LEXUS GX 460 (2019 year). Instruction - part 34

Con-

tinuous



The driver’s door was opened when

the shift lever was not in P and the

engine switch was not turned off.

 Shift the shift lever to P.

Con-

tinuous

Con-

tinuous

The driver’s door was opened and

closed while the electronic key was

not in the vehicle, the shift lever was

not in P and the engine switch was

not turned off.

 Shift the shift lever to P.

 Bring the electronic key back

into the vehicle.

Once

Contin-

uous

• An attempt was made to lock

either front door by opening a

door and putting the inside lock

button into the lock position, then

closing the door with the elec-

tronic key still inside the vehicle.

• An attempt was made to lock the

doors using the smart access sys-

tem with push-button start while

the electronic key was still inside

the vehicle.

 Retrieve the electronic key

from the vehicle and lock the

doors again.

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

(Flashes)

(Displayed alternately)

(Flashes)

537

When trouble

Once



• When the doors were unlocked

with the mechanical key and then

the engine switch was pressed,

the electronic key could not be

detected in the vehicle.

• The electronic key could not be

detected in the vehicle even after

the engine switch was pressed

two consecutive times.

 Touch the electronic key to the

engine switch while depressing

the brake pedal.



Power was turned off due to the

automatic power off function.

 Next time when starting the

engine, increase the engine

speed slightly and maintain that

level for approximately 5 min-

utes to recharge the battery.

Once



The electronic key has a low battery.

 Replace the electronic key bat-

tery. (

P. 489)

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

(Flashes)

538

Once



The driver’s door was opened and

closed with the engine switch turned

off and then the engine switch was

put in ACCESSORY mode twice

without the engine being started.

 Press the engine switch while

depressing the brake pedal.

During an engine starting proce-

dure in the event that the electronic

key was not functioning properly

(

P. 556), the engine switch was

touched with the electronic key.

 Press the engine switch within

10 seconds of the buzzer sound-

ing.

Once



The steering lock could not be

released within 3 seconds of the

engine switch being pressed.

 Press the engine switch while

depressing the brake pedal and

moving the steering wheel left

and right.

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

(Flashes)

539

When trouble

■

Warning buzzer
In some cases, the buzzer may not be heard due to being in a noisy location or audio

sound.

Once



An attempt was made to start the

engine with the shift lever in an

incorrect position.

 Shift the shift lever to P and start

the engine.

Once



An attempt was made to turn the

engine switch off when the shift

lever was not in P.

 To turn off the engine, first shift

the shift lever to P and then turn

the engine switch off.

Interior

buzzer

Exterior

buzzer

Warning message

Details/Actions

(Flashes)

540

If you have a flat tire

●

Stop the vehicle in a safe place on a hard, flat surface.

●

Set the parking brake.

●

Shift the shift lever to P.

●

Turn off the rear height control air suspension (if equipped). (

P. 341)

●

Stop the engine.

●

Turn on the emergency flashers. (

P. 508)

Your vehicle is equipped with a spare tire. The flat tire can be replaced with
the spare tire.
For details about tires:

P. 474

CAUTION

■

If you have a flat tire
Do not continue driving with a flat tire.

Driving even a short distance with a flat tire can damage the tire and the wheel beyond

repair, which could result in an accident.

Before jacking up the vehicle

541

When trouble

Jack
Tool box
Spare tire

Location of the spare tire, jack and tools

2
3

542

CAUTION

■

Using the tire jack
Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading

to death or serious injury.

●

Do not use the tire jack for any purpose other than replacing tires or installing and

removing tire chains.

●

Only use the tire jack that comes with this vehicle for replacing a flat tire.

Do not use it on other vehicles, and do not use other tire jacks for replacing tires on

this vehicle.

●

Always check that the tire jack is securely set to the jack point.

●

Do not put any part of your body under the vehicle while it is supported by the jack.

●

Do not start or run the engine while your vehicle is supported by the jack.

●

Do not raise the vehicle while someone is inside.

●

When raising the vehicle, do not put an object on or under the jack.

●

Do not raise the vehicle to a height greater than that required to replace the tire.

●

Use a jack stand if it is necessary to get under the vehicle.

●

Be sure to turn off the height control and stop the engine.

Take particular care when lowering the vehicle to ensure that no one working on or

near the vehicle will be injured.

■

Using the jack handle
Tighten all the jack handle bolts securely using a Phillips-head screwdriver, to prevent

the extension parts from coming apart unexpectedly.

543

When trouble

Remove the cover.

Unhook the rubber band and take
out the jack.

For loosening
For tightening

Remove the cover.

Take out the tool box.

Taking out the jack

Taking out the tool box

544

Assembling the jack handle.
Remove the jack handle and the jack handle extension bar from the tool box
and assemble by following these steps.

Loosen the bolt and the screw
using either the jack handle end
or a screwdriver.

Assemble the jack handle exten-
sion bar and the jack handle and
tighten the bolt and the screw.

Check that the bolt and screw are

firmly tightened.

Remove the cover.

To protect the bodywork, place a rag

between the screwdriver and the vehi-

cle body.

Taking out the spare tire

545

When trouble

Insert the jack handle extension into
the lowering socket.

Lower
Raise

Place a rag under the jack handle

extension to protect the rear bumper.

Lower the spare tire completely to
the ground.

If the spare tire becomes caught on the suspension components, raise the tire,
pull it towards the rear of the vehicle, and begin lowering it again.

Pull out the spare tire and remove
the holding bracket.

546

Chock the tires.

Pry off the wheel ornament, using
the beveled end of the wheel nut
wrench as shown.

To protect the wheel ornament, place a

rag between the wheel nut wrench and

the wheel ornament.

Slightly loosen the wheel nuts (one
turn).

Replacing a flat tire

Flat tire

Wheel chock position

Front

Left-hand side

Behind the rear right-hand side tire

Right-hand side

Behind the rear left-hand side tire

Rear

Left-hand side

In front of the front right-hand side tire

Right-hand side

In front of the front left-hand side tire

547

When trouble

Assembling the jack handle.
Remove the jack handle, jack handle extension bar and jack handle bar from
the tool box and assemble by following these steps.

Loosen the bolt and the screw
using either the jack handle end
or a screwdriver.

Assemble the jack handle exten-
sion bar and the jack handle bar
and tighten the bolts.

Check that the bolts are firmly tight-

ened.

Assemble the jack handle exten-
sion bar and the jack handle and
tighten the screw.

Check that the screw is firmly tight-

ened.

548

Position the jack at the jack points as
shown.

Front

Under the chassis frame side rail

Rear

Under the rear axle housing

Raise the vehicle until the tire is
slightly raised off the ground.

Remove all the wheel nuts and the
tire.

When resting the tire on the ground,

place the tire so that the wheel design

faces up to avoid scratching the wheel

surface.

549

When trouble

CAUTION

■

Replacing a flat tire

●

Observe the following precautions.

Failure to do so may result in serious injury:
• Lower the spare tire completely to the ground before removing it from under the

vehicle.

• Do not try to remove the wheel ornament by hand. Take due care in handling the

ornament to avoid unexpected personal injury.

• Do not touch the disc wheels or the area around the brakes immediately after the

vehicle has been driven.

After the vehicle has been driven the disc wheels and the area around the brakes

will be extremely hot. Touching these areas with hands, feet or other body parts

while changing a tire, etc. may result in burns.

●

Failure to follow these precautions could cause the nuts to loosen and the wheel may

fall off, which could lead to an accident causing death or serious injury.
• Never use oil or grease on the wheel bolts or wheel nuts.

Oil and grease may cause the wheel nuts to be excessively tightened, leading to

bolt or disc wheel damage. In addition, the oil or grease can cause the wheel nuts

to loosen and the wheel may fall off, causing a serious accident. Remove any oil or

grease from the wheel bolts or wheel nuts.

• Have the wheel nuts tightened with a torque wrench to 76 ft•lbf (103 N•m,

10.5 kgf•m) as soon as possible after changing wheels.

• Do not attach a heavily damaged wheel ornament, as it may fly off the wheel while

the vehicle is moving.

• When installing a tire, only use wheel nuts that have been specifically designed for

that wheel.

• If there are any cracks or deformations in the bolt screws, nut threads or bolt holes

of the wheel, have the vehicle inspected by your Lexus dealer.

550

Remove any dirt or foreign matter
from the wheel contact surface.

If foreign matter is on the wheel contact

surface, the wheel nuts may loosen

while the vehicle is in motion, and the

tire may come off the vehicle.

Install the spare tire and loosely
tighten each nut by hand to approxi-
mately the same amount.

Turn the lug nuts until the washers come

into contact with the disc wheel.

Lower the vehicle.

Installing the spare tire

Wheel nut

Washer

Disc wheel

551

When trouble
