CO0AE–01

B02030

Electric Cooling
Fan Connector

Upper Radiator Hose

Air Cleaner Inlet

MAF Meter Connector

Air Cleaner and MAF Meter Assembly

Intake Air Resonator

Electric Cooling Fan Assembly

Radiator Reservoir Hose

Wire Clamp

ECM Outlet Duct

x 6

EVAP Hose

Engine
Wire Clamp

–

COOLING (2JZ–GE)

ELECTRIC COOLING FAN

CO–25

1563

COMPONENTS

B00918

No.2 Fan Motor

Connector
Holder

Fan Shroud
Assembly

No.1 Fan

No.1 Fan Motor

No.2 Fan

CO–26

–

COOLING (2JZ–GE)

ELECTRIC COOLING FAN

1564

CO0AF–03

B02071

–

COOLING (2JZ–GE)

ELECTRIC COOLING FAN

CO–27

1565

REMOVAL

1.

DRAIN ENGINE COOLANT

2.

REMOVE AIR CLEANER INLET

3.

REMOVE AIR CLEANER AND MAF METER AS-
SEMBLY

4.

REMOVE ELECTRIC COOLING FAN

(a)

Disconnect the upper radiator hose from the radiator.

(b)

Disconnect the ECM outlet duct from the ECM box.

(c)

Disconnect the wire for electric cooling fan from the clamp
on the electric cooling fan.

(d)

Disconnect the 2 electric cooling fan connector.

(e)

Disconnect the radiator reservoir hose from the radiator.

(f)

Remove the 6 bolts and electric cooling fan.

CO0AG–01

B00919

B00921

CO–28

–

COOLING (2JZ–GE)

ELECTRIC COOLING FAN

1566

DISASSEMBLY

1.

REMOVE FANS

Remove the nut and fan. Remove the 2 fans.

2.

REMOVE FAN MOTORS

(a)

Disconnect the wires and connector holders from the fan
shroud.

(b)

Remove the 3 screws and fan motor. Remove the 2 fan
motors.
