LEXUS IS 300 (2019 year). Instruction

120

3-1. Key information

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Panic mode

■

Card key (if equipped)

●

The card key is not waterproof.

●

The mechanical key that is stored inside the card key should be used only if a problem

arises, such as when the card key does not operate properly.

●

If it is difficult to take out the mechanical key, push down the lock release button using a

pen tip etc. If it is still difficult to pull it out, use a coin etc.

■

When required to leave the vehicle’s key with a parking attendant
Set the luggage security system (

P. 131) on and lock the glove box (P. 432) as cir-

cumstances demand.

Remove the mechanical key for your own use and provide the attendant with the elec-

tronic key only.

■

If you lose your mechanical keys
New genuine mechanical keys can be made by your Lexus dealer using another

mechanical key and the key number stamped on your key number plate. Keep the plate

in a safe place such as your wallet, not in the vehicle.

When

is pressed for longer than about

one second, an alarm will sound intermittently

and the vehicle lights will flash to deter any per-

son from trying to break into or damage your

vehicle.
To stop the alarm, press any button on the elec-

tronic key.

●

To store the mechanical key in the card key,

insert it while pressing the lock release button.

●

If the battery cover is not installed and the bat-

tery falls out or if the battery was removed

because the key got wet, reinstall the battery

with the positive terminal facing the Lexus

emblem.

121

3-1. Key information

Op
era
tio

n of
ea

IS350 AWD/IS350/IS300 AWD/IS300_U

■

When riding in an aircraft
When bringing an electronic key onto an aircraft, make sure you do not press any but-

tons on the electronic key while inside the aircraft cabin. If you are carrying an electronic

key in your bag etc., ensure that the buttons are not likely to be pressed accidentally.

Pressing a button may cause the electronic key to emit radio waves that could interfere

with the operation of the aircraft.

■

Electronic key battery depletion

●

The standard battery life is 1 to 2 years. (The card key battery life is about a year and a

half.)

●

If the battery becomes low, an alarm will sound in the cabin when the engine is stopped.

(

P. 555)

●

As the electronic key always receives radio waves, the battery will become depleted

even if the electronic key is not used. The following symptoms indicate that the elec-

tronic key battery may be depleted. Replace the battery when necessary. (

P. 502)

• The smart access system with push-button start or the wireless remote control does

not operate.

• The detection area becomes smaller.

• The LED indicator on the key surface does not turn on.

●

To avoid serious deterioration, do not leave the electronic key within 3 ft. (1 m) of the

following electrical appliances that produce a magnetic field:
• TVs

• Personal computers

• Cellular phones, cordless phones and battery chargers

• Recharging cellular phones or cordless phones

• Table lamps

• Induction cookers

■

Replacing the battery
P. 502

■

Confirmation of the registered key number
The number of keys already registered to the vehicle can be confirmed. Ask your Lexus

dealer for details.

■

If a wrong key is used
The key cylinder rotates freely to isolate inside mechanism.

122

3-1. Key information

IS350 AWD/IS350/IS300 AWD/IS300_U

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject them to strong shocks or bend them.

●

Do not expose the keys to high temperatures for long periods of time.

●

Do not get the keys wet or wash them in an ultrasonic washer etc.

●

Do not attach metallic or magnetic materials to the keys or place the keys close to

such materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or anything else to the surface of the electronic key.

●

Do not place the keys near objects that produce magnetic fields, such as TVs, audio

systems and induction cookers, or medical electrical equipment, such as low-fre-

quency therapy equipment.

■

Carrying the electronic key on your person
Carry the electronic key 3.9 in. (10 cm) or more away from electric appliances that are

turned on. Radio waves emitted from electric appliances within 3.9 in. (10 cm) of the

electronic key may interfere with the key, causing the key to not function properly.

■

In case of a smart access system with push-button start malfunction or other key-

related problems
Take your vehicle with all the electronic keys provided with your vehicle, including the

card key, to your Lexus dealer.

123

3-1. Key information

Op
era
tio

n of
ea

IS350 AWD/IS350/IS300 AWD/IS300_U

NOTICE

■

When an electronic key is lost
If the electronic key remains lost, the risk of vehicle theft increases significantly. Visit

your Lexus dealer immediately with all remaining electronic keys and the card key that

were provided with your vehicle.

■

Handling the card key

●

Do not apply excess force when inserting the mechanical key into the card key. Doing

so may damage the card key.

●

If the battery or card key terminals get wet, the battery may corrode.

If the key is dropped into water, or if drinking water etc. is spilled on the key, immedi-

ately remove the battery cover and wipe the battery and terminals. (To remove the

battery cover, lightly grasp and pull it.) If the battery is corroded, have your Lexus

dealer replace the battery.

●

Do not crush the battery cover or use a screwdriver to remove the battery cover.

Forcibly removing the battery cover may bend or damage the key.

●

If the battery cover is frequently removed, the battery cover may become loose.

●

When installing the battery, make sure to check the direction of the battery.

Installing the battery in the wrong direction may cause the battery to deplete rapidly.

●

The surface of the card key may be damaged, or its coating may peel off in the follow-

ing situations:
• The card key is carried together with hard objects, such as coins and keys.

• The card key is scraped with a sharp object, such as the tip of a mechanical pencil.

• The surface of the card key is wiped with thinner or benzene.

124

IS350 AWD/IS350/IS300 AWD/IS300_U

3-2. Opening, closing and locking the doors and trunk

◆

Smart access system with push-button start

Carry the electronic key to enable this function.

Grip the driver’s door handle to
unlock the door. Grip the passen-
ger’s front door handle to unlock
all the doors.*

Make sure to touch the sensor on the

back of the handle.
The doors cannot be unlocked for 3

seconds after the doors are locked.

: The door unlock settings can be

changed. (

P. 128)

Touch the lock sensor (indentation on the upper part of the front door han-
dle) to lock all the doors.

Check that the door is securely locked.

◆

Wireless remote control

Locks all the doors

Check that the door is securely

locked.

Unlocks all the doors

Pressing the button unlocks the

driver’s door. Pressing the button

again within 5 seconds unlocks the

other doors.
Press and hold to open the windows

and moon roof.

: This setting must be customized at your Lexus dealer.

Doors

Unlocking and locking the doors from the outside

125

3-2. Opening, closing and locking the doors and trunk

Op
era
tio

n of
ea

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Operation signals
A buzzer sounds and the emergency flashers flash to indicate that the doors have been

locked/unlocked. (Locked: once; Unlocked: twice)
A buzzer sounds to indicate that the windows and moon roof are operating.

■

Security feature
If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the

security feature automatically locks the vehicle again.

■

Welcome light illumination control
The front position, tail and license plate lights automatically turn on at night when the

doors are unlocked using the entry function or wireless remote control if the light switch

is in the “AUTO” position.

■

When the door cannot be locked by the lock sensor on the upper part of the door han-

dle

■

Door lock buzzer
If an attempt to lock the doors is made when a door is not fully closed, a buzzer sounds

continuously for 5 seconds. Fully close the door to stop the buzzer, and lock the vehicle

once more.

■

Setting the alarm
Locking the doors will set the alarm system. (

P. 78)

■

If the smart access system with push-button start or the wireless remote control does

not operate properly
Use the mechanical key to lock and unlock the doors. (

P. 572)

Replace the key battery with a new one if it is depleted. (

P. 502)

If the door will not lock even when the topside

sensor area is touched, try touching both the

topside and underside sensor areas at the same

time.

126

3-2. Opening, closing and locking the doors and trunk

IS350 AWD/IS350/IS300 AWD/IS300_U

◆

Door lock switches

Locks all the doors
Unlocks all the doors

◆

Inside lock buttons

Locks the door
Unlocks the door

The front doors can be opened by

pulling the inside handle even if the

lock buttons are in the lock position.

Move the inside lock button to the lock position.
Close the door.

The door cannot be locked if the engine switch is in ACCESSORY or IGNITION

ON mode, or the electronic key is left inside the vehicle. However, the key may not be

detected correctly and the door may be locked.

Unlocking and locking the doors from the inside

Locking the doors from the outside without a key

127

3-2. Opening, closing and locking the doors and trunk

Op
era
tio

n of
ea

IS350 AWD/IS350/IS300 AWD/IS300_U

The door cannot be opened from inside
the vehicle when the lock is set.

Unlock
Lock

These locks can be set to prevent chil-

dren from opening the rear doors. Push

down on each rear door switch to lock

both rear doors.

The following functions can be set or canceled:

For instructions on customizing, refer to P. 613.

Rear door child-protector lock

Automatic door locking and unlocking systems

Function

Operation

Speed linked door locking function

All doors are automatically locked when

vehicle speed is approximately 12 mph

(20 km/h) or higher.

Shift position linked door locking function

All doors are automatically locked when

shifting the shift lever to position other

than P.

Shift position linked door unlocking func-

tion

All doors are automatically unlocked

when shifting the shift lever to P.

Driver's door linked door unlocking func-

tion

All doors are automatically unlocked

when driver’s door is opened.

128

3-2. Opening, closing and locking the doors and trunk

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Switching the door unlock function
It is possible to set which doors the entry function unlocks using the wireless remote con-

trol.

Turn the engine switch off.
When the indicator light on the key surface is not on, press and hold

for approximately 5 seconds while pressing and holding

The setting changes each time an operation is performed, as shown below. (When

changing the setting continuously, release the buttons, wait for at least 5 seconds, and

repeat step .)

To prevent unintended triggering of the alarm, unlock the doors using the wireless

remote control and open and close a door once after the settings have been changed. (If
a door is not opened within 60 seconds after

is pressed, the doors will be locked

again and the alarm will automatically be set.)

In a case that the alarm is triggered, immediately stop the alarm. (

P. 78)

Multi-information

display

Unlocking function

Beep

Holding the driver’s door handle

unlocks only the driver’s door.

Exterior: Beeps 3 times

Interior: Pings once

Holding the front passenger’s

door handle unlocks all the

doors.

Holding either front door handle

unlocks all the doors.

Exterior: Beeps twice

Interior: Pings once

129

3-2. Opening, closing and locking the doors and trunk

Op
era
tio

n of
ea

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Impact detection door lock release system
In the event that the vehicle is subject to a strong impact, all the doors are unlocked.

Depending on the force of the impact or the type of accident, however, the system may

not operate.

■

Using the mechanical key
The doors can also be locked and unlocked with the mechanical key. (

P. 572)

■

Conditions affecting the operation of the smart access system with push-button start

or wireless remote control
P. 137

■

Customization
Settings (e.g. unlocking function using a key) can be changed.

(Customizable features:

P. 613)

WARNING

■

To prevent an accident
Observe the following precautions while driving the vehicle.

Failure to do so may result in a door opening and an occupant being thrown out of the

vehicle, resulting in death or serious injury.

●

Ensure that all doors are properly closed and locked.

●

Do not pull the inside handle of the doors while driving.

Be especially careful with the front doors, as the doors may be opened even if the

inside lock buttons are in locked position.

●

Set the rear door child-protector locks when children are seated in the rear seats.

130

3-2. Opening, closing and locking the doors and trunk

IS350 AWD/IS350/IS300 AWD/IS300_U

Press the opener switch.

◆

Smart access system with push-button start

While carrying the electronic key,
press the button on the trunk lid.

When all the doors are unlocked with

the power door lock system, the

trunk can be opened without carry-

ing the electronic key.

◆

Wireless remote control

Press and hold the switch.

Trunk

The trunk can be opened using the trunk opener, entry function or wireless
remote control.

Opening the trunk from inside the vehicle

Opening the trunk from outside the vehicle

131

3-2. Opening, closing and locking the doors and trunk

Op
era
tio

n of
ea

IS350 AWD/IS350/IS300 AWD/IS300_U

Using the trunk grip, lower the trunk
without applying force to the side and
push the trunk down from the outside
to close it.

To protect luggage stored in the trunk against theft, the luggage security system
can be set to on.

Move the luggage security system
levers to the lock position.

To disable the trunk opener, turn the
main switch in the glove box off

On
Off

When the main switch is off, the trunk

lid cannot be opened even with the

wireless remote control or entry

function.

When closing the trunk

Luggage security system

132

3-2. Opening, closing and locking the doors and trunk

IS350 AWD/IS350/IS300 AWD/IS300_U

■

Trunk light
The trunk light turns on when the trunk is opened.

■

Function to prevent the trunk being locked with the electronic key inside

●

When all doors are locked, closing the trunk lid with the electronic key left inside the

trunk will sound an alarm.

In this case, the trunk lid can be opened pressing the trunk release button on the trunk

lid.

●

If the spare electronic key is put in the trunk with all the doors locked, the key confine-

ment prevention function is activated so the trunk can be opened. In order to prevent

theft, take all electronic keys with you when leaving the vehicle.

●

If the electronic key is put in the trunk with all the doors locked, the key may not be

detected depending on the location of the key and the surrounding radio wave condi-

tions. In this case, the key confinement prevention function cannot be activated, causing

the doors to lock when the trunk is closed. Make sure to check where the key is before

closing the trunk.

●

The key confinement prevention function cannot be activated if any one of the doors is

unlocked. In this case, open the trunk using the trunk opener.

■

Internal trunk release lever

■

Using the mechanical key
The trunk can be also opened using the mechanical key. (

P. 572)

■

If the smart access system with push-button start or the wireless remote control does

not operate properly
Use the mechanical key to unlock the trunk. (

P. 572)

Replace the key battery with a new one if it is depleted. (

P. 502)

■

When leaving a key to the vehicle with a parking attendant
P. 120

■

Customization
The trunk unlocking operation can be changed. (Customizable features:

P. 613)

The trunk lid can be opened by pulling the glow-

in-the-dark lever located on the inside of the

trunk lid to the side.
The lever will continue to glow for some time

after the trunk lid is closed.

133

3-2. Opening, closing and locking the doors and trunk

Op
era
tio

n of
ea

IS350 AWD/IS350/IS300 AWD/IS300_U

WARNING

Observe the following precautions.

Failure to do so may result in death or serious injury.

■

Before driving

●

Make sure that the trunk lid is fully closed. If the trunk lid is not fully closed, it may

open unexpectedly while driving and hit near-by objects or luggage in the trunk may

be thrown out, causing an accident.

●

Do not allow children to play in the trunk.

If a child is accidentally locked in the trunk, they could suffer from heat exhaustion,

suffocation or other injuries.

●

Do not allow a child to open or close the trunk lid.

Doing so may cause the trunk lid to open unexpectedly, or cause the child’s hands,

head, or neck to be caught by the closing trunk lid.

■

Important points while driving
Never let anyone sit in the trunk. In the event of sudden braking or a collision, they are

susceptible to death or serious injury.

134

3-2. Opening, closing and locking the doors and trunk

IS350 AWD/IS350/IS300 AWD/IS300_U

WARNING

■

Using the trunk
Observe the following precautions.

Failure to do so may cause parts of the body to be caught, resulting in serious injury.

●

Remove any heavy loads, such as snow and ice, from the trunk lid before opening it.

Failure to do so may cause the trunk lid to suddenly shut again after it is opened.

●

When opening or closing the trunk lid, thoroughly check to make sure the surround-

ing area is safe.

●

If anyone is in the vicinity, make sure they are safe and let them know that the trunk is

about to open or close.

●

Use caution when opening or closing the trunk lid in windy weather as it may move

abruptly in strong wind.

●

Do not attach any accessories other than genuine Lexus parts to the trunk lid. Such

additional weight on the trunk lid may cause the lid to suddenly shut again after it is

opened.

●

The trunk lid may suddenly shut if it is not

opened fully. It is more difficult to open or

close the trunk lid on an incline than on a level

surface, so beware of the trunk lid unexpect-

edly opening or closing by itself. Make sure

that the trunk lid is fully open and secure

before using the trunk.

●

When closing the trunk lid, take extra care to

prevent your fingers etc. from being caught.

●

When closing the trunk lid, make sure to

press it lightly on its outer surface. If the trunk

handle is used to fully close the trunk lid, it

may result in hands or arms being caught.

135

3-2. Opening, closing and locking the doors and trunk

Op
era
tio

n of
ea

IS350 AWD/IS350/IS300 AWD/IS300_U

●

Locks and unlocks the doors (

P. 124)

●

Opens the trunk (

P. 130)

●

Starts the engine (

P. 186)

■

Antenna location

■

Effective range (areas within which the electronic key is detected)

Smart access system with push-button start

The following operations can be performed simply by carrying the electronic
key (including the card key) on your person, for example in your pocket. The
driver should always carry the electronic key.

Antennas outside the cabin
Antennas inside the cabin
Antenna inside the trunk
Antenna outside the trunk

When locking or unlocking the doors
The system can be operated when the elec-

tronic key is within about 2.3 ft. (0.7 m) of

an outside door handle. (Only the doors

detecting the key can be operated.)
When opening the trunk
The system can be operated when the elec-

tronic key is within about 2.3 ft. (0.7 m) of

the trunk release button.
When starting the engine or changing engine switch modes
The system can be operated when the electronic key is inside the vehicle.

2
3
4

LEXUS IS 300 (2019 year). Instruction - part 8
