54 FRONT AXLE AND FINAL DRIVE 2 SPECIFICATIONS, TORQUE Torque values below cover all screws and bolts used, unless specified otherwise. METRIC Nm M5 6 ...................................................................................................... M6 9 ...................................................................................................... M8 25 ..................................................................................................... M10 45 ................................................................................................... M12 90 ................................................................................................... M14 105 .................................................................................................. M16 180 .................................................................................................. UNC / UNF 1/4 9 ...................................................................................................... 5/16 24 ................................................................................................... 3/8 39 ..................................................................................................... 7/16 78 ................................................................................................... 1/2 90 ..................................................................................................... 5/8 136 .................................................................................................... FRONT HUB AND SWIVEL DATA Front hub Front hub end float 0,010 mm .................................................. Drive shaft end play 0,08 to 0,25 mm ................................................ Swivel pin bearing preload ABS vehicles - Torque to turn 2. to 3. Nm ................................. Non ABS vehicles - Resistance to turn 1,16 to 1,46Kg ................... |
