LEXUS IS 300 (2019 year). Instruction - part 28





440

6-5. Using the other interior features

IS350 AWD/IS350/IS300 AWD/IS300_U

●

Reverse operation feature: To ensure adequate rear visibility, the rear sunshade auto-

matically lowers when the shift lever is shifted to R.
However, the rear sunshade is raised again if any of the following occurs:
• The button is pressed again.

*

• The shift lever is shifted into P.

• The shift lever is shifted out of R, and the vehicle reaches a speed of 9 mph (15 km/h).

If the engine is off when the rear sunshade has been lowered due to the reverse opera-

tion feature, it will not be raised even when the engine is turned on again and the vehi-

cle reaches a speed of 9 mph (15 km/h). To raise the sunshade again, press the button.

*

: Occasionally, the reverse function may not be carried out after the switch has been

pressed. Repeat the above operation to operate the function.

WARNING

When the rear sunshade is being operated, do not place fingers or other objects in the

fastener section or in the opening. They may get caught, causing injury.

NOTICE

●

To prevent battery discharge, do not operate the rear sunshade when the engine is

off.

●

To ensure normal operation of the rear sunshade, observe the following precautions:
• Do not place excessive load on the motor or other components of the rear sun-

shade.

• Do not place objects where they may hinder opening and closing operations.

• Do not attach items to the rear sunshade.

• Keep the opening clean and clear of obstructions.

• Do not operate the rear sunshade continuously for long periods of time.

441

6-5. Using the other interior features

6

Inte
rior fe

ature

s

IS350 AWD/IS350/IS300 AWD/IS300_U

An assist grip installed on the ceiling
can be used to support your body while
sitting on the seat.

The coat hooks are provided with the
rear assist grips.

Assist grips

WARNING

Do not use the assist grip when getting in or out of the vehicle or rising from your seat.

NOTICE

To prevent damage to the assist grip, do not put a heavy load on the assist grip.

Coat hooks

WARNING

Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS cur-

tain shield airbags deploy, these items may become projectiles, causing death or seri-

ous injury.

442

6-5. Using the other interior features

IS350 AWD/IS350/IS300 AWD/IS300_U

The HomeLink

®

 wireless control system in your vehicle has 3 buttons which can

be programmed to operate 3 different devices. Refer to the programming meth-
ods on the following pages to determine the method which is appropriate for the
device.

HomeLink

®

 indicator light

Garage door operation indicators
HomeLink

®

 icon

Illuminates while HomeLink

®

 is operat-

ing.

Buttons

■

Before programming HomeLink

®

●

During programming, it is possible that garage doors, gates, or other
devices may operate. For this reason, make sure that people and objects
are clear of the garage door or other devices to prevent injury or other
potential harm.

●

It is recommended that a new battery be placed in the remote control
transmitter for more accurate programming.

●

Garage door opener motors manufactured after 1995 may be equipped
with rolling code protection. If this is the case, you may need a stepladder
or other sturdy, safe device to reach the “Learn” or “Smart” button on the
garage door opener motor.

Garage door opener

The garage door opener can be programmed to operate garage doors, gates,
entry doors, door locks, home lighting systems, security systems, and other
devices.

Programming the HomeLink

®

1

2
3

4

443

6-5. Using the other interior features

6

Inte
rior fe

ature

s

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Programming HomeLink

®

Steps

 through

 must be performed within 60 seconds, otherwise the

indicator light will stop flashing and programming will not be able to be com-
pleted.

Press and release the HomeLink

®

 button you want to program and check

that the HomeLink

®

 indicator light flashes (orange).

Point the remote control transmit-
ter for the device at the rear view
mirror, 1 to 3 in. (25 to 75 mm)
from the HomeLink

®

 buttons.

Keep the HomeLink

®

 indicator light

in view while programming.

Program a device.

Programming a device other than an entry gate (for U.S.A. owners)

Press and hold the handheld transmitter button until the HomeLink

®

 indi-

cator light changes from slowly flashing orange to rapidly flashing green
(rolling code) or continuously lit green (fixed code), then release the but-
ton.

Programming an entry gate (for U.S.A. owners)/Programming a device
in the Canadian market

Press and release the remote control transmitter button at 2 second inter-
vals, repeatedly, until the HomeLink

®

 indicator light changes from slowly

flashing (orange) to rapidly flashing (green) (rolling code) or continuously
lit (green) (fixed code).
Test the HomeLink

®

 operation by pressing the newly programmed button

and observing the indicator light:

●

Indicator light illuminates: Programming of a fixed code device has com-
pleted. The garage door or other device should operate when a Home-
Link

®

 button is pressed and released.

1

3

1

2

3

4

444

6-5. Using the other interior features

IS350 AWD/IS350/IS300 AWD/IS300_U

●

Indicator light flashes rapidly: The garage door opener motor or other
device is equipped with a rolling code. To complete programming, firmly
press and hold the HomeLink

®

 button for 2 seconds then release it.

●

If the garage door or other device does not operate, proceed to “Pro-
gramming a rolling code system”.

Repeat the steps above to program another device for any of the remaining
HomeLink

®

 buttons.

■

Programming a rolling code system
2 or more people may be necessary to complete rolling code programming.

Locate the “Learn” or “Smart”
button on the garage door
opener motor in the garage.

This button can usually be found

where the hanging antenna wire is

attached to the unit. The name and

color of the button may vary by man-

ufacturer. Refer to the owner’s man-

ual supplied with the garage door

opener motor for details.

Press and release the “Learn” or
“Smart” button.
Perform   within 30 seconds
after performing  .

Press and hold the desired
HomeLink

®

 button (inside the

vehicle) for 2 seconds and
release it. Repeat this sequence
(press/hold/release) up to 3
times to complete programming.
If the garage door opener motor
operates when the HomeLink

®

button is pressed, the garage
door opener motor recognizes
the HomeLink

®

 signal.

5

1

2

3

2

3

445

6-5. Using the other interior features

6

Inte
rior fe

ature

s

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Enabling 2-way communication with a garage door (only available for com-
patible devices)
When enabled, 2-way communication allows you to check the status of the
opening and closing of a garage door through indicators in your vehicle.
2-way communication is only available if the garage door opener motor used
is a compatible device. (To check device compatibility, refer to
www.HomeLink.com.)

Within 5 seconds after programming the garage door opener has been
completed, if the garage door opener motor is trained to HomeLink

®

,

both garage door operation indicators will flash rapidly (green) and the
light on the garage door opener motor will blink twice, indicating that 2-
way communication is enabled.

If the indicators do not flash, perform



and   within the first 10 presses of

the HomeLink

®

 button after programming has been completed.

Press a programmed HomeLink

®

 button to operate a garage door.

Within 1 minute of pressing the HomeLink

®

 button, after the garage door

operation has stopped, press the “Learn” or “Smart” button on the garage
door opener motor. Within 5 seconds of the establishment of 2-way com-
munication with the garage door opener, both garage door operation indi-
cators in the vehicle will flash rapidly (green) and the light on the garage
door opener motor will blink twice, indicating that 2-way communication is
enabled.

■

Reprogramming a single HomeLink

®

 button

When the following procedure is performed, buttons which already have
devices registered to them can be overwritten:

With one hand, press and hold the desired HomeLink

®

 button.

When the HomeLink

®

 indicator starts flashing (orange), continue to hold

the HomeLink

®

 button and perform “Programming HomeLink

®

”

(it

takes 20 seconds for the HomeLink

®

 indicator to start flashing).

1

2

3

2
3

1

2

1

446

6-5. Using the other interior features

IS350 AWD/IS350/IS300 AWD/IS300_U

Press the appropriate HomeLink

®

 button. The HomeLink

®

 indicator light

should turn on.

The status of the opening and closing of
a garage door is shown by the indica-
tors.

Opening
Closing

This function is only available if the

garage door opener motor used is a

compatible device. (To check device

compatibility, refer to

www.HomeLink.com.)

The indicators can operate within approximately 820 ft. (250 m) of the garage
door. However, if there are obstructions between the garage door and the vehi-
cle, such as houses and trees, feedback signals from the garage door may not be
received.
To recall the previous door operation status, press and release either Home-

Link

®

 buttons

 and

 or

 and

 simultaneously. The

last recorded status will be displayed for 3 seconds.

Operating HomeLink

®

Garage door operation indicators

1

2

Color

Status

Orange (flashing)

Currently opening/closing

Green

Opening/closing has completed

Red (flashing)

Feedback signals cannot be received

447

6-5. Using the other interior features

6

Inte
rior fe

ature

s

IS350 AWD/IS350/IS300 AWD/IS300_U

Press and hold the 2 outside buttons for
10 seconds until the HomeLink

®

 indi-

cator light changes from continuously
lit (orange) to rapidly flashing (green).

If you sell your vehicle, be sure to erase
the programs stored in the HomeLink

®

memory.

■

Codes stored in the HomeLink

®

 memory

●

The registered codes are not erased even if the battery cable is disconnected.

●

If learning failed when registering a different code to a HomeLink

®

 button that already

has a code registered to it, the already registered code will not be erased.

■

Before programming

●

Install a new battery in the transmitter.

●

The battery side of the transmitter must be pointed away from the HomeLink

.

■

Certification for the garage door opener

For vehicles sold in the U.S.A./Canada

■

When support is necessary
Visit on the web at www.homelink.com/toyota or call 1-800-355-3515.

Erasing the entire HomeLink

®

 memory (all three codes)

448

6-5. Using the other interior features

IS350 AWD/IS350/IS300 AWD/IS300_U

WARNING

■

When programming a garage door or other remote control device
The garage door or other device may operate, so ensure people and objects are out of

danger to prevent potential harm.

■

Conforming to federal safety standards
Do not use the HomeLink

®

 compatible transceiver with any garage door opener or

device that lacks safety stop and reverse features as required by federal safety stan-

dards.

This includes any garage door that cannot detect an interfering object. A door or

device without these features increases the risk of death or serious injury.

■

When operating or programming HomeLink

®

Never allow a child to operate or play with the HomeLink

®

 buttons.

449

6-5. Using the other interior features

6

Inte
rior fe

ature

s

IS350 AWD/IS350/IS300 AWD/IS300_U

To turn the compass on or off, press and
hold the button for 3 seconds.

Compass

: If equipped

The compass on the inside rear view mirror indicates the direction in which
the vehicle is heading.

Operation

Displays and directions

Display

Direction

N

North

NE

Northeast

E

East

SE

Southeast

S

South

SW

Southwest

W

West

NW

Northwest

450

6-5. Using the other interior features

IS350 AWD/IS350/IS300 AWD/IS300_U

The direction display deviates from the true direction determined by the earth’s
magnetic field. The amount of deviation varies according to the geographic posi-
tion of the vehicle.

If you cross over a map boundary shown in illustration, the compass will deviate.

To obtain higher precision or perfect calibration, refer to the following.

■

Deviation calibration

Stop the vehicle.
Press and hold the button for 6
seconds.

A number (1 to 15) appears on the

compass display.

Press the button and, referring to the map above, select the number of the
zone where you are.

If the direction is displayed several seconds after adjustment, the calibration is

complete.

Calibrating the compass

1

2

3

451

6-5. Using the other interior features

6

Inte
rior fe

ature

s

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Circling calibration

Stop the vehicle in a place where it is safe to drive in a circle.
Press and hold the button for 9
seconds.

“C” appears on the compass display.

Drive the vehicle at 5 mph (8
km/h) or less in a circle until a
direction is displayed.

If there is not enough space to drive

in a circle, drive around the block

until a direction is displayed.

■

Conditions unfavorable to correct operation
The compass may not show the correct direction in the following conditions:

●

The vehicle is stopped immediately after turning.

●

The vehicle is on an inclined surface.

●

The vehicle is in a place where the earth's magnetic field is subject to interference by

artificial magnetic fields (underground car park/parking lot, under a steel tower,

between buildings, roof car park/parking lot, near an intersection, near a large vehicle,

etc.).

●

The vehicle has become magnetized.

(There is a magnet or metal object near the inside rear view mirror.)

●

The battery has been disconnected.

●

A door is open.

1

2

3

WARNING

■

While driving the vehicle
Do not adjust the display. Adjust the display only when the vehicle is stopped.

■

When doing the circling calibration
Secure a wide space, and watch out for people and vehicles in the vicinity. Do not vio-

late any local traffic rules while performing circling calibration.

452

6-5. Using the other interior features

IS350 AWD/IS350/IS300 AWD/IS300_U

NOTICE

■

To avoid compass malfunctions
Do not place magnets or any metal objects near the inside rear view mirror.

Doing this may cause the compass sensor to malfunction.

■

To ensure normal operation of the compass

●

Do not perform circling calibration of the compass in a place where the earth's mag-

netic field is subject to interference by artificial magnetic fields.

●

During calibration, do not operate electric systems (moon roof, power windows, etc.)

as they may interfere with the calibration.

454

IS350 AWD/IS350/IS300 AWD/IS300_U

7-1. Maintenance and care

●

Working from top to bottom, liberally apply water to the vehicle body, wheel
wells and underside of the vehicle to remove any dirt and dust.

●

Wash the vehicle body using a sponge or soft cloth, such as a chamois.

●

For hard-to-remove marks, use car wash soap and rinse thoroughly with
water.

●

Wipe away any water.

●

Wax the vehicle when the waterproof coating deteriorates.

If water does not bead on a clean surface, apply wax when the vehicle body is cool.

■

Self-restoring coat
The vehicle body has a self-restoring coating that is resistant to small surface scratches

caused in a car wash etc.

●

The coating lasts for 5 to 8 years from when the vehicle is delivered from the plant.

●

The restoration time differs depending on the depth of the scratch and outside tem-

perature.

The restoration time may become shorter when the coating is warmed by applying

warm water.

●

Deep scratches caused by keys, coins, etc. cannot be restored.

●

Do not use wax that contain abrasives.

■

Automatic car washes

●

Fold the mirrors before washing the vehicle. Start washing from the front of the vehicle.

Make sure to extend the mirrors before driving.

●

Brushes used in automatic car washes may scratch the vehicle surface and harm your

vehicle’s paint.

■

High pressure car washes

●

Do not allow the nozzles of the car wash to come within close proximity of the windows.

●

Before using the car wash, check that the fuel filler door on your vehicle is closed prop-

erly.

Cleaning and protecting the vehicle exterior

Perform the following to protect the vehicle and maintain it in prime condi-
tion:

455

7-1. Maintenance and care

7

Main

tenance an

d care

IS350 AWD/IS350/IS300 AWD/IS300_U

■

When using a car wash
If the door handle becomes wet while the electronic key is within the effective range, the

door may lock and unlock repeatedly. In that case, follow the following correction proce-

dures to wash the vehicle:

●

Place the key in a position 6 ft. (2 m) or more separate from the vehicle while the vehi-

cle is being washed. (Take care to ensure that the key is not stolen.)

●

Set the electronic key to battery-saving mode to disable the smart access system with

push-button start. (

P. 137)

■

Aluminum wheels

●

Remove any dirt immediately by using a neutral detergent.

●

Wash detergent off with water immediately after use.

●

To protect the paint from damage, make sure to observe the following precautions.
• Do not use acidic, alkaline or abrasive detergent

• Do not use hard brushes

• Do not use detergent on the wheels when they are hot, such as after driving or park-

ing in hot weather

■

Bumpers
Do not scrub with abrasive cleaners.

■

Front side windows water-repellent coating (if equipped)

●

The following precautions can extend the effectiveness of the water-repellent coating.
• Remove any dirt, etc. from the front side windows regularly.

• Do not allow dirt and dust to accumulate on the windows for a long period.

Clean the windows with a soft, damp cloth as soon as possible.

• Do not use wax or glass cleaners that contain abrasives when cleaning the windows.

• Do not use any metallic objects to remove condensation build up.

●

When the water-repellent performance has become insufficient, the coating can be

repaired. Contact your Lexus dealer.















Content   ..  26  27  28  29   ..
