Lexus GS300/400 (2000 year). Manual - part 74
1. Insert master key in the key cylinder.
2. Depress and release the acceleration pedal 6 times.
3. Depress and release the brake pedal 7 times.
4. Remove the master key.
HINT:
If the key cannot be pulled out within 30 sec. from the first brake
depression in the step 3, the key code deletion is canceled.
(Key code erased)
Within 15 sec.
Within 20 sec.
Within 10 sec.
END
5. Leave the vehicle more than 20 sec. without any
operation.
–
BODY ELECTRICAL
ENGINE IMMOBILISER SYSTEM
BE–245
2546
4.
ERASURE OF TRANSPONDER KEY CODE
There are 2 ways for erasure of transponder key code, one way is depressing brake pedal and acceleration
pedal and the other way is using LEXUS hand–held tester.
NOTICE:
Delete all other master and sub–key codes leaving the master key code to use the operation. When
using the key which was used before deletion, it is necessary to register the code again.
HINT:
When any operation time described below is over, registration mode completes.
When the next procedure is performed while the timer is working, the timer completes counting time,
then next timer starts.
(1)
Depressing brake pedal and acceleration pedal:
