LEXUS IS 300 (2019 year). Instruction - part 12

184

4-1. Before driving

IS350 AWD/IS350/IS300 AWD/IS300_U

Trailer towing

Lexus does not recommend towing a trailer with your vehicle. Lexus also does
not recommend the installation of a tow hitch or the use of a tow hitch carrier
for a wheelchair, scooter, bicycle, etc. Your vehicle is not designed for trailer
towing or for the use of tow hitch mounted carriers.

185

4-1. Before driving

4

Dr

iving

IS350 AWD/IS350/IS300 AWD/IS300_U

Dinghy towing

Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground)
behind a motor home.

NOTICE

■

To avoid serious damage to your vehicle
Do not tow your vehicle with the four wheels on the ground.

186

IS350 AWD/IS350/IS300 AWD/IS300_U

4-2. Driving procedures

Check that the parking brake is set.
Check that the shift lever is in P.
Firmly depress the brake pedal.

 and a message will be displayed on the multi-information display.

If it is not displayed, the engine cannot be started.

Press the engine switch shortly and
firmly.

When operating the engine switch, one

short, firm press is enough. It is not nec-

essary to press and hold the switch.
The engine will crank until it starts or for

up to 30 seconds, whichever is less.
Continue depressing the brake pedal

until the engine is completely started.
The engine can be started from any

engine switch mode.

Stop the vehicle.
Set the parking brake (

P. 200), and shift the shift lever to P.

Press the engine switch.
Release the brake pedal and check that the display on the meters is off.

Engine (ignition) switch

Performing the following operations when carrying the electronic key on your
person starts the engine or changes engine switch modes.

Starting the engine

1

2
3

4

Stopping the engine

1

2
3
4

187

4-2. Driving procedures

4

Dr

iving

IS350 AWD/IS350/IS300 AWD/IS300_U

Modes can be changed by pressing the engine switch with brake pedal released.
(The mode changes each time the switch is pressed.)

Off

*

The emergency flashers can be used.
The multi-information display will not be

displayed.

ACCESSORY mode

Some electrical components such as the

audio system can be used.
“ACCESSORY” will be displayed on the

meters.

IGNITION ON mode

All electrical components can be used.
“IGNITION ON” will be displayed on

the meters.

*

:  If the shift lever is in a position other than

P when turning off the engine, the
engine switch will be turned to ACCES-
SORY mode, not to off.

If the engine is stopped with the shift lever in a position other than P, the engine
switch will not be turned off but instead be turned to ACCESSORY mode. Per-
form the following procedure to turn the switch off:

Check that the parking brake is set.
Shift the shift lever to P.
Check that “Turn Off Vehicle” is displayed on the multi-information display
and then press the engine switch once.
Check that “Turn Off Vehicle” on the multi-information display is off.

Changing engine switch modes

1

2

3

When stopping the engine with the shift lever in a position other than P

1

2
3

4

188

4-2. Driving procedures

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Auto power off function
If the vehicle is left in ACCESSORY mode for more than 20 minutes or IGNITION ON

mode (the engine is not running) for more than an hour with the shift lever in P, the engine

switch will automatically turn off. However, this function cannot entirely prevent battery

discharge. Do not leave the vehicle with the engine switch in ACCESSORY or IGNI-

TION ON mode for long periods of time when the engine is not running.

■

Electronic key battery depletion
P. 121

■

Conditions affecting operation
P. 137

■

Notes for the entry function
P. 138

■

If the engine does not start

●

Check that the shift lever is securely set in P. The engine may not start if the shift lever is

displaced out of P.

●

The engine immobilizer system may not have been deactivated. (

P. 76)

Contact your Lexus dealer.

■

Steering lock
After turning the engine switch off and opening and closing the doors, the steering wheel

will be locked due to the steering lock function. Operating the engine switch again auto-

matically cancels the steering lock.

■

When the steering lock cannot be released

■

Steering lock motor overheating prevention
To prevent the steering lock motor from overheating, operation of the motor may be sus-

pended if the engine is turned on and off repeatedly in a short period of time. In this case,

refrain from operating the engine switch. After about 10 seconds, the steering lock

motor will resume functioning.

“Steering Wheel Lock Press Engine Switch

while Turning Wheel” will be displayed on the

multi-information display.
Check that the shift lever is in P. Press the

engine switch while turning the steering wheel

left and right.

189

4-2. Driving procedures

4

Dr

iving

IS350 AWD/IS350/IS300 AWD/IS300_U

■

When “Access System with Elec. Key Malfunction See Owner’s Manual” is displayed

on the multi-information display
The system may be malfunctioning. Have the vehicle inspected by your Lexus dealer

immediately.

■

If the electronic key battery is depleted
P. 502

■

Operation of the engine switch

●

If the switch is not pressed shortly and firmly, the engine switch mode may not change

or the engine may not start.

●

If attempting to restart the engine immediately after turning the engine switch off, the

engine may not start in some cases. After turning the engine switch off, please wait a

few seconds before restarting the engine.

■

If the smart access system with push-button start has been deactivated by a customized

setting
P. 572

WARNING

■

When starting the engine
Always start the engine while sitting in the driver’s seat. Do not depress the accelerator

pedal while starting the engine under any circumstances.

Doing so may cause an accident resulting in death or serious injury.

■

Caution while driving
If engine failure occurs while the vehicle is moving, do not lock or open the doors until

the vehicle reaches a safe and complete stop. Activation of the steering lock in this cir-

cumstance may lead to an accident, resulting in death or serious injury.

■

Stopping the engine in an emergency
If you want to stop the engine in an emergency while driving the vehicle, press and hold

the engine switch for more than 2 seconds, or press it briefly 3 times or more in succes-

sion. (

P. 515)

However, do not touch the engine switch while driving except in an emergency. Turning

the engine off while driving will not cause loss of steering or braking control, but the

power assist to these systems will be lost. This will make it more difficult to steer and

brake, so you should pull over and stop the vehicle as soon as it is safe to do so.

190

4-2. Driving procedures

IS350 AWD/IS350/IS300 AWD/IS300_U

NOTICE

■

To prevent battery discharge

●

Do not leave the engine switch in ACCESSORY or IGNITION ON mode for long

periods of time without the engine running.

●

If “ACCESSORY” or “IGNITION ON” is displayed on the meters while the engine is

not running, the engine switch is not off. Exit the vehicle after turning the engine

switch off.

●

Do not stop the engine when the shift lever is in a position other than P. If the engine is

stopped in another shift lever position, the engine switch will not be turned off but

instead  be  turned  to  ACCESSORY  mode.  If  the  vehicle  is  left  in  ACCESSORY

mode, battery discharge may occur.

■

When starting the engine

●

Do not race a cold engine.

●

If the engine becomes difficult to start or stalls frequently, have your vehicle checked

by your Lexus dealer immediately.

■

Symptoms indicating a malfunction with the engine switch
If the engine switch seems to be operating somewhat differently than usual, such as the

switch sticking slightly, there may be a malfunction. Contact your Lexus dealer immedi-

ately.

191

4-2. Driving procedures

4

Dr

iving

IS350 AWD/IS350/IS300 AWD/IS300_U

While the engine switch is in IGNITION ON mode, move the shift lever
with the brake pedal depressed.

When shifting the shift lever between P and D, make sure that the vehicle is com-

pletely stopped.

Automatic transmission

Shifting the shift lever

192

4-2. Driving procedures

IS350 AWD/IS350/IS300 AWD/IS300_U

*

1

: To improve fuel efficiency and reduce noise, shift the shift lever to D for normal driv-

ing.

*

2

: Any gear range can be fixed when driving in M mode.

■

Sport mode/Eco drive mode
P. 297

■

Snow mode
Snow mode can be selected to suit the conditions when driving on slippery
road surfaces, such as snow.
Press the switch.

Press the switch again to return to

normal mode.

Shift position purpose

Shift position

Objective or function

P

Parking the vehicle/starting the engine

R

Reversing

N

Neutral

(Condition in which the power is not transmitted)

D

Normal driving

*

1

M

M mode driving

*

2

 (

P. 194)

Selecting the driving mode

193

4-2. Driving procedures

4

Dr

iving

IS350 AWD/IS350/IS300 AWD/IS300_U

To drive using temporary shift range selection, operate the “-” or “+” paddle shift
switch.
When the “-” paddle shift switch is operated, the shift range will be downshifted
to a range that enables engine braking force that is suitable to driving conditions.
When the “+” paddle shift switch is operated, the shift range will be one gear
higher than the gear in use during normal D position driving.
Changing the shift range allows restriction of the highest gear, preventing unnec-
essary upshifting and enabling the level of engine braking force to be selected.

Upshifting
Downshifting

8-speed models: The selected shift

range, from D1 to D8, will be displayed

in the meter.
6-speed models: The selected shift

range, from D1 to D6, will be displayed

in the meter.
To return to normal D position driving,

the “+” paddle shift switch must be held

down for a period of time.

■

Shift ranges and their functions

A lower shift range will provide greater engine braking forces than a higher shift

range.

Selecting shift ranges in the D position

1

2

Meter display

Function

D2 - D8

(8-speed models)

A gear in the range between 1 and the selected gear is auto-

matically chosen depending on vehicle speed and driving

conditions

D2 - D6

(6-speed models)

D1

1st gear is set

194

4-2. Driving procedures

IS350 AWD/IS350/IS300 AWD/IS300_U

To enter M mode, shift the shift lever to M. Gears can then be selected by oper-
ating the shift lever or paddle shift switches, allowing you to drive in the gear of
your choice.

Upshifting
Downshifting

The gear changes once every time the

shift lever or paddle shift switch is oper-

ated.
8-speed models: The selected gear,

from M1 to M8, will be fixed and dis-

played in the meter.
6-speed models: The selected gear,

from M1 to M6, will be fixed and dis-

played in the meter.

When in the M position, the gear will not change unless the shift lever or pad-
dle shift switches are operated.
However, even when in the M position, the gears will be automatically
changed in the following situation:

●

When vehicle speed drops (downshift only).

●

When the automatic transmission fluid or engine coolant temperature is
low.

●

When automatic transmission fluid temperature is high.

●

When the needle of the tachometer is in the red zone (the range which
exceeds the allowable revs of the engine).

In the following situations, the gear will not shift even if the shift lever or paddle
shift switches are operated.

●

“Slippery Road. Cannot Shift to Lower Gear” is displayed on the multi
information display.

●

The vehicle speed is low (upshift only).

Selecting gears in the M position

1

2

195

4-2. Driving procedures

4

Dr

iving

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Automatic deactivation of shift range selection in the D position
Shift range selection in the D position will be deactivated in the following situations:

●

When the vehicle comes to a stop

●

If the accelerator pedal is depressed for more than a certain period of time

●

When the shift lever is shifted to a position other than D

■

To protect the automatic transmission
“Transmission Fluid Temp High See Owner’s Manual” is displayed on the multi-informa-

tion display and a function is adopted that automatically selects a higher shift range when

the fluid temperature is high. Have the vehicle inspected by your Lexus dealer.

■

Downshifting restriction warning buzzer
To help ensure safety and driving performance, downshifting operation may sometimes

be restricted. In some circumstances, downshifting may not be possible even when the

shift lever or paddle shift switch is operated. (A buzzer will sound twice.)

■

Snow mode automatic deactivation
Snow mode is automatically deactivated if the engine switch is turned off after driving in

snow mode.

■

Gear position display on the multi-information display
When Gear positions is selected for a Drive Information screen on the multi-information

display and the shift lever is in the D or M position, the currently selected gear position

will be displayed on the multi-information display. (The display changes according to the

shift lever position and driving conditions.)

■

When driving with dynamic radar cruise control activated
Even when performing the following actions with the intent of enabling engine braking,

engine braking will not activate because dynamic radar cruise control will not be can-

celed.

●

8-speed models: While driving in the D position, downshifting to 7, 6, 5 or 4.

(

P. 248)

●

6-speed models: While driving in the D position, downshifting to 5 or 4.

(

P. 248)

●

When switching the driving mode to sport mode while driving in D position.

(

P. 297)

■

Restraining sudden start (Drive-Start Control)

●

When the following unusual operation is performed, the engine output may be

restrained.
• When the shift lever is shifted from R to D, D to R, N to R, P to D, or P to R (D

includes M) with the accelerator pedal depressed, a warning message appears on

the multi-information display. (

P. 537)

• When the accelerator pedal is depressed too much while the vehicle is in reverse.

196

4-2. Driving procedures

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Shift lock system
The shift lock system is a system to prevent accidental operation of the shift lever in start-

ing.

The shift lever can be shifted from P only when the engine switch is in IGNITION ON

mode and the brake pedal is being depressed.

■

If the shift lever cannot be shifted from P
First, check whether the brake pedal is being depressed.
If the shift lever cannot be shifted with your foot on the brake pedal, there may be a prob-

lem with the shift lock system. Have the vehicle inspected by your Lexus dealer immedi-

ately.

The following steps may be used as an emergency measure to ensure that the shift lever

can be shifted.
Releasing the shift lock:

Set the parking brake.
Turn the engine switch to off.
Depress the brake pedal.

■

AI-SHIFT

●

The AI-SHIFT automatically selects the suitable gear according to driver performance

and driving conditions.

The AI-SHIFT automatically operates when the shift lever is in D. (Shifting the shift lever

to the M position cancels the function.)

●

8-speed models: The G AI-SHIFT is automatically changed to a suitable gear step

while running in sport mode according to the driving operations and running condi-

tions.

The G AI-SHIFT automatically operates when the drive mode select switch is set to

sport mode with the shift lever in the D position. (The function will be canceled, if the

drive mode is select switch is set to normal mode or shift lever is put in the M position.)

1

2
3

Pry the cover up with a flathead screwdriver

or equivalent tool.

To prevent damage to the cover, cover the tip

of the screwdriver with a rag.

Press the shift lock override button.

The shift lever can be shifted while the button

is pressed.

4

5

197

4-2. Driving procedures

4

Dr

iving

IS350 AWD/IS350/IS300 AWD/IS300_U

WARNING

■

When driving on slippery road surfaces
Be careful of downshifting and sudden acceleration, as this could result in the vehicle

skidding to the side or spinning.

■

To prevent an accident when releasing the shift lock
Before pressing the shift lock override button, make sure to set the parking brake and

depress the brake pedal.

If the accelerator pedal is accidentally depressed instead of the brake pedal when the

shift lock override button is pressed and the shift lever is shifted out of P, the vehicle

may suddenly start, possibly leading to an accident resulting in death or serious injury.

198

4-2. Driving procedures

IS350 AWD/IS350/IS300 AWD/IS300_U

The lever will return to its original position after operation.

Right turn
Lane change to the right (move the
lever partway and release it)

The right hand signals will flash 3 times.

Lane  change  to  the  left  (move  the
lever partway and release it)

The left hand signals will flash 3 times.

Left turn

■

If the turn signals do not stop flashing after turning left or right, or if you want
to stop them flashing
Operate the lever in the opposite direction to either position

 or

. If you

move the lever to either position

 or

, the selected turn signals will flash.

Turn signal lever

Operating instructions

1

2

3

4

2

3

1

4

199

4-2. Driving procedures

4

Dr

iving

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Turn signals can be operated when
The engine switch is in IGNITION ON mode.

■

If the indicator flashes faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned out.

■

If the turn signals stop flashing before a lane change has been performed
Operate the lever again.

■

Customization
The number of times the turn signals flash during a lane change can be changed.

(Customizable feature

P. 613)
