BO0AQ–01

BO–78

–

BODY

SLIDING ROOF

1256

1997 LEXUS ES300   (RM511U)

INSTALLATION

Installation is in the reverse order of removal (See page

BO–72

).

BO0AR–03

N21803

Instrument Panel Reinforcement

Front Passenger
Airbag Assembly

Front Pillar Garnish

Front Door
Opening Trim Cover

Front Door
Scuff Inside Plate

RH Floor
Carpet Bracket

Upper Console Panel

Lower Panel

Cowl Side
Trim

Front Door
Scuff Inside Plate

A

No.2 Brace

I

I

A

A

I

I

End Cluster
Finish Panel

Lower Finish
Plate

I

I

I

I

I

I

J

No.1 Mounting
Bracket

No.1 Floor
Brace

Front Pillar Garnish

Nozzle Side
Defroster No.1

E

B

Lower Cover

No.2 Under Cover

Cluster Finish
Panel

LH Floor
Carpet Bracket

Front Ash
Receptacle

Rear Console
Box

Box Bottom
No.2 Mat

Rear Ash
Receptacle

Rear Cup
Holder

Lower LH Panel

H

H H

H

B

B

C

C

G

G

G

G

F

K

H

H

Front Console
Box

B

B

B

B

G

F

H H

G

G

D

D

D

D

N·m (kgf·cm, ft·lbf) : Specified torque

No.1 Lower Panel

Steering Column Cover

Combination Switch

Steering Wheel

Steering
Wheel Pad

Lower No.2
Finish Panel
Retainer

Lower No.1
Finish Panel
Retainer

Finish Upper
Panel

No.2 Side
Defroster Nozzle

Cowl Side
Trim

CD Chenger
Assembly

Center Cluster
Finish Panel

Radio and
A/C Control Panel
Assembly

Instrument
Panel Safety
Pad

Combination Meter

Front Door
Opening Trim
Cover

20 (204, 15)

35 (360, 26)

–

BODY

INSTRUMENT PANEL

BO–79

1257

1997 LEXUS ES300   (RM511U)

INSTRUMENT PANEL

COMPONENTS

N21802

Side Defroster Nozzle
No.1 Duct

Defroster Nozzle

Side Defroster Nozzle No.2 Duct

Defroster Nozzle No.1 Garnish

Heater to Register
No.1 Duct

Heater to Register
No.2 Duct

Heater to Register
No.3 Duct

No.3 Register

Instrument Panel Safety Pad

No.1 Register

Instrument Panel Wire

Center Bracket

H

H

H

H H

H

H

H

H

H

H

H

H

H

H

H

H

H

BO–80

–

BODY

INSTRUMENT PANEL

1258

1997 LEXUS ES300   (RM511U)

V08545

A

Shape

Size

B

C

D

E

F

G

H

I

J

K

Shape

Size

Shape

Size

mm (in.)

ø = 8
    (0.31)

L = 22
    (0.87)

ø = 6
    (0.24)

L = 20
    (0.79)

ø = 6
    (0.24)

L = 16
    (0.63)

ø = 6
    (0.24)

L = 16
    (0.63)

ø = 6
    (0.24)

L = 20
    (0.79)

ø = 6
    (0.24)

L = 18
    (0.71)

ø = 5.22
 (0.2055)

L = 20
    (0.79)

ø = 5.22
 (0.2055)

L = 16
    (0.63)

ø = 8
    (0.31)

ø = 6
    (0.24)

ø = 6
    (0.24)

–

BODY

INSTRUMENT PANEL

BO–81

1259

1997 LEXUS ES300   (RM511U)

HINT:
Screw shapes and sizes are indicated in the table below. The codes (A – K) correspond to those indicated
on the previous pages.
