PP0T0–01

PP–64

–

PREPARATION

SUPPLEMENTAL RESTRAINT SYSTEM

LEXUS RX300   (RM785E)

EQUIPMENT

Torque wrench

Bolt: Length: 35 mm (1.38 in.) Pitch: 1.0 mm (0.039 in.)

Diam: 6.0 mm (0.236 in.)

Airbag disposal

Tire Width: 185 mm (7.28 in.) Inner diam: 360 mm (14.17 in.)

Airbag disposal

Tire with disc wheel Width: 185 mm (7.28 in.)

Inner diam: 360 mm (14.17 in.)

Airbag disposal

Vinyl bag

Airbag disposal

PP0O0–02

–

PREPARATION

BODY ELECTRICAL

PP–65

LEXUS RX300   (RM785E)

BODY ELECTRICAL

SST (Special Service Tools)

09843–18020

Diagnosis Check Wire

PP0O1–02

PP–66

–

PREPARATION

BODY ELECTRICAL

LEXUS RX300   (RM785E)

RECOMMENDED TOOLS

09041–00030

Torx Driver T30 .

For removing and installing

steering wheel pad

09042–00010

Torx Socket T30 .

For removing and installing

steering wheel pad

09082–00040

TOYOTA Electrical Tester.

PP0O2–02

–

PREPARATION

BODY ELECTRICAL

PP–67

LEXUS RX300   (RM785E)

EQUIPMENT

Voltmeter

Ammeter

Ohmmeter

Test lead

Thermometer

Engine coolant temperature sender gauge, Engine oil level warn-

ing switch, Seat heater

Syphon

Brake fluid level warning switch

Oil bath

Engine oil level warning switch

Bulb (1.4 W)

Defogger switch

Bulb (3.4 W)

Fuel sender gauge, Engine coolant temperature receiver gauge,

Seat belt warning relay

Dry cell battery

Fuel sender gauge, Power mirror

Heat light

Seat heater

Hexagon wrench (6 mm)

Power seat

Torque wrench

Clip remover

For removing cowl louver

Masking tape

Rear window defogger wire

Tin foil

Rear window defogger wire
