1
.

CAUTION: Do not use compressed air to clean the sensor. Do not clean the sensor with solvents or

cleaning agents of any type, use a clean dry cloth.

Clean the component mating faces.

2
.

CAUTION: Do not apply any lubricant to the new valve.

NOTE:

If the sensor is replaced on a 'running' wheel, the new sensor identification will be learnt when the vehicle is
first driven. If a new sensor is fitted to the spare wheel the identification for that sensor must be programmed
into the Tire Pressure Monitoring System (TPMS) module using T4. The identifcation code is provided on a
label with the complete assembly and is also printed on the casing of each sensor.

Install the tire low pressure sensor.

Install and hand tighten the nut whilst keeping the sensor in place.

Tighten the nut to 6.5 Nm (4.8 lb.ft).

4 . Install the wheel and tire.

Tighten the wheel nuts to 140 Nm (103 lb.ft).

Tire Pressure Monitoring System Front Antenna (86.53.16)

Removal

1 . Raise and support the vehicle.

2 . Remove the fender splash shield.

For additional information, refer to

Fender Splash Shield (76.10.48)

3 . Remove the tire pressure antenna.

Remove the 2 retainers.

Installation

1 . To install, reverse the removal procedure.

2 . Initiate a new tire pressure antenna using T4.

Tire Pressure Monitoring System Rear Antenna (86.53.17)
