283

When constant speed control mode is selected, your vehicle will maintain a set
speed without controlling the vehicle-to-vehicle distance. Select this mode only
when vehicle-to-vehicle distance control mode does not function correctly due
to a dirty radar sensor, etc.

With the cruise control off, press and
hold the “ON/OFF” button for 1.5
seconds or more.

Immediately after the “ON/OFF” but-

ton is pressed, the radar cruise control

indicator will come on. Afterwards, it

switches to the cruise control indicator.
Switching to constant speed control

mode is only possible when operating

the lever with the cruise control off.

Accelerate or decelerate, with
accelerator pedal operation, to the
desired vehicle speed (at or above
approximately 25 mph [40 km/h])
and push the lever down to set the
speed.

Cruise control “SET” indicator will come

on.
The vehicle speed at the moment the

lever is released becomes the set speed.
Adjusting the speed setting:

P. 280

Canceling and resuming the speed setting:

P. 282

Selecting constant speed control mode

284

4-5. Using the driving support systems

■

Dynamic radar cruise control with full-speed range can be set when

●

The shift lever is in D or range 4 or higher of S has been selected.

●

Range 4 or higher of D has been selected by using the paddle shift switch (vehicles with

paddle shift switches).

●

Vehicle speed is at or above approximately 30 mph (50 km/h).

However, when a preceding vehicle is detected, the dynamic radar cruise control with

full-speed range can be set even if the vehicle speed is below approximately 30 mph

(50 km/h).

■

Accelerating after setting the vehicle speed
The vehicle can accelerate by operating the accelerator pedal. After accelerating, the

set speed resumes. However, during vehicle-to-vehicle distance control mode, the vehi-

cle speed may decrease below the set speed in order to maintain the distance to the pre-

ceding vehicle.

■

When the vehicle stops while follow-up cruising

●

Pushing the lever up while the vehicle ahead stops will resume follow-up cruising if the

vehicle ahead starts off within approximately 3 seconds after the lever is pushed up.

●

If the vehicle ahead starts off within 3 seconds after your vehicle stops, follow-up cruis-

ing will be resumed.

■

Automatic cancelation of vehicle-to-vehicle distance control mode
Vehicle-to-vehicle distance control mode is automatically canceled in the following situ-

ations:

●

Actual vehicle speed falls below approximately 25 mph (40 km/h) when there are no

vehicles ahead.

●

The preceding vehicle leaves the lane when your vehicle is following at a vehicle speed

at or below approximately 25 mph (40 km/h). Otherwise, the sensor can not properly

detect the vehicle. (“CRUISE NOT AVAILABLE No Preceding Vehicles” is displayed

on the multi-information display)

●

VSC is activated.

●

Active TRAC is activated for a period of time.

●

When the VSC or Active TRAC system is turned off.

●

When second start mode is set.

●

The sensor cannot detect correctly because it is covered in some way.

●

Pre-collision braking is activated.

●

The parking brake is operated.

●

The vehicle is stopped by system control on a steep incline.

●

The following are detected when the vehicle has been stopped by system control:
• The driver is not wearing a seat belt.

• The driver’s door is opened.

• The vehicle has been stopped for about 3 minutes

●

The switching operation continues for 5 seconds or more after the center differential

lock switch has been operated.

If vehicle-to-vehicle distance control mode is automatically canceled for any other rea-

son, there may be a malfunction in the system. Contact your Lexus dealer.

285

4-5. Using the driving support systems

iving

■

Automatic cancelation of constant speed control mode
Constant speed control mode is automatically canceled in the following situations:

●

Actual vehicle speed is more than approximately 10 mph (16 km/h) below the set vehi-

cle speed.

●

Actual vehicle speed falls below approximately 25 mph (40 km/h).

●

VSC is activated.

●

Active TRAC is activated for a period of time.

●

When the VSC or Active TRAC system is turned off.

●

Pre-collision braking is activated.

●

The switching operation continues for 5 seconds or more after the center differential

lock switch has been operated.

If constant speed control mode is automatically canceled for any other reason, there may

be a malfunction in the system. Contact your Lexus dealer.

■

Brake system operation sound
If the brakes are applied automatically while the vehicle is in vehicle-to-vehicle distance

control mode, a brake system operation sound may be heard. This does not indicate a

malfunction.

■

Warning messages and buzzers for dynamic radar cruise control with full-speed range
Warning messages and buzzers are used to indicate a system malfunction or to inform

the driver of the need for caution while driving. If a warning message is shown on the

multi-information display, read the message and follow the instructions.

■

When the sensor may not be correctly detecting the vehicle ahead
In the case of the following and depending on the conditions, operate the brake pedal

when deceleration of the system is insufficient or operate the accelerator pedal when

acceleration is required.

As the sensor may not be able to correctly detect these types of vehicles, the approach

warning (

P. 282) may not be activated.

●

Vehicles that cut in suddenly

●

Vehicles traveling at low speeds

●

Vehicles that are not moving in the same lane

●

Vehicles with small rear ends (trailers with no load on board, etc.)

●

Motorcycles traveling in the same lane

●

When water or snow thrown up by the surrounding vehicles hinders the detecting of

the sensor

286

4-5. Using the driving support systems

■

Conditions under which the vehicle-to-vehicle distance control mode may not function

correctly
In the case of the following conditions, operate the brake pedal (or accelerator pedal,

depending on the situation) as necessary.

As the sensor may not be able to correctly detect vehicles ahead, the system may not

operate properly.

●

When the vehicle ahead of you decelerates suddenly

●

When driving on a road surrounded by a structure, such as in a tunnel or on a bridge

●

While the vehicle speed is decreasing to the set speed after the vehicle accelerates by

depressing the accelerator pedal

●

When your vehicle is pointing upwards

(caused by a heavy load in the luggage com-

partment, etc.)

●

Preceding vehicle has an extremely high

ground clearance

●

When the road curves or when the lanes are

narrow

●

When steering wheel operation or your posi-

tion in the lane is unstable

287

4-5. Using the driving support systems

iving

Cruise control



Use the cruise control to maintain a set speed without depressing the accelera-
tor pedal.

Indicators
Cruise control switch

Press the “ON/OFF” button to acti-
vate the cruise control.

Cruise control indicator will come on.
Press the button again to deactivate the

cruise control.

Accelerate or decelerate the vehicle
to the desired speed, and push the
lever down to set the speed.

“SET” indicator will come on.
The vehicle speed at the moment the

lever is released becomes the set speed.



: If equipped

Summary of functions

Setting the vehicle speed

288

4-5. Using the driving support systems

To change the set speed, operate the lever until the desired set speed is obtained.

Increases the speed
Decreases the speed

Fine adjustment: Momentarily move the

lever in the desired direction.
Large adjustment: Hold the lever in the

desired direction.

The set speed will be increased or decreased as follows:
Fine adjustment: By 1 mph (1.6 km/h)

or 1 km/h (0.6 mph)

each time the lever is

operated
Large adjustment: The set speed can be increased or decreased continually until the

lever is released.

: When the set speed is shown in “MPH”

: When the set speed is shown in “km/h”

Pulling the lever toward you cancels
the constant speed control.

The speed setting is also canceled when

the brakes are applied.

Pushing the lever up resumes the
constant speed control.

Resuming is available when the vehicle

speed is more than approximately 25

mph (40 km/h).

■

Cruise control can be set when

●

The shift lever is in the D or range 4 or higher of S has been selected.

●

Range 4 or higher has been selected by using the paddle shift. (vehicles with paddle

shift switches)

●

Vehicle speed is above approximately 25 mph (40 km/h).

■

Accelerating after setting the vehicle speed

●

The vehicle can be accelerated normally. After acceleration, the set speed resumes.

●

Even without canceling the cruise control, the set speed can be increased by first accel-

erating the vehicle to the desired speed and then pushing the lever down to set the new

speed.

Adjusting the set speed

Canceling and resuming the constant speed control

289

4-5. Using the driving support systems

iving

■

Automatic cruise control cancelation
Cruise control will stop maintaining the vehicle speed in any of the following situations:

●

Actual vehicle speed falls more than approximately 10 mph (16 km/h) below the preset

vehicle speed.

At this time, the memorized set speed is not retained.

●

Actual vehicle speed is below approximately 25 mph (40 km/h).

●

VSC is activated.

●

Active TRAC is activated for a period of time.

●

The switching operation continues for 5 seconds or more after the center differential

lock switch has been operated.

●

When the VSC or Active TRAC system is turned off.

■

If “Cruise Control Malfunction Visit Your Dealer” is shown on the multi-information

display
Press the “ON/OFF” button once to deactivate the system, and then press the button

again to reactivate the system.

If the cruise control speed cannot be set or if the cruise control cancels immediately after

being activated, there may be a malfunction in the cruise control system. Have the vehi-

cle inspected by your Lexus dealer.

WARNING

■

To avoid operating the cruise control by mistake
Switch the cruise control off using the “ON/OFF” button when not in use.

■

Situations unsuitable for cruise control
Do not use cruise control in any of the following situations.

Doing so may result in loss of control and could cause an accident resulting in death or

serious injury.

●

In heavy traffic

●

On roads with sharp bends

●

On winding roads

●

On slippery roads, such as those covered with rain, ice or snow

●

On steep hills

Vehicle speed may exceed the set speed when driving down a steep hill.

●

When your vehicle is towing a trailer or during emergency towing

290

4-5. Using the driving support systems

Driving mode select switch

Normal mode/Customized mode
Normal mode and customized mode are selected by pressing the driving
mode select switch. Each time the switch is pressed, the driving mode
changes between normal mode and customized mode. When customized
mode is selected, the “CUSTOMIZE” indicator will be illuminated.

Press the switch to change the driving mode to normal mode when not in normal

mode.

• Normal mode

Provides an optimal balance of fuel economy, quietness, and dynamic per-
formance. Suitable for city driving.

• Customized mode

Allows you to drive with the following functions set to your preferred set-
tings.
Customized mode settings can only be changed on the drive mode cus-
tomization display of the Remote touch screen. (

P. 584)

The driving modes can be selected to suit driving condition.

291

4-5. Using the driving support systems

iving

Comfort mode
By controlling the suspension, riding comfort is further enhanced. Suitable for
city driving.

When not in comfort mode and the driving mode select switch is turned to the left, the

“COMFORT” indicator comes on in the multi-information display.

Eco drive mode
Helps the driver accelerate in an eco-friendly manner and improve fuel econ-
omy through moderate throttle characteristics and by controlling the opera-
tion of the air conditioning system (heating/cooling).

When in comfort mode, if the driving mode select switch is turned to the left, the

“ECO” indicator will come on in the multi-information display.

Sport mode

• SPORT S mode

Controls the transmission and engine to provide quick, powerful accelera-
tion. This mode is suitable for when agile driving response is desired, such
as when driving on roads with many curves.

When not in SPORT S mode, if the driving mode select switch is turned to the

right, the “SPORT S” indicator will come on in the multi-information display.

• SPORT S+ mode

Helps to ensure steering performance and driving stability by simultane-
ously controlling the steering and suspension in addition to the transmis-
sion and engine. Suitable for sportier driving.

When in SPORT S mode, if the driving mode select switch is turned to the right,

the “SPORT S+” indicator will come on in the multi-information display.

Function

Setting

Powertrain

Normal

Power

Eco

Chassis

Normal

Sport

Air conditioning system

Normal

Eco

292

4-5. Using the driving support systems

■

Operation of the air conditioning system in Eco drive mode
Eco drive mode controls the heating/cooling operations and fan speed of the air condi-

tioning system to enhance fuel efficiency. To improve air conditioning performance,

adjust the fan speed or turn off eco mode of the air conditioning system. (

P. 405)

■

Automatic deactivation of sport mode and customized mode
If the engine switch is turned off after driving in sport mode or customized mode, the

drive mode will be changed to normal mode.

■

Driving mode pop-up display
When the driving mode is changed, the selected driving mode will be temporarily dis-

played on the side display. (

P. 398)

293

4-5. Using the driving support systems

iving

Intuitive parking assist

Front corner sensors
Front center sensors
Rear corner sensors
Rear center sensors

On/off

To turn the system on, press the switch.

The indicator light comes on and the

buzzer sounds to inform the driver that

the system is operational.
To turn the system off, press the switch

again.

The distance from your vehicle to nearby obstacles when parallel parking or
maneuvering into a garage is measured by the sensors and communicated via
the multi-information display, the remote touch screen, and a buzzer. Always
check the surrounding area when using this system.

Types of sensors

2
3
4

Intuitive parking assist switch

294

4-5. Using the driving support systems

When the sensors detect an obstacle, a graphic is shown on the multi-informa-
tion display and the remote touch screen depending on the position and distance
to the obstacle.



Multi-information display
Front corner sensor operation
Front center sensor operation
Rear corner sensor operation
Rear center sensor operation



Remote touch screen
Intuitive parking assist
Rear Cross Traffic Alert (if
equipped)

A graphic is automatically displayed on

the side display when an obstacle is

detected. The screen can be set so that

the graphic is not displayed.

: Select to mute the buzzer

sounds.

Display

2
3
4

295

4-5. Using the driving support systems

iving

■

Distance display
Sensors that detect an obstacle will illuminate continuously or blink.

Sensor detection display, obstacle distance

Multi-information

display

Remote touch

screen

Approximate distance to obstacle

Corner sensor/

front center sensor Rear center sensor

(continuous)

Front center

sensor:

3.3 ft. (100 cm) to

2.0 ft. (60 cm)

4.9 ft. (150 cm) to

2.6 ft. (80 cm)

(continuous)

2.0 ft. (60 cm) to

1.5 ft. (45 cm)

2.6 ft. (80 cm) to

2.1 ft. (65 cm)

(continuous)

1.5 ft. (45 cm) to

1.1 ft. (35 cm)

2.1 ft. (65 cm) to

1.6 ft. (50 cm)

(blinking)

(continuous)

Less than

1.1 ft. (35 cm)

Less than

1.6 ft. (50 cm)

296

4-5. Using the driving support systems

■

Buzzer operation and distance to an obstacle
A buzzer sounds when the sensors are operating.

●

The buzzer sounds faster as the vehicle approaches an obstacle.
When the vehicle comes within the following distance of the obstacle, the
buzzer sounds continuously.

• Front center sensors: Approximately 1.1 ft. (35 cm)
• Corner: Approximately 1.1 ft. (35 cm)
• Rear center sensors: Approximately 1.6 ft. (50 cm)

●

When 2 or more obstacles are detected simultaneously, the buzzer system
responds to the nearest obstacle. If one or both come within the above dis-
tances, the beep will repeat a long tone, followed by fast beeps.

●

You can change the volume of the warning beeps. (

P. 297)

Approximately 3.3 ft. (100 cm)
Approximately 4.9 ft. (150 cm)
Approximately 2.0 ft. (60 cm)
Approximately 2.0 ft. (60 cm)

The diagram shows the detection range

of the sensors. Note that the sensors

may not be able to detect obstacles that

are extremely close to the vehicle.
The range of the sensors may change

depending on the shape of the object

etc.

Detection range of the sensors

2
3
4

297

4-5. Using the driving support systems

iving

You can change the buzzer sound volume and the screen operating conditions.

Press the “SETUP” button.
Select “Vehicle”, and then select “LEXUS Park Assist”/“LEXUS Park Assist
Settings” on the screen.
Select the desired item.

The buzzer sound volume can be
adjusted.
On or off can be selected for intu-
itive parking assist display.
Front or rear center sensors dis-
play and tone indication can be
set.

Setting up intuitive parking assist

298

4-5. Using the driving support systems

■

The intuitive parking assist can be operated when

●

Front corner sensors:
• The engine switch is in IGNITION ON mode.

• The shift lever is in a position other than P.

• The vehicle speed is less than approximately 6 mph (10 km/h).

(At any speed when the shift lever is in R)

●

Front center sensors:
• The engine switch is in IGNITION ON mode.

• The shift lever is in a position other than P or R.

• The vehicle speed is less than about 6 mph (10 km/h).

●

Rear corner and rear center sensors:
• The engine switch is in IGNITION ON mode.

• The shift lever is in R.

■

Intuitive parking assist display
When an obstacle is detected while the rear view monitor system, Lexus parking assist

monitor or Multi-terrain Monitor is in use, the warning indicator will appear in the upper

corner of the screen even if the display setting has been set to off.

■

Sensor detection information

●

The sensor’s detection areas are limited to the areas around the vehicle’s bumper.

●

Certain vehicle conditions and the surrounding environment may affect the ability of a

sensor to correctly detect an obstacle. Particular instances where this may occur are

listed below.
• There is dirt, snow or ice on the sensor. (Wiping the sensors will resolve this prob-

lem.)

• The sensor is frozen. (Thawing the area will resolve this problem.)

In especially cold weather, if a sensor is frozen the screen may show an abnormal

display, or obstacles may not be detected.

• The sensor is covered in any way.

• The vehicle is leaning considerably to one side.

• On an extremely bumpy road, on an incline, on gravel, or on grass.

• The vicinity of the vehicle is noisy due to vehicle horns, motorcycle engines, air

brakes of large vehicles, or other loud noises producing ultrasonic waves.

• There is another vehicle equipped with parking assist sensors in the vicinity.

• The sensor is coated with a sheet of spray or heavy rain.

• The vehicle is equipped with a fender pole or wireless antenna.

• The bumper or sensor receives a strong impact.

• The vehicle is approaching a tall or curved curb.

• In harsh sunlight or intense cold weather.

• The area directly under the bumpers is not detected.

• If obstacles draw too close to the sensor.

• A non-genuine Lexus suspension (lowered suspension etc.) is installed.

• People may not be detected if they are wearing certain types of clothing.

In addition to the examples above, there are instances in which, because of their shape,

signs and other objects may be judged by a sensor to be closer than they are.

Content .. 16 17 18 19 ..
