Taillight and Stop Light

Taillight Disconnection Warning

If any of the taillights are disconnected when the light control SW is at TAIL or HEAD while the ignition SW is ON, the light
failure sensor detects the voltage difference, and blinks the rear lights warning light to warn the driver.

Stop Light Disconnection Warning

If any of the stop lights are disconnected when the brake pedal is depressed while the ignition SW is ON, the light failure
sensor detects the voltage difference, and blinks the rear lights warning light to warn the driver.

TAIL Relay

5–3 : Closed with the light control SW at TAIL or HEAD position

L4  Light Failuer Sensor

7–Ground : Approx. 12 volts with stop light SW on
3–Ground : Approx. 12 volts with the light control SW at TAIL or HEAD position
8–Ground : Approx. 12 volts with the ignition SW at ON or ST position

11–Ground : Always continuity

S13  Stop Light SW

1–2 : Closed with brake pedal depressed
