LEXUS RX 350 L (2019 year). Instruction

109

2. Instrument cluster

Instrument cl

uste
r

RX350/RX350L_U

Vehicle speed display area

Displays the following items:

• Vehicle speed

• Speed limit (vehicles with a navigation system) (U.S.A. only)

Eco Driving Indicator/Tachometer (

P. 111)

Shift position display (

P. 236, 240)

HUD (Head-up display) switch (

P. 109)

◆

Enabling/Disabling the head-up display

Press the HUD (Head-up display)
switch.

◆

Changing settings of the head-up display

Select

on the multi-information display (

P. 97) to change the following

settings:

■

Display brightness/position
Select to adjust the brightness and position of the head-up display.

■

Display content
Select to enable/disable the following items:

• Route guidance to destination (if equipped)

• Driving assist system status (if equipped)

• Compass (if equipped)

• Audio system operation status

■

Eco Driving Indicator/Tachometer
Select to display Eco Driving Indicator/tachometer/no content.

Using the head-up display

6
7
8

110

2. Instrument cluster

RX350/RX350L_U

Displays the following multi-information display linked icons:

: Master warning icon

Displayed when a warning message is displayed on the multi-information
display. (

P. 661)

: Information icon

Displayed when a suggestion/advice pop-up display is displayed on the
multi-information display. (

P. 105)

Displays the following items in the appropriate situation:

■

Warning/Message (if equipped)
Displays the following system warning/messages:

• Pre-collision warning (pre-collision system)

• Alert from the Intelligent Clearance Sonar system

• Notification message (Dynamic radar cruise control with full-speed range)

■

Audio system operation status
Displayed when the audio system is operated.

■

Outside temperature
Displayed in the following situations:

• When the engine switch is turned to IGNITION ON mode

• When the low outside temperature indicator is flashing

Displayed content is the same as that displayed on the multi-information display. For

details, refer to the explanation of the outside temperature display on the multi-infor-

mation display. (

P. 86)

icons

Message display area

111

2. Instrument cluster

Instrument cl

uste
r

RX350/RX350L_U

Displays the following items which are linked to the navigation system:

■

Street name
The name of the street that the vehicle is currently driving on is displayed on
the bottom of the display area.
When the navigation system is performing route guidance, the name of the
next street will be displayed on the top of the display area.

■

Route guidance to destination
Displayed when the navigation system is performing route guidance. When
approaching an intersection, an arrow will be displayed to indicate the sug-
gested direction of travel.

■

Compass
Displays the direction of travel.

■

Eco Driving Indicator

Eco Driving Indicator Zone Dis-
play
Eco driving ratio based on accel-
eration
Zone of Eco driving

Displayed content is the same as that

displayed on the multi-information

display (Eco Driving Indicator). For

details, refer to P. 105.

■

Tachometer
Displays the engine speed in revolutions per minute.

Navigation system-linked display area (if equipped)

Eco Driving Indicator/Tachometer

112

2. Instrument cluster

RX350/RX350L_U

■

Head-up display
The head-up display may seem dark or hard to see when viewed through sunglasses,

especially polarized sunglasses.

Adjust the brightness of the head-up display or remove your sunglasses.

■

When the battery is disconnected
The customize settings of the head-up display will be reset.

■

Display brightness
The brightness of the head-up display can be adjusted on

of the multi-information

display. Also, it is automatically adjusted according to the ambient brightness.

■

Enabling/disabling of the head-up display
If the head-up display is disabled, it will remain disabled when the engine switch is turned

off then back to IGNITION ON mode.

■

Automatic adjustment of the head-up display position
A desired head-up display position can be entered to memory and recalled automati-

cally by the driving position memory system. (

P. 172)

■

Street name display (vehicles with a navigation system)
Only street names which are included in the map data will be displayed.

WARNING

■

Before using the head-up display

●

Check that the position and brightness of the head-up display image does not inter-

fere with safe driving. Incorrect adjustment of the image’s position or brightness may

obstruct the driver’s view and lead to an accident, resulting in death or serious injury.

●

Do not continuously look at the head-up display while driving as you may fail to see

pedestrians, objects on the road, etc. ahead of the vehicle.

■

Caution for changing settings of the head-up display
As the engine needs to be running while changing the settings of the head-up display,

ensure that the vehicle is parked in a place with adequate ventilation. In a closed area

such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect

and enter the vehicle. This may lead to death or a serious health hazard.

113

2. Instrument cluster

Instrument cl

uste
r

RX350/RX350L_U

NOTICE

■

To prevent damage to components

■

When changing the settings of the head-up display
To prevent battery discharge, ensure that the engine is running while the changing the

settings of the head-up display.

●

Do not place any drinks near the head-up dis-

play projector. If the projector gets wet, elec-

trical malfunctions may result.

●

Do not place anything on or put stickers onto

the head-up display projector.

Doing so could interrupt head-up display

indications.

●

Do not touch the inside of the head-up display

projector or thrust sharp edges or the like into

the projector.

Doing so could cause mechanical malfunc-

tions.

114

2. Instrument cluster

RX350/RX350L_U

Audio system screen
“MENU” button
Lexus Display Audio controller
“MENU” button
Remote Touch knob
“ENTER” button

: Vehicles with a Lexus Display Audio sys-

tem

: Vehicles with a navigation system

Fuel consumption information

Fuel consumption information can be displayed on the audio system.
Vehicles with a navigation system (12.3-inch display): The fuel consumption
information can be displayed and operated on the side display.

2
3
4
5
6

115

2. Instrument cluster

Instrument cl

uste
r

RX350/RX350L_U



Lexus Display Audio screen

Press the “MENU” button on the Lexus Display Audio controller, then select
“Info” on the “Menu” screen, and then select “Fuel Consumption”.

If the “Trip Information” screen does not appear, move the controller to the right and

select “Trip Information”.

Fuel consumption in the past 15 min-
utes
Current fuel consumption
Average vehicle speed since the
engine was started.
Elapsed time since the engine was
started.
Cruising range (

P. 117)



Navigation system screen

Press the “MENU” button on the Remote Touch, then select

on the “Menu”

screen, and then select “Fuel Consumption”.

If the “Past Record” screen is displayed, select “Trip Information”.

Resetting the consumption data
Fuel consumption in the past 15 min-
utes
Current fuel consumption
Average vehicle speed since the
engine was started.
Elapsed time since the engine was
started.
Cruising range (

P. 117)

Average fuel consumption for the past 15 minutes is divided by color into past
averages and averages attained since the engine switch was last turned to IGNI-
TION ON mode. Use the displayed average fuel consumption as a reference.
The image is an example only.

Trip information

2
3

3
4

116

2. Instrument cluster

RX350/RX350L_U



Lexus Display Audio screen

Press the “MENU” button on the Lexus Display Audio controller, then select
“Info” on the “Menu” screen, and then select “Fuel Consumption”.

If the “Past Record” screen does not appear, move the controller to the right and

select “Past Record”.

Previous fuel consumption record
Current fuel consumption
Best recorded fuel consumption



Navigation system screen

Press the “MENU” button on the Remote Touch, then select

on the “Menu”

screen, and then select “Fuel Consumption”.

If the “Trip Information” screen is displayed, select “Past Record”.

Resetting the past record data
Best recorded fuel consumption
Average fuel consumption
Previous fuel consumption record
Updating the average fuel con-
sumption data

The average fuel consumption history is divided by color into past averages and
the average fuel consumption since the last updated. Use the displayed average
fuel consumption as a reference.
The image is an example only.

Past record

2
3

2
3
4
5

117

2. Instrument cluster

Instrument cl

uste
r

RX350/RX350L_U

■

Updating the past record data



Vehicles with a Lexus Display Audio system

Update the average fuel consumption by moving the controller to the left and select

“Update” to measure the current fuel consumption again.



Vehicles with a navigation system

Update the average fuel consumption by selecting “Update” to measure the current fuel

consumption again.

■

Resetting the data



Vehicles with a Lexus Display Audio system

The fuel consumption data can be deleted by moving the controller to the left and select

“Clear”.



Vehicles with a navigation system

The fuel consumption data can be deleted by selecting “Clear”.

■

Cruising range
Displays the estimated maximum distance that can be driven with the quantity of fuel

remaining.
This distance is computed based on your average fuel consumption.

As a result, the actual distance that can be driven may differ from that displayed.

118

2. Instrument cluster

RX350/RX350L_U

Vehicle information can be displayed on the side display (

P. 501), then select

“<” or “>” to select the desired screen.



Fuel consumption

Displays the average fuel consumption
for the past 10 minutes in 1 minute inter-
vals, as well as the cruising range.



Past record

Displays the average fuel consumption
and highest fuel consumption.



Trip information

Displays the cruising range, average
fuel consumption and the amount of
time elapsed since the engine was
started.

The image is an example only, and may vary slightly from actual conditions.

Using the side display (vehicles with a navigation system [12.3-inch dis-
play])

120

RX350/RX350L_U

3-1. Key information

The following keys are provided with the vehicle.

Electronic keys

• Operating the smart access sys-

tem with push-button start
(

P. 146)

• Operating the wireless remote

control function

Mechanical keys
Key number plate

Locks all the doors (

P. 124)

Unlocks all the doors (

P. 124)

Opens the windows

and the

moon roof

1, 2

or panoramic moon

roof

1, 2

(

P. 124)

Opens and closes the power back
door (

P. 130)

Sounds the alarm (

P. 121)

: If equipped

: This setting must be customized at your Lexus dealer.

Keys

The keys

2
3

Wireless remote control

2
3

121

3-1. Key information

Op
era
tio

n of
ea

RX350/RX350L_U

To take out the mechanical key, push
the release button and take the key out.

The mechanical key can only be

inserted in one direction, as the key only

has grooves on one side. If the key can-

not be inserted in a lock cylinder, turn it

over and re-attempt to insert it.
After using the mechanical key, store it

in the electronic key. Carry the mechan-

ical key together with the electronic key.

If the electronic key battery is depleted

or the entry function does not operate

properly, you will need the mechanical

key. (

P. 684)

■

Panic mode

■

When required to leave the vehicle’s key with a parking attendant
Lock the glove box as circumstances demand. (

P. 530)

Remove the mechanical key for your own use and provide the attendant with the elec-

tronic key only.

■

If you lose your mechanical keys
New genuine mechanical keys can be made by your Lexus dealer using another

mechanical key and the key number stamped on your key number plate. Keep the plate

in a safe place such as your wallet, not in the vehicle.

■

When riding in an aircraft
When bringing an electronic key onto an aircraft, make sure you do not press any but-

tons on the electronic key while inside the aircraft cabin. If you are carrying an electronic

key in your bag, etc., ensure that the buttons are not likely to be pressed accidentally.

Pressing a button may cause the electronic key to emit radio waves that could interfere

with the operation of the aircraft.

Using the mechanical key

When

is pressed for longer than about

one second, an alarm will sound intermittently

and the vehicle lights will flash to deter any per-

son from trying to break into or damage your

vehicle.
To stop the alarm, press any button on the elec-

tronic key.

122

3-1. Key information

RX350/RX350L_U

■

Electronic key battery depletion

●

The standard battery life is 1 to 2 years.

●

If the battery becomes low, an alarm will sound in the cabin when the engine is stopped.

(

P. 623)

●

As the electronic key always receives radio waves, the battery will become depleted

even if the electronic key is not used. The following symptoms indicate that the elec-

tronic key battery may be depleted. Replace the battery when necessary. (

P. 623)

• The smart access system with push-button start or the wireless remote control does

not operate.

• The detection area becomes smaller.

• The LED indicator on the key surface does not turn on.

●

To reduce key battery depletion when the electronic key is to not be used for long peri-

ods of time, set the electronic key to the battery-saving mode.

(

P. 148)

●

To avoid serious deterioration, do not leave the electronic key within 3 ft. (1 m) of the

following electrical appliances that produce a magnetic field:
• TVs

• Personal computers

• Cellular phones, cordless phones and battery chargers

• Recharging cellular phones or cordless phones

• Induction cookers

• Table lamps

■

Replacing the battery
P. 623

■

Confirmation of the registered key number
The number of keys already registered to the vehicle can be confirmed. Ask your Lexus

dealer for details.

■

If a wrong key is used
The key cylinder rotates freely, isolated from the internal mechanism.

123

3-1. Key information

Op
era
tio

n of
ea

RX350/RX350L_U

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject them to strong shocks or bend them.

●

Do not expose the keys to high temperatures for long periods of time.

●

Do not get the keys wet or wash them in an ultrasonic washer, etc.

●

Do not attach metallic or magnetic materials to the keys or place the keys close to

such materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or anything else to the surface of the electronic key.

●

Do not place the keys near objects that produce magnetic fields, such as TVs, audio

systems and induction cookers, or medical electrical equipment, such as low-fre-

quency therapy equipment.

■

Carrying the electronic key on your person
Carry the electronic key 3.9 in. (10 cm) or more away from electric appliances that are

turned on. Radio waves emitted from electric appliances within 3.9 in. (10 cm) of the

electronic key may interfere with the key, causing the key to not function properly.

■

In case of a smart access system with push-button start malfunction or other key-

related problems
Take your vehicle with all the electronic keys provided with your vehicle to your Lexus

dealer.

■

When an electronic key is lost
If the electronic key remains lost, the risk of vehicle theft increases significantly. Visit

your Lexus dealer immediately with all remaining electronic keys that were provided

with your vehicle.

124

RX350/RX350L_U

3-2. Opening, closing and locking the doors

◆

Smart access system with push-button start

Carry the electronic key to enable this function.

Grip the driver’s door handle to
unlock the door. Grip any passen-
ger door handle to unlock all the
doors.

Make sure to touch the sensor on the

back of the handle.
The doors cannot be unlocked for

3 seconds after the doors are locked.

: The door unlock settings can be

changed. (

P. 128,726)

Touch the lock sensor (indentation on the surface of the door handle) to
lock all the doors.

Check that the door is securely locked.

◆

Wireless remote control

Locks all the doors

Check that the door is securely

locked.

Unlocks all the doors

Pressing the button unlocks the

driver’s door. Pressing the button

again within 3 seconds unlocks the

other doors.
Press and hold to open the win-
dows

and the moon roof

1, 2

panoramic moon roof

1, 2

: If equipped

: This setting must be customized at your Lexus dealer.

Side doors

The vehicle can be locked and unlocked using the entry function, wireless
remote control or door lock switches.

Locking and unlocking the doors from the outside

LEXUS RX 350 L (2019 year). Instruction - part 7
