DI–532

–

DIAGNOSTICS

ENGINE IMMOBILISER SYSTEM

LEXUS RX300   (RM785E)

4

Does it operate normally after replacement of transponder key amplifier?

Yes

Replace transponder key amplifier.

No

Replace engine and ECT ECU.

I03114

CODE

RXCK

TXCT

18

19

E10

28

V

P

GR

4

3

2

T7
Transponder Key
Amplifier

Engine and ECT ECU

E10

E10

CODE

RXCK

TXCT

–

DIAGNOSTICS

ENGINE IMMOBILISER SYSTEM

DI–533

LEXUS RX300   (RM785E)

DTC

B2797/99 Communication Malfunction No.1

CIRCUIT DESCRIPTION

This code is detected when although the communication has been performed normally, an error occurs.
(Example. Some noise is in cluded in communication line.)

DTC No.

DTC Detecting Condition

Trouble Area

B2797/99

Communication error

S Wire Harness

S Transponder Key Amplifier

S Engine & ECT ECU

WIRING DIAGRAM

DI1AU–16

I02681

Noise

DI–534

–

DIAGNOSTICS

ENGINE IMMOBILISER SYSTEM

LEXUS RX300   (RM785E)

INSPECTION PROCEDURE

1

Noise check

PREPARATION:
Insert already registered master key in the key cylinder.
CHECK:
Using an oscilloscope or hand–held tester, check that noise is
included in the CODE terminal of engine & ECT ECU.
OK:

No noise is detected.

NG

Try to find the cause of the noise and remove it.

OK

2

Does it operate normally after replacement of transponder key amplifier?

Yes

Replace transponder key amplifier.

No

Replace engine & ECT ECU.

I03114

CODE

RXCK

TXCT

18

V

P

GR

4

3

2

T7
Transponder Key
Amplifier

28

19

Engine and ECT ECU

E10

E10

E10

CODE

RXCK

TXCT

–

DIAGNOSTICS

ENGINE IMMOBILISER SYSTEM

DI–535

LEXUS RX300   (RM785E)

DTC

B2798/99 Communication malfunction No.2

CIRCUIT DESCRIPTION

DTC No.

DTC Detecting Condition

Trouble Area

B2798/99

Communication error

S Key

S Transponder Key Coil

S Transponder Key Amplifier

S Wire harness

S Engine & ECT ECU

WIRING DIAGRAM

DI1AV–16
