A14986

RH Fender Apron Seal

Alternator
Drive Belt

PS Pump
Drive Belt

64 (650, 47)

32 (320, 23)

No. 2 RH Engine
Mounting Bracket

Engine Moving
Control Rod

Ground Strap

z Gasket

N·m (kgf·cm, ft·lbf) : Specified torque

56 (570, 41)

z Gasket

z Non–reusable part

No. 2 Front Exhaust Pipe

z Gasket

56 (570, 41)

80 (810, 59)

Master Cylinder
Reservoir

Front Upper
Suspension Brace

Cruise Control Actuator

80 (810, 59)

Cruise Control Actuator
Connector

WU–TWC

V–Bank Cover

PS Vane Pump

43 (440, 32)

Air Cleaner Cap

Air Cleaner Case

EVAP Hose

Air Filter

MAF Meter
Connector

z Gasket

Compression Spring

62 (630, 46)

62 (630, 46)

62 (630, 46)

PS Oil Pressure
Switch Connector

z Gasket

62 (630, 46)

EM–28

–

ENGINE MECHANICAL

CYLINDER HEAD

LEXUS RX300   (RM785E)

A14991

No.1 VSV Connector for ASIC

Air Intake Chamber Stay

Throttle Position
Sensor Connector

Accelerator Cable

Brake Booster
Vacuum Hose

ISC Valve
Connector

No. 1 Engine
Hanger

VSV Connector
for EVAP

Ground Cable

Ground Cable

Ground Strap

PCV Hose
Air Intake Chamber
Assembly

z Gasket

Purge Hose

Water Bypass Hose

Vacuum Hose

Intake Manifold
Assembly

Injector Connector

N·m (kgf·cm, ft·lbf)

z Gasket

Water Temperature
Sender
Connector

Ground Strap
Connector

Water Outlet
z Gasket

: Specified torque

z Non–reusable part

19.5 (200, 14)

39 (400, 19)

43 (440, 32)

Upper Radiator
Hose

15 (150, 11)

15 (150, 11)

Water Bypass
Hose

Ignition Coil
Connector

Ignition Coil

Spark Plug

x 9

Heater Hose

Gasket

z Retainer

Fuel Hose Clamp

PS Pressure
Tube

–

ENGINE MECHANICAL

CYLINDER HEAD

EM–29

LEXUS RX300   (RM785E)

A14987

Timing Belt

No. 2 Timing Belt Cover

RH Engine Mounting Bracket

28 (290, 21)

Crankshaft
Pulley

No. 1 Timing Belt Cover

Engine Wire
Protector

No. 2 Idler Pulley

43 (440, 32)

125 (1,300, 35)
*88 (900, 65)

RH Camshaft Timing Pulley

LH Camshaft
Timing Pulley

Timing Belt Tensioner

27 (280, 20)

Timing Belt Guide

No. 2 Alternator
Bracket

215 (2,200, 159)

125 (1,300, 94)

Dust Boot

N·m (kgf·cm, ft·lbf) : Specified torque

* For use with SST

z Non–reusable part

EM–30

–

ENGINE MECHANICAL

CYLINDER HEAD

LEXUS RX300   (RM785E)

A05278

Engine Wire

Engine Wire

RH Exhaust Manifold

49 (500, 36)

x6

Cylinder Head Rear Plate

z O–Ring

PS Pump Bracket

43 (440, 32)

Gasket

No. 3 Timing Belt cover

Collar

Water Inlet
Pipe

x6

z O–Ring

Oil Dipstick Guide

N·m (kgf·cm, ft·lbf) : Specified torque

z Non–reusable part

z Gasket

Engine Wire

Engine Wire

49 (500, 36)

Bushing

Camshaft Position
Sensor

LH Exhaust
Manifold Stay

x6

z Gasket

z O–Ring

z O–Ring

LH Exhaust Manifold

z O–Ring

Camshaft Timing
Oil Control Valve

Camshaft Position
Sensor

RH Exhaust
Manifold Stay

34 (350, 25)

z O–Ring

–

ENGINE MECHANICAL

CYLINDER HEAD

EM–31

LEXUS RX300   (RM785E)
