LEXUS RC300, RC350 (2019 year). Instruction - part 20

313

7-2. Steps to take in an emergency

RC350AWD_RC350_RC300AWD_RC30

0_OM_(U)_1810

n t

ris

Stop the engine. Set the parking
brake and shift the shift lever to P.

Remove the mud, snow or sand
from around the rear wheels.

Place wood, stones or some other
material under the rear wheels to
help provide traction.

Restart the engine.

Shift the shift lever to D or R and
release the parking brake. Then,
while exercising caution, depress
the accelerator pedal.

■

When it is difficult to free the vehicle

Press the

switch to turn off TRAC.

If the vehicle becomes stuck

Carry out the following proce-
dures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:

Recovering procedure

WARNING

■

When attempting to free a stuck vehi-

cle

If you choose to push the vehicle back

and forth to free it, make sure the sur-

rounding area is clear to avoid striking

other vehicles, objects or people. The

vehicle may also lunge forward or lunge

back suddenly as it becomes free. Use

extreme caution.

■

When shifting the shift lever

Be careful not to shift the shift lever with

the accelerator pedal depressed.

This may lead to unexpected rapid accel-

eration of the vehicle that may cause an

accident resulting in death or serious

injury.

NOTICE

■

To avoid damaging the transmission

and other components

●

Avoid spinning the rear wheels and

depressing the accelerator pedal

more than necessary.

●

If the vehicle remains stuck even after

these procedures are performed, the

vehicle may require towing to be freed.

314

7-2. Steps to take in an emergency

RC350AWD_RC350_RC300AWD_RC30

0_OM_(U)_1810

315

RC350AWD_RC350_RC300AWD_RC30

0_OM_(U)_1810

Vehi

cle

spec

ifi

tions

Vehicle specifications

8-1. Specifications

Maintenance data (fuel, oil level,

etc.) ...............................................

316

Fuel information.........................

327

Tire information..........................

329

8-2. Customization

Customizable features............

339

8-3. Items to initialize

Items to initialize ........................

349

8-4. Certifications

Certifications ..............................

350

316

8-1. Specifications

RC350AWD_RC350_RC300AWD_RC30

0_OM_(U)_1810

8-1.Specifications

: Unladen vehicle

: Vehicles with 265/35R19 tires

■

Vehicle identification number

The vehicle identification number
(VIN) is the legal identifier for your
vehicle. This is the primary identifica-
tion number for your Lexus. It is used in
registering the ownership of your vehi-
cle.
This number is stamped on the top left
of the instrument panel and in the
engine compartment.



RC350/RC300 AWD



RC300

Maintenance data (fuel, oil level, etc.)

Dimensions and weight

Overall length

185.0 in. (4700 mm)

Overall width

72.4 in. (1840 mm)

Overall height

54.9 in. (1395 mm)

Wheelbase

107.5 in. (2730 mm)

Tread

Front

62.2 in. (1580 mm)

Rear

63.0 in. (1600 mm)

61.8 in. (1570 mm)

Vehicle capacity weight (Occupants + luggage)

700 lb. (320 kg)

Vehicle identification

317

8-1. Specifications

RC350AWD_RC350_RC300AWD_RC30

0_OM_(U)_1810

Vehi

cle

spec

ifi

tions

This number is also on the Certification
Label.

■

Engine number

The engine number is located as
shown.



RC350/RC300 AWD



RC300

■

RC350/RC300 AWD

■

RC300

Engine

Model

3.5 L 6-cylinder (2GR-FKS) engine

Type

6-cylinder V type, 4-cycle, gasoline

Bore and stroke

3.70

 3.27 in. (94.0  83.0 mm)

Displacement

210.9 cu. in. (3456 cm

)

Drive belt tension

Automatic adjustment

Model

2.0 L 4-cylinder (8AR-FTS) engine

Type

4-cylinder in line, 4-cycle, gasoline (with tur-
bocharger)

Bore and stroke

3.39

 3.39 in. (86.0  86.0 mm)

Displacement

121.9 cu. in. (1998 cm

)

Drive belt tension

Automatic adjustment

318

8-1. Specifications

RC350AWD_RC350_RC300AWD_RC30

0_OM_(U)_1810

■

Oil capacity (Drain and refill [Reference

])

: The engine oil capacity is a reference quantity to be used when changing the engine oil.

Warm up and turn off the engine, wait more than 5 minutes, and check the oil level on the
dipstick.

■

Engine oil selection

“Toyota Genuine Motor Oil” is used in
your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor Oil”
or equivalent to satisfy the following
grade and viscosity.
Oil grade: ILSAC GF-5 multigrade
engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good starting
in cold weather.

If SAE 0W-20 is not available, SAE
5W-20 oil may be used. However, it
must be replaced with SAE 0W-20 at
the next oil change.

Fuel

Fuel type

Unleaded gasoline only

Octane Rating

91 (Research Octane Number 96) or higher

Fuel tank capacity (Reference)

17.5 gal. (66.3 L, 14.6 Imp. gal.)

Lubrication system

With filter



RC350

6.0 qt. (5.7 L, 5.0 Imp. qt.)



RC350 AWD/RC300 AWD

6.8 qt. (6.4 L, 5.6 Imp. qt.)



RC300

4.9 qt. (4.6 L, 4.0 Imp. qt.)

Without filter



RC350

5.8 qt. (5.5 L, 4.8 Imp. qt.)



RC350 AWD/RC300 AWD

6.3 qt. (6.0 L, 5.3 Imp. qt.)



RC300

4.5 qt. (4.3 L, 3.8 Imp. qt.)

319

8-1. Specifications

RC350AWD_RC350_RC300AWD_RC30

0_OM_(U)_1810

Vehi

cle

spec

ifi

tions

Outside temperature

Oil viscosity (0W-20 is explained here
as an example):
• The 0W in 0W-20 indicates the

characteristic of the oil which allows
cold startability. Oils with a lower
value before the W allow for easier
starting of the engine in cold
weather.

• The 20 in 0W-20 indicates the vis-

cosity characteristic of the oil when
the oil is at high temperature. An oil
with a higher viscosity (one with a
higher value) may be better suited if
the vehicle is operated at high
speeds, or under extreme load con-

ditions.

How to read oil container label:
The International Lubricant Specifica-
tion Advisory Committee (ILSAC)
Certification Mark is added to some oil
containers to help you select the oil you
should use.

: The fluid capacity is a reference quantity.

If replacement is necessary, contact your Lexus dealer.

Cooling system

Capacity

RC350/RC3
00 AWD

10.0 qt. (9.5 L, 8.4 Imp. qt.)

RC300



Gasoline engine

8.5 qt. (8.0 L, 7.0 Imp. qt.)



Intercooler

3.3 qt. (3.1 L, 2.7 Imp. qt.)

Coolant type

Use either of the following:
 “Toyota Super Long Life Coolant”

 Similar high-quality ethylene glycol-based non-silicate,

non-amine, non-nitrite, and non-borate coolant with
long-life hybrid organic acid technology

Do not use plain water alone.

320

8-1. Specifications

RC350AWD_RC350_RC300AWD_RC30

0_OM_(U)_1810

■

Spark plug

: The fluid capacity is a reference quantity.

If replacement is necessary, contact your Lexus dealer.

Ignition system (spark plug)

RC350/RC300 AWD

RC300

Make

DENSO FK20HBR8

NGK DILFR7K9G

Gap

0.031 in. (0.8 mm)

0.035 in. (0.9 mm)

NOTICE

■

Iridium-tipped spark plugs

Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

Electrical system (battery)

Open voltage at 68°F (20°C):

12.3 V or higher
If the voltage is lower than the standard value,
charge the battery.
(Voltage is checked 20 minutes after the engine
and all lights are turned off.)

Charging rates

5 A max.

Automatic transmission

Fluid capacity



RC350

10.0 qt. (9.5 L, 8.4 Imp. qt.)



RC350 AWD/RC300 AWD

10.6 qt. (10.0 L, 8.8 Imp. qt.)



RC300

9.2 qt. (8.7 L, 7.7 Imp. qt.)

Fluid type

Toyota Genuine ATF WS

NOTICE

■

Automatic transmission fluid type

Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in

shift quality, locking up of your transmission accompanied by vibration, and ultimately

damage the transmission of your vehicle.

321

8-1. Specifications

RC350AWD_RC350_RC300AWD_RC30

0_OM_(U)_1810

Vehi

cle

spec

ifi

tions



Vehicles without LSD (Limited Slip Differential)



Vehicles with LSD (Limited Slip Differential)

: Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory.

Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equivalent oil of
matching quality to satisfy the above specification. Please contact your Lexus dealer for
further details.

Front differential (AWD models)

Oil capacity

0.74 qt. (0.70 L, 0.61 Imp. qt.)

Oil type and viscosity

Hypoid gear oil API GL-5
Above 0°F (-18°C): SAE90
Below 0°F (-18°C): SAE80W or SAE80W-90

Rear differential

Oil capacity

1.42 qt. (1.35 L, 1.19 Imp. qt.)

Oil type and viscosity

Toyota Genuine Differential Gear Oil LT

75W-85 GL-5 or equivalent

Oil capacity

1.42 qt. (1.35 L, 1.19 Imp. qt.)

Oil type and viscosity

Toyota Genuine Differential Gear Oil LX

75W-85 GL-5 or equivalent

Brakes

Pedal clearance



RC350

4.3 in. (108 mm) Min.



RC350 AWD/RC300 AWD

4.5 in. (115 mm) Min.



RC300

4.1 in. (104 mm) Min.

Pedal free play

0.04

0.24 in. (1.06.0 mm)

Brake pad wear limit

0.04 in. (1.0 mm)

Parking brake lining wear limit

0.04 in. (1.0 mm)

322

8-1. Specifications

RC350AWD_RC350_RC300AWD_RC30

0_OM_(U)_1810

: Minimum pedal clearance when depressed with a force of 112.4 lbf (500 N, 51.0 kgf)

while the engine is running.

: Parking brake pedal travel when depressed with a force of 67.4 lbf (300 N, 30.6 kgf)



Type A

Parking brake pedal travel

8 - 11 clicks

Fluid type

SAE J1703 or FMVSS No.116 DOT 3, or SAE
J1704 or FMVSS No.116 DOT 4 brake fluid

Steering

Free play

Less than 1.2 in. (30 mm)

Tires and wheels

Tire size

235/45R18 94Y, T155/70D17 110M (spare)

Tire inflation pressure (Rec-
ommended cold tire inflation
pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in
countries where such speeds are permitted by law)

Add 3 psi (20 kPa, 0.2 kgf/cm

or bar) to the front tires, 6

psi (40 kPa, 0.4 kgf/cm

or bar) to the rear tires. Never

exceed the maximum cold tire inflation pressure indicated
on the tire sidewall.

Wheel size

 8J, 17  4T (spare)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

323

8-1. Specifications

RC350AWD_RC350_RC300AWD_RC30

0_OM_(U)_1810

Vehi

cle

spec

ifi

tions



Type B



Type C

Tire size

235/45R18 94Y, T145/70D18 107M (spare)

Tire inflation pressure (Rec-
ommended cold tire inflation
pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in
countries where such speeds are permitted by law)

Add 3 psi (20 kPa, 0.2 kgf/cm

or bar) to the front tires, 6

psi (40 kPa, 0.4 kgf/cm

or bar) to the rear tires. Never

exceed the maximum cold tire inflation pressure indicated
on the tire sidewall.

Wheel size

 8J, 18 4T (spare)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Tire size

P235/45R18 94V, T155/70D17 110M (spare)

Tire inflation pressure (Rec-
ommended cold tire inflation
pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in
countries where such speeds are permitted by law)

Add 3 psi (20 kPa, 0.2 kgf/cm

or bar) to the front tires, 6

psi (40 kPa, 0.4 kgf/cm

or bar) to the rear tires. Never

exceed the maximum cold tire inflation pressure indicated
on the tire sidewall.

Wheel size

 8J, 17  4T (spare)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

324

8-1. Specifications

RC350AWD_RC350_RC300AWD_RC30

0_OM_(U)_1810



Type D



Type E

Tire size

P235/45R18 94V, T145/70D18 107M (spare)

Tire inflation pressure (Rec-
ommended cold tire inflation
pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in
countries where such speeds are permitted by law)

Add 3 psi (20 kPa, 0.2 kgf/cm

or bar) to the front tires, 6

psi (40 kPa, 0.4 kgf/cm

or bar) to the rear tires. Never

exceed the maximum cold tire inflation pressure indicated
on the tire sidewall.

Wheel size

 8J, 18  4T (spare)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Tire size

235/40R19 96V, T155/70D17 110M (spare)

Tire inflation pressure (Rec-
ommended cold tire inflation
pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 36 psi (250 kPa, 2.5 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in
countries where such speeds are permitted by law)

Add 6 psi (40 kPa, 0.4 kgf/cm

or bar) to the front tires, 8

psi (50 kPa, 0.5 kgf/cm

or bar) to the rear tires. Never

exceed the maximum cold tire inflation pressure indicated
on the tire sidewall.

Wheel size

 8J, 17  4T (spare)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

325

8-1. Specifications

RC350AWD_RC350_RC300AWD_RC30

0_OM_(U)_1810

Vehi

cle

spec

ifi

tions



Type F



Type G

Tire size

235/40R19 96V, T145/70D18 107M (spare)

Tire inflation pressure (Rec-
ommended cold tire inflation
pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 36 psi (250 kPa, 2.5 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in
countries where such speeds are permitted by law)

Add 6 psi (40 kPa, 0.4 kgf/cm

or bar) to the front tires, 8

psi (50 kPa, 0.5 kgf/cm

or bar) to the rear tires. Never

exceed the maximum cold tire inflation pressure indicated
on the tire sidewall.

Wheel size

 8J, 18  4T (spare)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Tire size

Front tires: 235/40R19 96Y XL
Rear tires: 265/35R19 94Y
Spare tire: T155/70D17 110M

Tire inflation pressure (Rec-
ommended cold tire inflation
pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 36 psi (250 kPa, 2.5 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in
countries where such speeds are permitted by law)

Add 6 psi (40 kPa, 0.4 kgf/cm

or bar) to the front tires.

Never exceed the maximum cold tire inflation pressure
indicated on the tire sidewall.

Wheel size

Front wheels: 19

 8J

Rear wheels: 19

 9J

Spare wheel: 17

 4T

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

326

8-1. Specifications

RC350AWD_RC350_RC300AWD_RC30

0_OM_(U)_1810



Type H

A: Wedge base bulbs (amber)
B: Wedge base bulbs (clear)

Tire size

Front tires: 235/40R19 96Y XL
Rear tires: 265/35R19 94Y
Spare tire: T145/70D18 107M

Tire inflation pressure (Rec-
ommended cold tire inflation
pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 36 psi (250 kPa, 2.5 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in
countries where such speeds are permitted by law)

Add 6 psi (40 kPa, 0.4 kgf/cm

or bar) to the front tires.

Never exceed the maximum cold tire inflation pressure
indicated on the tire sidewall.

Wheel size

Front wheels: 19

 8J

Rear wheels: 19

 9J

Spare wheel: 18

 4T

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Light bulbs

Bulb No.

Type

Exterior

Rear turn signal lights



Interior

Vanity lights



Footwell lights

194

3.8

Trunk light



327

8-1. Specifications

RC350AWD_RC350_RC300AWD_RC30

0_OM_(U)_1810

Vehi

cle

spec

ifi

tions

■

Gasoline quality

In very few cases, driveability problems may

be caused by the brand of gasoline you are

using. If driveability problems persist, try

changing the brand of gasoline. If this does

not correct the problem, consult your Lexus

dealer.

■

Recommendation of the use of gasoline

containing detergent additives

●

Lexus recommends the use of gasoline

that contains detergent additives to avoid

the build-up of engine deposits.

●

All gasoline sold in the U.S.A. contains

minimum detergent additives to clean

and/or keep clean intake systems, per

EPA’s lowest additives concentration pro-

gram.

●

Lexus strongly recommends the use of

Top Tier Detergent Gasoline. For more

information on Top Tier Detergent Gaso-

line and a list of marketers, please go to

the official website www.toptiergas.com.

■

Recommendation of the use of low

emissions gasoline

Gasolines containing oxygenates such as

ethers and ethanol, as well as reformulated

gasolines, are available in some cities.

These fuels are typically acceptable for use,

providing they meet other fuel require-

ments.
Lexus recommends these fuels, since the

formulations allow for reduced vehicle

emissions.

■

Non-recommendation of the use of

blended gasoline

●

Use only gasoline containing up to 15%

ethanol.

DO NOT use any flex-fuel or gasoline

that could contain more than 15% etha-

nol, including from any pump labeled
E30 (30% ethanol [

]), E50 (50%

ethanol [

]), E85 (85% ethanol [

])

(which are only some examples of fuel

containing more than 15% ethanol).

●

If you use gasohol in your vehicle, be sure

that it has an octane rating no lower than

91.

●

Lexus does not recommend the use of

gasoline containing methanol.

■

Non-recommendation of the use of gas-

oline containing MMT

Some gasoline contains an octane enhanc-

ing additive called MMT (Methylcyclopen-

tadienyl Manganese Tricarbonyl).
Lexus does not recommend the use of gas-

oline that contains MMT. If fuel containing

MMT is used, your emission control system

may be adversely affected.
The malfunction indicator lamp on the

instrument cluster may come on. If this hap-

pens, contact your Lexus dealer for service.

■

If your engine knocks

●

Consult your Lexus dealer.

●

You may occasionally notice light knock-

ing for a short time while accelerating or

Fuel information

You must only use unleaded gaso-
line.

Select premium unleaded gasoline
with an octane rating of 91
(Research Octane Number 96) or
higher required for optimum
engine performance and fuel econ-
omy.
If the octane rating is less than 91,
damage to the engine may occur
and may void the vehicle warranty.

At minimum, the gasoline you use
should meet the specifications of
ASTM D4814 in the U.S.A..

328

8-1. Specifications

RC350AWD_RC350_RC300AWD_RC30

0_OM_(U)_1810

driving uphill. This is normal and there is

no need for concern.

NOTICE

■

Notice on fuel quality

●

Do not use improper fuels. If improper

fuels are used, the engine will be dam-

aged.

●

Do not use leaded gasoline.

Leaded gasoline can cause damage to

your vehicle’s three-way catalytic con-

verters causing the emission control

system to malfunction.

●

Do not use gasohol other than the type

previously stated.

Other gasohol may cause fuel system

damage or vehicle performance prob-

lems.

●

Using unleaded gasoline with an

octane number or rating lower than

the level previously stated may cause

persistent heavy knocking.

At worst, this may lead to engine dam-

age and will void the vehicle warranty.

■

When refueling with gasohol

Take care not to spill gasohol. It can dam-

age your vehicle’s paint.

■

Fuel-related poor driveability

If poor driveability (poor hot starting,

vaporization, engine knocking, etc.) is

encountered after using a different type

of fuel, discontinue the use of that type of

fuel.

Content .. 18 19 20 21 ..
