LEXUS NX 300H (2019 year). Instruction

Pictorial index

Pictorial index

■

Exterior

The shape of the headlights may differ depending on the grade, etc.

Side doors..................................................................................................................P.104
Locking/unlocking ............................................................................................................ P.104
Opening/closing the side windows ............................................................................P.142
Locking/unlocking by using the mechanical key................................................P.389
Warning messages .......................................................................................................... P.376

Back door ................................................................................................................. P.108

Opening from inside the cabin

...................................................................................... P.111

Opening from outside .............................................................................................. P.109 , 111
Warning messages .......................................................................................................... P.376

Outside rear view mirrors....................................................................................P.140
Adjusting the mirror angle............................................................................................. P.140
Folding the mirrors..............................................................................................................P.141

Driving position memory

...............................................................................................P.132

Defogging the mirrors.................................................................................................... P.267

Windshield wipers ........................................................................................P.188, 193

Pictorial index

LEXUS NX300h Owners Manu-

al_USA_M78287_en

Precautions against winter season............................................................................P.256
To prevent freezing (windshield wiper de-icer) ....................................................P.271
Precautions against car wash ....................................................................................... P.313

Fuel filler door..........................................................................................................P.195
Refueling method .............................................................................................................. P.195
Fuel type/fuel tank capacity .........................................................................................P.403

Tires............................................................................................................................P.337
Tire size/inflation pressure ...........................................................................................P.408
Winter tires/tire chain ....................................................................................................P.256
Checking/rotation/tire pressure warning system.............................................. P.337
Coping with flat tires........................................................................................................ P.379

Hood ..........................................................................................................................P.326
Opening ...............................................................................................................................P.326
Engine compartment cover .........................................................................................P.329
Engine oil..............................................................................................................................P.404
Coping with overheat .....................................................................................................P.396
Warning messages .......................................................................................................... P.376

Headlights.................................................................................................................P.182

Parking lights/daytime running lights...............................................................P.182

Fog lights................................................................................................................... P.188

Turn signal lights...................................................................................................... P.176

Tail lights ....................................................................................................................P.182

License plate lights .................................................................................................P.182

Back-up light
Shifting the shift lever to R...............................................................................................P.173

Side marker lights...................................................................................................P.182

: If equipped

Light bulbs of the exterior lights for driving
(Replacing method: P.355, Watts: P.409)

Pictorial index

LEXUS NX300h Owners Manu-

al_USA_M78287_en

■

Instrument panel

Power switch ............................................................................................................P.168
Starting the hybrid system/changing the modes........................................ P.168, 170
Emergency stop of the hybrid system......................................................................P.360
When the hybrid system will not start ......................................................................P.387
Warning messages .......................................................................................................... P.376

Shift lever...................................................................................................................P.173
Changing the shift position.............................................................................................P.173
Precautions against towing...........................................................................................P.362
When the shift lever does not move ...........................................................................P.174

Meters..........................................................................................................................P.79
Reading the meters/adjusting the instrument panel light...........................P.79, 83
Warning lights/indicator lights ...................................................................................... P.74
When the warning lights come on............................................................................. P.367

Multi-information display...................................................................................... P.84
Display......................................................................................................................................P.84
Energy monitor.....................................................................................................................P.93

Pictorial index

LEXUS NX300h Owners Manu-

al_USA_M78287_en

When the warning messages are displayed.......................................................... P.376

Turn signal lever ...................................................................................................... P.176
Headlight switch......................................................................................................P.182
Headlights/parking lights/tail lights/license plate lights/daytime running lights

................................................................................................................................................... P.182

Fog lights ...............................................................................................................................P.188

Windshield wiper and washer switch......................................................P.188, 193
Usage............................................................................................................................P.188, 193
Adding washer fluid.........................................................................................................P.333
Warning messages .......................................................................................................... P.376

Emergency flasher switch ...................................................................................P.360

Hood lock release lever.......................................................................................P.326

Tilt and telescopic steering control switch

...................................................P.137

Adjustment ............................................................................................................................P.137

Driving position memory

..............................................................................................P.132

Tilt and telescopic steering lock release lever

............................................P.137

Adjustment ............................................................................................................................P.137

Air conditioning system .......................................................................................P.266
Usage.....................................................................................................................................P.266
Rear window defogger................................................................................................... P.267

Audio system

: If equipped

: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

Pictorial index

LEXUS NX300h Owners Manu-

al_USA_M78287_en

■

Switches

Instrument panel light control switches ............................................................ P.83

Odometer/trip meter and trip meter reset button ....................................... P.83

Front seat heater switches

...............................................................................P.274

Seat ventilator switches

....................................................................................P.275

Automatic High Beam switch..............................................................................P.185

BSM (Blind Spot Monitor) main switch

.........................................................P.241

Power back door switch

....................................................................................... P.111

Heated steering wheel switch

.........................................................................P.274

Camera switch

*1, 2

Rear seat operation switches

...........................................................................P.128

: If equipped

: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

A
B
C
D

E
F

Pictorial index

LEXUS NX300h Owners Manu-

al_USA_M78287_en

Power window switches........................................................................................P.142

Window lock switch ...............................................................................................P.143

Outside rear view mirror switches....................................................................P.140

Door lock switch......................................................................................................P.106

Driving position memory switches

...................................................................P.132

HUD (Head-up display) switches

...................................................................... P.89

ASC (Active Sound Control) dial

......................................................................P.181

: If equipped

Audio remote control switches

Paddle shift switches..............................................................................................P.175

A
B
C
D

E
F

A
B

Pictorial index

LEXUS NX300h Owners Manu-

al_USA_M78287_en

Meter control switches.......................................................................................... P.84

Vehicle-to-vehicle distance switch ...................................................................P.221

Cruise control switch
Dynamic radar cruise control with full-speed range ...........................................P.217

LDA (Lane Departure Alert with steering control) switch .........................P.211

Talk switch

Telephone switches

: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

EV drive mode switch ............................................................................................. P.171

Driving mode select switch................................................................................ P.248

VSC off switch..........................................................................................................P.251

Parking brake switches......................................................................................... P.177
Applying/releasing ............................................................................................................P.177
Precautions against winter season............................................................................ P.257
Warning buzzer/message.................................................................................. P.178, 376

Brake hold switch.................................................................................................... P.179

Remote Touch.........................................................................................................P.262

Rear seat heater switches

..................................................................................P.274

Pictorial index

LEXUS NX300h Owners Manu-

al_USA_M78287_en

■

Interior

SRS airbags................................................................................................................ P.32

Floor mats....................................................................................................................P.24

Front seats.................................................................................................................P.126

Rear seats..................................................................................................................P.127

Head restraints........................................................................................................P.135

Seat belts .....................................................................................................................P.26

Console box............................................................................................................ P.280

Inside lock buttons..................................................................................................P.107

Cup holders ............................................................................................................ P.280

Assist grips ...............................................................................................................P.295

A
B
C
D

E
F

Pictorial index

LEXUS NX300h Owners Manu-

al_USA_M78287_en

■

Ceiling

Inside rear view mirror ..........................................................................................P.138

Sun visors..................................................................................................................P.286

Vanity mirrors .........................................................................................................P.286

Interior light

......................................................................................................... P.277

Personal lights......................................................................................................... P.277

Moon roof switches

.............................................................................................P.144

“SOS” button

....................................................................................................... P.304

Garage door opener switches

........................................................................P.296

: If equipped

: The illustration shows the front, but they are also equipped in the rear.

A
B
C
D

E
F

LEXUS NX300h Owners Manu-

al_USA_M78287_en

For safety and security

1-1. For safe use

Before driving.................................

For safe driving..............................

Seat belts .........................................

SRS airbags ....................................

Front passenger occupant classifi-

cation system ................................

Safety information for children

Child restraint systems ..............

Exhaust gas precautions ...........

1-2. Hybrid system

Hybrid system features...............

Hybrid system precautions......

1-3. Theft deterrent system

Immobilizer system .....................

Alarm...................................................

1-1. For safe use

LEXUS NX300h Owners Manu-

al_USA_M78287_en

1-1.For safe use

Use only floor mats designed specifi-
cally for vehicles of the same model
and model year as your vehicle. Fix
them securely in place onto the carpet.

Insert the retaining hooks (clips)
into the floor mat eyelets.

Turn the upper knob of each retain-
ing hook (clip) to secure the floor
mats in place.

Always align

the marks.

The shape of the retaining hooks (clips)
may differ from that shown in the illustra-
tion.

Before driving

Observe the following before start-
ing off in the vehicle to ensure
safety of driving.

Installing floor mats

WARNING

Observe the following precautions.

Failure to do so may cause the driver’s

floor mat to slip, possibly interfering with

the pedals while driving. An unexpect-

edly high speed may result or it may

become difficult to stop the vehicle. This

could lead to an accident, resulting in

death or serious injury.

■

When installing the driver’s floor mat

●

Do not use floor mats designed for

other models or different model year

vehicles, even if they are Lexus Genu-

ine floor mats.

●

Only use floor mats designed for the

driver’s seat.

●

Always install the floor mat securely

using the retaining hooks (clips) pro-

vided.

●

Do not use two or more floor mats on

top of each other.

●

Do not place the floor mat bottom-

side up or upside-down.

■

Before driving

●

Check that the floor mat is securely

fixed in the correct place with all the

provided retaining hooks (clips). Be

especially careful to perform this

check after cleaning the floor.

●

With the hybrid system stopped and

the shift lever in P, fully depress each

pedal to the floor to make sure it does

not interfere with the floor mat.

1-1. For safe use

LEXUS NX300h Owners Manu-

al_USA_M78287_en

For safety and security

Adjust the angle of the seatback so
that you are sitting straight up and
so that you do not have to lean for-
ward to steer. (

P.126)

Adjust the seat so that you can
depress the pedals fully and so that
your arms bend slightly at the
elbow when gripping the steering
wheel. (

P.126, 137)

Lock the head restraint in place
with the center of the head restraint
closest to the top of your ears.
(

P.135)

Wear the seat belt correctly.
(

P.27)

Make sure that all occupants are wear-
ing their seat belts before driving the
vehicle. (

P.27)

Use a child restraint system appropri-
ate for the child until the child becomes
large enough to properly wear the
vehicle’s seat belt. (

P.47)

Make sure that you can see the rear of

For safe driving

For safe driving, adjust the seat and
mirror to an appropriate position
before driving.

Correct driving posture

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Do not adjust the position of the

driver’s seat while driving.

Doing so could cause the driver to lose

control of the vehicle.

●

Do not place a cushion between the

driver or passenger and the seatback.

A cushion may prevent correct pos-

ture from being achieved, and reduce

the effectiveness of the seat belt and

head restraint.

●

Do not place anything under the front

seats.

Objects placed under the front seats

may become jammed in the seat

tracks and stop the seat from locking in

place. This may lead to an accident

and the adjustment mechanism may

also be damaged.

●

Always observe the legal speed limit

when driving on public roads.

●

When driving over long distances, take

regular breaks before you start to feel

tired. Also, if you feel tired or sleepy

while driving, do not force yourself to

continue driving and take a break

immediately.

Correct use of the seat belts

Adjusting the mirrors

1-1. For safe use

LEXUS NX300h Owners Manu-

al_USA_M78287_en

the vehicle clearly, by adjusting the
inside and outside rear view mirrors
properly. (

P.138, 140)

Seat belts

Make sure that all occupants are
wearing their seat belts before driv-
ing the vehicle.

WARNING

Observe the following precautions to

reduce the risk of injury in the event of

sudden braking, sudden swerving or an

accident.

Failure to do so may cause death or seri-

ous injury.

■

Wearing a seat belt

●

Ensure that all passengers wear a seat

belt.

●

Always wear a seat belt properly.

●

Each seat belt should be used by one

person only. Do not use a seat belt for

more than one person at once, includ-

ing children.

●

Lexus recommends that children be

seated in the rear seat and always use

a seat belt and/or an appropriate child

restraint system.

●

To achieve a proper seating position,

do not recline the seat more than nec-

essary. The seat belt is most effective

when the occupants are sitting up

straight and well back in the seats.

●

Do not wear the shoulder belt under

your arm.

●

Always wear your seat belt low and

snug across your hips.

1-1. For safe use

LEXUS NX300h Owners Manu-

al_USA_M78287_en

For safety and security

 Extend the shoulder belt so that it

comes fully over the shoulder, but
does not come into contact with the
neck or slide off the shoulder.

 Position the lap belt as low as possi-

ble over the hips.

 Adjust the position of the seatback.

Sit up straight and well back in the
seat.

 Do not twist the seat belt.

WARNING

■

Pregnant women

Obtain medical advice and wear the seat

belt in the proper way. (

P.27)

Women who are pregnant should posi-

tion the lap belt as low as possible over

the hips in the same manner as other

occupants, extending the shoulder belt

completely over the shoulder and avoid-

ing belt contact with the rounding of the

abdominal area.
If the seat belt is not worn properly, not

only the pregnant woman, but also the

fetus could suffer death or serious injury

as a result of sudden braking or a colli-

sion.

■

People suffering illness

Obtain medical advice and wear the seat

belt in the proper way. (

P.27)

■

When children are in the vehicle

Do not allow children to play with the

seat belt. If the seat belt becomes twisted

around a child’s neck, it may lead to

choking or other serious injuries that

could result in death. If this occurs and

the buckle cannot be unfastened, scis-

sors should be used to cut the belt.

■

Seat belt damage and wear

●

Do not damage the seat belts by allow-

ing the belt, plate, or buckle to be

jammed in the door.

●

Inspect the seat belt system periodi-

cally. Check for cuts, fraying, and loose

parts. Do not use a damaged seat belt

until it is replaced. Damaged seat belts

cannot protect an occupant from

death or serious injury.

●

Ensure that the belt and plate are

locked and the belt is not twisted.

If the seat belt does not function cor-

rectly, immediately contact your Lexus

dealer.

●

Replace the seat assembly, including

the belts, if your vehicle has been

involved in a serious accident, even if

there’s no obvious damage.

●

Do not attempt to install, remove,

modify, disassemble or dispose of the

seat belts. Have any necessary repairs

carried out by your Lexus dealer. Inap-

propriate handling may lead to incor-

rect operation.

Correct use of the seat belts

LEXUS NX 300H (2019 year). Instruction - part 1
