Lexus RX300 (MCU15). Manual - part 471

PP–4

–

PREPARATION

ENGINE MECHANICAL

LEXUS RX300   (RM785E)

09330–00021

Companion Flange Holding Tool

Crankshaft pulley

09608–03071

Replacer

Spark plug tube gasket

09816–30010

Oil Pressure Switch Socket

Knock sensor

09843–18020

Diagnosis Check Wire

09950–50012

Puller C Set

(09951–05010)

Hanger 150

Crankshaft pulley

Crankshaft timing pulley

(09952–05010)

Slide Arm

Crankshaft pulley

Crankshaft timing pulley

(09953–05010)

Center Bolt 100

Crankshaft pulley

Crankshaft timing pulley

(09953–05020)

Center Bolt 150

Crankshaft pulley

Crankshaft timing pulley

(09954–05010)

Claw No.1

Crankshaft timing pulley

(09954–05020)

Claw No.2

Crankshaft pulley

09950–70010

Handle Set

(09951–07100)

Handle 100

Valve guide bushing

Crankshaft rear oil seal

–

PREPARATION

ENGINE MECHANICAL

PP–5

LEXUS RX300   (RM785E)

09960–10010

Variable Pin Wrench Set

(09962–01000)

Variable Pin Wrench Arm Assy

Camshaft timing pulley

Camshaft sub–gear

(09963–01000)

Pin 10

Camshaft timing pulley

(09963–00500)

Pin 5

Camshaft sub–gear

PP06P–06

PP–6

–

PREPARATION

ENGINE MECHANICAL

LEXUS RX300   (RM785E)

RECOMMENDED TOOLS

09040–00011

Hexagon Wrench Set .

09090–04020

Engine Sling Device

For suspending engine

09200–00010

Engine Adjust Kit .

09258–00030

Hose Plug Set .

Plug for the vacuum hose, fuel

hose etc

09904–00010

Expander Set .

PP06Q–02

–

PREPARATION

ENGINE MECHANICAL

PP–7

LEXUS RX300   (RM785E)

EQUIPMENT

Abrasive compound

Caliper gauge

CO/HC meter

Connecting rod aligner

Cylinder gauge

Dial indicator

Dye penetrant

Engine tune–up tester

Groove cleaning tool

Heater

Magnetic finger

Micrometer

OBDII scan tool

Pin hole grinder

Piston pin hole

Piston ring compressor

Piston ring expander

Plastigage

Precision straight edge

Ridge reamer

Soft brush

Spring tester

Valve spring

Steel square

Valve spring

Thermometer

Torque wrench

Valve seat cutter

Vernier calipers

Wire brush

Valve
