PP0TW–01

–

PP–25

77

RECOMMENDED TOOLS

09082–00040

TOYOTA Electrical Tester.

PP0TX–01

PP–26

–

78

EQUIPMENT

Dial indicator

Commutator runout

Magnetic finger

Steel ball

Press

Magnetic switch terminal kit

Pull scale

Brush spring

Sandpaper

Commutator

Torque wrench

V–block

Commutator

Vernier calipers

Commutator, Brush

PP0TY–04

–

PREPARATION

CHARGING (2JZ–GE)

PP–27

79

CHARGING (2JZ–GE)

SST (Special Service Tools)

09285–76010

Injection Pump Camshaft Bearing

Cone Replacer

Rotor rear bearing cover

09820–00021

Alternator Rear Bearing Puller

09820–00030

Alternator Rear Bearing Replacer

Rotor rear bearing

09820–63010

Alternator Pulley Set Nut Wrench

Set

09950–40011

Puller B Set

(09951–04020)

Hanger 200

Rectifier end frame

(09952–04010)

Slide Arm

Rectifier end frame

(09953–04030)

Center Bolt 200

Rectifier end frame

(09954–04010)

Arm 25

Rectifier end frame

(09955–04041)

Claw No.4

Rectifier end frame

09950–60010

Replacer Set

(09951–00500)

Replacer 50

Rotor front bearing

PP0TZ–01

PP–28

–

PREPARATION

CHARGING (2JZ–GE)

80

RECOMMENDED TOOLS

09082–00040

TOYOTA Electrical Tester.
