Lexus ES300 (1997 year). Manual - part 505

PP075–07

–

PREPARATION

IGNITION

PP–21

66

1997 LEXUS ES300   (RM511U)

IGNITION

RECOMMENDED TOOLS

09082–00040

TOYOTA Electrical Tester.

09200–00010

Engine Adjust Kit .

PP076–01

PP–22

–

PREPARATION

IGNITION

67

1997 LEXUS ES300   (RM511U)

EQUIPMENT

Megger insulation resistance meter

Spark plug

Spark plug cleaner

PP077–03

–

PREPARATION

STARTING

PP–23

68

1997 LEXUS ES300   (RM511U)

STARTING

SST (Special Service Tools)

09286–46011

Injection Pump Spline Shaft

Puller

Armature bearing

09810–38140

Starter Magnet Switch Nut Wrench

14

Terminal nut

09820–00030

Alternator Rear Bearing Replacer

Armature front bearing

PP078–03

PP–24

–

PREPARATION

STARTING

69

1997 LEXUS ES300   (RM511U)

RECOMMENDED TOOLS

09082–00040

TOYOTA Electrical Tester.
