202

Horn

10A
HORN

From Power Source System (See Page 56)

2

3

1

5

1D

3

1H

1

2Q

6

2G

22

1

1

1

C

o

m

b

inat

ion S

W

C1

0

Horn

(Low)

H12

Horn

(High)

H11

G–

B

G–

B

G–

W

Ho

rn

G–W

HORN
Relay

203

HORN Relay

5–3 : Closed with the horn SW on

  :  Parts Location

Code

See Page

Code

See Page

Code

See Page

C10

38

H11

36

H12

36

: Junction Block and Wire Harness Connector

Code

See Page

Junction Block and Wire Harness (Connector Location)

1D

25

Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)

1H

25

Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)

2G

28

Engine Room Main Wire and Driver Side J/B (Lower Finish Panel)

2Q

29

Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)

Service Hints

204

Cigarette Lighter and Power Outlet

15A
POWER
POINT

From Power Source System (See Page 56)

2A

9

15A
CIG

2A

6

4

2

IB

Junction
Connector

J 4

A

1

2

W–

B

V

P

W–

B

Power
Outlet

P 6

Cigarette
Lighter

C 5

205

C5  Cigarette Lighter

2–Ground : Approx. 12 volts with ignition SW at ACC or ON position
4–Ground : Always continuity

P6  Power Outlet

1–Ground : Approx. 12 volts with ignition SW at ACC or ON position
2–Ground : Always continuity

  :  Parts Location

Code

See Page

Code

See Page

Code

See Page

C5

38

J4

39

P6

39

: Junction Block and Wire Harness Connector

Code

See Page

Junction Block and Wire Harness (Connector Location)

2A

28

Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)

: Ground Points

Code

See Page

Ground Points Location

IB

46

Instrument Panel Brace LH

Service Hints
