P00601
Adhesive
A05416
1
2
3
4
5
6
7
8
EM–116
–
ENGINE MECHANICAL
CYLINDER BLOCK
LEXUS RX300 (RM785E)
30.
INSTALL OIL PRESSURE SWITCH
(See page LU–1)
31.
INSTALL ALTERNATOR, BRACKET AND
ADJUSTING BAR ASSEMBLY
Torque: 43 N·m (440 kgf·cm, 32 ft·lbf)
32.
CONNECT OIL PRESSURE SWITCH CONNECTOR
33.
CONNECT CRANKSHAFT POSITION SENSOR
CONNECTOR
34.
INSTALL CYLINDER HEAD
(See page EM–60)
35.
INSTALL TIMING PULLEYS AND BELT
(See page EM–22)
36.
REMOVE ENGINE STAND
37.
INSTALL DRIVE PLATE
(a)
Apply adhesive to 2 or 3 threads of the bolt end.
Adhesive:
Part No.08833–00070, THREE BOND 1324 or equiva-
lent
(b)
Install the front spacer, drive plate and rear plate on the
crankshaft.
(c)
Install and uniformly tighten the 8 bolts in several passes,
in the sequence shown.
Torque: 83 N·m (850 kgf·cm, 61 ft·lbf)
