return to the mode it was in before the battery was discharged.

Before disconnecting the battery, turn the engine switch off.

If you are unsure what mode the engine switch was in before the battery discharged, be

especially careful when reconnecting the battery.

●

The power back door must be initialized. (

P. 138)

■

When replacing the battery

●

Use a battery with the same case size as the previous battery and an equivalent 20

hour rate capacity (20HR) or greater.
• If the sizes differ, the battery cannot be properly secured.

• If the 20 hour rate capacity is low, even if the time period where the vehicle is not

used is a short time, the battery may discharge and the engine may not be able to

start.

●

For details, consult your Lexus dealer.

690

8-2. Steps to take in an emergency

RX350/RX350L_U

WARNING

■

When removing the battery terminals
Always remove the negative (-) terminal first. If the positive (+) terminal contacts any

metal in the surrounding area when the positive (+) terminal is removed, a spark may

occur, leading to a fire in addition to electrical shocks and death or serious injury.

■

Avoiding battery fires or explosions
Observe the following precautions to prevent accidentally igniting the flammable gas

that may be emitted from the battery:

●

Make sure each jumper cable is connected to the correct terminal and that it is not

unintentionally in contact with any other than the intended terminal.

●

Do not allow the other end of the jumper cable connected to the “+” terminal to come

into contact with any other parts or metal surfaces in the area, such as brackets or

unpainted metal.

●

Do not allow the + and - clamps of the jumper cables to come into contact with each

other.

●

Do not smoke, use matches, cigarette lighters or allow open flame near the battery.

■

Battery precautions
The battery contains poisonous and corrosive acidic electrolyte, while related parts

contain lead and lead compounds. Observe the following precautions when handling

the battery:

●

When working with the battery, always wear safety glasses and take care not to allow

any battery fluids (acid) to come into contact with skin, clothing or the vehicle body.

●

Do not lean over the battery.

●

In the event that battery fluid comes into contact with the skin or eyes, immediately

wash the affected area with water and seek medical attention.

Place a wet sponge or cloth over the affected area until medical attention can be

received.

●

Always wash your hands after handling the battery support, terminals, and other bat-

tery-related parts.

●

Do not allow children near the battery.

691

8-2. Steps to take in an emergency

When trouble

ari

ses

RX350/RX350L_U

WARNING

■

When replacing the battery

●

When the vent plug and indicator are close to the hold down clamp, the battery fluid

(sulfuric acid) may leak.

●

For information regarding battery replacement, contact your Lexus dealer.

NOTICE

■

When handling jumper cables
When connecting the jumper cables, ensure that they do not become entangled in the

cooling fans or engine drive belt.

692

8-2. Steps to take in an emergency

RX350/RX350L_U

Stop the vehicle in a safe place and turn off the air conditioning system, and
then stop the engine.
If you see steam:
Carefully lift the hood after the steam subsides.
If you do not see steam:
Carefully lift the hood.
After the engine has cooled down
sufficiently, inspect the hoses and
radiator core (radiator) for any
leaks.

Radiator
Cooling fans

If a large amount of coolant leaks,

immediately contact your Lexus

dealer.

The coolant level is satisfactory if it is
between the “FULL” and “LOW”
lines on the reservoir.

Reservoir
“FULL” line
“LOW” line
Radiator cap

If your vehicle overheats

The following may indicate that your vehicle is overheating.

●

The needle of the engine coolant temperature gauge (

P. 86) enters the

red zone, or a loss of engine power is experienced. (For example, the vehi-
cle speed does not increase.)

●

“Engine Coolant Temp High Stop in a Safe Place See Owner’s Manual” is
shown on the multi-information display.

●

Steam comes out from under the hood.

Correction procedures

2
3
4

693

8-2. Steps to take in an emergency

When trouble

ari

ses

RX350/RX350L_U

Add coolant if necessary.

Water can be used in an emergency if

coolant is unavailable.

Start the engine and turn the air conditioning system on to check that the radi-
ator cooling fans operate and to check for coolant leaks from the radiator or
hoses.

The fans operate when the air conditioning system is turned on immediately after a

cold start. Confirm that the fans are operating by checking the fan sound and air flow.

If it is difficult to check these, turn the air conditioning system on and off repeatedly.

(The fans may not operate in freezing temperatures.)

If the fans are not operating:
Stop the engine immediately and contact your Lexus dealer.
If the fans are operating:
Have the vehicle inspected at the nearest Lexus dealer.
Check if “Engine Coolant Temp High Stop in a Safe Place See Owner’s Man-
ual” is shown on the multi-information display.
If the message does not disappear:
Stop the engine and contact your Lexus dealer.
If the message is not displayed:
Have the vehicle inspected at the nearest Lexus dealer.

694

8-2. Steps to take in an emergency

RX350/RX350L_U

WARNING

■

To prevent an accident or injury when inspecting under the hood of your vehicle
Observe the following precautions.

Failure to do so may result in serious injury such as burns.

●

If steam is seen coming from under the hood, do not open the hood until the steam

has subsided. The engine compartment may be very hot.

●

Keep hands and clothing (especially a tie, a scarf or a muffler) away from the fans and

belts. Failure to do so may cause the hands or clothing to be caught, resulting in seri-

ous injury.

●

Do not loosen the radiator cap and the coolant reservoir cap while the engine and

radiator are hot.

High temperature steam or coolant could spray out.

NOTICE

■

When adding engine coolant
Add coolant slowly after the engine has cooled down sufficiently. Adding cool coolant

to a hot engine too quickly can cause damage to the engine.

■

To prevent damage to the cooling system
Observe the following precautions:

●

Avoid contaminating the coolant with foreign matter (such as sand or dust etc.).

●

Do not use any coolant additive.

695

8-2. Steps to take in an emergency

When trouble

ari

ses

RX350/RX350L_U

Stop the engine. Shift the shift lever to P and set the parking brake.
Remove the mud, snow or sand from around the front wheels.
Place wood, stones or some other material under the front wheels to help pro-
vide traction.
Restart the engine.
AWD models: Activate all-wheel drive lock mode. (

P. 377)

Shift the shift lever to D or R and release the parking brake. Then, while exer-
cising caution, depress the accelerator pedal.

■

When it is difficult to free the vehicle

If the vehicle becomes stuck

Carry out the following procedures if the tires spin or the vehicle becomes
stuck in mud, dirt or snow:

Press

to turn off TRAC.

2
3

4
5
6

696

8-2. Steps to take in an emergency

RX350/RX350L_U

WARNING

■

When attempting to free a stuck vehicle
If you choose to push the vehicle back and forth to free it, make sure the surrounding

area is clear to avoid striking other vehicles, objects or people. The vehicle may also

lunge forward or lunge back suddenly as it becomes free. Use extreme caution.

■

When shifting the shift lever
Be careful not to shift the shift lever with the accelerator pedal depressed.

This may lead to unexpected rapid acceleration of the vehicle that may cause an acci-

dent resulting in death or serious injury.

NOTICE

■

To avoid damage to the transmission and other components

●

Avoid spinning the front wheels and depressing the accelerator pedal more than nec-

essary.

●

If the vehicle remains stuck even after these procedures are performed, the vehicle

may require towing to be freed.

●

When a warning message for the automatic transmission fluid temperature is dis-

played while attempting to free a stuck vehicle, immediately remove your foot from

the accelerator pedal and wait until the warning message disappears. Otherwise, the

transmission may become damaged. (

P. 662)

698

RX350/RX350L_U

9-1. Specifications

: RX350

: RX350L

: Unladen vehicle

: Vehicles with towing package

: For GGL25L-BWZGBA models*

: Except for GGL25L-BWZGBA models*

: Vehicles with separate seat

: Vehicles with bench seat

: The model code is indicated on the Certification Label. (

P. 699)

Maintenance data (fuel, oil level, etc.)

Dimensions and weight

Overall length

192.5 in. (4890 mm)

196.9 in. (5000 mm)

Overall width

74.6 in. (1895 mm)

Overall height

67.7 in. (1720 mm)

Wheelbase

109.8 in. (2790 mm)

Tread

Front

64.4 in. (1635 mm)

64.5 in. (1640 mm)

Rear

64.0 in. (1625 mm)

64.1 in. (1630 mm)

Vehicle capacity weight

(Occupants + luggage)

1050 lb. (480 kg)

1, 5

920 lb. (420 kg)

1, 6

1140 lb. (520 kg)

2, 7

1235 lb. (560 kg)

2, 8

Trailer Weight Rating

(Trailer weight + cargo weight)

3500 lb. (1585 kg)

699

9-1. Specifications

icl

e spe

cif

atio

RX350/RX350L_U

■

Vehicle identification number
The vehicle identification number (VIN) is the legal identifier for your vehicle.
This is the primary identification number for your Lexus. It is used in register-
ing the ownership of your vehicle.
This number is stamped on the top
left of the instrument panel.

This number is also on the Certifica-
tion Label.

On some models, this number is also
stamped under the right-hand front
seat.

Vehicle identification

700

9-1. Specifications

RX350/RX350L_U

■

Engine number
The engine number is stamped on
the engine block as shown.

: The engine oil capacity is a reference quantity to be used when changing the engine

oil. Warm up and turn off the engine, wait more than 5 minutes, and check the oil level
on the dipstick.

Engine

Model

3.5 L 6-cylinder (2GR-FKS)

Type

6-cylinder V type, 4-cycle, gasoline

Bore and stroke

3.70

 3.27 in. (94.0  83.0 mm)

Displacement

210.9 cu. in. (3456 cm

)

Valve clearance (engine cold)

Automatic adjustment

Drive belt tension

Automatic adjustment

Fuel

Fuel type

Unleaded gasoline only

Octane Rating

87 (Research Octane Number 91) or higher

Fuel tank capacity (Reference)

19.2 gal. (72.5 L, 15.9 Imp. gal.)

Lubrication system

Oil capacity
(Drain and refill - reference

)

With filter



Vehicles with towing package

5.8 qt. (5.5 L, 4.8 Imp. qt.)



Vehicles without towing package

5.7 qt. (5.4 L, 4.8 Imp. qt.)

Without filter

5.6 qt. (5.3 L, 4.7 Imp. qt.)

LEXUS RX 350 L (2019 year). Instruction - part 43
