AC0X3–01

–

AIR CONDITIONING

EVAPORATOR

AC–53

2738

INSPECTION

1.

CHECK EVAPORATOR FINS FOR BLOCKAGE

If the fins are clogged, clean them with compressed air.
NOTICE:
Never use water to clean the evaporator.
2.

CHECK FITTING FOR CRACKS OR SCRATCHES

If necessary, repair or replace.

AC0X4–01

AC–54

–

AIR CONDITIONING

EVAPORATOR

2739

INSTALLATION

Installation is in the reverse order of removal (See page

AC–51

).

AC0X5–01

I02403

–

AIR CONDITIONING

HEATER RADIATOR

AC–55

2740

HEATER RADIATOR

REMOVAL

1.

REMOVE A/C UNIT (See page

AC–24

)

2.

REMOVE HEATER RADIATOR

(a)

Remove the screw and clamp.

(b)

Pull out the heater radiator.

AC0X6–01

AC–56

–

AIR CONDITIONING

HEATER RADIATOR

2741

INSPECTION

INSPECT FINS FOR BLOCKAGE
If the fins are clogged, clean them with compressed air.
