LEXUS IS 300 (2019 year). Instruction

552

8-2. Steps to take in an emergency

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Warning messages
The warning message illustrations used are intended as examples, and may differ from

the image that is actually displayed on the multi-information display.

■

Warning message in radar cruise mode
In the following cases, the warning message may not be displayed even if vehicle-to-vehi-

cle distance decreases:

●

When your vehicle and the vehicle ahead are traveling at the same speed or the vehi-

cle ahead is traveling more quickly than your vehicle

●

When the vehicle ahead is traveling at a very low speed

●

Immediately after cruise control speed is set

●

At the instant the accelerator pedal is depressed

■

The LDA (Lane Departure Alert with steering control) lane departure warning func-

tion
In the following situations, the warning message will not be displayed even if a lane line is

crossed.

●

When the vehicle speed deviates from the operating range of the LDA system func-

tions (

P. 245)

●

When the lane lines cannot be recognized (

P. 247)

■

Resetting the message indicating maintenance is required (if equipped)
Make sure to reset the oil change system. (

P. 462, 477)

■

Conditions that the tire pressure warning system may not function properly
P. 490

■

Warning buzzer
P. 529

553

8-2. Steps to take in an emergency

When trouble

ari

ses

IS350 AWD/IS350/IS300 AWD/IS300_U

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

Con-

tinuous



The driver’s door was opened when

the shift lever was not in P and the

engine switch was not turned off.

 Shift the shift lever to P.

Con-

tinuous

Con-

tinuous

The driver’s door was opened and

closed while the electronic key was

not in the vehicle, the shift lever was

not in P and the engine switch was

not turned off.

 Shift the shift lever to P.

 Bring the electronic key back

into the vehicle.

Once



The electronic key is not detected

when an attempt is made to start the

engine.

 Start the engine with the elec-

tronic key present.

(Flashes)

(Displayed alternately)

(Flashes)

554

8-2. Steps to take in an emergency

IS350 AWD/IS350/IS300 AWD/IS300_U

Once

Con-

tinuous

An attempt was made to exit the

vehicle with the electronic key and

lock the doors without first turning

the engine switch off when the shift

lever was in P.

 Turn the engine switch off and

lock the doors again.

Once

3 times

The electronic key was carried out-

side the vehicle and a door other

than the driver’s door was opened

and closed while the engine switch

was in a mode other than off.

 Bring the electronic key back

into the vehicle.

The driver’s door was opened and

closed while the electronic key was

not in the vehicle, the shift lever was

in P and the engine switch was not

turned off.

 Turn the engine switch off.

 Bring the electronic key back

into the vehicle.

9 times



An attempt was made to drive when

the electronic key was not inside the

vehicle.

 Confirm that the electronic key

is inside the vehicle.

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

(Displayed alternately)

(Flashes)

555

8-2. Steps to take in an emergency

When trouble

ari

ses

IS350 AWD/IS350/IS300 AWD/IS300_U



Con-

tinuous

An attempt was made to lock the

doors using the smart access system

with push-button start while the

electronic key was still inside the

vehicle.

 Retrieve the electronic key

from the vehicle and lock the

doors again.

Once

Con-

tinuous

An attempt was made to lock either

front door by opening a door and

putting the inside lock button into

the lock position, then closing the

door with the electronic key still

inside the vehicle.

 Retrieve the electronic key

from the vehicle and lock the

doors again.

Once



The electronic key has a low battery.

 Replace the electronic key bat-

tery. (

P. 502)

Once



The steering lock could not be

released within 3 seconds of the

engine switch being pressed.

 Press the engine switch while

depressing the brake pedal and

moving the steering wheel left

and right.

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

(Flashes)

556

8-2. Steps to take in an emergency

IS350 AWD/IS350/IS300 AWD/IS300_U

Once



• When the doors were unlocked

with the mechanical key and then

the engine switch was pressed,

the electronic key could not be

detected in the vehicle.

• The electronic key could not be

detected in the vehicle even after

the engine switch was pressed

two consecutive times.

 Touch the electronic key to the

engine switch while depressing

the brake pedal.

Once



During an engine starting proce-

dure in the event that the electronic

key was not functioning properly

(

P. 573), the engine switch was

touched with the electronic key.

 Press the engine switch within

10 seconds of the buzzer sound-

ing.



Indicates that:

• With the engine switch off, the

doors were unlocked and then the

driver's door was opened and

closed.

• The engine switch was turned to

ACCESSORY mode without

starting the engine.

• The shift lever was shifted to P or

N from another shift position with

the engine switch in IGNITION

ON mode.

 Press the engine switch while

depressing the brake pedal.

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

557

8-2. Steps to take in an emergency

When trouble

ari

ses

IS350 AWD/IS350/IS300 AWD/IS300_U

Once



The engine switch has been turned

off with the shift lever in a position

other than P or N.

 Shift the shift lever to P.

Once



After the engine switch has been

turned off with the shift lever in a

position other than P, the shift lever

has been shifted to P.

 Turn the engine switch off.



Power was turned off due to the

automatic power off function.

 Next time when starting the

engine, increase the engine

speed slightly and maintain that

level for approximately 5 min-

utes to recharge the battery.

Con-

tinuous



Indicates that the engine was

stopped in an emergency while driv-

ing

 To restart the engine, shift the

shift lever to N and turn the

engine switch to IGNITION

ON mode.

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

(Flashes)

558

8-2. Steps to take in an emergency

IS350 AWD/IS350/IS300 AWD/IS300_U

: The engine may not be restarted depending on the vehicle condition.

■

Warning messages
P. 552

■

Warning buzzer
P. 529

Once



Indicates that the engine switch has

been pressed while driving

 Except when emergency stop-

ping of the vehicle is needed,

immediately release the engine

switch.

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

(Flashes)

559

8-2. Steps to take in an emergency

When trouble

ari

ses

IS350 AWD/IS350/IS300 AWD/IS300_U

●

Stop the vehicle in a safe place on a hard, flat surface.

●

Set the parking brake.

●

Shift the shift lever to P.

●

Stop the engine.

●

Turn on the emergency flashers. (

P. 514)

If you have a flat tire

Your vehicle is equipped with a spare tire. The flat tire can be replaced with
the spare tire.
For details about tires:

P. 485

WARNING

■

If you have a flat tire
Do not continue driving with a flat tire.

Driving even a short distance with a flat tire can damage the tire and the wheel beyond

repair, which could result in an accident.

Before jacking up the vehicle

561

8-2. Steps to take in an emergency

When trouble

ari

ses

IS350 AWD/IS350/IS300 AWD/IS300_U

WARNING

■

Using the tire jack
Observe the following precautions.

Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading

to death or serious injury.

●

Do not use the tire jack for any purpose other than replacing tires or installing and

removing tire chains.

●

Only use the tire jack that comes with this vehicle for replacing a flat tire.

Do not use it on other vehicles, and do not use other tire jacks for replacing tires on

this vehicle.

●

Put the jack properly in its jack point.

●

Do not put any part of your body under the vehicle while it is supported by the jack.

●

Do not start the engine or drive the vehicle while the vehicle is supported by the jack.

●

Do not raise the vehicle while someone is inside.

●

When raising the vehicle, do not put an object on or under the jack.

●

Do not raise the vehicle to a height greater than that required to replace the tire.

●

Use a jack stand if it is necessary to get under the vehicle.

●

When lowering the vehicle, make sure that there is no-one near the vehicle. If there

are people nearby, warn them vocally before lowering.

562

8-2. Steps to take in an emergency

IS350 AWD/IS350/IS300 AWD/IS300_U

Remove the luggage mat.
Take out the jack handle from the
reverse side of the luggage mat.
Remove the spacer.

Take out the jack.

For tightening
For loosening

If the jack is too tightly installed to be

removed by hand, insert a tool, such

as the screwdriver included with the

vehicle, into the hole of the jack (por-

tion “A”) and loosen the jack.

Taking out the jack and jack handle

563

8-2. Steps to take in an emergency

When trouble

ari

ses

IS350 AWD/IS350/IS300 AWD/IS300_U

Remove the luggage mat.
Remove the spacer and tool tray.

Loosen the center fastener that
secures the spare tire.

If the center fastener cannot be turned

by hand, use the wheel nut wrench that

is stored in the trunk. (To secure the tire,

tighten the center fastener by hand. Do

not use the wrench or other tools.)

Taking out the spare tire

WARNING

■

When storing the spare tire
Be careful not to catch fingers or other body parts between the spare tire and the body

of the vehicle.

564

8-2. Steps to take in an emergency

IS350 AWD/IS350/IS300 AWD/IS300_U

Chock the tires.

Slightly loosen the wheel nuts (one
turn).

Turn the tire jack portion “A” by hand
until the notch of the jack is in con-
tact with the jack point.

The jack point guides are located under

the rocker panel. They indicate the jack

point positions.

Replacing a flat tire

Flat tire

Wheel chock positions

Front

Left-hand side

Behind the rear right-hand side tire

Right-hand side

Behind the rear left-hand side tire

Rear

Left-hand side

In front of the front right-hand side tire

Right-hand side

In front of the front left-hand side tire

565

8-2. Steps to take in an emergency

When trouble

ari

ses

IS350 AWD/IS350/IS300 AWD/IS300_U

Raise the vehicle until the tire is
slightly raised off the ground.

Remove all the wheel nuts and the
tire.

When resting the tire on the ground,

place the tire so that the wheel design

faces up to avoid scratching the wheel

surface.

WARNING

■

Replacing a flat tire

●

Do not touch the disc wheels or the area around the brakes immediately after the

vehicle has been driven.

After the vehicle has been driven the disc wheels and the area around the brakes will

be extremely hot. Touching these areas with hands, feet or other body parts while

changing a tire, etc. may result in burns.

●

Failure to follow these precautions could cause the wheel nuts to loosen and the tire

to fall off, resulting in death or serious injury.
• Never use oil or grease on the wheel bolts or wheel nuts.

Oil and grease may cause the wheel nuts to be excessively tightened, leading to

bolt or disc wheel damage. In addition, the oil or grease can cause the wheel nuts

to loosen and the wheel may fall off, causing a serious accident. Remove any oil or

grease from the wheel bolts or wheel nuts.

• Have the wheel nuts tightened with a torque wrench to 76 ft•lbf (103 N•m,

10.5 kgf•m) as soon as possible after changing wheels.

• Do not attach a heavily damaged wheel ornament, as it may fly off the wheel while

the vehicle is moving.

• When installing a tire, only use wheel nuts that have been specifically designed for

that wheel.

• If there are any cracks or deformations in the bolt screws, nut threads or bolt holes

of the wheel, have the vehicle inspected by your Lexus dealer.

566

8-2. Steps to take in an emergency

IS350 AWD/IS350/IS300 AWD/IS300_U

Remove any dirt or foreign matter
from the wheel contact surface.

If foreign matter is on the wheel contact

surface, the wheel nuts may loosen

while the vehicle is in motion, causing

the tire to come off.

Install the spare tire and loosely tighten each wheel nut by hand by approxi-
mately the same amount.
When replacing an aluminum wheel
with a steel wheel, tighten the wheel
nuts until the tapered portion comes
into loose contact with the disc
wheel seat.

Lower the vehicle.

Firmly tighten each wheel nut two or
three times in the order shown in the
illustration.

Tightening torque:

76 ft•lbf (103 N•m, 10.5 kgf•m)

Stow the flat tire, tire jack and all tools.

Installing the spare tire

Tapered portion

Disc wheel

seat

567

8-2. Steps to take in an emergency

When trouble

ari

ses

IS350 AWD/IS350/IS300 AWD/IS300_U

■

The compact spare tire

●

The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the

tire sidewall.

Use the compact spare tire temporarily, and only in an emergency.

●

Make sure to check the tire inflation pressure of the compact spare tire.

(

P. 595)

■

When using the compact spare tire
As the compact spare tire is not equipped with a tire pressure warning valve and trans-

mitter, low inflation pressure of the spare tire will not be indicated by the tire pressure

warning system. Also, if you replace the compact spare tire after the tire pressure warn-

ing light comes on, the light remains on.

■

When the compact spare tire is equipped
The vehicle becomes lower when driving with the compact spare tire compared to when

driving with standard tires.

■

If you have a flat rear tire on a road covered with snow or ice (vehicles with front and

rear tires of the same size)
Install the compact spare tire on one of the front wheels of the vehicle. Perform the fol-

lowing steps and fit tire chains to the rear tires:

Replace a front tire with the compact spare tire.
Replace the flat rear tire with the tire removed from the front of the vehicle.
Fit tire chains to the rear tires.

2
3

LEXUS IS 300 (2019 year). Instruction - part 35
