Lexus ES300 (2002 year). Manual - part 186
D–22
TABLE OF HOUSING SHAPE
Wire Harness Repair Manual (RM1022E)
97
<FEMALE> 16P, 17P, 23P Waterproof Type
1 2 3 4
5 6 7 8
9 10 11 12
13 14 15 16
1 2 3
4 5 6 7 8
9 10 11 12 13
14 15 16
90980–10101
90980–10288
1 2 3 4
5 6 7
8 9 10 11 12 13 14 15 16
14
15
3
4
5
1
2
6
7
8
9
10 11
12 13
16 17
90980–11463
90980–11601
1 2 3
4
5 6
7 8 9
10 11
12 13 14
15
16 17 21
20
18
23
22
19
1 2 3
4
5 6
7 8 9
10 11
12 13 14
15
16 17 21
20
18
23
22
19
90980–11195
90980–11323
