SS05W–10
SS–40
–
SERVICE SPECIFICATIONS
AIR CONDITIONING
152
1997 LEXUS ES300 (RM511U)
TORQUE SPECIFICATION
Part tightened
N·m
kgf·cm
ft·lbf
Compressor x Discharge hose
10
100
7
Compressor x Suction hose
10
100
7
Condenser x Disaharge hose
22
225
16
Condenser x Liquid tube
14
140
10
Receiver x Liquid tube
5.4
55
48 in.·lbf
A/C unit x Liquid tube and suction tube
10
100
7
Expansion valve x Evaporator
5.4
55
48in.·lbf
Compressor x Engine
25
250
18
Compressor x Compressor bracket
25
250
18
Drive belt adjusting bar bracket x Compressor
25
250
18
Drive belt adjusting bar bracket x Adjusting bar
18
185
13
Pivot bolt
56
570
41
Adjusting lock bolt
18
185
13
Pressure switch x Liquied tube
10
100
7
Pressure plate x Compressor
13.2
135
9
Suction line (Piping joint)
32
330
24
Suction line (Block joint)
10
100
7
Liquid line (Block joint)
10
100
7
