Lexus ES300 (1997 year). Manual - part 113
BE05D–03
BE–58
–
BODY ELECTRICAL
COMBINATION METER
1442
1997 LEXUS ES300 (RM511U)
COMBINATION METER
TROUBLESHOOTING
PRECAUTIONS
(a)
When checking voltage, resistance, etc., use a high impedance type tester (It is impossible to use a
simple tester).
(b)
When the ignition switch is turned to START, all meters will go out but this is normal.
(c)
When replacing the internal mechanism (computer parts) of the meter, be careful that no part of your
body or clothing comes in contact with the terminals of the leads from the IC, etc. of the replacement
parts (spare parts).
(d)
Do not disconnect the battery while the engine is running as this would cause an instant reverse
charge, resulting in damage to the components.
(e)
Always disconnect the battery terminals before pulling apart connectors or terminals.
(f)
To prevent damage, handle meters with care.
Trouble
Refer to
No display at all.
1
The four indicator needles do not light up.
Replace com-
bination meter
computer.
One indicator needle does not light up.
2
The character plate is not illuminated at one or two loca-
tions.
3
All Meters, Gauges, and Illuminations
Brightness does not change even when light control
switch is operated (OFF
↔
TAIL).
4
Brightness does not change even when rheostat volume
is turned.
5
Remains dimmed when the light control switch is turned
OFF.
Replace com-
bination meter
computer.
Does not go out while starter running.
6
S
d
t
Speedometer does not operate while driving.
7
Speedometer
Vehicle speed signal (4P) faulty.
8
Tachometer
Tachometer does not operate while engine running.
9
Fuel Gauge
Does not operate or operation is abnormal.
10
Fuel Level Warning
Warning light does not light up or always lights up.
11
Engine Coolant Temperature Gauge
Does not operate or operation is abnormal.
12
Low Oil Pressure warning
Abnormal operation or warning light does not light up.
13
Brake Warning
Abnormal operation or warning light does not light up.
14
Rear Lights Warning
Abnormal operation or warning light does not light up.
15
Open Door Warning
Abnormal operation or warning light does not light up.
16
Engine Oil Level Warning
Abnormal operation or warning light does not light up.
17
Seat Belt Warning Chime
Abnormal operation or chime does not operate.
Seat Belt Warning
Abnormal operation or warning light does not light up.
18
