Lexus ES300 (2002 year). Manual - part 270

020ZK-01

02-54

-

PREPARATION

SLIDING ROOF/CONVERTIBLE

97

2002 LEXUS ES300 REPAIR MANUAL   (RM911U)

SLIDING ROOF/CONVERTIBLE

PREPARATION

Recomended Tools

09041-00020

Torx Driver T25

SLIDING ROOF HOUSING

SUB-ASSY

09070-20010

Moulding Remover

SLIDING ROOF HOUSING

SUB-ASSY

020YG-01

-

PREPARATION

ENGINE HOOD/DOOR

02-55

98

2002 LEXUS ES300 REPAIR MANUAL   (RM911U)

ENGINE HOOD/DOOR

PREPARATION

SST

09812-00010

Door Hinge Set Bolt Wrench

FRONT DOOR

Recomended Tools

09041-00020

Torx Driver T25

FRONT DOOR

REAR DOOR

09042-00010

Torx Socket T30

FRONT DOOR

REAR DOOR

09042-00020

Torx Socket T40

FRONT DOOR

REAR DOOR

09070-20010

Moulding Remover

FRONT DOOR

REAR DOOR

Equipment

Clip remover

Tape

To avoid surface damage

Torque wrench

020ZJ-01

02-56

-

PREPARATION

EXTERIOR/INTERIOR TRIM

99

2002 LEXUS ES300 REPAIR MANUAL   (RM911U)

EXTERIOR/INTERIOR TRIM

PREPARATION

Recomended Tools

09070-20010

Moulding Remover

FRONT DOOR BELT MOULDING

ASSY LH

REAR DOOR BELT MOULDING

ASSY LH

ROOF DRIP SIDE FINISH

MOULDING CENTER LH

ROOF HEADLINING ASSY

Equipment

Adhesive tape

To avoid surface damage.

Clip remover

Cleaner

Heat light

Moulding

Piano wire

Moulding

Tape

To avoid surface damage.

Wooden block or similar object

For tying both piano wire ends

020ZH-01

-

PREPARATION

VEHICLE CONTROL SYSTEM

02-57

100

2002 LEXUS ES300 REPAIR MANUAL   (RM911U)

VEHICLE CONTROL SYSTEM

PREPARATION

Recomended Tools

09082-00040

TOYOTA Electrical Tester

IGNITION OR STARTER SWITCH

ASSY

09082-00050

TOYOTA Electrical Tester Set

IGNITION OR STARTER SWITCH

ASSY
