Positioning a floor jack

◆

Front

◆

Rear



GS350/GS300

When using a floor jack, follow the instructions in the manual provided with
the jack and perform the operation safely.
When raising your vehicle with a floor jack, position the jack correctly.
Improper placement may damage your vehicle or cause injury.

2WD models

AWD models

377

Main

tenance an

d care



GS F

NOTICE

■

When using a jack at the rear of the vehicle (GS F)
Do not set the jack in either of the positions

indicated by the illustration.

378

Engine compartment



GS350

Fuse boxes

(

P. 414)

Battery

(

P. 392)

Engine oil level dipstick

(

P. 383)

Engine coolant reservoir

(

Engine oil filler cap (

P. 385)

Brake fluid reservoir

(

P. 391)

Washer fluid tank

(

P. 394)

Electric cooling fans
Condenser (

Radiator (

2
3

8
9

379

Main

tenance an

d care



GS300

Fuse boxes

(

P. 414)

Battery

(

P. 392)

Intercooler coolant reservoir

(

Engine oil level dipstick

(

P. 383)

Engine oil filler cap (

P. 385)

Engine coolant reservoir

(

Brake fluid reservoir

(

P. 391)

Washer fluid tank

(

P. 394)

Condenser (

Electric cooling fans
Radiator (

2
3

8
9

380



GS F

Fuse boxes

(

P. 414)

Battery

(

P. 392)

Engine oil level dipstick

(

P. 383)

Engine coolant reservoir

(

Engine oil filler cap (

P. 385)

Brake fluid reservoir

(

P. 391)

Washer fluid tank

(

P. 394)

Electric cooling fans
Condenser (

Radiator (

2
3

8
9

381

Main

tenance an

d care

■

Removing the engine compartment cover



GS350/GS300 (Right-hand side)



GS350/GS300 (Center)



GS F

Engine compartment cover

382

■

Installing the clips

Push up center portion
Insert
Press

2
3

NOTICE

■

Checking the engine compartment cover after installation
Make sure that the cover is securely installed in its original position.

383

Main

tenance an

d care

With the engine at operating temperature and turned off, check the oil level on
the dipstick.

■

Checking the engine oil

Park the vehicle on level ground. After warming up the engine and turning
it off, wait more than 5 minutes for the oil to drain back into the bottom of
the engine.
Holding a rag under the end, pull the dipstick out.

Wipe the dipstick clean.

Engine oil



GS350



GS300



GS F

384

Reinsert the dipstick fully.
Holding a rag under the end, pull the dipstick out and check the oil level.

Low
Normal
Excessive

The shape of the dipstick may differ depending on the type of vehicle or engine.

Wipe the dipstick and reinsert it fully.

4
5

2
3



Flat dipstick



Non-flat dipstick

385

Main

tenance an

d care

■

Adding engine oil
If the oil level is below or near the low level mark, add engine oil of the same
type as that already in the engine.

Make sure to check the oil type and prepare the items needed before adding
oil.

Remove the oil filler cap by turning it counterclockwise.
Add engine oil slowly, checking the dipstick.
Install the oil filler cap by turning it clockwise.



GS350



GS300



GS F

Engine oil selection

P. 526, 528

Oil quantity (Low

 Full)

1.6 qt. (1.5 L, 1.3 Imp.qt.)

Items

Clean funnel

2
3

386

■

Engine oil consumption
A certain amount of engine oil will be consumed while driving. In the following situations,

oil consumption may increase, and engine oil may need to be refilled in between oil

maintenance intervals.

●

When the engine is new, for example directly after purchasing the vehicle or after

replacing the engine

●

If low quality oil or oil of an inappropriate viscosity is used

●

When driving at high engine speeds or with a heavy load, or when driving while accel-

erating or decelerating frequently

●

When leaving the engine idling for a long time, or when driving frequently through

heavy traffic

■

After changing the engine oil (GS350/GS300)
The engine oil maintenance data should be reset. Perform the following procedures:

Press

of the meter control switch and select

Press

of the meter control switch and select “Vehicle Settings”. Then press

Press

of the meter control switch and select “Oil Maintenance”. Then press

Select “Yes” and press .
A message is displayed on the multi-informa-

tion display.

WARNING

■

Used engine oil

●

Used engine oil contains potentially harmful contaminants which may cause skin dis-

orders such as inflammation and skin cancer, so care should be taken to avoid pro-

longed and repeated contact. To remove used engine oil from your skin, wash

thoroughly with soap and water.

●

Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of

used oil and filters in household trash, in sewers or onto the ground.

Call your Lexus dealer, service station or auto parts store for information concerning

recycling or disposal.

●

Do not leave used engine oil within the reach of children.

4
5

387

Main

tenance an

d care

NOTICE

■

To prevent serious engine damage
Check the oil level on a regular basis.

■

When replacing the engine oil

●

Be careful not to spill engine oil on the vehicle components.

●

Avoid overfilling, or the engine could be damaged.

●

Check the oil level on the dipstick every time you refill the vehicle.

●

Be sure the engine oil filler cap is properly tightened.

388

The coolant level is satisfactory if it is between the “FULL”/“F” and “LOW”/“L”
lines on the reservoir when the engine is cold.

■

Engine coolant reservoir

Reservoir cap
“FULL” line
“LOW” line

If the level is on or below the “LOW” line, add coolant up to the “FULL” line.

(

P. 512)

■

Intercooler coolant reservoir (GS300 only)

Reservoir cap
“F” line
“L” line

If the level is on or below the “L” line,

add coolant up to the “F” line.

(

P. 512)

Coolant

2
3



GS350



GS300



GS F

2
3

389

Main

tenance an

d care

■

Coolant selection
Only use “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol

based non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid

organic acid technology.
U.S.A.:

“Toyota Super Long Life Coolant” is a mixture of 50% coolant and 50% deionized water.

(Minimum temperature: -31

F [-35C])

Canada:

“Toyota Super Long Life Coolant” is a mixture of 55% coolant and 45% deionized water.

(Minimum temperature: -44

F [-42C])

For more details about coolant, contact your Lexus dealer.

■

If the coolant level drops within a short time of replenishing
Visually check the radiator, hoses, engine coolant reservoir caps, drain cock and water

pump.

If you cannot find a leak, have your Lexus dealer test the cap and check for leaks in the

cooling system.

WARNING

■

When the engine is hot
Do not remove the engine coolant reservoir cap, the intercooler coolant reservoir cap

or the coolant inlet cap. (

P. 516)

The cooling system may be under pressure and may spray hot coolant if the cap is

removed, causing serious injuries, such as burns.

NOTICE

■

When adding coolant
Coolant is neither plain water nor straight antifreeze. The correct mixture of water and

antifreeze must be used to provide proper lubrication, corrosion protection and cool-

ing. Be sure to read the antifreeze or coolant label.

■

If you spill coolant
Be sure to wash it off with water to prevent it from damaging parts or paint.

390

Check the radiator and condenser and clear away any foreign objects.
If either of the above parts is extremely dirty or you are not sure of their condi-
tion, have your vehicle inspected by your Lexus dealer.

Radiator and condenser

WARNING

■

When the engine is hot
Do not touch the radiator or condenser as they may be hot and cause serious injuries,

such as burns.
